Why Choose The 3Z RF Vision Because It Helps Contractors and Sub-Contractors on: • Ease of use • Minimize time at site • Eliminate site re-visits • Provide quality closeout reports • Reduce OPEX cost • Improve Microwave performance degradation 2 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

Why Choose The 3Z RF Vision Optimize Time At Site With The RF Vision Alignment Tool • Lower OPEX cost by reducing time to align or trouble shoot a site and guarantee accurate measurements with line of sight image reports with GEO coding. • Because it provides a complete report with evidence of the work done at site, Customer will receive quality site validation right from the start. 3 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

Why Choose The 3Z RF Vision Prepare for the future with the RF Vision Alignment Tool With GNSS technology and visual information (see what the antenna is seeing) becomes valuable for future technologies. 4 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision 3Z RF Vision Overview • Built-in and Mechanically Aligned Camera • Built- in Impact resistant 5”Intuitive Touch - Screen interface • Dual Alignment Mode: Panel or Microwave • Multiple satellite constellations: GPS and Glonass. Beidou and Galileo will be available on future releases • Small Size, Rugged Design, and IP65 Rating • Automatic Site Report generation with line of sight image and GEO Coding 5 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision How it works: * * With multi constellation and dual frequency Technology the end user will receive an improvement on: • More Accurate Azimuth Results • Multipath Rejection Signals – Works well on crowded towers • Faster Satellite Acquisition * Future Releases 6 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision How It Works: For a faster more accurate alignment we have given the user sight of what Includes Mechanically Aligned Camera the alignment tool sees and we have embedded augmented reality technology With Augmented Reality Technology to present the antennas current values as the cross-hair and the target values as the bull's-eye. Simply the user must align the cross-hair to the bull's-eye and you got a perfect alignment To Facilitate The Alignment At Site And Provide More Information 7 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision Panel Antenna Alignment Mode Optimizes The Time At Site Panel Antenna Alignment Mode With Activated Camera Feature Panel Antenna Alignment Mode With Disactivated Camera Feature 8 www.3ztelecom.com

3Z RF Vision Microwave Antenna Alignment Mode Optimizes The Time At Site Microwave Alignment Mode With Activated Camera Feature Microwave Alignment Mode With Disactivated Camera Feature The Tool will do the math for you and compute the Azimuth and Tilt based on the target Lat/long and Height 9 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

RF Vision Operation Video Click to access the video: https://3ztelecom.com/wp-content/uploads/2018/03/MOVIE-Alignment-settings.mp4 10 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision Includes Strap Bracket Strap Bracket specs: Approx. Weight: • 2lbs. 10 oz. (1.19 Kg) Capabilities: • Antenna Panel (RAN – Cellular) • Microwave drum antennas 1’ (0.305m) to 10’ (3.05m – with extended straps) Webbing Strap Lengths and Material: • Two Standard 8’ Polyester webbing straps included With the clamp. Other sizes available upon request. 11 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 11

3Z RF Vision Strap Clamp Easy to attach to the antenna (MW or Panel) 12 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 11

RF Vision Mounting Brackets (Add On) Lip Clamp Mounting Fixtures Ericsson Air 32 Bracket 13 www.3ztelecom.com

RF Vision Mounting Brackets (Add On) Nokia FASB Standoffs Extended Webbing for the Strap Clamp We offer 6’ diameter and 10’ diameter 14 www.3ztelecom.com

3Z RF Vision (Add On) Laser Range Finder For Additional Height Measurements The Laser Range Finder Integrates fast, precise measurements with photo documentation. Measuring range up to 660 ft. with accuracy of ± 1mm. Bluetooth Measurement Transfer 93.3’ 15 www.3ztelecom.com

3Z RF Vision (Add On) Laser Range Finder Ground Verification Kit 16 www.3ztelecom.com

3Z RF Vision Format Reports: PDF, BMP, CSV 17 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision Format Reports: PDF, BMP, CSV 18 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision Kit Includes: 19 www.3ztelecom.com 3Z Telecom, Inc. I Antenna Alignment Solutions I 1

3Z RF Vision 20 www.3ztelecom.com
