SLIDE 1
New coolants: case study
- Prof. dr. ir. Ibo van de Poel, Faculty of TPM
New coolants: case study Prof. dr. ir. Ibo van de Poel, Faculty of - - PowerPoint PPT Presentation
New coolants: case study Prof. dr. ir. Ibo van de Poel, Faculty of - - PowerPoint PPT Presentation
New coolants: case study Prof. dr. ir. Ibo van de Poel, Faculty of TPM CFC 12 CFC 12 Inflammable CFC 12 Inflammable Non toxic CFC 12 Inflammable Non toxic Good thermodynamic properties CFC 12 Inflammable Non
SLIDE 2
SLIDE 3
CFC 12
- Inflammable
SLIDE 4
CFC 12
- Inflammable
- Non toxic
SLIDE 5
CFC 12
- Inflammable
- Non toxic
- Good thermodynamic properties
SLIDE 6
CFC 12
- Inflammable
- Non toxic
- Good thermodynamic properties
- Stable
SLIDE 7
CFC 12
- Inflammable
- Non toxic
- Good thermodynamic properties
- Stable
But: contribution to ozone depletion
SLIDE 8
Values
SLIDE 9
Values
- Safety specified as inflammability
SLIDE 10
Values
- Safety specified as inflammability
- Health specified as non-toxicity
SLIDE 11
Values
- Safety specified as inflammability
- Health specified as non-toxicity
- Environmental sustainability specified as:
Low ODP (Ozone Depletion Potential) Low GWP (Global warming Potential)
SLIDE 12
Other important design requirements
SLIDE 13
Other important design requirements
- Energy efficiency
– good thermodynamic properties
SLIDE 14
Other important design requirements
- Energy efficiency
– good thermodynamic properties
- Costs and availability
SLIDE 15
Other important design requirements
- Energy efficiency
– good thermodynamic properties
- Costs and availability
- Compatibility
– compatibility with materials – miscibility with lubricants (solubility, lubricity) – (minimal) adaptions in compressor
SLIDE 16
SLIDE 17
Increasing Toxicity
SLIDE 18
Health
SLIDE 19
Increasing Flammabality
SLIDE 20
Safety
SLIDE 21
Long atmospheric lifetime
SLIDE 22
Sustainability
SLIDE 23
SLIDE 24
SLIDE 25
= HFC134a
SLIDE 26
Why HFC 134a?
HFC134a attractive to chemical industry because:
- Patentable
- Not too inexpensive
SLIDE 27
Patents HFC 134a
2 4 6 8 10 12 World Intellectual Property Organisation European Patent Office US Patent and Trademark Office
SLIDE 28
Why HFC 134a?
Refrigerator firms also choose for HFC134a because of:
- Low impact on price
- Availability (from chemical firms)
- Compressors and lubricants adapted to HFC134a
SLIDE 29
‘In my nearly 25 years of working with the heating, ventilating, air-conditioning and refrigeration industry , I have never seen this industry put so much time and effort into one problem as they have into the CFC problem’.
SLIDE 30
Video ‘Greenfreeze and SolarChill’
SLIDE 31
ODP GWP Toxic? Flammable? CFC 12
1 10900 No No
HFC 134a
1430 No No
HC 600a (isobutane)
3 No Yes
SLIDE 32
ODP GWP Toxic? Flammable? CFC 12
1 10900 No No
HFC 134a
1430 No No
HC 600a (isobutane)
3 No Yes
SLIDE 33
Isobutane (HC600a)
Codes like ASHRAE 15 Safety Code for Mechanical Refrigeration:
Forbad flammable coolants
SLIDE 34
Re-specification of safety
SLIDE 35
Re-specification of safety
First:
- non-flammability of coolant
SLIDE 36
Re-specification of safety
First:
- non-flammability of coolant
Later:
- ignition and explosion risks of refrigerator
SLIDE 37
Re-specification of safety
First:
- non-flammability of coolant
Later:
- ignition and explosion risks of refrigerator
(can also be reduced by refrigerator design)
SLIDE 38
Summary
The greenfreeze innovation was:
SLIDE 39
Summary
The greenfreeze innovation was:
- Responsible
SLIDE 40
Summary
The greenfreeze innovation was:
- Responsible
- Radical
SLIDE 41
Summary
The greenfreeze innovation was:
- Responsible
- Radical
- Initiated by outsiders
SLIDE 42
