GCT634: Musical Applications of Machine Learning

Music Classification Overview and Audio Features

Graduate School of Culture Technology, KAIST Juhan Nam

Outlines

• Definition of Music Classification Tasks
• Overview of Music Classification Systems
• Audio Features

Definition

• Categorizing input audio into labels
• Labels can be anything, even including note, chord or beat notations
• However, we limit them to semantic words such as genre, mood,

instrument, era and other word-based descriptions Model Input Output

Types of Music Classification Tasks

• Genre/Mood classification
• Classify music clips into a category
• Single-label classification
• Instrument Identification
• Can be recast as a classification problem
• Polyphonic cases: pre-dominant instrument detection (single-label

classification) or multiple instrument detection (multiple-label classification)

• Music Auto-Tagging
• Labels can be anything (e.g. genre, mood, instrument, era, vocal quality)
• Multi-label classification

Music Genre

• Numerous genres and their sub-genres
• http://research.google.com/bigpicture/music/
• http://en.wikipedia.org/wiki/List_of_popular_music_genres
• Evolutionary and influence-based
• https://frananddavesmusicaladventure.wordpress.com/the-music-tree/
• http://www.historyshots.com/rockmusic/
• http://techno.org/electronic-music-guide/
• Based on cultural context
• Many cultural communities (or countries with homogenous culture) have

different genre distributions

• Unique genres (e.g. trot) and different popularity (e.g. metal)

Genre Categories in MIREX

Blues Jazz Country/Western Baroque Classical Romantic Electronica Hip-Hop Rock HardRock/Metal

US Pop Genre Classification

Axe Bachata Bolero Forro Gaucha Merengue Pagode Salsa Sertaneja Tango

Latin Genre Classification

Ballad Dance Folk Hip-hop R&B Rock Trot

K-pop Classification

http://www.music-ir.org/mirex/wiki/2017:Audio_Classification_(Train/Test)_Tasks

• MIREX (Music Information Retrieval Evaluation eXchange)
• Community-based algorithm evaluation framework and events

Music Mood

• Russel’s circumplex model of affect
• “Arousal-Valence” 2D space

Models in Music Psychology 2/2

Dimensional

Russell’s

circumplex model

10/10/2012

Russell, J. A. 1980. A circumplex model of affect. Social , 39: 1161‐ 1178.

27

Music Mood

• Mood clustering
• Using mood labels for songs ( “allmusic.com”)
• Song by mood matrix à mood by mood correlation matrix à clustering

Mood Label Clustering

Mood labels for albums

10/10/2012

Mood labels for songs

C1 C2 C3 C4 C5

Hu, X., & Downie, J. S. (2007). Exploring Mood Metadata: Relationships with Genre, Artist and Usage Metadata. In

31

10/10/2012 30

(Hu, 2007)

Mood Categories in MIREX

• The five clusters are used in the MIREX mood classification task

Mood Classification

Cluster_1: passionate, rousing, confident, boisterous, rowdy Cluster_2: rollicking, cheerful, fun, sweet, amiable/good natured Cluster_3: literate, poignant, wistful, bittersweet, autumnal, brooding Cluster_4: humorous, silly, campy, quirky, whimsical, witty, wry Cluster_5: aggressive, fiery, tense/anxious, intense, volatile, visceral http://www.music-ir.org/mirex/wiki/2017:Audio_Classification_(Train/Test)_Tasks

Overview of Music Classification Systems

Classifier Feature Extraction Audio Representations

“Metal” “Jazz” “Classical” (?)

Overview of Music Classification Systems

Classifier Feature Extraction Audio Representations

• Audio representations
• Low-level representation of audio
• Preserve the majority of information in input data
• e.g. waveform, spectrogram, mel-spectrogram

“Metal” “Jazz” “Classical” (?)

Overview of Music Classification Systems

Classifier Feature Extraction Audio Representations

• Feature extraction
• Summary of acoustic or musical patterns that explain the characteristics of

the audio representations

• e.g. MFCC, chroma, learning-based feature represenations

“Metal” “Jazz” “Classical” (?)

Overview of Music Classification Systems

Classifier Feature Extraction Audio Representations

• Classifiers
• Determine the category based on the extracted features
• A learning algorithm is necessary: e.g. SVM, GMM, NN
• Training and Testing

“Metal” “Jazz” “Classical” (?)

It is important to extract good audio features!

Classifier Feature Extraction Audio Representations

“Metal” “Jazz” “Classical” Feature Space

Good Features Bad Features

“Metal” “Jazz” “Classical” Feature Space

Let’s listen to examples

• What the genre of the music ?
• What the mood of the music ?
• What are the features of the music that explain your answers?

Human Knowledge to Explain Music

• Acoustic Level
• Loudness
• Pitch
• Timbre
• Musical Level
• Instrumentation
• Rhythm
• Key and scale
• Chord and melodic pattern
• Lyrics, structure, singing style, …

Two Approaches in Music Classification

• Feature engineering
• Features are designed based on domain knowledge and heuristics
• Traditional approach: e.g. MFCC+GMM model
• Feature learning
• Features are learned using optimization algorithms
• Recent approach: e.g. deep neural networks

Classifier Feature Extraction Audio Representations

Let’s focus on the feature engineering approach first!

Feature Engineering Model

• Feature extraction is divided into several steps

Normalization Temporal Summarization Frame-Level Audio Features

(G. Tzanetakis)

(Frame-Level) Audio Features

• Loudness
• Root-Mean-Squares (RMS) of audio frames
• Timbre features
• Zero-crossing rate
• MFCC (w/ delta or double-delta): spectral envelop
• Spectral summary: centroid, roll-off, …
• Pitch/Harmony features
• Chroma
• Rhythm features (this is not frame-level)
• Beat histogram, Tempogram

Zero-Crossing Rate (ZCR)

• ZCR is low for harmonic (voiced) sounds and high for noisy

(unvoiced) sounds

• Useful to classify different drum sounds (e.g. bass, snare, high-hat)
• For narrow-band periodic signals, it is related to the F0

Voiced Unvoiced

Spectral Statistics

• Spectral Centroid: “Center of gravity” of the spectrum
• Associated with the brightness of sounds
• Spectral Roll-off: frequency under which 85% or 95% of spectral

energy is concentrated in

SC(t) = fk Xt(k)

k

∑

Xt(k)

k

∑

Xt(k)

k Rt

∑

= 0.85 Xt(k)

k N

∑

Examples of Spectral Centroids

time [sec] frequency [Hz]

0.5 1 1.5 2 2.5 3 3.5 4 4.5 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000

Classical: “Beethoven String Quartet” Pop: “Video killed the radio star”

time [sec] frequency [Hz]

0.5 1 1.5 2 2.5 3 3.5 4 4.5 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000

Spectral Statistics

• Spectral Spread(SS): a measure of the bandwidth of the

spectrum

• Spectral flatness (SF): a measure of the noisiness of the

spectrum

• The ratio between the geometric and arithmetic means

SS(t) = ( fk − SC(t))2 Xt(k)

k

∑

Xt(k)

k

∑

SF(t) = Xt(k)

k

∏

K

1 K Xt(k)

k

∑

Mel-Frequency Cepstral Coefficient (MFCC)

• Most popularly used audio feature for timbre feature extraction
• Extract spectral envelop from an audio frame
• Standard audio feature in speech recognition
• Introduced in music domain by Logan in 2000
• Computation Steps

DCT Log magnitude DFT (audio frame) Mapping freq. scale to mel

Mel-Frequency Spectrogram

• Convert linear frequency to mel scale
• Usually reduce the dimensionality of spectrum

Spectrum Spectrum (mel-scaled)

Discrete Cosine Transform

• Real-valued transform: similar to DFT
• De-correlate the mel-scaled log spectrum and reduce the dimensionality

again

Spectrum (mel-scaled) MFCC

XDCT (k) = 2 N x(n)cos(πk N (n − 0.5))

n=1 N−1

∑

Reconstructed Frequency Spectrum from MFCC

Frequency spectrum (512 bins) Frequency spectrum (mel-scaled, 60 bins) MFCC (13 dim) Reconstructed Frequency Spectrum (mel-scaled) Reconstructed Frequency spectrum

Comparison of Spectrogram and MFCC

Spectrogram Mel-frequency Spectrogram MFCC Reconstructed Spectrogram from MFCC

Sound Examples of MFCC

• Original:
• MFCC reconstruction (using white-noise as a source):

Post-processing

• Adding temporal dynamics
• Short-term dynamics of features are characterized with delta or double-

delta

• 39 MFCCs in speech recognition: 13 MFCCs + 13 delta + 13 double-delta

Δx = x(n)− x(n − h) h ΔΔx = Δx(n)− Δx(n − h) h

Pitch and Chroma

• The basic assumption in tonal harmony is

that octave-distance notes belong to the same pitch class

• No dissonance among them
• As a result, there are “12 pitch class”
• Shepard represented the octave

equivalence with “pitch helix”

• Chroma: represents the inherent circularity of

pitch organization

• Height: naturally increase and have one octave

apart for one rotation

Pitch Helix and Chroma (Shepard, 2001)

Pitch and Chroma

• Chroma is independent of the height
• Shepard tone: single pitch class in harmonics
• Constant rising and falling

Optical illusion stairs Shepard tone https://vimeo.com/34749558

Chroma Audio Features

• Chroma features are audio feature vectors that contain relative

distribution of pitch classes of audio

• Ideally, they can be obtained by polyphonic note transcription
• In practice, chroma features are obtained by projecting all time-frequency

energy onto 12 pitch classes

• Mainly used for chord recognition, key estimation, music and

audio synchronization and “score-level” tasks

• It is often used for music classification but not as much effective as MFCC

Chroma Features: FFT-based approach

• Compute spectrogram and mapping matrix
• Convert frequency to music pitch scale and get the pitch class
• Set one to the corresponding pitch class and, otherwise, set zero
• Adjust non-zeros values such that low-frequency content have more

weights

Chroma Features: Filter-bank approach

• A filter-bank can be used to get a log-

scale time-frequency representation

• Center frequencies are arranged over 88

piano notes

• band widths are set to have constant-Q and

robust to +/- 25 cent detune

• The outputs that belong to the same

pitch class are wrapped and summed.

(Müller, 2011)

Sound Examples of Chroma

• Original:
• MFCC reconstruction (using white-noise as a source):
• Pitch-Invariance
• Chroma reconstruction:
• Timbre-Invariance

Feature Summarization and Normalization

• Summarization
• Summary statistics
• Temporal pooling: mean, variance, min, max over a context window
• Temporal modulation: DFT of time-trajectory over sub-bands
• Code-book approach
• Vector quantization: create codebook by K-means clustering
• Accumulate the code-book indices as a histogram
• Normalization
• Standardization
• Zero mean: subtract means
• Unit variance: divided variances for individual dimensions
