Digital Progressive Lenses

The ideal solution for Presbyopia

The ideal solution for Presbyopia

Maximum distortion Width of progressive zone Corridor Length Width of far zone Width of reading zone

Progressive Lenses Parameters

Far Vision

30° Eye path

The natural eye path changes according to prescription. Difference between additions can be between 3.5° and 8°

Conventional lens New generation lens

Actual eye path Optimized eye path

Eye path

Low Add High Add

Eye path of different Add

Width of progressive zone Width of reading zone Distortion free far zone Balance & minimize the distortion Lens design Technology Parameters for designing the best Progressive Lenses

R1 Far Zone Rn Progressive Zone R2 Near Zone Controlling the distortion is the key to the ultimate progressive lens Topographic Map

Minimizing distortions

Vista Progressive Lenses has precise hi-tech Eye Element Technology that ensures accurate analysis necessary for Sophisticated lenses. By observing exact vision requirements, designers can finally create tailor-made lenses.

Eye Element Technology

The technology that enables us to design progressive lenses through an exact simulation

• f the natural human eye view.

Eye Element Technology

The optical power is created by 3 parameters: thickness, index and curvatures

The surface of the lens is scanned by a 3D measuring system, mapping the curvatures of the lens.

Eye Element Technology

27mm Light does not always travel straight into the eye

Eye Element Technology

27 mm

Eye Element technology allows the progressive wearer to view clearly without moving their head…. …… regardless of the path, light travels

Eye Element Technology

The surface data & a highly advanced mathematical algorithm are the basis to Eye-Element Technology which takes into account numerous parameters: 1. Lens index refraction 2. Lens prescription 3. Lens center thickness 4. Distance from the eye to the back vertex of the lens 5. Distance from the lens to the object 6. Object's angular position in the eye's field of vision 7. Pantoscopic tilt of the frame 8. Pupil distance 9. Thickness reduction prism, and more. By taking all of these parameters into consideration, Eye-Element Technology enabled the creation of the perfect progressive lens.

Eye Element Technology

Clear Distance, Intermediate & Near Vision Zones

Eye Element Technology

Extensive research lead to major discovery …

A perfect harmony for the eyes. Eye Element technology that allows clear vision for short, mid and long distance with the same lens.

Eye Element Technology

Because Vista Progressive is based on the advanced Eye-Element Technology, vision clarity is enhanced even more, bringing it to an optimal level in every vision zone.

A technological breakthrough, Eye-Element Technology ensures the softest lens design for every vision zone, by pushing the distortions down and to the sides. Soft Design

Aspheric in all its zones, Vista Progressive is the thinnest possible lens. Vista Progressive is designed for a variety of frame sizes - small and large alike.

Asphericity and Easy Adaptation

Eye Element technology offers the softest feel among any progressive lens. It adapts to you rather than making you adapt to it. Ultra Soft Design

Eye Element technology allows the thinner lens

• ptions with utmost clarity

Superior Cosmetics

Visual Simulator

Surround Vision

Vista Progressive ensures improved peripheral vision because it is designed through an exact simulation of the human eye.

Distortions

Binocular Vision

Vista Progressive guarantees perfect Binocular Vision, enabling patients to clearly perceive an object's depth and dimension.

Prism Balance

Enables the user to perceive the depth and dimension of any object with clarity

Binocular Vision

Vista Progressive is based

• n

the advanced Eye Element Technology vision clarity is enhanced even more, bringing it to an optimal level in every vision zone.

Super Clarity

Easier Adaptation & Comfort

Soft Design

Width of Far Vision (+4mm): 0.5 [D]- 16.2 mm 1.0 [D]- Unlimited Max Cylinder [D]- Nasal: 1.5[D] Max Cylinder [D]- Temporal: 1.5 [D] Width of Corridor (-6mm): 1.0[D]- 9 mm Length of corridor: 14.2 mm Minimum fitting: 19 mm Width of near Vision (-18 mm): 1.0[D]- 21.63 mm

Soft Design

Vista Progressive offers a wider viewing area especially in the near

Wider Viewing Area at all Levels

+ + + +

30 mm 75 mm Large Small

Designed for any size

Vista Progressive offers best value for money without compromising on design. Making it more affordable to the wearer.

Best Value for Money

During wearer trials conducted with over 150 opticians in various countries, 90% of the wearers adapted to Vista Progressive within a matter of few hours.

Wearer Trials conducted in different countries

Surround Vision: Vista Progressive ensures improved peripherial

vision because it is designed through an exact simulation Of the eye

Summary Prism Balance: Vista Progressive guarantees perfect binocular vision

enabling patients to clearly perceive an object’s depth and dimension.

Super Clarity: Vista Progressive is based on the advanced Eye

Element Technology, vision clarity is enhanced even more, bringing it to an optimal level in every vision zone.

Soft Design: A technological breakthrough, Vista’s Eye Element

Technology ensures the softest lens design for every vision zone.

Rodenstock Life 2 Hoya GP Wide Zeiss Gradal Top Sola Max

Analyzed by Rotlex Class I on a random lens

Comparison

Hoya GP Wide Rodenstock Life 2 Zeiss Gradal Top Sola Max

Comparison

Zeiss Gradal Top Rodenstock Life 2 Hoya GP Wide Sola Max

Comparison

Sola Max Rodenstock Life 2 Hoya GP Wide Zeiss Gradal Top

Comparison

PGX

Mineral Plastic

Index 1.60 Index 1.70 Index 1.60 Index 1.67

White White Clear & Transitions Clear & Transitions

Availability

Vista Progressive

Clear & Transitions PBX PGX

Index 1.52

White PBX

Index 1.50

Fitting Process

With regular corridor progressive lenses

Limited choice in frames

Also Available in short

Unlimited Variety with Vista Short

Lens that does not compromise on style

Eye Point simulation

Optimum design for small frame

The world’s smallest progressive lens

Vista Short

The world’s smallest progressive lens with the softest design

Vista Short has taken the world by storm due to its additional unique features

Unique “Eye Element Technology” has created the softest, short corridor progressive lens, especially designed for small

• frames. Soft design ensures easy

adaptation and greater comfort.

Vista Short

Aspheric in every vision zone resulting in the thinnest possible lens. Perfectly formulated short corridor facilitates easy transition between the far vision and the reading zones.

Vista Short

Improved peripheral vision Perfect binocular vision provides the advantage of perceiving any object’s depth and dimension with utmost clarity.

Vista Short

Vista Short 5/200

• 30
• 25
• 20
• 15
• 10
• 5

5 10 15 20 25 30

• 30
• 25
• 20
• 15
• 10
• 5

5 10 15 20 25 30

Width of Far Vision at Fitting Point: 0.5 [D] – 16.2 mm 1.0 [D] – Entire lens Width Width of Corridor: 1.0 [D] – 6.25 mm Max Cylinder [D] – Nasal 1.5 [D] Width of near Vision 15 Mm below Fitting Point: 1.0 [D] – 15 mm Length of corridor: 13 mm Minimum Fitting Height: 16 mm Max Cylinder [D]: Temporal: 15 mm

Vista Short AO Compact

Comparison

Mineral Plastic

Index 1.50 Index 1.60 Index 1.67

White PGX Clear & Transitions Clear & Transitions

Vista Short Progressive

Clear & Transitions

Availability Index 1.50

Fitting Guide
