Network Monitoring Session Description CoreGRID Workshop on Grid Middleware Dresden June 2007 Augusto Ciuffoletti INFN Italy A. Papadogiannakis Forth - Crete M. Polychronakis Forth Crete Summary Describe a network

slide-1
SLIDE 1

CoreGRID Workshop on Grid Middleware Dresden June 2007

Network Monitoring Session Description

Augusto Ciuffoletti – INFN – Italy

  • A. Papadogiannakis – Forth - Crete
  • M. Polychronakis – Forth – Crete
slide-2
SLIDE 2

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Summary

  • Describe a network monitoring framework
  • Define a solution
  • Introduce the schema describing network

monitoring requests within such solution

slide-3
SLIDE 3

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Narrowing the scope: GRID resources

  • A GRID is a collection of resources: among
  • thers, network paths
  • A path is seen as an atomic resource: we do not

distinguish links, routers etc.

  • A path exists between any pair of non-network

resources

  • Non-network resources are partitioned into

Domains

slide-4
SLIDE 4

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Narrowing the scope: Network Monitoring

  • Network Monitoring addresses network paths
  • Network Monitoring is performed by specific

resources, that we call Network Monitoring Elements

  • Network Monitoring is managed by specific

agents, that we call Network Monitoring Agents

  • There is at least one Network Monitoring Agent

for each Domain

  • Each network path can be monitored by at least
  • ne Network Monitoring Element
slide-5
SLIDE 5

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Narrowing the scope: NM management

  • Network Monitoring Agents form a community

that cooperate peer-to-peer

  • The scope of a Network Monitoring Agent is

limited to a single Domain

  • A Network Monitoring Agent has access to a

directory describing the capabilities of the Network Monitoring Elements

  • We envision the case of Network Monitoring

Agents specialized in monitoring some remote domains

slide-6
SLIDE 6

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Narrowing the scope: NM requests

  • Network Monitoring aims at the observation of

the performance of the network resources allocated to a complex computational task, that we call Workflow

  • NM requests are issued by the agent

responsible for Workflow management

  • NMA dynamically configure NMEs to operate

measurements

  • NMEs returns a stream of observations to the

Workflow Management Agent

slide-7
SLIDE 7

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

The Big Picture (small example)

slide-8
SLIDE 8

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Observations: pro

  • No repositories needed for traces, since
  • bservations are produced and consumed on

the fly

  • Scalability is improved:

– no n2 structures in the system – no n2 activities in the system – domains limit the scope of agents to a fraction of n

  • Directories describe static capabilities of

resources (which is what they are done for)

slide-9
SLIDE 9

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Observations: con

  • Design a coordination pattern for Network

Monitoring Agents

  • Network Monitoring Elements must be

dynamically configurable (no ping.conf)

  • A protocol to submit monitoring requests from

Workflow Monitoring Agents to Network Monitoring Elements (via NMAs)

  • Another to return observations backward,

possibly as a multicast

slide-10
SLIDE 10

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The Workflow Monitoring Agent issues a request to the local Network Monitoring Agent

slide-11
SLIDE 11

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The Workflow Monitoring Agent routes the request to a peer (hierarchy?)

slide-12
SLIDE 12

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The Workflow Monitoring Agent routes the request to a peer (2nd step)

slide-13
SLIDE 13

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The Workflow Monitoring Agent delivers the request the the Network Monitoring Element

slide-14
SLIDE 14

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The Network Monitoring activity starts between the Storage and the Computing Element

slide-15
SLIDE 15

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The stream carrying monitoring results is routed to the controlling Network Monitoring Agent

slide-16
SLIDE 16

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The stream by-passes the intermediate Network Monitoring Agent

slide-17
SLIDE 17

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Request/Response protocol The stream carrying the results reaches the requesting Workflow Monitoring Agent

slide-18
SLIDE 18

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Security issues

  • All communications are authenticated (except

those produced by the monitoring tool inside the NME)

  • Only communications between the Network

Monitoring Agents require a global authentication support (a prototype exists)

  • Other can be based on local policies
slide-19
SLIDE 19

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

The XSD schema

  • The schemas have been written to fixate the

ideas about the architecture.

  • The use of XML addresses the portability of a

possible implementation.

  • The basic data item is the

NetworkMonitoringSession type

slide-20
SLIDE 20

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Attributes of the Network Monitoring Session

Identification

<attribute name="SessionId" type="string" use="required"/>

Lifetime

<attribute name="StartAt" type="dateTime" use="required"/> <attribute name="Duration" type="duration" use="required"/>

Resources for the result stream

<attribute name="BandwidthLimit" type="nonNegativeInteger" default="0"/> <attribute name="Priority" type="nonNegativeInteger" default="0"/>

slide-21
SLIDE 21

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Elements of the Network Monitoring Session

Identification of the requesting WMA (for routing)

<element name="RequestFrom" type="nmsd:WorkflowMonitoringTaskType" maxOccurs="unbounded"/>

Route stack (for reverse routing)

<element name="Route" type="nmsd:RouteStackType"/>

Involved Domains (for NME selection)

<element name="NetworkElement" type="nmsd:NetworkElementType"/>

Measurement descriptor (details in next slide)

<element name="MeasurementStream" type="nmsd:MeasurementStreamType"/>

slide-22
SLIDE 22

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Definition of the Measurement Stream

A Measurement Stream contains several distinct data streams, with an identifying attribute:

<attribute name=”CharacteristicStreamId” type=”string”\>

each data stream is described by elements:

<element name="SamplePeriod" type="float" minOccurs="0"/> <element name="SourceIP" type="string" minOccurs="0" maxOccurs="unbounded"/> <element name="DestinationIP" type="string" minOccurs="0" maxOccurs="unbounded"/>

...and by a choice of tool specific options...

slide-23
SLIDE 23

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Tool specific options

Each element contains options for one single tool:

<choice> <element name="PingOptions" type="pt:PingOptionsType"/> <element name="AppmonOptions" type="am:AppmonOptionsType"/> </choice>

Each element is passed (in principle untouched) to a single NME. Ping (active): packet size, data aggregation etc. Appmon (passive): packet filter, data aggregation, characteristic, anonymization etc..

slide-24
SLIDE 24

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Separation of concern

  • NMA access all parts of the Network Monitoring

Session description except the Measurement Stream descriptor (header?)

  • WMA and NME produce/consume the sequence
  • f Measurement Stream descriptors (payload?)
  • The inter-NMA protocol acts as a transport for

Network Monitoring Stream descriptors

slide-25
SLIDE 25

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Tool oriented description

  • The WMA directly addresses a tool, and its

capabilities

  • Decouples design of network monitoring tools
  • The protocol between the WMAs does not

depend on the definition of the requested measurements

slide-26
SLIDE 26

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

Outline of the stream contents

  • One frame series for each element in the

Measurement Stream descriptor

  • Demultiplexing using Session and Measurement

identifiers

  • Also in this case, NMAs offer a transport service
  • De-multiplexing is on the WMA, as well as frame

unmarshalling.

slide-27
SLIDE 27

European Research Network on Foundations, Software Infrastructures and Applications for large scale distributed, GRID and Peer-to-Peer Technologies

  • We focus on monitoring activity finalized to

workflow monitoring

  • We introduce an architecture that includes

consumers, producers and infrastructure

  • We outline a request protocol, and design a

schema that describes a monitoring session

  • We outline a streaming protocol to deliver the

results

  • Experiments on the way...
  • Full presentation and a paper on my WEB page

OGF20 link
