SLIDE 1

A critjcal look on rice husk gasifjcatjon in Cambodia: engineering and sustainability

Nguyen Hong Nam

Seminar on Energy, Environment & Sustainable Development Hanoi, February 2, 2015

SLIDE 2

Clean energy technologies and Sustainable development laboratory (CleanED)

Director

Dr. Minh Ha-Duong, CNRS

Co-director

Dr. Laurent Van de Steene, CIRAD

Researcher

Dr. Nguyen Dinh Quang, Director of RE Department, USTH

PhD student

Msc. Nguyen Trinh Hoang Anh, USTH

PhD student

Msc. Nguyen Hong Nam, USTH

Executjve secretary

Msc. Tran Hoang Anh, Paris 7

Researcher

Dr. Nguyen Xuan Truong, USTH

PhD student

Msc. Pham Duy An, USTH

Lab technician

Msc. Pham Xuan Huynh, IES

2

SLIDE 3

A critjcal look on rice husk gasifjcatjon in Cambodia: engineering and sustainability

3

Nguyen Hong Nam PhD student at CleanED, USTH

USTH Seminar on Energy, Environment & Sustainable Development February 2, 2015

SLIDE 4

A critjcal look on rice husk gasifjcatjon in Cambodia: engineering and sustainability

4

Gasifjcatjon, an appropriate technology for Cambodia ? Gasifjcatjon, an appropriate technology for Cambodia ? Rice milling sector overview Rice milling sector overview Lessons learned Lessons learned Summary and concluding remarks Summary and concluding remarks

SLIDE 5

5

Rice husk Syngas (H2+CO)

Rice husk Gasification technology

SLIDE 6

6

Gasifier filters dual fuel or 100% gas Engine + generator

SLIDE 7

Technical potentjal of rice husk power

4-6 kg rice husk ≈ 1 liter diesel ≈ 3 kWh*

300 Million liters diesel 1.5 Million tons rice husk/year 900 GWh (30% of electricity demand**)

= = *Source: Baseline study waste to energy for the rice milling sector in Cambodia, SNV Netherlands Development Organizatjon, 2012 ** Electricity consumptjon in 2014 = 3 000 GWh, Independent Statjstjc and analysis IEA)

SLIDE 8

Rice growing areas in Cambodia

SLIDE 9

Source: Cambodia Consultjng Development Engineering (CCDE), 2014

9

Electricity tarifg from diesel based generatjon: $0.75 - $1/kWh

SLIDE 10

Appropriate

technology: “small-scale, decentralized, labor-intensive, energy- effjcient, environmentally sound, and locally controlled” (Hazeltine, B.; Bull, C.,1999).

Rice husk gasifjcatjon, an appropriate technology for Cambodia ?

SLIDE 11

A critjcal look on rice husk gasifjcatjon in Cambodia: engineering and sustainability

11

Gasifjcatjon, an appropriate technology for Cambodia ? Gasifjcatjon, an appropriate technology for Cambodia ? Rice milling sector overview Rice milling sector overview Lessons learned Lessons learned Summary and concluding remarks Summary and concluding remarks

SLIDE 12

12

SLIDE 13

362 in operatjon
33 are connected to the grid
54 have a rice husk gasifjer

Source : Federatjon of Cambodian Rice Millers Associatjon (FCRMA) survey, 2014

13

405 rice mills in Cambodia

SLIDE 14

14

54 rice mills with gasifjers

9% 7% 83% Grid Own machine + grid Own machine

Sources of Electricity supply to operate rice mill

SLIDE 15

15

54 rice mills with gasifjers

5 10 15 20 25 1 17 21 8 1 1 2 3

Rice mills with RHG by milling capacity

SLIDE 16

A critjcal look on rice husk gasifjcatjon in Cambodia: engineering and sustainability

16

Gasifjcatjon, an appropriate technology for Cambodia ? Gasifjcatjon, an appropriate technology for Cambodia ? Data collectjon Data collectjon Lessons learned Lessons learned Summary and concluding remarks Summary and concluding remarks

SLIDE 17

17

1. Gasifjcatjon technology works in

Cambodia

SLIDE 18

18

Dual fuel gas-diesel at Golden Daun Keo rice mill, Battambang, Cambodia, 2014-12-20 100% gas engine at HAK SE Plant, Kompong Cham, Cambodia, 2014-12-21

SLIDE 19

19

2. Pollutjon is a problem

SLIDE 20

Solid and liquid wastes from gasifjcatjon system at Yam Chan rice mill, Batuambang province, Cambodia, 2014 - 12 – 20 Wastes from the gasifjcatjon system at rice mill- Deum Pou village, Cambodia, 2014- 12-19 Liquid waste from the gasifjcatjon system- Deum Pou village, Cambodia. 2014-12-19

20

SLIDE 21

Rice husk ash from the gasifjcatjon system- Deum Pou village, Cambodia. 2014-12-19 Rice husk as from gasifjed rice husk. UNIDO rural electricity pilot, KH. 2014-12-20 Rice husk ash from gasifjcatjon system at Yam Chan rice mill, Batuambang province, Cambodia, 2014 - 12 – 20

21

SLIDE 22

22

3. There is no enforced standard

from the government

SLIDE 23

A network or map of actors

SLIDE 24

24

4. Technology has been transfered

in 2 ways: formally and informally

SLIDE 25

600kW gasifjer, local manufacturer at Yam Chan rice mill, Batuambang province, Cambodia, KH. 2014 - 12 – 20 600kW Gasifjer at Golden Daun Keo rice mill, Batuambang, Cambodia, KH. 2014-12-20

25

SLIDE 26

26

5. Correlatjon between technology -

environmental quality control and management

SLIDE 27

Profitability objective Technology choice Pollution level

Black water pond - rice mill at Deum Pou village, Cambodia. 2014-12-19 Cleaning water system - UNIDO Project in Siem Siep Province, Cambodia. 2014-12-20

SLIDE 28

28

6. Rice husk is now a commodity

SLIDE 29

Rice husk truck for Thailand. Baitang trading mill, Cambodia, 2014- 12-20

29

SLIDE 30

30

7. Key factors for
peratjng/installing a gasifjer

SLIDE 31

Key factors:
Price of husk
Price of diesel fuel
Price of available electricity network
Other factor: load factor of rice mill.
Price of ash and environmental constraints are less

important.

31

SLIDE 32

Periodization of the economic power supply source

A graph here

SLIDE 33

33

8. The sector is concentratjng

SLIDE 34

Yam Chan rice mill, Battambang province, Cambodia, 2014 - 12 – 20 Baitang PLC , Battambang province, Cambodia Rice mill at Deum Pou village, Cambodia, 2014-12-19

SLIDE 35

A critjcal look on rice husk gasifjcatjon in Cambodia: engineering and sustainability

35

Gasifjcatjon, an appropriate technology for Cambodia ? Gasifjcatjon, an appropriate technology for Cambodia ? Data collectjon Data collectjon Lessons learned Lessons learned Summary and concluding remarks Summary and concluding remarks

SLIDE 36

3 key messages to remember

Rice husk gasifjcatjon technology works in Cambodia

and contribute to the development of the agricultural sector.

Rice husk was before a waste from rice mills, is now

becoming commodity.

Pollutjon from gasifjcatjon installatjons is a problem

and need to be treated in an appropriate way.

Minh Ha-Duong, Hong Nam Nguyen. Rice husk gasification for electricity generation in Cambodia in December 2014. [Research Report] Université de Sciences et Technologies de Hanoi. 2014. <hal-01107615>

SLIDE 37

“Has gasifjer” positjvely associated with “Is connected to the grid”?

On-grid Ofg-grid Row totals Rice husk gasifjer 9 44 53 Does not have rice husk gasifjer 24 276 300 Column totals 33 320 353

“Independence test”:

Operatjng rice mills in Cambodia

SLIDE 38

Small-scale Yes Decentralized Yes Labor-intensive Yes compared to a power plant Energy-effjcient >steam engine, <steam turbine Environmentally sound No Locally controlled To some extend

Gasifjcatjon may not remain an appropriate technology in Cambodia.

SLIDE 39

Biomass potentjal in Vietnam

Source: VTT Technology Research Center of Finland (2010)

SLIDE 40

Prospect for rice husk to energy in Vietnam

Small scale rice husk gasifjer stove developed by SNV in Vietnam Rice husk Co-fjring

SLIDE 41
