OIZ OMR

XC

EMBARGO 25TH JUNE 4 PM (TC+2)

NEW

AIM FOR THE TOP

1 OMR STRUCTURE FULL EPS // FIBERLINK // UFO 2 2 RACE FOCUS DESIGN INSIDE LINE // FULL ICR 3 XC ULTIMATE WEAPON AD DYNAMICS // RACE GEO// TWO STROKE 4 SMART FEATURES TWO BOTTLES // DROPPER // BO BEARINGS 5 MyO

*

MAKING THE BEST EVEN BETTER

1 OMR STRUCTURE FULL EPS

Orbea Monocoque Race The lightest and most sophisticated construction available today. // FULL EPS // OMR FIBERS // 3D CNC MACHINED

1,6 kg

• f best fibers, engineering

& manufacturing ever

59gr

1 OMR STRUCTURE FIBERLINK

Lightest and most advanced link ever in Orbea range. Aerospatial material for a rocket bike.

Evolve or die Oiz UFO construction is refined for maximum performance.

1 OMR STRUCTURE UFO 2

It’s the quickest way around the competition - and the optimal route for control cables racing to your fingertips.

2 RACE STYLING INSIDE LINE

// Hidden remote actuator & cable // Better & lighter look // More room for triangle // More durability & less hassle // Exclusive Fox-Orbea partnership

2 RACE FOCUS DESIGN INSIDE LINE

PATENT PENDING

Clean, simple, low-maintenan-

• ce. Oiz internal cable routing is

as sophisticated as Oiz itself.

2 RACE FOCUS DESIGN FULL ICR

Low sag, full travel, maximum efficiency - The fastest Oiz starts with smart suspension.

3 PURE XC ADVANCED DYNAMICS KINEMATICS

Low sag, full travel, maximum efficiency - The fastest Oiz starts with smart suspension.

3 PURE XC ADVANCED DYNAMICS KINEMATICS

LEVERAGE RATIO

WHEEL TRAVEL

2.00 2.60 2.23 60

90 100 OIZ 2019 OIZ 2018

3 PURE XC ADVANCED DYNAMICS KINEMATICS

ANTI-SQUAT

WHEEL TRAVEL

85% 120% 100% 50

90 100 OIZ 2019 OIZ 2018

3 PURE XC WC GEOMETRY

The same handling characteristics that win the most grueling World Cup races make Oiz the perfect all-around cross country performer.

15.5/SM 17.5/MD 19/LG 21 /XL 15.5/SM

3 PURE XC WC/TR GEOMETRY

435 mm (417mm) OIZ 2019 OIZ 2017 69º (70º) 75º (74º) 435 mm (440mm)

OIZ TESTS

*

Static stiffness tests

Front (Contact point, 29 fork&wheel) (mm) Rear stiffness (axle) (mm) Ultimate fatigue testing Weight Suspension Travel Anti-Squad SAG

2019

20,1 6,7 105% 1510 100 114%

Improvement

110% 109% 117% 99% 111% 112%

2017

22,15 7,3 90% 1519,4 90 102%

OIZ TESTS

*

WEIGHT COMPARISON

2,3 Kg

• 75gr DIRECCIÓN

1,97 Kg 2,2 Kg 2,5 Kg

• 250gr freno

1,83 Kg

*

WEIGHT OIZ

*

WEIGHT OIZ

*

3 PURE XC TWO STROKE

What could possibly be as cool as the world’s most efficient, sleek and sophis- ticated 100mm XC bike? The same bike with 120mm travel. // Dropper option // Trail tires option

100MM XC 120MM TR

3 PURE XC TWO STROKE

100mm 120mm 100mm 120mm 75º 74º 69º 68º

ULTIMATE WORLD CUP WEAPON WITH 100MM TRAVEL MARATHON SPECIALIST WITH 120MM TRAVEL

*

ONE FRAME TWO PERSONALITIES

FORK SHOCK SEATPOST TYRES

XC SPECS

Fox Factory SC32 Rem 100 Fox Fact I-line 190x40 FSA SLK/K-Force Ardent Race (front) Ikon (Rear)

TR SPECS

Fox Factory SC34 Rem 120 Fox Fact I-line 190x45 Race Face Aeffect 125mm Forecaster 2,35 (Front) Ardent race (Rear)

UPCHARGE

129€ 99/59€ 0€

DROPPER COMPATIBLE 1x SPECIFIC

with SL chainguide

TWO BOTTLES

FULL COMPLEMENT

enduro BO bearings

Features Features Features Features

MYO IS MORE THAN AN ONLINE DISTRACTION - IT’S A SALES TOOL MYO HAS DRAMATICALLY INCREASED ROAD SALES MYO IS ABOUT RIDERS EXPERIENCING THE ORBEA BRAND

MyO

M10

FOX SC FACT 1x12 Eagle X01 Xmax ELITE

M-TEAM

FOX SC FACT 1x12 XTR DT XRC1200

M10 TR

M10 PACK120mm TIRES DROPPER

M-LTD

FOX SC FACT 1x12 Eagle XX1 Xmax CARBON

OIZ OMR COLORS & SPECS

THANKS
