NCDOT Transportation Updates April 13, 2016 Presenter Name Malcolm K. Fearing NCDOT Division One Board Member Agenda Acknowlegements NCDOT Mission About NCDOT NCDOT Divisions Division One NCDOT Budget Project

slide-1
SLIDE 1

Presenter Name

NCDOT Transportation Updates

Malcolm K. Fearing NCDOT Division One Board Member

April 13, 2016

slide-2
SLIDE 2

Transportation

Agenda

  • Acknowlegements
  • NCDOT Mission
  • About NCDOT
  • NCDOT Divisions
  • Division One
  • NCDOT Budget
  • Project Development/Local Input
  • Bonner Bridge
  • Alligator River Bridge
  • Mid Currituck Bridge
  • Colington Road Widening
  • Wright Memorial Bridge
  • Noteworthy Projects
  • Ferry Division
  • Questions

2

slide-3
SLIDE 3

Transportation

3

ACKNOWLEDGEMENTS

slide-4
SLIDE 4

Transportation

4

NCDOT MISSION STATEMENT

slide-5
SLIDE 5

Transportation

5

North Carolina Department of Transportation

slide-6
SLIDE 6

Transportation

6

NCDOT DIVISIONS

slide-7
SLIDE 7

Transportation

7

NCDOT DIVISION ONE

slide-8
SLIDE 8

Transportation

8

NCDOT BUDGET INFO

slide-9
SLIDE 9

Transportation

9

Project Development & Local Input

slide-10
SLIDE 10

Transportation

10

B-2500: Bonner Bridge Replacement

slide-11
SLIDE 11

Transportation

11

Part 1: Transportation Prior to the Bridge….

  • Mr. Tillett’s private ferry

State Ferry at Oregon Inlet

  • Mid-1920’s: A private ferry service was established by Capt. J.B.

“Toby” Tillett

  • 1934: NC Highway Commission began subsidizing Mr. Tillett’s
  • perations
  • 1950: State of NC bought Mr. Tillett’s Fery Service and operated in

until 1963

slide-12
SLIDE 12

Transportation

12

Part 1: Transportation Prior to the Bridge….

Ferry at Oregon Inlet Unimproved Road Hard Surfaced Road Unimproved Road

Excerpts from 1951 North Carolina State Travel Map

slide-13
SLIDE 13

Transportation

13

Part 1: Transportation Prior to the Bridge….

Metal Planks being placed as a foundation what would become NC 12

slide-14
SLIDE 14

Transportation

14

Part 2: First Bonner Bridge Construction

Bonner Bridge Under Construction Bonner Bridge

  • Built 1963
  • At a Cost of

$4,000,000

slide-15
SLIDE 15

Transportation

15

Part 2: First Bonner Bridge Construction

Future Oregon Inlet Fishing Center

Bonner Bridge Under Construction

slide-16
SLIDE 16

Transportation

16

Part 3: Oregon Inlet Ever Changing

slide-17
SLIDE 17

Transportation

17

Part 3: Bonner Bridge Replacement

  • Due to the complexities associated with

this project the B-2500 Project is subdivided into several smaller projects along Pea Island

  • B-2500 Bonner Bridge-$246 Million
  • B-2500 Phase IIA – New Inlet Short Term

Improvements-$14 Million

  • B2500 Phase IIB – Fish Hook Bridge-

Rodanthe-$198 Million

  • Beach Nourishment - $20.3 Million
  • Total: $478.3 Million
slide-18
SLIDE 18

Transportation

18

Part 3: Bonner Bridge Replacement

  • Design-build contract awarded to PCL Civil Constructors, Inc., in July 2011
  • HDR Engineering, Inc. of the Carolinas- lead design firm
  • Bid was $215.8
  • About 3 year construction time
slide-19
SLIDE 19

Transportation

19

Part 3: Bonner Bridge Replacement

slide-20
SLIDE 20

Transportation

20

Part 3: Bonner Bridge Replacement

slide-21
SLIDE 21

Transportation

21

Alligator River Bridge Replacement

slide-22
SLIDE 22

Transportation

22

Part 1: Prior to Alligator Bridge-Ferry

Proposed Ferry Ramp Proposed Channel & Basin

1948 map shows proposed ferry at US 64 (now SR 1153-Old Ferry Landing Road)

  • Thomas A Baum operated ferry at

Alligator River

  • The ferry route ran from Fort

Landing in Tyrrell County to East Lake

  • Car and driver cost $0.75, extra

passengers $0.10 (early costs: no date)

  • Crossing Time was 50 minutes
slide-23
SLIDE 23

Transportation

23

Part 1: Prior to Alligator River Bridge

  • 1938 County Map that depicts Toll Ferry
  • 1950s- Cars waiting to ride ferry
slide-24
SLIDE 24

Transportation

24

Part 2: Construction of Alligator River Bridge

  • Construction on the

2.8 mile bridge began in 1960 and completed in 1962

  • It is a single swing

span bridge and its technology is significant as it was

  • ne of the first three,

long-span applications of welded girders in North Carolina as a major project and design of the State Highway Commission

slide-25
SLIDE 25

Transportation

25

Part 3: Replacement of Alligator River Bridge

slide-26
SLIDE 26

Transportation

26

Part 3: Replacement of Alligator River Bridge

slide-27
SLIDE 27

Transportation

27

Mid Currituck Bridge

slide-28
SLIDE 28

Transportation

28

Mid Currituck Bridge

Mid-Currituck Bridge

7 miles long two-lane bridge across Currituck

  • Sound. Estimated Costs are $595 million
slide-29
SLIDE 29

Transportation

29

Colington Road Widening

slide-30
SLIDE 30

Transportation

30

Colington Road Widening

  • From end of Colington Road to

Colington Drive the proposed project will only involve resurfacing;

  • From Colington Drive to Baum

Bay Drive (SR 1452) the proposed section will be 11 foot travel lanes with 10 foot shoulders(7’paved);

  • Between Baum Bay and 900’ east
  • f Veterans Drive the project will
  • nly involve resurfacing;
  • From 900’ east of Veterans to US

158 the project includes 2-11’ travel lanes;1-11’ two-way center turn lane, and 8’ shoulders(4’ paved)

slide-31
SLIDE 31

Transportation

31

Wright Memorial Bridge-Currituck Sound

slide-32
SLIDE 32

Transportation

32

Part 1: Currituck Sound in the 1930s

slide-33
SLIDE 33

Transportation

33

Part 2: Currituck Sound Bridge

slide-34
SLIDE 34

Transportation

34

Noteworthy Projects

slide-35
SLIDE 35

Transportation

35

Ferry Division

slide-36
SLIDE 36

Transportation

36

Questions?
