Next Generation OR Lighting System

Fadl Amsalam Mechanical Engineering Alex Enriquez Mechanical Engineering David Lyon Mechanical Engineering Ryan Seidel Mechanical Engineering Jun Huang Mechanical Engineering

  • Dr. Webster Johnson

Mechanical Engineering

Sponsor Advisor

slide-2
SLIDE 2

Background

Redesigning Maquet’s operating room light suspension system

Current Problem:

  • Light mobility
  • Drift
  • Dead zones
  • Maintenance
slide-3
SLIDE 3

Project Specification

Must Do Should Do Would be nice

Support a Load of 20 kg Vertical positioning Force <= 16.5 N Articulation Force <= 25 N Vertical Range 1-2.1 m Max Radial Distance 2.5 m No Dead Zones Spin Range 420° Smooth Motion Small Gaps (IP44 rating) MFGT cost $1940.00 Surfaces, Corners & Edges No Surface Liquid Pooling Multiple Loads Meet IEC Medical Standards IEC 60601

slide-4
SLIDE 4

Design Solution

  • Present your design solution
  • Help your audience understand your final

design

  • Presentation may include:
  • Assembly model
  • Renderings of key components
  • Animation of device in action
  • Rendered would be nice
  • Physical hardware
  • Other visual aids as appropriate

Our Design Solution

Range

slide-5
SLIDE 5
  • Delrin bushings
  • Grease
  • Shaft within a

shaft

  • Concise
  • Rigid
slide-6
SLIDE 6

Gear 1 is fixed (connected to upper arm) Arm rotates freely

slide-7
SLIDE 7

Fabrication

  • Fabricated

○ Frame, Arms, Laser cut parts - Transfer Flow

  • Purchased

○ Bearings, Gears, Fasteners (Delrin Bushings<Bearings)

slide-8
SLIDE 8

Fabrication Difficulties

  • Tolerances
  • Light attachment
  • Joints
  • Springs
slide-9
SLIDE 9
slide-10
SLIDE 10

Testing

  • Loads
  • Articulation Forces
  • Vertical Range
  • Horizontal Range
  • Braking System
slide-11
SLIDE 11

Total Cost Excluding Labor - Last semester.

Raw material $772 Purchased parts $825 Outside of Manufacturing $1,210 shipping $260 Total

$3,067

slide-12
SLIDE 12

Total Project Cost

Raw material $750.57 Fabrication $515.63 Frame $250 Hardware $72.07 Total

$ 1516.2

slide-13
SLIDE 13

Details Budget:

Material = $ 750

  • Spring $203
  • Bearing $105.68
  • Gear $211.02

Free Donation

  • Transfer Flow
  • Material $ 78
  • Labor $ 115
  • Scotty Vanni
slide-14
SLIDE 14

Fabrication:

slide-15
SLIDE 15

Reflection

❖ Budget ❖ Springs ❖ Suspension Joint ❖ Upper Control Arm

slide-16
SLIDE 16

QUESTIONS?

In Conclusion...
