SLIDE 1
Neural Machine Translation
Gongbo Tang
8 October 2018
Outline
1
Neural Machine Translation
2
Advances and Challenges
Gongbo Tang Neural Machine Translation 2/52
Neural Machine Translation Gongbo Tang 8 October 2018 Outline - - PowerPoint PPT Presentation
Neural Machine Translation Gongbo Tang 8 October 2018 Outline - - PowerPoint PPT Presentation
Neural Machine Translation Gongbo Tang 8 October 2018 Outline Neural Machine Translation 1 Advances and Challenges 2 Gongbo Tang Neural Machine Translation 2/52 Neural Machine Translation Figure Recurrent neural network based NMT
SLIDE 2
SLIDE 3
Neural Machine Translation
Figure – Recurrent neural network based NMT model
From Thang Luong’s Thesis on Neural Machine Translation Gongbo Tang Neural Machine Translation 3/52
SLIDE 4
Neural Machine Translation
Figure – NMT model with attention mechanism
Example from Rico Sennrich’s EACL 2017 NMT talk Gongbo Tang Neural Machine Translation 4/52
SLIDE 5
Modelling Translation
Suppose that we have:
a source sentence S of length m (x1, . . . , xm) a target sentence T of length n (y1, . . . , yn)
We can express translation as a probabilistic model
T ∗ = arg max
T
p(T|S)
Expanding using the chain rule gives
p(T|S) = p(y1, . . . , yn|x1, . . . , xm) =
n
- i=1
p(yi|y1, . . . , yi−1, x1, . . . , xm)
Gongbo Tang Neural Machine Translation 5/52
SLIDE 6
Modelling Translation
Target-side language model:
p(T) =
n
- i=1
p(yi|y1, . . . , yi−1)
Translation model:
p(T|S) =
n
- i=1
p(yi|y1, . . . , yi−1, x1, . . . , xm)
We could just treat sentence pair as one long sequence, but:
We do not care about p(S) We may want different vocabulary, network architecture for source text
Gongbo Tang Neural Machine Translation 6/52
SLIDE 7
Attentional Encoder-Decoder : Maths
simplifications of model by [Bahdanau et al., 2015] (for illustration)
plain RNN instead of GRU simpler output layer we do not show bias terms decoder follows Look, Update, Generate strategy [Sennrich et al., 2017] Details in https://github.com/amunmt/amunmt/blob/master/contrib/notebooks/dl4mt.ipynb
notation W, U, E, C, V are weight matrices (of different dimensionality)
E one-hot to embedding (e.g. 50000 · 512) W embedding to hidden (e.g. 512 · 1024) U hidden to hidden (e.g. 1024 · 1024) C context (2x hidden) to hidden (e.g. 2048 · 1024) Vo hidden to one-hot (e.g. 1024 · 50000) separate weight matrices for encoder and decoder (e.g. Ex and Ey) input X of length Tx; output Y of length Ty
Example from Rico Sennrich’s EACL 2017 NMT talk Gongbo Tang Neural Machine Translation 7/52
SLIDE 8
Encoder
Figure – NMT model with attention mechanism
Example from Rico Sennrich’s EACL 2017 NMT talk Gongbo Tang Neural Machine Translation 8/52
SLIDE 9
Encoder
Encoder with bidirectional Recurent Neural Networks
Input Word Embeddings Left-to-Right Recurrent NN Right-to-Left Recurrent NN
Gongbo Tang Neural Machine Translation 9/52
SLIDE 10
Encoder
Encoder with bidirectional Recurent Neural Networks
Input Word Embeddings Left-to-Right Recurrent NN Right-to-Left Recurrent NN
− → h j =
- 0,
, if j = 0 tanh(− → W xExxj + − → U xhj−1) , if j > 0 ← − h j =
- 0,
, if j = Tx + 1 tanh(← − W xExxj + ← − U xhj+1) , if j ≤ Tx hj = (− → h j, ← − h j)
Gongbo Tang Neural Machine Translation 9/52
SLIDE 11
Decoder
Figure – NMT model with attention mechanism
Example from Rico Sennrich’s EACL 2017 NMT talk Gongbo Tang Neural Machine Translation 10/52
SLIDE 12
Decoder
Context State
ti-1 ti
Word Prediction
yi-1 Eyi-1
Selected Word
yi Eyi
Embedding
si si-1 ci ci-1
Gongbo Tang Neural Machine Translation 11/52
SLIDE 13
Decoder
Context State
ti-1 ti
Word Prediction
yi-1 Eyi-1
Selected Word
yi Eyi
Embedding
si si-1 ci ci-1
si =
- tanh(Ws
← − h i),
, if i = 0 tanh(WyEyyi−1 + Uysi−1 + Cci) , if i > 0
ti = tanh(Uosi + WoEyyi−1 + Coci) yi = softmax(Voti)
Gongbo Tang Neural Machine Translation 11/52
SLIDE 14
Decoder
Training yi is known, the training objective is to assign higher possibility to the correct output word. One of the cost functions is the negative log of the probability given to the correct word transaltion. cost = −logti[yi]
Gongbo Tang Neural Machine Translation 12/52
SLIDE 15
Decoder
Training yi is known, the training objective is to assign higher possibility to the correct output word. One of the cost functions is the negative log of the probability given to the correct word transaltion. cost = −logti[yi] Inference yi is unknown, we compute the probability distribution over all the vocabulary. Greedy search : select the word with the highest probability. Beam search : keep the top k most likely word choices.
Gongbo Tang Neural Machine Translation 12/52
SLIDE 16
Decoding
! 0.928 0.175 <eos> 0.999 0.175 hello 0.946 0.056 world 0.957 0.100
Greedy search
Gongbo Tang Neural Machine Translation 13/52
SLIDE 17
Decoding
! 0.928 0.175 <eos> 0.999 0.175 hello 0.946 0.056 world 0.957 0.100
Greedy search
hello 0.946 0.056 world 0.957 0.100 World 0.010 4.632 . 0.030 3.609 ! 0.928 0.175 ... 0.014 4.384 <eos> 0.999 3.609 world 0.684 5.299 HI 0.007 4.920 <eos> 0.994 4.390 Hey 0.006 5.107 <eos> 0.999 0.175
K = 3
Beam search
Gongbo Tang Neural Machine Translation 13/52
SLIDE 18
Attention
Figure – NMT model with attention mechanism
Example from Rico Sennrich’s EACL 2017 NMT talk Gongbo Tang Neural Machine Translation 14/52
SLIDE 19
Attention
αi h Encoder hidden states Attention Decoder Networks Softmax Predictions si−1 ci Gongbo Tang Neural Machine Translation 15/52
SLIDE 20
Attention
αi h Encoder hidden states Attention Decoder Networks Softmax Predictions si−1 ci
eij = v⊤
a tanh(Wasi−1 + Uahj)
αij = softmax(eij) ci =
Tx
- j=1
αijhj
Gongbo Tang Neural Machine Translation 15/52
SLIDE 21
Overview of NMT
Pros More fluent translation Less lexical errors Less word order errors Less morphology errors Cons Expensive computation Over-translation and under-translation (Adequacy) Bad at translating long sentences Need more data Black box
Gongbo Tang Neural Machine Translation 16/52
SLIDE 22
Overview of NMT
Pros More fluent translation Less lexical errors Less word order errors Less morphology errors Cons Expensive computation Over-translation and under-translation (Adequacy) Bad at translating long sentences Need more data Black box
Gongbo Tang Neural Machine Translation 16/52
SLIDE 23
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 24
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 25
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 26
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 27
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 28
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 29
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 30
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 31
Advances and Challenges
Attention mechanism Model Architectures Monolingual data Models at different levels Linguistic features Modelling coverage Domain adaption Transfer learning what is NMT not good at ?
Gongbo Tang Neural Machine Translation 17/52
SLIDE 32
Attention Mechanism and Alignment
From What does Attention in Neural Machine Translation Pay Attention to ? Gongbo Tang Neural Machine Translation 18/52
SLIDE 33
Attention Mechanism and Alignment
POS tag attention to alignment points % attention to
- ther words %
NUM 73 27 NOUN 68 32 ADJ 66 34 PUNC 55 45 ADV 50 50 CONJ 50 50 VERB 49 51 ADP 47 53 DET 45 55 PRON 45 55 PRT 36 64 Overall 54 46
Table 8: Distribution of attention probability mass (in %) over alignment points and the rest of the words for each POS tag.
From What does Attention in Neural Machine Translation Pay Attention to ? Gongbo Tang Neural Machine Translation 19/52
SLIDE 34
Attention Mechanism and Alignment
relations between Obama and Netanyahu have been strained for years . die Beziehungen zwischen Obama und Netanjahu sind seit Jahren angespannt . 56 89 72 16 26 96 79 98 42 11 11 14 38 22 84 23 54 10 98 49 das Verhältnis zwischen Obama und Netanyahu ist seit Jahren gespannt . the relationship between Obama and Netanyahu has been stretched for years . 11 47 81 72 87 93 95 38 21 17 16 14 38 19 33 90 32 26 54 77 12 17
(a) Desired Alignment (b) Mismatched Alignment
Gongbo Tang Neural Machine Translation 20/52
SLIDE 35
Attention and Unknown Words
- 1. Find the corresponding
source word
- 2. Lookup dictionary for
translation
- Example from Zhaopeng Tu’s Tutorial,
method from On Using Very Large Target Vocabulary for Neural Machine Translation Gongbo Tang Neural Machine Translation 21/52
SLIDE 36
Attention Mechanisms
αt h Encoder hidden states Attention Decoder Networks Softmax Predictions st−1 ct
(a) Vanilla attention mechanism
αt h Encoder hidden states Multi-head Attention Decoder Block Decoder Block Softmax Predictions st−1 ct st−1 ct
n-layer blocks
(b) Advanced attention mechanism Gongbo Tang Neural Machine Translation 22/52
SLIDE 37
Attention Mechanisms
αt h Encoder hidden states Attention Decoder Networks Softmax Predictions st−1 ct
(a) Vanilla attention mechanism
αt h Encoder hidden states Multi-head Attention Decoder Block Decoder Block Softmax Predictions st−1 ct st−1 ct
n-layer blocks
(b) Advanced attention mechanism Multi-Head Attention Gongbo Tang Neural Machine Translation 22/52
SLIDE 38
Transformer Attention and Vanilla Attention
w e r g a r a n t i e r t d e n L e u t e n e i n e S t e l l e ? who guarantees people a job ? </s> w e r g a r a n t i e r t d e n L e u t e n e i n e S t e l l e ? who guarantees people a job ? </s> w e r g a r a n t i e r t d e n L e u t e n e i n e S t e l l e ? who guarantees people a job ? </s>
(a) Layer 1 (b) Layer 2 (c) Layer 3
wer garantiert den Leuten eine Stelle ? who guarantees people a job ? </s> wer garantiert den Leuten eine Stelle ? who guarantees people a job ? </s> wer garantiert den Leuten eine Stelle ? who guarantees people a job ? </s>
(d) Layer 4 (e) Layer 5 (f) Layer 6
wer garantiert den Leuten eine Stelle ? who guarantees people a job ? </s> wer garantiert den Leuten eine Stelle ? who guarantees people a job ? </s> wer garantiert den Leuten eine Stelle ? who guarantees people a job ? </s>
(g) Layer 7 (h) Layer 8 (i) RNN
Gongbo Tang Neural Machine Translation 23/52
SLIDE 39
Transformer Attention and Vanilla Attention
0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 L1 L2 L3 L4 L5 L6 L7 L8 Average attention weight Ambi. Nouns Tokens
Figure – Attention weights in different Transformer attention Layers
Gongbo Tang Neural Machine Translation 24/52
SLIDE 40
Fine-grained Attention Mechanism
(a) (b) Figure 1: (a) The conventional attention mechanism and (b) The proposed fine-grained attention
- mechanism. Note that
t αt′,t = 1 in the conventional method, and t αd t′,t = 1 for all dimension
d in the proposed method.
Fine-Grained Attention Mechanism for Neural Machine Translation Gongbo Tang Neural Machine Translation 25/52
SLIDE 41
Model Architectures
Neural networks Vanilla RNN LSTM/GRU CNN Self-attention
x1 x2 x3 x4 x5 (a) RNN x1 x2 x3 x4 x5
padding padding
(b) CNN x1 x2 x3 x4 x5 (c) Self-attention
Gongbo Tang Neural Machine Translation 26/52
SLIDE 42
Model Architectures
Encoder-decoders With residual feed-forward layers Cascaded encoder Multi-column encoder
Gongbo Tang Neural Machine Translation 27/52
SLIDE 43
Model Architectures
Encoder-decoders With residual feed-forward layers Cascaded encoder Multi-column encoder
(a) Cascaded Encoder (b) Multi-Column Encoder Gongbo Tang Neural Machine Translation 27/52
SLIDE 44
Character-level Models
MT is an open-vocabulary problem
compounding and other productive morphological processes
they charge a carry-on bag fee. sie erheben eine Hand|gepäck|gebühr.
names
Obama(English; German) Обама (Russian) オバマ (o-ba-ma) (Japanese)
technical terms, numbers, etc.
But, limited vocabulary causes out-of-vocabulary words.
Gongbo Tang Neural Machine Translation 28/52
SLIDE 45
Character-level Models
Character-level models small vocabulary do not require segmentation/tokenization can model different, rare mopholigical variants of a word
Gongbo Tang Neural Machine Translation 29/52
SLIDE 46
Character-level Models
Character-level models small vocabulary do not require segmentation/tokenization can model different, rare mopholigical variants of a word sentence length is longer (harder for training) training time is longer
Gongbo Tang Neural Machine Translation 29/52
SLIDE 47
Character-level Models
* C2W Compositional Model BLSTM W h e r e Word Vector for "Where"
Figure – C2W Compositional model
From Chracter-based Neural Machine Translation Gongbo Tang Neural Machine Translation 30/52
SLIDE 48
Character-level Models
** V2C Generation Model Forward LSTM e s t a e s t a EOW SOW
Figure – V2C generation model
From Chracter-based Neural Machine Translation Gongbo Tang Neural Machine Translation 31/52
SLIDE 49
Hybrid-level Models
from Achieving Open Vocabulary Neural Machine Translation with Hybrid Word-Character Models Gongbo Tang Neural Machine Translation 32/52
SLIDE 50
Subword-level Models
Byte pair encoding algorithm Frequent character n-grams (or whole words) are merged into a single symbol.
Gongbo Tang Neural Machine Translation 33/52
SLIDE 51
Subword-level Models
Byte pair encoding algorithm Frequent character n-grams (or whole words) are merged into a single symbol.
Gongbo Tang Neural Machine Translation 34/52
SLIDE 52
Subword-level Models
Byte pair encoding algorithm Frequent character n-grams (or whole words) are merged into a single symbol.
Gongbo Tang Neural Machine Translation 35/52
SLIDE 53
Subword-level Models
Byte pair encoding algorithm Frequent character n-grams (or whole words) are merged into a single symbol.
Gongbo Tang Neural Machine Translation 36/52
SLIDE 54
Subword-level Models
Byte pair encoding algorithm Frequent character n-grams (or whole words) are merged into a single symbol.
Gongbo Tang Neural Machine Translation 37/52
SLIDE 55
Subword-level Models
Byte pair encoding algorithm Frequent character n-grams (or whole words) are merged into a single symbol.
Gongbo Tang Neural Machine Translation 38/52
SLIDE 56
Subword-level Models
Byte pair encoding algorithm symbols can be applied to unknown words trade-off between text length and vocabulary size
Gongbo Tang Neural Machine Translation 39/52
SLIDE 57
Subword-level Models
Byte pair encoding algorithm symbols can be applied to unknown words trade-off between text length and vocabulary size
Gongbo Tang Neural Machine Translation 40/52
SLIDE 58
Subword-level Models
Byte pair encoding algorithm symbols can be applied to unknown words trade-off between text length and vocabulary size
Gongbo Tang Neural Machine Translation 41/52
SLIDE 59
Subword-level Models
Byte pair encoding algorithm symbols can be applied to unknown words trade-off between text length and vocabulary size
Gongbo Tang Neural Machine Translation 42/52
SLIDE 60
Subword-level Models
Byte pair encoding algorithm symbols can be applied to unknown words trade-off between text length and vocabulary size
Gongbo Tang Neural Machine Translation 43/52
SLIDE 61
Subword-level Models
Byte pair encoding algorithm symbols can be applied to unknown words trade-off between text length and vocabulary size
Gongbo Tang Neural Machine Translation 44/52
SLIDE 62
Monolingual Data
Use target-side monolingual data to enhance models.
Gongbo Tang Neural Machine Translation 45/52
SLIDE 63
Monolingual Data
Use target-side monolingual data to enhance models. Dummy source No source sentence randomly sample from monolingual data each epoch freeze encoder/attention layers for monolingual training instances Synthetic source Produce synthetic source-side sentence via Back-translation. Back-translation : use a trained model on the opposite direction to generate source-side sentence. randomly sample from back-translated data synthetic and real parallel data are not distinguished
Gongbo Tang Neural Machine Translation 45/52
SLIDE 64
Linguistic Features
morphological features part-of-speech tags syntactic dependency labels
Gongbo Tang Neural Machine Translation 46/52
SLIDE 65
Linguistic Features
morphological features part-of-speech tags syntactic dependency labels Feature embeddings are concatenated to the word embeddings.
− → h j = tanh(− → W(
|F|
- k=1
Ekxjk) + − → U − → h j−1)
|
E1(close) = 0.4 0.1 0.2 E2(adj) = 0.1 E1(close) E2(adj) = 0.4 0.1 0.2 0.1
from Linguistic Input Features Improve Neural Machine Translation Gongbo Tang Neural Machine Translation 46/52
SLIDE 66
Modelling Coverage
Problems
- ver-translation : unnessarily translated for multiple times
under-translation : mistakenly untranslated Coverage Model coverage vector to guide the attention networks pay more attention to the untranslated words Context Gate Content words rely more on the source context Function words rely more on the target context control the ratio of source and target context
Gongbo Tang Neural Machine Translation 47/52
SLIDE 67
Modelling Coverage
Problems
- ver-translation : unnessarily translated for multiple times
under-translation : mistakenly untranslated Coverage Model coverage vector to guide the attention networks pay more attention to the untranslated words Context Gate Content words rely more on the source context Function words rely more on the target context control the ratio of source and target context
Gongbo Tang Neural Machine Translation 47/52
SLIDE 68
Modelling Coverage
Problems
- ver-translation : unnessarily translated for multiple times
under-translation : mistakenly untranslated Coverage Model coverage vector to guide the attention networks pay more attention to the untranslated words Context Gate Content words rely more on the source context Function words rely more on the target context control the ratio of source and target context
Gongbo Tang Neural Machine Translation 47/52
SLIDE 69
Domain Adaption with Continued Training
SGD is sensitive to order of training instances best practice:
first train on all available data continue training on in-domain data
Large BLEU improvements reported with minutes of training time
[Sennrich et al., 2016, Luong and Manning, 2015, Crego et al., 2016]
tst2013 tst2014 tst2015
0.0 10.0 20.0 30.0 40.0
26.5 23.5 25.5 30.4 25.9 28.4
BLEU Fine-tuning in IWSLT (en-de) Baseline Finetuned
Generic system (≈ 8M sentences), Fine-tune with TED (≈ 200k )
Example from Rico Sennrich’s EACL 2017 NMT talk Gongbo Tang Neural Machine Translation 48/52
SLIDE 70
Transfer Learning
Use the hidden representations in NMT as pre-trained embeddings
1: Illustration of our approach, after (Belinkov et al., 2017): (i) NMT system trained on
Evaluating Layers of Representation in Neural Machine Translation on Part-of-Speech and Semantic Tagging Tasks Gongbo Tang Neural Machine Translation 49/52
SLIDE 71
Amount of Training Data
106 107 108 10 20 30 21.8 23.4 24.9 26.2 26.9 27.9 28.6 29.2 29.6 30.1 30.4 16.4 18.1 19.6 21.2 22.2 23.5 24.7 26.1 26.9 27.8 28.6 1.6 7.2 11.9 14.7 18.2 22.4 25.7 27.4 29.2 30.3 31.1 Corpus Size (English Words) BLEU Scores with Varying Amounts of Training Data Phrase-Based with Big LM Phrase-Based Neural
Gongbo Tang Neural Machine Translation 50/52
SLIDE 72
Long Sentences
10 20 30 40 50 60 70 80 25 30 35 27.1 28.5 29.6 31 33 34.7 34.1 31.3 27.7 26.9 27.6 28.7 30.3 32.3 33.8 34.7 31.5 33.9 Sentence Length (source, subword count) BLEU BLEU Scores with Varying Sentence Length Neural Phrase-Based
Gongbo Tang Neural Machine Translation 51/52
SLIDE 73
Furthur More ...
using discourse-level information external alignment to guide the attention combining NMT models with SMT models multilingual translation training criteria (beyond Maximum likelihood estimation) dual learning (less training data) unsupervised learning (only monolingual data)
Gongbo Tang Neural Machine Translation 52/52
