NetFPGA Summer Course Presented by: Noa Zilberman Yury Audzevich Technion August 2 August 6, 2015 http://NetFPGA.org Summer Course Technion, Haifa, IL 2015 1 DESIGNING CORES Summer Course Technion, Haifa, IL 2015 2 Outline What

slide-1
SLIDE 1

Summer Course Technion, Haifa, IL 2015

1

NetFPGA Summer Course

Presented by: Noa Zilberman Yury Audzevich Technion August 2 – August 6, 2015

http://NetFPGA.org

slide-2
SLIDE 2

Summer Course Technion, Haifa, IL 2015

2

DESIGNING CORES

slide-3
SLIDE 3

Summer Course Technion, Haifa, IL 2015

3

Outline

  • What is a core?
  • IP Core logic
  • IP cores packaging

– Vivado – TCL

  • Instantiating IPs
  • Using Subcores
  • Compile
  • Do’s and Don’ts
slide-4
SLIDE 4

Summer Course Technion, Haifa, IL 2015

4

The role of Cores

  • A Core (also known as IP Core) is a stand

alone module

  • Can be reused

– Within a design – Between designs

  • Can be configured
  • Can be written in different languages

– Verilog, VHDL, system Verilog, C ….

  • The module is “packaged” as a core
slide-5
SLIDE 5

Summer Course Technion, Haifa, IL 2015

5

IP Core Logic

  • Design your module
  • “Ignore” the top project
  • Can be anything from one HDL file to a

complex design

  • Test you core in a simulation

– Write a core-specific test bench – Not a must

  • Set timing constraints
  • All done?

– Time to wrap your core

slide-6
SLIDE 6

Summer Course Technion, Haifa, IL 2015

6

Packaging Cores

  • There are (at least) two ways to package a

core:

– Through the Vivado GUI – Using TCL scripts

  • We will explore both
  • For best reuse across projects, we

recommend using TCL scripts

– You can use the GUI and still export TCL – But they are not fully compatible

slide-7
SLIDE 7

Summer Course Technion, Haifa, IL 2015

7

Packaging a Core using Vivado

Create a new project

slide-8
SLIDE 8

Summer Course Technion, Haifa, IL 2015

8

Packaging a Core using Vivado (2)

Select the project’s name

slide-9
SLIDE 9

Summer Course Technion, Haifa, IL 2015

9

Packaging a Core using Vivado (3)

Select “RTL Project”

slide-10
SLIDE 10

Summer Course Technion, Haifa, IL 2015

10

Packaging a Core using Vivado (4)

Add HDL files

slide-11
SLIDE 11

Summer Course Technion, Haifa, IL 2015

11

Packaging a Core using Vivado (5)

Select Device XC7VX690TFFG1761-3

slide-12
SLIDE 12

Summer Course Technion, Haifa, IL 2015

12

Packaging a Core using Vivado (6)

Summary

slide-13
SLIDE 13

Summer Course Technion, Haifa, IL 2015

13

Packaging a Core using Vivado (7)

Project Summary

Source Files

slide-14
SLIDE 14

Summer Course Technion, Haifa, IL 2015

14

Packaging a Core using Vivado (8)

Tools  Create and package IP

slide-15
SLIDE 15

Summer Course Technion, Haifa, IL 2015

15

Packaging a Core using Vivado (9)

Package your current project

slide-16
SLIDE 16

Summer Course Technion, Haifa, IL 2015

16

Packaging a Core using Vivado (10)

Select target folder

slide-17
SLIDE 17

Summer Course Technion, Haifa, IL 2015

17

Packaging a Core using Vivado (11)

slide-18
SLIDE 18

Summer Course Technion, Haifa, IL 2015

18

Packaging a Core using Vivado (12)

Edit core’s identification fields

Change category

slide-19
SLIDE 19

Summer Course Technion, Haifa, IL 2015

19

Packaging a Core using Vivado (13)

Select category

  • r create a new
  • ne
slide-20
SLIDE 20

Summer Course Technion, Haifa, IL 2015

20

Packaging a Core using Vivado (14)

Define File Groups and add subcores

slide-21
SLIDE 21

Summer Course Technion, Haifa, IL 2015

21

Packaging a Core using Vivado (15)

Select subcore A subcore is an IP instantiated within the core

slide-22
SLIDE 22

Summer Course Technion, Haifa, IL 2015

22

Packaging a Core using Vivado (16)

Update parameters and set default values

slide-23
SLIDE 23

Summer Course Technion, Haifa, IL 2015

23

Packaging a Core using Vivado (17)

Update ports Note related warnings

slide-24
SLIDE 24

Summer Course Technion, Haifa, IL 2015

24

Packaging a Core using Vivado (18)

Right click  Edit IP bus Interface

slide-25
SLIDE 25

Summer Course Technion, Haifa, IL 2015

25

Packaging a Core using Vivado (19)

Edit parameters values

slide-26
SLIDE 26

Summer Course Technion, Haifa, IL 2015

26

Packaging a Core using Vivado (20)

Updating the memory map is possible

(Not required in most NetFPGA cores)

slide-27
SLIDE 27

Summer Course Technion, Haifa, IL 2015

27

Packaging a Core using Vivado (21)

Customize GUI

slide-28
SLIDE 28

Summer Course Technion, Haifa, IL 2015

28

Packaging a Core using Vivado (22)

Core Summary Any errors? Warnings?

slide-29
SLIDE 29

Summer Course Technion, Haifa, IL 2015

29

Packaging a Core using Vivado (23)

Job done!

slide-30
SLIDE 30

Summer Course Technion, Haifa, IL 2015

30

Packaging a core using TCL

  • Start from a template of an existing core
  • Place all your HDL files under

<core_name>/hdl

  • Edit <core_name>.tcl
  • Update Makefile with the name of the core
  • Run make
  • You may want to add your core to

$SUME_FOLDER/Makefile as well

– Note that the order of generation matters

slide-31
SLIDE 31

Summer Course Technion, Haifa, IL 2015

31

<core_name>.tcl

  • TCL file structure:

– Project Defines – Creating the project – Adding the HDL files – Packaging the project – Adding core information & parameters – Validation – Completing the project

slide-32
SLIDE 32

Summer Course Technion, Haifa, IL 2015

32

<core_name>.tcl

  • TCL file structure:

– Project Defines

Recommend to keep identical Recommend not to change

slide-33
SLIDE 33

Summer Course Technion, Haifa, IL 2015

33

<core_name>.tcl

  • TCL file structure:

– Creating the project

slide-34
SLIDE 34

Summer Course Technion, Haifa, IL 2015

34

<core_name>.tcl

  • TCL file structure:

– Adding the HDL files

slide-35
SLIDE 35

Summer Course Technion, Haifa, IL 2015

35

<core_name>.tcl

  • TCL file structure:

– Adding core information & parameters

slide-36
SLIDE 36

Summer Course Technion, Haifa, IL 2015

36

<core_name>.tcl

  • TCL file structure:

– Packaging the project – core information

slide-37
SLIDE 37

Summer Course Technion, Haifa, IL 2015

37

<core_name>.tcl

  • TCL file structure:

– Packaging the project – parameters

slide-38
SLIDE 38

Summer Course Technion, Haifa, IL 2015

38

<core_name>.tcl

  • TCL file structure:

– Packaging the project – bus parameters

slide-39
SLIDE 39

Summer Course Technion, Haifa, IL 2015

39

<core_name>.tcl

  • TCL file structure:

– Validation

Read the output and look for reported issues

slide-40
SLIDE 40

Summer Course Technion, Haifa, IL 2015

40

<core_name>.tcl

  • TCL file structure:

– Completing the project

Update the IP catalog to see the new core in the repo

slide-41
SLIDE 41

Summer Course Technion, Haifa, IL 2015

41

Using an IP

Open IP Catalog Select IP

slide-42
SLIDE 42

Summer Course Technion, Haifa, IL 2015

42

Set IP name and parameters values

slide-43
SLIDE 43

Summer Course Technion, Haifa, IL 2015

43

Generate IP outputs (e.g. template, simulation) Can take some time to generate

slide-44
SLIDE 44

Summer Course Technion, Haifa, IL 2015

44

Add IP in TCL

  • From within a project:
slide-45
SLIDE 45

Summer Course Technion, Haifa, IL 2015

45

Using Subcores

  • What happens if you use an IP core within

your core?

  • How do you call it?
  • How do you pass parameters to it?
  • What happens if the same core is

instantiated in multiple different cores, with different settings?

– An IP can be created only once (using the same name) – A created IP can have only a single set of values for its parameters

slide-46
SLIDE 46

Summer Course Technion, Haifa, IL 2015

46

Using Subcores

  • Solution: Subcores
  • Indicate that an IP core instantiates other IP cores
  • Can propagate parameters values in HDL
slide-47
SLIDE 47

Summer Course Technion, Haifa, IL 2015

47

Compile

  • TCL only
  • Run:
slide-48
SLIDE 48

Summer Course Technion, Haifa, IL 2015

48

Do’s and Don’ts

  • Don’t create the same IP multiple times

– Save synthesis time!

  • Don’t “create IP” within IPs
  • Use add_subcores
  • Make sure all parameters are available to

the user

  • Validate your design
  • Provide useful information in your core

identification

  • Update core versions!
slide-49
SLIDE 49

Summer Course Technion, Haifa, IL 2015

49
