New Approach to the Presbyopia Treatment

Introduction Tri-ED EDOF Concepts Active Diffractive Optic Semi-Apodized Optic True TriFocality All in One Platform Technical Specifications First Clinical Results Competition – Product Segmentation

All-in-One Platform

True Trifocality with EDOF Square Edge Aspheric Optic Chromatic Aberration Control Plate Haptic - MICS

Introduction

Active Diffractive Optic Seamless Continuous Vision Balanced Near/Intermediate Addition Pupil-Independent Premium Material Photo protection

Full Diffractive Trifocal Optic Enhanced by Depth of Focus Vision*

* Patent Pending New Design

New! True Trifocal optic having superior MTF results at intermediate zones

Enhanced Depth of Focus Concept in Reviol Tri-ED Optic

• 1. Active Diffractive Optic
• 2. Semi-Apodization
• 3. True TriFocality

Active Diffractive Optic

Characteristic of Active Diffractive Optic Maximum Light Energy Transmission The Reliable performance of Reviol Active-Diffractive IOL has been proven in

• ver forty countries with thousand implantations

Enhanced Depth of Focus Concept

Active Diffractive Reviol Tri-ED

Maximum Light Transmission Effective light transmission reach up 89.1%, It means light loss is 10.9% which is minimum value in the trifocal IOL market . Light Loss in Competitors

15.0% in Physiol 14.3% in Zeiss

Semi-Apodized Trifocal Optic

Benefits of Semi-Apodization Optimal Light Distribution

Enhanced Depth of Focus Concept

Semi-Apodization

Optimal Light Distribution Light is distributed through the focal area with excellent balance. Reviol Tri-ED light splitting structure of transmitted light in 6 mm aperture:

44% for Far 28% for Intermediate 28% for Near

• II. Optimum Light Distribution

Comparative Test Results of transmitted light in 3mm Aperture

Models Far Intermediate Near Reviol Tri-ED 46% 25% 29% AT LISA tri 50% 20% 30% Finevision 50% 17% 33%

True Trifocality

Enhanced Depth of Focus Concept

True trifocal? Appropriate Disparity between focus

True Trifocality

Appropriate Disparity Reviol Tri-ED is combined with 3.0D Near Addition and 1.5D Intermediate Addition. Focal overlapping between light centralization in different points plays a negative role in image quality and photopic phenomena (glare/halo) problems*.

Opthalmic Optic General Information III

*Petermeier K., Messias A., Gekeler F., Szurman P. Effect of +3.00 diopter and +4.00 diopter additions in multifocal intraocular lenses on defocus profiles, patient satisfaction and contrast sensitivity. J. Cataract Refract Surg 2011; 37 (4): 720-6.

True Trifocality

and comfortable distance for the patients… Trifocal IOL

Near Addition Intermediate Addition

Reviol Tri-ED

3.00D - 42 cm 1.50D – 80 cm *

AT LISA tri

3.33D - 40 cm 1.66D –76 cm **

Finevision

3.50D - 36 cm 1.75D – 60 cm ***

Near/Intermediate Additions

* Data on file: First Clinical Findings. ** Comparison of a bifocal and a trifocal intraocular lens. E.Law R. Aggarwal H. Kasaby. Free Paper Session ESRCS 2014 London. *** Diffractive multifocal IOLs: a comparative study of Finevision versus ReSTOR 2.5 and 3.0D. K.Gundersen. Free Paper Session ESRCS 2014 London.

Active Diffractive Optic True Trifocality Semi Apodization

Enhanced Depth of Focus Concept

Enhanced Depth of Focus

See the MTF Results!

Enhanced Depth of Focus Concept

MTF is direct quantitative measurement of an optical system. Criteria has been determined by ISO Standard 11979. Typical Monofocal and Bifocal IOL graphs

Enhanced Depth of Focus Concept

Reviol Tri-ED shows superior MTF values even between far-intermediate and intermediate-near area ensures seamless continuous vision at all distance!

Enhanced Depth of Focus Concept

Comparative MTF Results at 50 lp/mm

Models Far Focus Intermediate Focus Near Focus Reviol Tri-ED 43 22 23 AT LISA tri 34 16 21 Finevision 36 17 20

The more resolution is The more patient is…

Unique Design of Reviol Tri-ED

Superior MTF Results Optimum Light Distribution Good Focal Disparity Maximum Light Transfer Seamless Continuous Vision

Seamless Continuous Vision

Reviol Tri-ED All-in-One Platform! Aspheric Optic All Square Enhanced Edge Efficient Photo Protection Chromatic Aberration Control

Technical Features

First Clinical Findings Clinical studies have been running on three different center. 26 patient had Tri-ED implantation so far Happy patients… Happy surgeons!

Post-op Refraction Spherical Equivalent

• 0.18 ± 0.38

First Clinical Findings

Visual Acuity UDVA (Uncorrected Far)

• 0.03 ± 0.07

UIVA (Uncorrected Intermediate) 0.16 ± 0.09 UVNA (Uncorrected Near) 0.06 ± 0.12 *LogMar Acuity First Clinical Findings

Defocus Curve Distinctive intermediate acuity First Clinical Findings

Good Contrast Sensitivity Results Contrast sensitivities are measured by CSV1000E, Vector Vision by glare and without glare. All eyes showed good results at 3, 6, 12 and 18 spatial frequency (cpd) Patient Satisfaction No moderate/severe glare halo problem reported. Over 95% of patients dont need glasses. First Clinical Findings

Competition AT LISA Tri

Trifocal & Bifocal Combination 1,66D intermediate - 3,66 near addition Pupil-independent Hydrophilic acrylic with hydrophobic surface Plate haptic 6.0 mm, 11.0 mm

Competition

Competition Finevision

Convolution steps 1,75D intermediate - 3,50 near addition Pupil-independent Hydrophilic acrylic (Micro F 25%, Pod F 26&) Micro F 6,15mm – 10.75 mm Pod F 6.0 mm – 11.40 mm

Competition

Competition Specification Reviol Tri-ED AT LISA tri Finevision Optic Semi-apodized Trifocal (EDOF) Pupil- Independent Trifocal + Bifocal Combination Pupil- Independent Trifocal Convolution Pupil-Independent Material Hydrophilic acrylic (25%) with hydrophobic surface Hydrophilic acrylic (25%) with hydrophobic surface Hydrophilic acrylic (Micro F 25%, Pod F 26&) Intermediate & Near Addition 1.5D – 3.0D 1,66D – 3,66D 1.75D – 3.50D Diopter Range 0.0D – 32.0D with 0.5D increments 0.0D – 32.0D with 0.5D increments 10.0D – 35.0D with 0.5D increments

Competition Spesification Reviol Tri-ED AT LISA tri Finevision Square Edge Yes Yes Yes Angulation 0⁰ 0⁰ 5⁰ Haptic Plate Haptic 6.0mm – 11.0 mm (MICS) Plate Haptic 6.0mm – 11.0 mm (MICS) Micro F 6,15mm – 10.75 mm Pod F 6.0 mm – 11.40 mm Light Filtration UV/Violet UV UV/Blue Light

Take-Home Message

• EDOF vision - Excellent MTF Results
• Highest value on light transmission
• Balanced intermediate1,5D / near addition3.0D: 42 cm – 80 cm
• Semi-Apodization – Light Distribution 44% F

, 28% I and 28% N
