NCDOT/ AGC Workshop Roadway Breakout Vickie Davis, PE 2 U-2579B - - PowerPoint PPT Presentation
NCDOT/ AGC Workshop Roadway Breakout Vickie Davis, PE 2 U-2579B - - PowerPoint PPT Presentation
NCDOT/ AGC Workshop Roadway Breakout Vickie Davis, PE 2 U-2579B Winston-Salem Northern Beltway 3 Existing Snowplowable Markers 4 5 Construction Surveying Conduct survey preconstruction meeting to discuss control and required
SLIDE 2
SLIDE 3
3
U-2579B Winston-Salem Northern Beltway
SLIDE 4
Existing Snowplowable Markers
4
SLIDE 5
5
SLIDE 6
Construction Surveying
➢ Conduct survey preconstruction meeting to
discuss control and required submittals ➢ Will Contractor use Automated Machine Guidance? Submit AMG plan ➢ NCDOT Standard Specifications Section 801 ➢ Manual for Construction Layout TO BE REVISED 2018
6
SLIDE 7
Manual for Construction Layout
7
SLIDE 8
Digital Terrain Models ➢ If the Contractor elects to use Automated Machine
Guidance, a Digital Terrain Model (DTM) shall be developed and submitted to the Engineer for review ➢ RE should consult with Division Locating Engineer who can assist with review of DTM ➢ RE offices will receive Trimble Business Center software; Location & Surveys Unit providing training
8
SLIDE 9
Guardrail Installation
9
GUARDRAIL INSTALLATION- MASH 2016
SLIDE 10
HOW IS GUARDRAIL APPROVED??
Guardrail Installation
10
➢ Guardrail and terminals are crash tested in laboratory settings ➢ FHWA and AASHTO joint task force evaluated how terminals performed in real-world conditions using actual crash data
SLIDE 11
Based on their findings…
Guardrail Installation
11
Manual for Assessing Safety Hardware (MASH)
✓ AASHTO’s Manual for Assessing Safety Hardware was published in 2009 ✓ Updated guidelines for crash testing permanent and temporary highway safety features including guardrail terminals
http://safety.fhwa.dot.gov/roadway_dept/policy_guide/road_hardware/ctrmeasures/mash/
SLIDE 12
History of Testing Procedures
➢ Procedures for crash testing have evolved
Guardrail Installation
12
Highway Research Correlation Services Circular 482 1962 NCHRP Report 153 1974 NCHRP Report 230 1980 NCHRP Report 350 1993
AASHTO MASH is the newest and safest generation
- f roadside hardware.... Approved by FHWA in 2015
SLIDE 13
Guardrail Installation
13
Manual for Assessing Safety Hardware (MASH)
SLIDE 14
Guardrail Installation
14
SLIDE 15
Guardrail Installation
15
SLIDE 16
Supplemental Agreements
(Projects Let prior to January 2018)
Guardrail Installation
16
SLIDE 17
Guardrail Installation
17
SLIDE 18
Rdwy Standard Drawing 862.01
18
SLIDE 19
Guardrail Installation
19
SLIDE 20
B-77 STRUCTURE ANCHOR UNIT
Guardrail Installation
20
SLIDE 21
B-83 STRUCTURE ANCHOR UNIT
21
SLIDE 22
Transition in Guardrail Height …
Guardrail Installation
22
SLIDE 23
Guardrail Installation
23
SLIDE 24
Type III Guardrail Anchor Units
Guardrail Installation
24
SLIDE 25
Type III Guardrail Anchor Units
Guardrail Installation
25
X
SLIDE 26
Type III Guardrail Anchor Units
Guardrail Installation
26
Due to error in RSD 862.03 look for this detail in plans 1’-9” to center
- f end shoe
SLIDE 27
Guardrail End Units- MASH
Guardrail Installation
27
FOR POSTED SPEEDS ≥ 45 MPH USE GREU TYPE TL-3 FOR POSTED SPEEDS < 45 MPH USE GREU TYPE TL-2
SLIDE 28
NCDOT Vendor Approved Products List
Guardrail Installation
28
➢ Currently only 3 MASH approved Guardrail End Units
➢ NO Flared End MASH approved End Units at this time
SLIDE 29
Guardrail Installation
29
MSKT (Road Systems) Soft Stop (Trinity) Max Tension (Lindsay)
SLIDE 30
Project Special Provisions
Guardrail Installation
30
SLIDE 31
Assembling Instructions
Guardrail Installation
31
https://connect.ncdot.gov/resources/ Specifications/Pages/2018-Roadway- Standard-Drawings.aspx
