New from EnGenius The ENS Series Wireless Outdoor Access Points & Bridges for Business 1 New from EnGenius Wireless Outdoor The ENS Series Access Points Wireless Outdoor Bridges ENS200 ENS202 ENS500 ENS500EXT ENS200EXT ENS202EXT 2
SLIDE 2
SLIDE 3
3
Target Markets
Customers
- Small businesses
- Businesses expanding to additional offices in
business parks or corporate campuses
- Schools and universities looking for an
economical network expansion solution
- Homeowners wishing to expand their home
network around their property or to guest houses or other out buildings
- Vertical markets – Recreation (RV Parks,
campgrounds, resort areas)
SLIDE 4
4
Target Markets
Sales Channels
- Channel Distributors
- Retail
- etail
- VARs and System Integrators
- Managed Service Providers
SLIDE 5
5
Product Overview
SLIDE 6
High output power (dBm) High Gain (dBi) Internal or External Antennas Results in Strong Transmission Rate and longer range coverage Key Selling Points
SLIDE 7
7
Made for Harsh Outdoor Environments
Specifically designed for outdoor deployments and are IP65-rated for waterproofing and dustproofing. Housings are also made with a UV resistant material.
Key Selling Points
SLIDE 8
Protective Cover for Ethernet Ports
Each ENS AP and Bridge includes a proprietary PoE (Power-over-Ethernet) Injector with its own power adapter.
Key Selling Points
SLIDE 9
9 2.4 GHz / 150 Mbps 400mW Tx Power Internal 8 dBi Directional Antenna IP65 Weatherproof 2 Fast-Ethernet Ports PoE Kit included
- Great Distance & Coverage
- High output power with internal, directional high-gain
antennas for greater coverage
- 4 operation modes: Access Point, Client Bridge, Client
Router and WDS
ENS Series Single Band 2.4 GHz Wireless Outdoor Bridges
2.4 GHz / 300 Mbps 400mW Tx Power Internal 8 dBi Directional Antenna IP65 Weatherproof 2 Fast-Ethernet Ports PoE Kit included
ENS200 ENS202
SLIDE 10
10 2.4 GHz / 150 Mbps 400mW Tx Power 1 detachable 5 dBi Antenna IP65 Weatherproof 2 Fast-Ethernet Ports PoE Kit included
- Great Distance & Coverage
- High output power with external, omni-directional high-
gain antennas for greater coverage
- 4 operation modes: Access Point, Client Bridge, Client
Router and WDS
ENS Series Single Band 2.4 GHz Wireless Outdoor Access Points
2.4 GHz / 300 Mbps 400mW Tx Power 2 detachable 5 dBi Antennas IP65 Weatherproof 2 Fast-Ethernet Ports PoE Kit included
ENS200EXT ENS202EXT
SLIDE 11
11 5 GHz / 300 Mbps 400mW Tx Power Internal directional 10 dBi Antenna IP65 Weatherproof 2 Fast-Ethernet Ports PoE Kit included
- Great Distance & Coverage
- High output power with internal, directional high-gain
antennas for greater coverage
- 4 operation modes: Access Point, Client Bridge, Client
Router and WDS
ENS Series Single Band 5 GHz Wireless Outdoor Bridge and Access Points
5 GHz / 300 Mbps 400mW Tx Power 2 detachable 5 dBi Antennas IP65 Weatherproof 2 Fast-Ethernet Ports PoE Kit included
ENS500 ENS500EXT
SLIDE 12
12
Common Use Case Scenarios
SLIDE 13
13
Most Common Use Case Scenario for ENS200, ENS202, and ENS500
ENS Series Outdoor Bridges
Two compatible ENS bridge units used to extend a company network by creating a wireless bridge between buildings Office Building / School Building
SLIDE 14
14
ENS Series Outdoor Access Points
Most Common Use Case Scenario for ENS200EXT, ENS202EXT, and ENS500EXT An ENS Access Point deployed to provide connectivity to a company network or its Internet connection for employees or guests Office Building / School Building Shopping Mall / Restaurant
SLIDE 15
15
Key Differentiators between EnGenius ENS and ENH Series Products
- More competitively priced / ample range for
most business uses
- Greater sales volume potential
- Better retail packaging for increased visibility
- n shelf
SLIDE 16
16
BEFORE – ENH Retail Packaging difficult to see on shelf
SLIDE 17
17
AFTER – ENS Retail Packaging
- Easier to find in store and more informative
- Router-size boxes / larger form factor and front facing
SLIDE 18
18
Relative Performance
The performance between ENH series and ENS series will be noticeable in longer range connectivity. For most business deployments the ENS Series is more than adequate.
SLIDE 19
19
ENS200 2.4 GHz / 150 Mbps
Single Band
Performance
ENS200EXT 2.4 GHz / 150 Mbps ENS202 2.4 GHz / 300 Mbps ENS500 5 GHz / 300 Mbps ENS202EXT 2.4 GHz / 300 Mbps ENS500EXT 5 GHz / 300 Mbps
Price
ENH200 2.4 GHz / 150 Mbps
Dual Band
ENH210 2.4 GHz / 300 Mbps ENH210EXT 2.4 GHz / 300 Mbps ENH700EXT 2.4 + 5 GHz 300 Mbps ENH202 2.4 GHz / 300 Mbps ENH500 5 GHz / 300 Mbps
SLIDE 20
20
ENS200
MAP: $59.99
Single Band
Performance
ENS200EXT MAP: $59.99 ENS202 MAP: $79.99 ENS500 MAP: $79.99 ENS202EXT MAP: $89.99 ENS500EXT MAP: $89.99
Price
ENH200 MAP: $79.99
Dual Band
ENH210 MAP: $269.99 ENH210EXT MAP: $279.99 ENH700EXT MAP: $549.99 ENH202 MAP: $99.99 ENH500 MAP: $99.99
Price Gap
SLIDE 21
Model
ENH200 ENS200
Description
Wireless Outdoor CPE Wireless Outdoor CPE
Wireless Lan Standard
Wireless N 150 2.4GHz Wireless N 150 2.4GHz
Output Power
27dBm 26dBm
Tx/Rx
1T1R 1T1R
Antenna Type
10dBi 8 dBi
Device Interface
2 x LAN Port 2 x LAN Port
EIRP
37dBM 34dBM
PoE Injector
Yes, and Reset button included Yes and without Reset button
Price (MAP)
$79.99 $59.99
21
Comparison with ENH Product 2.4GHz N150 Bridge
SLIDE 22
22 Model
ENH202 ENS202
Description
Wireless Outdoor CPE Wireless Outdoor CPE
Wireless Lan Standard
Wireless N 300 2.4GHz Wireless N 300 2.4GHz
Output Power
29dBm 26dBm
Tx/Rx
2T2R 2T2R
Antenna Type
10dBi 8 dBi
Device Interface
2 x LAN Port 2 x LAN Port
EIRP
39dbm 34dBM
PoE Injector
Yes, and Reset button included Yes and without Reset button
Price(MAP)
$99.99 $79.99
Comparison with ENH Product 2.4GHz N300 Bridge
SLIDE 23
Model
ENH500 ENS500
Description
Wireless Outdoor CPE Wireless Outdoor CPE
Wireless Lan Standard
Wireless N 300 5GHz Wireless N 300 5GHz
Output Power
27±2dBm 27±2dBm
Tx/Rx
2T2R 2T2R
Antenna Type
13dBi 10dBi
Device Interface
2 x LAN Port 2 x LAN Port
EIRP
40dbm 36dBM
PoE Injector
Yes, and Reset button included Yes, and without Reset button
Price (MAP)
$99.99 $79.99
23
Comparison with ENH Product 5 GHz N300 Bridge
SLIDE 24
24 Model
ENH200EXT ENS200EXT
Description
Wireless Outdoor CPE Wireless Outdoor CPE
Wireless Lan Standard
Wireless N 150 2.4GHz Wireless N 150 2.4GHz
Output Power
27dBm 26dBm
Tx/Rx
1T1R 1T1R
Antenna Type N/A
5 dBi
Device Interface
2 x LAN Port 2 x LAN Port
EIRP
37dBM 34dBM
PoE Injector
Yes, and Reset button included Yes, and without Reset button
Price(MAP)
$79.99 $59.99
Comparison with ENH Product 2.4GHZ N150 Access Point
