New Opera House in Copenhagen By Hans Kragh, Ramboll Who am I Hans Kragh Senior Project Director Rambll, Denmark-Employed since 1980 Ramboll Approx. 9.000 Employees Main offices in Denmark, Sweden, Norway, Finland & UK More info:

slide-1
SLIDE 1

New Opera House in Copenhagen

By Hans Kragh, Ramboll

slide-2
SLIDE 2

2 Slide New Opera House in Copenhagen

Hans Kragh Senior Project Director Rambøll, Denmark-Employed since 1980 Ramboll

  • Approx. 9.000 Employees

Main offices in Denmark, Sweden, Norway, Finland & UK More info: www.ramboll.com www.ramboll.pl

Who am I

slide-3
SLIDE 3

3 Slide New Opera House in Copenhagen

slide-4
SLIDE 4

4 Slide New Opera House in Copenhagen

Donation from the A. P. Møller Foundation

slide-5
SLIDE 5

5 Slide New Opera House in Copenhagen

  • Mr. Møller
slide-6
SLIDE 6

6 Slide New Opera House in Copenhagen

Client’s Brief

Auditorium w ith w orld class acoustics High quality indoor clim ate Theatre tecnique better than the best European opera houses A repertoire theatre w ith a capacity of 3 ongoing perform ances and facillities for ballet Delivery no later than 3 ½ year after design start ( w orld record!)

slide-7
SLIDE 7

7 Slide New Opera House in Copenhagen

Key Figures

Sound level in auditorium – PNC 1 5 4 0 .0 0 0 m 2 and 1 2 4 2 room s 6 stages and a separate studio stage W orking place for opera, ballet and m usicians Price approx. 3 5 0 m illion Euro

slide-8
SLIDE 8

8 Slide New Opera House in Copenhagen

Consultants

Consulting engineer Ram bøll Architect Henning Larsen Architects Theatre technology Theatre Plan, UK Acoustics Arup Acoustics, UK Subconsultans – Buro Happold and Jonathan Speirs - UK

slide-9
SLIDE 9

9 Slide New Opera House in Copenhagen

How to design and built an Opera in 3½ year

Design and built at ( nearly) the sam e tim e. Deliver project packages every 2 w eeks. Quick decission process by the Client. No discussions w ith the end user The Engeneer and the Architect w orking together in a Project Office on site

4 5 0 Ram bøll em ployees involved each perform ing from 1 0 to 6 .0 0 0 hours

slide-10
SLIDE 10

10 Slide New Opera House in Copenhagen

Location in Inner Harbour in Copenhagen

New Opera House Royal Castle Marble Church Christiania Little Mermaid

slide-11
SLIDE 11

11 Slide New Opera House in Copenhagen

Main Layout

Studio stage Rear stage Fitt-up stage Rehearsal stage Side stages Foyer Auditorium Main stage Dressing rooms

slide-12
SLIDE 12

12 Slide New Opera House in Copenhagen

Cross Section

Orchestra rehearsal Scene area Foyer Auditorium Main stage/ Flytower Rehearsal rooms Studio stage Loading dock Orchestra pit Plant rooms

slide-13
SLIDE 13

13 Slide New Opera House in Copenhagen

Google Earth

slide-14
SLIDE 14

14 Slide New Opera House in Copenhagen

OPERAEN SET FRA LANGEBRO

The Opera Seen from the Inner Harbour

slide-15
SLIDE 15

15 Slide New Opera House in Copenhagen

View to the Royal Castle

slide-16
SLIDE 16

16 Slide New Opera House in Copenhagen

Foyer and Roof

slide-17
SLIDE 17

17 Slide New Opera House in Copenhagen

Back Side

slide-18
SLIDE 18

18 Slide New Opera House in Copenhagen

Harbour view from Foyer Balcony

slide-19
SLIDE 19

19 Slide New Opera House in Copenhagen

Opera by Night

slide-20
SLIDE 20

20 Slide New Opera House in Copenhagen

Opera by Night

slide-21
SLIDE 21

21 Slide New Opera House in Copenhagen

Foyer

slide-22
SLIDE 22

22 Slide New Opera House in Copenhagen

Foyer

slide-23
SLIDE 23

23 Slide New Opera House in Copenhagen

Orchestra Rehearsal Room

slide-24
SLIDE 24

24 Slide New Opera House in Copenhagen

Auditorium – seen from the Stage

slide-25
SLIDE 25

25 Slide New Opera House in Copenhagen

Auditorium

slide-26
SLIDE 26

26 Slide New Opera House in Copenhagen

Small Studio Stage

slide-27
SLIDE 27

27 Slide New Opera House in Copenhagen

Scenery Tecnique

slide-28
SLIDE 28

28 Slide New Opera House in Copenhagen

Building services

slide-29
SLIDE 29

29 Slide New Opera House in Copenhagen

Heat Consumption

3 .4 MW

District Heating

2 5 AHU 4 0 0 .0 0 0 m 3/ h 1 2 0 0 convectors Hot tap w ater Under floor heating 2 5 km tubes Local heating 4 0 fan heaters etc.

slide-30
SLIDE 30

30 Slide New Opera House in Copenhagen

Design Key Figures – Heating System

Low tem perature 2 -pipe heating system - 6 5 / 4 0 ° C Flow velocity for pipes – 0 .5 to 0 .8 m / s Pressure controlled variable speed pum ps Dynam ic pressure balancing system s

slide-31
SLIDE 31

31 Slide New Opera House in Copenhagen

3 .4 MW Heating Plant

Heating Plant

slide-32
SLIDE 32

32 Slide New Opera House in Copenhagen

Plant rooms

k

slide-33
SLIDE 33

33 Slide New Opera House in Copenhagen

Distribution System – Overall principle

Distribution storey

Heating plant area Low noise Auditorium area No noise Risers

District heating

2 x 7 5 % redundancy

slide-34
SLIDE 34

34 Slide New Opera House in Copenhagen

Distribution Storey

3 D - Model Real

slide-35
SLIDE 35

35 Slide New Opera House in Copenhagen

9 1 no. m ixing units Dim ensions from Ø 1 5 to Ø 1 6 8 m m Prefabricated

Mixing Units

slide-36
SLIDE 36

36 Slide New Opera House in Copenhagen

Dynamic Pressure Balancing System

Challenge :

Many consumers Widely distributed heating system Successiv flow adjustment Fluctuated consumption

Advantages :

Low energy cost for pumps Low noise emission Load controlled flow Controlled temperature drop of heating medium Low consequence when changing the heat consumption

slide-37
SLIDE 37

37 Slide New Opera House in Copenhagen

Indoor Climate simulation for Dressingroom

CFD – pattern for cross sektion

  • f a dressingroom
slide-38
SLIDE 38

38 Slide New Opera House in Copenhagen

CFD – Convector Load 1500 W

slide-39
SLIDE 39

39 Slide New Opera House in Copenhagen

CFD – Convector Load 1056 W

slide-40
SLIDE 40

40 Slide New Opera House in Copenhagen

CFD – Convector Load 616 W

slide-41
SLIDE 41

Slide New Opera House in Copenhagen

Cooling System

2 ,5 MW Cooling system s 2 system s – 1 0 / 1 5 °C and 1 5 / 1 8 °C Free-cooling by sea W ater Process cooling all over the year Com bined Underfloor heating/ cooling No noise cooling by cooling W alls

slide-42
SLIDE 42

42 Slide New Opera House in Copenhagen

Cooling system – Overall principle

Chiller Free- Cooling Bernoulli Filter Seawater inlet Seawater

  • utlet

Note:

3 identically systems with cross connections Main components are redundant Frequenzy regulated Pumps

Strainer

To buffertank & distribution

slide-43
SLIDE 43

43 Slide New Opera House in Copenhagen

Sea water cooling - advantages

High COP’s for chillers

  • Approx. 6 ,0 for 1 0 / 1 5 degree C system
  • Approx. 8 ,0 for 1 5 / 1 8 degree C system

Free cooling w hen Seaw ater is cold enough No visible condensers on roof etc.

slide-44
SLIDE 44

44 Slide New Opera House in Copenhagen

Mean seawater temperature in Copenhagen

Copenhagen 2 4 6 8 10 12 14 16 18 20 jan feb mar apr maj jun jul aug sep

  • kt

nov dec Month Seaw ater tem perature Temperature

slide-45
SLIDE 45

45 Slide New Opera House in Copenhagen

Cooling Plant

slide-46
SLIDE 46

Slide New Opera House in Copenhagen

Quiet cooling

slide-47
SLIDE 47

47 Slide New Opera House in Copenhagen

18 km Ø 22 mm tubes for foyer Heating 50 W/ m 2 Cooling 30 W/ m 2 C/ c - 150 mm

Combined Under Floor Heating/ Cooling

slide-48
SLIDE 48

48 Slide New Opera House in Copenhagen

Com bined underfloor cooling/ heating Heating Cooling

Combined Heating/ Cooling Arrangement

slide-49
SLIDE 49

49 Slide New Opera House in Copenhagen

CDF – Simulation for Foyer

Temperature (ºC) 29 28 27 26 25

Air Speed (m/s) >0.5 0.4 0.3 0.2 <0.1
slide-50
SLIDE 50

50 Slide New Opera House in Copenhagen

High pressure Mist humidification

slide-51
SLIDE 51

51 Slide New Opera House in Copenhagen

High pressure Mist Humidification

Potable Water Salt Filter Reverse

  • smosis

Filter High pressure Mist Pump UV- Light protection 100 bar Waste Water Nozzles in Pipe Nozzles in Pipe

Main Stage 400 liter Water

  • pr. Hour
slide-52
SLIDE 52

52 Slide New Opera House in Copenhagen

100 200 300 400 500 600

Steam Ultrasound Compresed air High pressure mist

600 600-

  • 800

800 Watt Watt 30-50 Watt 50 50-

  • 75

75 Watt Watt 6-7 Watt Energi consum ption in w att/ liter w ater

( for produktion of hum idification)

600 500 400 300 200 100

Energy consumption for Humidification

slide-53
SLIDE 53

53 Slide New Opera House in Copenhagen

High pressure Mist Humification in small Rooms

23 Rehearsal Rooms 58 Dressingrooms

slide-54
SLIDE 54

Slide New Opera House in Copenhagen

Sprinkling

High Risc = Harbour W ater Norm al Risc = Potable W ater 3 0 m 3 reservoir Main Stage = 6 .0 0 0 l W ater/ m in De Luge System for Main Stage 4 pc. Pre-action System s > 4 3 0 0 sprinklers Drop dow n sprinklers

slide-55
SLIDE 55

Slide New Opera House in Copenhagen

Sanitary

OBS

Note: The only Ashtray in the Opera

275 WC 370 Wash Basins 120 Showers

slide-56
SLIDE 56

Slide New Opera House in Copenhagen

Compressed air system

PN 1 0 bar Capacity = 6 m 3 / m in Dew point = 2 degree C ( -3 0 degree C for outdoor bollards) W atercooled Com pressorunit

  • Appox. 5 0 supply points

Supply to : W ork room s Mobile seats Bernoulli filters Sound closures Sprinklersystem s Moveable bollards

slide-57
SLIDE 57

57 Slide New Opera House in Copenhagen

Acoustic solutions

slide-58
SLIDE 58

58 Slide New Opera House in Copenhagen

PNC 15 – Preferred Noise Criterion

slide-59
SLIDE 59

59 Slide New Opera House in Copenhagen

Acoustic Solutions for Piping System

Machinery and pum ps are located in separate room s I solated plinth for pum ps Low velocity in pipes Spring suspensions Pressure controlled pum ps Flexible connection for box in box room s Acoustic pipe closures

slide-60
SLIDE 60

60 Slide New Opera House in Copenhagen

Piping to a Box in Box Construction

Inner box Outer box Flexible reinforced tube Combined fire and acoustics closure

slide-61
SLIDE 61

61 Slide New Opera House in Copenhagen

Combined Fire and Acoustics Closure

More than 2 0 .0 0 0 closures for pipes

slide-62
SLIDE 62

62 Slide New Opera House in Copenhagen

Elements for low noise ventilation

Silensers Lining Lagging Low Air velocity

slide-63
SLIDE 63

63 Slide New Opera House in Copenhagen

Acoustic solutions for Ducts

Double Silencer turning 3 6 0 degree in Rehearsal Room

slide-64
SLIDE 64

64 Slide New Opera House in Copenhagen

Light and noise

Lightning gives noise

The ”pling”-factor Frequency related buzzing

Consequense

Heavy goods m aterials in Lam ps Special room s for spots etc. Specially light bulps Fiber Optics light

Follow spot Room

slide-65
SLIDE 65

65 Slide New Opera House in Copenhagen

No-noise Fiber optics in auditorium

5 0 light sources, 1 0 0 W each Located outside Auditorium No heat gain in Auditorium

slide-66
SLIDE 66

Slide New Opera House in Copenhagen

Ventilation

3 0 large ventilation plants Capacity approx. 4 0 0 .0 0 0 m 3 / h W instrong ventilators overall Air velocity in ducts m ax 2 ,5 m / s Variable Air Volum en – controlling Com fort and process ventilation

slide-67
SLIDE 67

Slide New Opera House in Copenhagen

Ventilation - Comfort

Overview Auditorium - 7 0 .0 0 0 m ³ / h Foyer - 4 0 .0 0 0 m ³ / h Studie Stage - 2 0 .0 0 0 m 3 / h Canteen - 2 0 .0 0 0 m ³ / h Orchestra Rehearsal - 1 2 .0 0 0 m ³ / h Rehearsal Stage - 1 5 .0 0 0 m ³ / h Dressing Room s/ offices -3 5 .0 0 0 m ³ / h Rehearsal Room s - 2 5 .0 0 0 m ³ / h AHU for a ½ Auditorium

slide-68
SLIDE 68

68 Slide New Opera House in Copenhagen

Auditorium – Principle for ventilation

Early Sketch

slide-69
SLIDE 69

69 Slide New Opera House in Copenhagen

CFD - layout

kjg

Fly Tower Auditorium Extract Orchestra Pit Performers Stage Supply Stage Lighting Stalls 1

st Tier

2

nd Tier

3

rd Tier

Acoustic Ceiling Perforated Ceiling

slide-70
SLIDE 70

70 Slide New Opera House in Copenhagen

CFD- simulation for Auditorium

slide-71
SLIDE 71

Slide New Opera House in Copenhagen

CFD – simulations in Auditorium

slide-72
SLIDE 72

72 Slide New Opera House in Copenhagen

CFD in Auditorium

slide-73
SLIDE 73

Slide New Opera House in Copenhagen

Ventilation in Auditorium

slide-74
SLIDE 74

Slide New Opera House in Copenhagen

Capacity is approx. 40.000m3/h Pressure drop for diffusor is 13 Pa by 12 l/s

Plenum under Auditorium

slide-75
SLIDE 75

Slide New Opera House in Copenhagen

Ducts above Auditorium

Ø 1,5 m Ducts

slide-76
SLIDE 76

76 Slide New Opera House in Copenhagen

CFD – simulation in Orchestra Rehearsal Room

Velocity I so Plot

slide-77
SLIDE 77

77 Slide New Opera House in Copenhagen

CFD of Orchestra Rehearsal Room

slide-78
SLIDE 78

78 Slide New Opera House in Copenhagen

CFD simulation for Small Studio Stage

slide-79
SLIDE 79

79 Slide New Opera House in Copenhagen

MOCK UP’s

slide-80
SLIDE 80

80 Slide New Opera House in Copenhagen

MOCK- UP I 1:1

Mock-up of Foyer Facade – outside view

slide-81
SLIDE 81

81 Slide New Opera House in Copenhagen

INDE I MOCK- UP´ EN

Mock-up of Foyer Facade – inside view

slide-82
SLIDE 82

82 Slide New Opera House in Copenhagen

MOCK- UP AF FACADEN

2 storey Mock-up of facade

slide-83
SLIDE 83

83 Slide New Opera House in Copenhagen

MOCK- UP AF SIDEBYGNINGER

2 storey Mock-up of Dressingroom

slide-84
SLIDE 84

84 Slide New Opera House in Copenhagen

Mock up of Balcony

( Were used for ventilation tests)

slide-85
SLIDE 85

85 Slide New Opera House in Copenhagen

ACOUSTIC VIND ARCHITECT

Modelling

slide-86
SLIDE 86

86 Slide New Opera House in Copenhagen

Test and Com m issioning

slide-87
SLIDE 87

87 Slide New Opera House in Copenhagen

1: 1 Acoustic and indoor climate test

W e invited 1 5 0 0 test- persons and asked for their oppinion upon acoustic and indoor clim ate

slide-88
SLIDE 88

88 Slide New Opera House in Copenhagen

Test in Rooms

Artificial heat gain during testing and adjustm ent of ventilation, cooling and BMS. Docum entation through logning and BMS

slide-89
SLIDE 89

89 Slide New Opera House in Copenhagen

Energy effiency - Highlights

slide-90
SLIDE 90

90 Slide New Opera House in Copenhagen

Energy effiency – General

Big roof gives shade for foyer Bagside roof gives shade for canteen Shaded glass High insulation standard – Heat loss is 7 0 % of public dem ands LON controlled lightning by PI R sensors and daylight sensors

slide-91
SLIDE 91

91 Slide New Opera House in Copenhagen

Energy effiency – ventilation

Very low velocity in ducts VAV system s w here possible Frequency converters for all fans – even for CAV system s Effective heat recovery in AHU’s BMS controlled system s

slide-92
SLIDE 92

92 Slide New Opera House in Copenhagen

Energy effiency - Mechanical

Freecooling Very high cooling COP and high tem perature cooling District heating and low tem perature heating Frequency converters for all pum ps Low velocity in pipes Dynam ic balancing heating and cooling system s High pressure m ist system s

slide-93
SLIDE 93

93 Slide New Opera House in Copenhagen

Please notice . . . . . .

slide-94
SLIDE 94

94 Slide New Opera House in Copenhagen

Non reflective Walls

slide-95
SLIDE 95

95 Slide New Opera House in Copenhagen

Fossils in facade

slide-96
SLIDE 96

96 Slide New Opera House in Copenhagen

Hidden Door in facade

slide-97
SLIDE 97

97 Slide New Opera House in Copenhagen

Olafur Eliassons Chandelier in the Foyer

slide-98
SLIDE 98

98 Slide New Opera House in Copenhagen

Slit wodden Wall in Auditorium

slide-99
SLIDE 99

99 Slide New Opera House in Copenhagen

Per Kierkeby Relief in foyer

Art

slide-100
SLIDE 100

100 Slide New Opera House in Copenhagen

The golden Ceiling in Auditorium

slide-101
SLIDE 101

101 Slide New Opera House in Copenhagen

Motorroom in top of Flytower

slide-102
SLIDE 102

102 Slide New Opera House in Copenhagen

Heating Panels for Sensible Ballet Feet

Hidden heating panels

slide-103
SLIDE 103

103 Slide New Opera House in Copenhagen

The opera doesn’t end till the fat lady sings

slide-104
SLIDE 104

104 Slide New Opera House in Copenhagen

Questions?

Questions ?
