Networking approaches in a Container World

Antoni Segura Puimedon Principal Sw. Engineer Flavio Castelli Engineering Manager Neil Jerram Senior Sw. Engineer

Who we are

Disclaimer

• There a many container engines, we’ll focus on Docker
• Multiple networking solutions are available:

○ Introduce the core concepts ○ Many projects → cover only some of them

• Container orchestration engines:

○ Often coupled with networking ○ Focus on Docker Swarm and Kubernetes

• Remember: the container ecosystem moves at a fast pace, things can

suddenly change

The problem

• Containers are lightweight
• Containers are great for microservices
• Microservices: multiple distributed processes communicating
• Lots of containers that need to be connected together

Single host

host networking

Containers have full access to the host interfaces!!!

host container-a eth0 lo ...

host networking

Containers able to:

• See all host interfaces
• Use all host interfaces

Containers can’t (without CAPS)

• Modify their IP addresses
• Modify their IP routes
• Create virtual devices
• Interact with iptables/ebtables

$ docker run --net=host -it --rm alpine /bin/sh / # ip link show 1: lo: <LOOPBACK,UP,LOWER_UP> mtu 65536 qdisc noqueue state UNKNOWN qlen 1 link/loopback 00:00:00:00:00:00 brd 00:00:00:00:00:00 2: wlp4s0: <BROADCAST,MULTICAST,UP,LOWER_UP> mtu 1500 qdisc mq state UP qlen 1000 link/ether e4:b3:18:d2:f6:ea brd ff:ff:ff:ff:ff:ff 3: enp0s31f6: <BROADCAST,MULTICAST> mtu 1500 qdisc noop state DOWN qlen 1000 link/ether c8:5b:76:36:b6:0b brd ff:ff:ff:ff:ff:ff 4: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN link/ether 02:42:7e:62:3d:37 brd ff:ff:ff:ff:ff:ff / #

Bridged networking

• Linux bridge
• Containers connected to the

bridge with veth pairs

• Each container gets its own IP

and kernel networking namespace

• Containers can talk to each
• ther and to the host via IP

host eth0 docker0

172.17.0.0/16

Forwarding container-a veth0 veth1 container-b veth2 veth3

Bridged networking

• Outwards connectivity via IP

forwarding and masquerading

• The bridge and containers use a

private subnet

$ ip address show dev docker0 4: docker0: <NO-CARRIER,BROADCAST,MULTICAST,UP> mtu 1500 qdisc noqueue state DOWN group default link/ether 02:42:7e:62:3d:37 brd ff:ff:ff:ff:ff:ff inet 172.17.0.1/16 scope global docker0 valid_lft forever preferred_lft forever $ sudo iptables -t nat -L POSTROUTING Chain POSTROUTING (policy ACCEPT) target prot opt source destination MASQUERADE all -- 172.17.0.0/16 anywhere $ docker run --net=bridge -it --rm alpine /bin/sh -c '/sbin/ip -4 address show dev eth0; ip -4 route show' 50: eth0@if51: <BROADCAST,MULTICAST,UP,LOWER_UP,M-DOWN> mtu 1500 qdisc noqueue state UP inet 172.17.0.2/16 scope global eth0 valid_lft forever preferred_lft forever default via 172.17.0.1 dev eth0 172.17.0.0/16 dev eth0 src 172.17.0.2

Bridged networking

• Services are exposed with

iptables DNAT rules

• Iptables performance

deteriorates as rule amount increases

• Limited to how many host ports

are free to be bound

$ docker run --net=bridge -d --name nginx -p 8000:80 nginx $ sudo iptables -t nat -n -L Chain PREROUTING (policy ACCEPT) target prot opt source destination DOCKER all -- 0.0.0.0/0 0.0.0.0/0 ADDRTYPE match dst-type LOCAL Chain OUTPUT (policy ACCEPT) target prot opt source destination DOCKER all -- 0.0.0.0/0 !127.0.0.0/8 ADDRTYPE match dst-type LOCAL Chain POSTROUTING (policy ACCEPT) target prot opt source destination MASQUERADE all -- 172.17.0.0/16 0.0.0.0/0 MASQUERADE tcp -- 172.17.0.2 172.17.0.2 tcp dpt:80 Chain DOCKER (2 references) target prot opt source destination RETURN all -- 0.0.0.0/0 0.0.0.0/0 DNAT tcp -- 0.0.0.0/0 0.0.0.0/0 tcp dpt:8000 to:172.17.0.2:80

Multi host

host-A host-B host-C container-0 2 container-0 1 container-0 3 container-0 4 container-0 5 container-0 6 frontend network application network database network eth0 eth0

Multi host networking scenarios

eth0

a big host-A frontend network container-0 2 container-0 1 container-0 3 container-0 4 container-0 5 container-0 6 application network database network VM-1 VM-2 VM-3

Multi host networking scenarios

Multi host routing solutions

Routing approach

• Managed common IP space at

the container level

• Assigns /24 subnet to each

host

• Inserts routes to each host /24

into the routing table of each host

• Main implementations

○ Calico ○ Flannel ○ Romana ○ Kuryr ■ Calico

host-a eth0 docker0

10.0.8.1/24

container-a

10.0.8.2/24

container-b

10.0.8.3/24

host-b eth0 docker0

10.0.9.1/24

container-c

10.0.9.2/24

container-d

10.0.9.3/24

172.16.0.0/16 172.16.0.4/16 172.16.0.5/16

Calico’s approach

• Felix agent agent per node that

sets up a vRouter: ○ Kernel’s L3 forwarding ○ Handles ACLs with iptables ○ Uses BIRD’s BGP to keep /32 or /128 routes to each container updated ○ Etcd as data store ○ Replies container ARP reqs with host hwaddr

host-a eth0 docker0

10.0.8.1/24

container-a

10.0.8.2/24

container-b

10.0.8.3/24

host-b eth0 docker0

10.0.9.1/24

container-c

10.0.9.2/24

container-d

10.0.9.3/24

172.16.0.0/16 172.16.0.4/16 172.16.0.5/16 BGP vRouter BGP vRouter

Flannel approach

• Flanneld agent

○ Etcd as data store ○ Keeps /24 routes to hosts up to date ○ No ACLs/isolation

Canal

• Developed by Tigera
• Announced on May 9th 2016

Multi host overlay solutions

• Encapsulates multiple networks
• ver the physical networking

○ UDP ○ vxlan ○ geneve ○ GRE

• Connect containers to virtual

networks

• Main projects

○ Docker’s native overlay ○ Flannel ○ Weave ○ Kuryr ■ OVS (OVN, Dragonflow) ■ MidoNet ■ PLUMgrid

Overlay approach

host-a eth0 net-x

10.0.8.1/24

container-a

10.0.8.2/24

container-b

10.0.8.3/24

host-b eth0 net y

10.0.9.1/24

container-c

10.0.7.4/24

container-d

10.0.7.3/24

172.16.0.0/16 172.16.0.4/16 172.16.0.5/16

net-y

10.0.7.1/24

container-c

10.0.7.2/24

encapsulation encapsulation encapsulated container traffic

OpenStack & containers with Kuryr

• Allows you to have both VMs,

containers and containers-in-VMs in the same

• verlay
• Allows reusing VM nets for

containers and viceversa

• Allows you to have separate
• verlay nets routed to each
• ther
• Isolation from the host

networking

• Can have Swarm and

Kubernetes on the same overlay

Overlay underlay

Routing vs Overlay Good Bad Routing

• Native performance
• Easy debugging
• Requires control over the

infrastructure

• Hybrid cloud more complicated

(requires VPN)

• Can run out of addresses

(mitigation: IPv6)

Overlay

• Easier inter-cloud
• Easier hybrid workloads
• Doesn’t require control over the

infrastructure

• More implementation choice
• Inferior performances (mitigation:

hw acceleration and jumbo frame)

• Debugging more complicated

Competing COE-Networking interaction

Container Network Model (CNM)

• Implemented by Docker’s Libnetwork
• Separated IPAM and Remote Drivers
• Docker ≥ 1.12 Swarm mode only works

with native overlay driver

• Some of the Libnetwork remote drivers:

○ OpenStack Kuryr ○ Calico ○ Weave

Container Network Interface (CNI)

• Implemented by Kubernetes, rkt, Mesos,

Cloud Foundry and Kurma

• Plugins:

○ Calico ○ Flannel ○ Weave ○ OpenStack Kuryr (unreleased)

More challenges

Service discovery

• Producer: A container that runs a service
• Consumer: A container when consuming a service
• Need a way for consumers to find producer endpoints

Service discovery challenges

#1 Finding the producer host-A web-01 eth0 Where is redis? host-B redis-01 eth0 Lacks SD host-A web-01 eth0 host-B redis-01 eth0 host-C redis-02 eth0 #2 Moving services

Service discovery challenges

#3 Multiple choice host-A web-01 eth0 Which redis? host-B redis-01 eth0 host-C redis-02 eth0 host-D redis-03 eth0

Addressing service discovery

Use DNS

• Problematic for highly dynamic deployments:

○ Containers can die/be moved somewhere more often than DNS caches expire ○ If we try to improve it by reducing DNS TTL → more load on the server ○ Some clients ignore TTL → old entries are cached

Note well:

• Docker < 1.11: updates /etc/hosts dynamically
• Docker ≥1.11: integrates a DNS server

Key-value store

• Rely on a k/v store

○ etcd, ○ consul, ○ zookeeper

• Producer register its IP and port
• Orchestration engine handles this data to the consumer
• At run time either:

○ Change your application to read data straight from the k/v ○ Rely on some helper that exposes the values via environment file or configuration file

Changes, multiple choices & ingress traffic

Orchestration engine services

• Services get a unique and

stable Virtual IP Address

• VIP always points to one of the

service containers

• Consumers are pointed to the

VIP

• Offered by Kubernetes and

Docker 1.12+

• Can run in parallel to DNS for

legacy apps

host-B redis-01 eth0 host-C redis-02 eth0 host-A web-01 eth0

redis service VIP

33

Ingress traffic: Routing requests to ever-changing container topology

Kubernetes has three service modes:

• ClusterIP: VIP internal to cluster

communication only. (can use externalIP)

• NodePort: Like Docker 1.12+
• Loadbalancer: Uses NodePort at the

cluster level and uses one of its pluggable load balancer drivers to instantiate and update external load balancers (gce, aws, OSt) Docker 1.12+ service approach

• Define services using the --publish/-p flag
• Services get exposed on all cluster nodes
• n specific port mappings

node_IP:service_port

Load balancer host-B guestbook

• 01

8081 blog-01 8080 host-A guestbook

• 01

8081 8080 host-C 8081 blog-01 8080

Load balanced ingress traffic flow

• Load balancer picks a host
• Traffic is handled by cluster

service

• Works even when the node

chosen by the LB is not running the container

Recap

Not just a matter of connecting containers:

• Service discovery
• Handling changes & multiple

choices

• Handling ingress traffic

Approach Spec Calico routing CNI, CNM Docker

• verlay

CNM Flannel routing, overlay CNI, CNM Kuryr routing, overlay CNI, CNM Weave

• verlay

CNI, CNM

Q&A
