NEBC Database Course 2008 Welcome Introduction to Databases

Tim Booth : tbooth@ceh.ac.uk

Course Overview

What you will take home:

• What is a relational database?
• Why would you use one?
• How do you interact with one?
• How do you design and build one?
• What is the theory behind good relational design?
• What software is available?
• How can I build user interfaces, or display my data on the web?

What is a database?

• Most general definition:

“A database is an integrated collection of data organised to meet the needs of one or more users”

• Databases stored on computer may be of various types:
• Flat file database such as a comma-

separated file

• Indexed file database such as BLAST dbs
• 'Flat' relational database such as

Access .mdb

• Database managed by a dedicated

application (RDBMS) such as PostgreSQL

• r Oracle.

Benefits of a Relational Approach

• Database structure reflects the structure of the data
• Eliminate redundant data
• Data validation
• Powerful querying via SQL
• Security, data integrity and multi-user access
• Compatibility with a huge range of existing software and

development tools

What is a Relational Database?

• A relational database is a collection of tables. Each table has

rows and columns, and looks rather like a spreadsheet.

• The movie table in the example database:

The Example Database

• The 'bighit' database represents a video store.
• Each person has access to an individual copy of this database,

and we will explore it as the course progresses.

• The next slide shows a selection of tables in the database, and

links between them.

The Example Database

More about database tables

• Tables are properly called 'relations'.
• A table holds a collection of records or 'tuples'. These are

shown as rows when you view the data.

• Each record has a fixed set of fields or 'attributes', each of

which contains data of a specified type. These appear as columns in the data view.

• Inside the database, the order of the rows and columns is not
• significant. The database sorts them when you ask to display

the data.

• A database can have many different tables, corresponding to

things we want to store data about.

• Other entities can also live in your database – we shall meet

them later!

Access the sample database

• Each user has a private copy of the sample database. We will

log in now.

• Start the pgAdmin III application from under System Tools in

the main menu.

• File → Add Server
• Select the server in the tree view, login with user/pass
• In the tree browser, open 'databases' then 'student0?'.
• Open the 'bighit' schema, then the 'tables' link.
• Select the 'movie' table – note the definition which appears in

the right pane.

• Right click and select View data → View all rows.

Introducing SQL

• SQL is a language we will use to get at the data in the database
• Generally human readable
• Retrieve information with SELECT statements
• eg. SELECT * FROM MOVIE
• A result set comes back.

Bring up an SQL Editor Window

• Click the pencil icon to get a new SQL editor window.
• In the new window, use the eraser icon to clear any text

already in the input box.

Talking SQL

• Type the query shown (1) and hit the green arrow (2) to run it.

2 2 1 1

More about SQL

• SQL is the Structured Query Language
• The language and structure of databases are intimately linked.
• Sometimes pronounced 'sequel' – especially by Microsoft

devotees.

• Invented by Dr. Edgar Frank 'Ted' Codd (1924-2003), who was

from Oxford, and set down the foundations of the relational database concept while working in the IBM San Jose Research Laboratory.

• The classic paper 'A relational model of data for large shared

data banks' appeared in the ACM (Association for Computing Machinery) magazine, June 1970

Being More Specific

• The general form of basic SELECT statements:

SELECT title, year FROM movie WHERE year > 1990 ORDER BY year SELECT WHAT FROM WHICH TABLE WHERE SOME TEST ORDER BY WHICH COLUMN

• The last two parts are both optional.
• SELECT * is a special case to get all columns.

Modifying Data

• INSERT, DELETE and UPDATE are the commands to modify

data. DELETE FROM reservation where accountid = 23 DELETE FROM TABLE WHERE CONDITION INSERT INTO reservation (accountid, movieid, datereserved) VALUES (23, 15, '12 June') INSERT INTO TABLE (COLUMNS) VALUES (VALUES)

Modifying Data 2

• INSERT, DELETE and UPDATE are the commands to modify

data. UPDATE movie SET genre = 'fantasy', rating = 'PG' WHERE id = 15 UPDATE TABLE SET COLUMN1 = VALUE1, COLUMN2 = VALUE2 WHERE CONDITION

Getting Exactly What You Want

• In a RDB you try not to store redundant or derived data.
• For example, we store the year of release of a movie, but not

the age.

• We can specify a calculation within the SELECT statement to

calculate the age of a movie on-the-fly. A) SELECT title, year from movie B) SELECT title, extract(YEAR FROM now()) - year FROM movie

• 'extract' and 'now' are functions.

Name That Column

• Column aliases allow you to specify the name of a column

retrieved with SELECT.

• Running the previous example, we see that the second column

gets called '?column?', because the database has no idea what to call the result of the formula.

• We can simply say:

SELECT title, extract(YEAR FROM now()) - year as age FROM movie

Learning by Example

• SQL allows you to derive data by supplying a variety of

functions and constructs.

• Rather than just talking through them, we will introduce some

by example in the exercises.

Relational Databases in Biology

• Some databases, such as the NCBI Taxonomy, can be

downloaded and set up on a local machine. ftp://ftp.ncbi.nih.gov/pub/taxonomy/

• Ensembl permits direct access to the core database, which we

will look at later. The document describing how to get access is here: http://cvsweb.sanger.ac.uk/cgi−bin/cvsweb.cgi/ ~checkout~/ensembl/docs/tutorial/ensembl_tutorial.pdf

• For large datasets, deploying an RDBMS can provide fast,

flexible access to the data. Most data-portal websites have such a database at their heart.

Credits

• The Bighit database is adapted from the website of Greg

Riccardi - http://riccardi.pearsoncmg.com/dbmgmt/.

• Examples and quotes from Database Design and Management,

by Rob Eadie (Continuum, 1998).

• Programming the Perl DBI, Alligator Descartes & Tim Bunce,

(O'Reilly 2000)

• Course originally delivered in 2004; developed by Tim Booth,

Joe Wood, Bela Tiwari and Dan Swan at the EGTDC.
