Next Generation Sequencing The basics

Wilfred van IJcken Erasmus MC Center for Biomics Biomedical Research Techniques (XVIth ed.), Nov 6

Center for Biomics

Learning objectives

Next generation sequencing (NGS): The basics  Background  Illumina sequencing technology  Terminology Next presentation  Research applications  Diagnostic applications  Future directions

What is next generation sequencing?

• Sequencing technology developed after Sanger
• Millions of reads in parallel (MPS)
• Shorter (<400bp) sequencing reads
• Enables analysis of complex mixtures of DNA or RNA
• Enables genome wide approach
• Different vendors with different approaches
• MPS = massive parallel sequencing

NGS systems on the market High Throughput Special Desktop

Different characteristics

Sequencing technology Readlength Speed Output Applications Run cost

Illumina systems

• 6 Tb per run

MiSeq HiSeq 2500 NextSeq 500 HiSeq X Ten

Data amount Purchase cost

HiSeq 4000 MiniSeq

8 Gb

Run costs

NovaSeq6000

NGS flow

Isolate Library Sequence Intake Report

ID amount sex disease DNA or RNA blood plasma saliva FFPE cells Select region of interest PCR capture chemistry enzymes detection signal yield quality Variation Match phenotype?

DNA library prep

Sequencing by Synthesis cluster generation

lane flowcell

Bridge amplification

Sequencing

incorporated

Sequencing and basecalling Read 1

Base calling 1 2 3 7 8 9 4 5 6 Image acquisition

C A A G T A A C …

A T G C

SingIe-end, paired end, index read

Single Read Paired end read

GATCG

Index read Single read = sequence from one side of the fragment Paired end = sequence from both sides of the fragment

Indexing enables sample multiplexing

Index = different nucleic acid code per sample  introduced during sampleprep  read during index read Enables multiple samples in one flowcell lane

GATCG

Index

CGTGA ATCGG TCTCT

Patient 1 Patient 2 Patient 3 Patient 4

Sequence Index 1

Sequence Index 2

Sequence Read 2

1 2 3 7 8 9 4 5 6 Image acquisition

C A A G T A A C …

Summary sequencing technology Read 1 Index 1 Read 2 Index 2

Simplified RNA sample preparation

DNA Reverse transcriptase RNA Adaptor 1 Adaptor 2

Output file from basecalling

• Many file types: qseq, fastq, etc…
• Each system own format.
• Large file sizes: >400 million reads per lane

ASCII Character Q-score PF (0,1) Sequence Instrument Run ID Lane Tile X-coord Y-coord Index # Read #

C A A G T A A C …

Data analysis not trivial due to data volumes and complexity

Data Volume Total Final Comment

HiSeq 2000 200G run Image Data 32 TB Intensity Data 2 TB Optionally transferred Base Call / Quality Score Data 0.25 TB 0.25 TB 1 byte/base (raw) assuming qseq generation offline Alignment Output 6 TB (3 TB) 1.2 TB Remove intermediate files GAIIx 50G run Image Data 6.9 TB Optionally transferred Intensity Data 0.93 TB 0.93 TB Base Call / Quality Score Data 0.17 TB 0.17 TB Alignment Output 1.2 TB 1.2 TB

150 M reads x 8 lanes x 100 bp x 2 (paired end) = 240 Gbp Storage and compute needed Core facilities

Terminology

• Next generation sequencing, AKA:
• - Deep sequencing
• - MPS = massive parallel sequencing

1 2 3 7 8 9 4 5 6

T G C T A C G A T …

Read Cluster # of sequencing cycles = readlength

Alignment, Mapping

AAAACGCGCTTAGCCTTTTTTCGACTGTCGAGTGGAACGCCGCTAGCTAGGCGC AAAACGCGCTTAGCCTTTTTTCGACTGTCGAGTGGATCGCCGCTAGCTAGGCGC TAGCCTTTTTTCGACTGTCGAGTGGATCGCCG AGCCTTTTTTCGACTGTCGAGTGGATCGCCGC GCCTTTGTTCGACTGTCGAGTGGATCGCCGCT CCTTTGTTCGACTGTCGAGTGGATCGCCGCTA

Consensus sequence Reference sequence Heterozygous SNP mismatch

Read depth

• Average read depth can differ a lot from read depth !

AAAACGCGCTTAGCCTTTTTTCGACTGTCGAGTGGATCGCCGCTAGCTAGGCGC TAGCCTTTTTTCGACTGTCGAGTGGATCGCCG AGCCTTTTTTCGACTGTCGAGTGGATCGCCGC GCCTTTGTTCGACTGTCGAGTGGATCGCCGCT CCTTTGTTCGACTGTCGAGTGGATCGCCGCTA GACTGTCGAGTGGATCGCCGCTAGCTAGG CTGTCGAGTGGATCGCCGCTAGCTAGG 5 7 1

Aka depth of coverage

Accuracy, error rate, quality score

• Single base error rate =
• Total number of mismatched bases found in mapped sequence reads

from a sequencing run, divided by the mappable yield.

• Quality scores (Q scores / phred scores)
• - derived from an examination of the intensity peaks around each base
• - range from 0 – 41, higher corresponds to higher quality
• - Q = -10log10 p, p is basecall error probability

Quality score Probability of incorrect base call Base call accuracy 10 (Q10) 1 in 10 90% 20 (Q20) 1 in 100 99% 30 (Q30) 1 in 1000 99.9%

Traditional vs NextGen Sequencing

1 sequence read per basepair Multiple sequence reads per basepair Sanger sequencing: NGS:

LNA Genomics core facility at ErasmusMC www.biomics.nl w.vanijcken@erasmusmc.nl

Erasmus Center for Biomics
