Neutron TOF in the MPD ECAL

Rahul Sahay Chris Marshall Lawrence Berkeley National Laboratory 18 September, 2019

slide-2
SLIDE 2

Chris Marshall 2

Motivation

  • Neutron kinetic energy is generally not visible in LAr

TPCs

  • Small (~20%) fraction of neutron KE shows up in detector

via neutron re-interactions

  • Neutrons in the 10s to 100s MeV are a significant

source of neutrino energy misreconstruction

  • Neutron production in ν-Ar scattering is highly

uncertain → Measuring neutron energy spectrum in ND could constrain our missing energy corrections at FD

slide-3
SLIDE 3

Chris Marshall 3

Reminder: basic premise

  • Assuming neutron comes from

primary vertex, start and end positions are measured

  • Vertex time comes from charged

particle hits in ECAL, correcting for TOF back to vertex

  • Use neutron TOF to determine

its momentum

  • This works in any detector with

fast timing and 3D position reconstruction, i.e. MPD ECAL

  • r 3DST

ν μ n p Measure interaction vertex time from muon hits in ECAL

x0,t0 x1,t1

Measure neutron “endpoint” from scatter, i.e. n+12C→p+X

slide-4
SLIDE 4

Chris Marshall 4

Advantages of MPD ECAL vs. 3DST

  • Feasibility of neutron TOF

measurement has been demonstrated in 3DST

  • Two main advantages of

pursuing neutron TOF using MPD ECAL

  • Neutrons produced in ν-Ar

interactions → directly applicable to ν-Ar modeling of FD

  • Low density of gas TPC → lever

arm of several meters, compared to O(1m) scattering length in 3DST → improved energy resolution

ν μ n p ν n μ p

slide-5
SLIDE 5

Chris Marshall 5

Disadvantages of ECAL vs. 3DST

  • Often miss neutron scatters that
  • ccur in passive absorber of

ECAL → poor energy reco

  • Long lever arm → long TOF →

more beam pile-up problems

ν μ n p ν n μ p

2mm Cu 5mm CH

n

slide-6
SLIDE 6

Chris Marshall 6

Simulation details

  • Detector hall consists of rock, LAr TPC, Gas TPC + ~300t ECAL + 100t

cylindrical magnet (geometry created by Eldwain with NDGGD)

  • Guess on the rock location: 2m gap from rock to front of LAr TPC, rock right

below and ~4m above detectors, no side rock as hall will be wide in the x dimension

Rock events only Everything but rock

slide-7
SLIDE 7

Chris Marshall 7

Signal and background

  • Signal is νμ CC interaction in gas TPC, with a fiducial

volume 50cm from the edge of the active region

  • Overlay background events ±1μs from signal, and

reconstruct entire spill, with hit timing resolution in the ECAL of ±0.7 ns

  • 770 rock and 120 detector hall ν interactions per spill at

1.2 MW FHC, simulated separately and overlaid

slide-8
SLIDE 8

Chris Marshall 8

Almost-real reconstruction

  • Hits in active ECAL elements are formed, including

scintillator quenching effects

  • Ionization hits from charged particles originating in gas

TPC or entering the ECAL from the outside are excluded, but any hit with a neutral ancestor (neutron

  • r photon) is considered
  • Selection cut for neutrons uses both topological and

energy information

  • Basically neutrons are single-cell, high-energy hits, while

photons are typically multi-cell, more uniform energy

slide-9
SLIDE 9

Chris Marshall 9

Energy resolution

  • Very good energy resolution when reconstructed neutron

scatter is the first one

  • But due to the high passive fraction, ~50% of the events are

rescatters

slide-10
SLIDE 10

Chris Marshall 10

Energy resolution

  • At higher energies, resolution gets somewhat worse, up to ~40% for

first scatter

  • Fraction of rescatter events plateaus at ~60% at high energy
  • Could be improved by increasing CH/passive ratio
slide-11
SLIDE 11

Chris Marshall 11

Rock background: how much rock?

  • Simulated 2m thick rock
  • n top and bottom of

hall, and 4m upstream, no downstream rock

  • Plot shows all vertex

positions – note the beam divergence is non- negligible over this region

  • Where are the vertices

that produce neutron scatters in the ECAL?

slide-12
SLIDE 12

Chris Marshall 12

How much rock is enough? ν vertices producing ECAL activity

  • Most of the vertices

that produce ECAL neutrons are very near the detector hall

  • Expected, as ~1m

rock will attenuate neutrons

slide-13
SLIDE 13

Chris Marshall 13

How thick rock do we need to worry about?

  • Distance between neutrino interaction vertex that produces neutron hits in ECAL

and edge of hall

  • 2m on sides, and 4m upstream, is sufficient, maybe we underestimate by few %
  • Integrating, we expect ~10 neutron hits in the ECAL per spill, i.e. 1 per μs – this is

going to be sub-dominant

Upstream rock Top/bottom rock

slide-14
SLIDE 14

Chris Marshall 14

Hall-originating event vertices

  • First, position of all

interactions in detector hall

slide-15
SLIDE 15

Chris Marshall 15

Hall-originating event vertices

  • Position of neutrino

interaction for events that produce neutron candidates in ECAL

  • Predominant

background source is ECAL itself

  • Second is the magnet,

especially upstream

  • Most downstream parts
  • f LAr also contribute
slide-16
SLIDE 16

Chris Marshall 16

Intrinsic background

μ π

  • Backgrounds can
  • riginate in gas TPC

from neutrons produced by charged particle interactions

  • Often, the scatter
  • ccurs in the ECAL,

and the neutron is spatially near the TPC track vector, and can be rejected

slide-17
SLIDE 17

Chris Marshall 17

Intrinsic background

μ π

  • But when interaction
  • ccurs in the TPC, it

is very hard to distinguish from primary neutrons

  • This is the most

challenging background

slide-18
SLIDE 18

Chris Marshall 18

External (pile-up) background

μ π

  • Pile-up can produce

neutrons that accidentally coincide in time with a GAr TPC event

  • It is possible to apply

a veto when ECAL activity is observed just before a gas TPC interaction, which may produce neutrons

μ

slide-19
SLIDE 19

Chris Marshall 19

External (pile-up) background

μ π

  • But neutrons which

traverse the GAr are hard to veto – the TOF is 10s to 100s ns, and the rate is too high to veto these events

μ

slide-20
SLIDE 20

Chris Marshall 20

Out of the box

  • Pile-up backgrounds

are flat in Δt, so they tend to very low reco kinetic energy

  • Basically we can't

measure 20 MeV neutrons at full intensity because their time of flight is ~50 ns

slide-21
SLIDE 21

Chris Marshall 21

Zoom in

  • At high energy,

dominant background is from non-primary neutrons produced in the signal neutrino interaction

  • At low energy,

dominant background is accidental activity

slide-22
SLIDE 22

Chris Marshall 22

Charged particle trajectory cut

μ π

  • Project charged

tracks into the ECAL

  • Look at the distance

between a neutron candidate and the nearest charged track trajectory

  • Backgrounds from

charged particle interactions in the ECAL will be close

slide-23
SLIDE 23

Chris Marshall 23

Cut #1: charged particle distance

  • Plot shows all

candidates >5 MeV neutron energy

  • Cut at 80 cm
  • Rejects neutron

candidates from the signal interaction

  • Does not remove

accidentals

slide-24
SLIDE 24

Chris Marshall 24

ECAL activity veto

μ π

  • For each neutron

candidate, determine the time and distance to other ECAL activity

  • Exclude (-5, +10)ns

window around GAr vertex, where ECAL activity will be due to the signal interaction

μ

ECAL veto Δx, Δt

slide-25
SLIDE 25

Chris Marshall 25

Distance and Δt to ECAL veto

  • Signal is flat in Δt to random ECAL activity, peak around 6m is because most

pile-up is upstream-entering, and most signal neutrons are downstream, and thus ~6m apart

  • Background is generally close in time and space to other ECAL activity and

can be vetoed with almost no signal loss

Signal Pile-up

slide-26
SLIDE 26

Chris Marshall 26

Projected onto distance axis

  • Pile-up neutrons that

don't go all the way through gas TPC are easily rejected by cut at 2m

  • Pile-up for neutrons

that scatter far from where they are produced is not rejected – the veto is too long and would reject too much signal

slide-27
SLIDE 27

Chris Marshall 27

Isolation from other ECAL clusters

  • Largely redundant

with cut on entering charged tracks

  • But can remove

some additional background where track does not come from gas TPC

slide-28
SLIDE 28

Chris Marshall 28

Reco KE distribution

  • No cuts
slide-29
SLIDE 29

Chris Marshall 29

Reco KE distribution

  • Charged TPC track

cut

slide-30
SLIDE 30

Chris Marshall 30

Reco KE distribution

  • Charged TPC track

cut

  • ECAL activity veto
slide-31
SLIDE 31

Chris Marshall 31

Reco KE distribution

  • Charged TPC track

cut

  • ECAL activity veto
  • Isolation from other

clusters

slide-32
SLIDE 32

Chris Marshall 32

Reco KE distribution

  • Charged TPC track

cut

  • ECAL activity veto
  • Isolation from other

clusters

  • Forward neutrons
  • nly
slide-33
SLIDE 33

Chris Marshall 33

Selection efficiency

  • Efficiency for all

neutrons is ~40-50% with loose selection cuts

slide-34
SLIDE 34

Chris Marshall 34

Sample purity

  • But purity for all

neutrons is only ~40%

  • ~20% due to pile-up

background, the rest due to neutrons (or photons) from the gas TPC event

  • Better photon

rejection in progress, should help purity at high reconstructed KE

slide-35
SLIDE 35

Chris Marshall 35

Sample purity (forward)

  • Slightly better at

high energy when you only consider forward neutrons

slide-36
SLIDE 36

Chris Marshall 36

Conclusions

  • Neutron reconstruction in MPD is challenging
  • Can achieve ~50% efficiency with ~50% purity for

forward neutrons

  • Energy resolution is poor and biased above ~100 MeV

due to missing the initial scatter, could be improved by

  • ptimizing active fraction (more CH)
  • Non-primary neutrons are a major background
  • Backgrounds from rock are minimal – magnet, ECAL,

and LAr TPC are major sources

slide-37
SLIDE 37

Chris Marshall 37

Next steps

  • Improve n/γ cut by voxylizing hits in each layer and

looking at transverse quantities

  • Look at RHC
  • Less pile-up background
  • Less non-primary background on average due to lower

energy hadrons

  • More energetic primary neutrons
slide-38
SLIDE 38

Chris Marshall 38

Backup

slide-39
SLIDE 39

Chris Marshall 39

Distance to ECAL activity (>50 MeV reco only)

  • Most pile-up is

reconstructed at very low energy

slide-40
SLIDE 40

Chris Marshall 40

Kink track angle

  • Maximum kink angle
  • Some gas-induced

non-primary neutrons are correlated with interactions in the TPC which produce large kinks

slide-41
SLIDE 41

Chris Marshall 41

Purity for leading neutron only

  • All angles
  • Slightly higher purity
slide-42
SLIDE 42

Chris Marshall 42

Eff for leading neutron only

  • All angles
  • Similar efficiency to

considering all neutrons

slide-43
SLIDE 43

Chris Marshall 43

Backward neutrons

  • More pile-up, less

signal

slide-44
SLIDE 44

Chris Marshall 44

Tighter pile-up cut

  • Nominal cut only excludes neutrons within 2m of ECAL

activity

  • But can also exclude entire ECAL for fast-coincident activity

Signal Pile-up

slide-45
SLIDE 45

Chris Marshall 45

Tighter pile-up cut

  • Reduced efficiency, but only slightly improved purity
  • Not a good cut – vetoing on activity far away from the

neutron candidate removes too much signal
