Multiresolution Matrix Factorization

Risi Kondor, The University of Chicago

Nedelina Teneva UChicago Pramod Mudrakarta UChicago

.

Wavelets on graphs

• Learning on graphs
• Semi-supervised learning

[Shuman et al., 2013]]

2/32 .

2/32

.

Wavelets on graphs: recent work

• Diffusion Wavelets [Coifman & Maggioni, 2006]
• Treelets [Lee, Nadler & Wasserman, 2008]
• Spectral graph wavelets [Hammond, Vandergheynst & Gribonval, 2010]
• Tree wavelets [Gavish, Nadler & Coifman, 2010]
• Laplacian eignevector based wavelets [Irion & Saito, 2015]

3/32 .

3/32

.

Wavelets on graphs

← →

Fast multilevel matrix algorithms

4/32 .

4/32

Multiresolution analysis

.

Fourier to Wavelets

− →

• Canonical (eigenfunctions of

translation operator / Laplacian).

• Perfectly localized in frequency.
• Perfectly delocalized in position.
• Generated from some mother

wavelet by translations and dilations.

• Localized in space and frequency.
• Much better at resolving

discontinuities.

6/32 .

6/32

.

Multiresolution on R: wavelets

• 1. Define the mother wavelet ψ.
• 2. Define the basis

ψℓ

m(x) = 2−ℓ/2 ψ(2−ℓx − m)

• 3. The wavelet transform of a function f is

f(x) = ∑

ℓ,m αℓ

mψℓ m(x) + ∑

m βmφm(x)

7/32 .

7/32

.

More abstractly...

Repeatedly split the space of functions on X into the direct sum of a

• Scaling space Vℓ+1 (with basis

{ φℓ

m

}

)

• Wavelet space Wℓ+1 (with basis

{ ψℓ

m

}

). The key to fast wavelet transforms is the that each orthogonal map

Vℓ → Vℓ+1 ⊕ Wℓ+1

is a very sparse.

8/32 .

8/32

.

Multiresolution on R

Mallat [1989] showed (roughly) that if

• 1. ∩

j Vℓ = {0},

• 2. ∪

ℓ Vℓ is dense in L2(R),

• 3. If f ∈ Vℓ then f′(x) = f(x − 2ℓm) is also in Vℓ for any m ∈ Z,
• 4. If f ∈ Vℓ, then f′(x) = f(2x) is in Vℓ−1,

then there is a mother wavelet ψ and a father wavelet φ s. t.

ψℓ

m = 2−ℓ/2 ψ(2−ℓx − m)

and

φℓ

m = 2−ℓ/2 φ(2−ℓx − m).

9/32 .

9/32

.

Multiresolution on discrete spaces

Which of the ideas from classical multiresolution still make sense?

• Repeatedly split L(X) into smoother and rougher parts. ✓
• Basis functions should be localized in space & frequency. ✓
• Each Φℓ

Qℓ

− → Φℓ+1 ∪ Ψℓ+1 transform is orthogonal and sparse. ✓

• Each ψℓ

m is derived by translating ψℓ → MAYBE

• Each ψℓ is derived by scaling ψ → ???

10/32 .

10/32

.

General principles

• 1. The sequence L(X) = V0 ⊃ V1 ⊃ V2 ⊃ . . . is a filtration of Rn in terms
• f smoothness with respect to T in the sense that

µℓ = inf

f∈Vℓ\{0} ⟨f, Tf⟩ / ⟨f, f⟩

increases at a given rate.

• 2. The wavelets are localized in the sense that

inf

x∈X sup y∈X

ψℓ

m(y)

d(x, y)α

increases no faster than a certain rate.

• 3. Letting Qℓ be the matrix expressing Φℓ∪Ψℓ in the previous basis Φℓ−1, i.e.,

φℓ

m = ∑dim(Vℓ−1) i=1

[Qℓ]m,i φℓ−1

i

ψℓ

m = ∑dim(Vℓ−1) i=1

[Qℓ]m+dim(Vℓ−1),i φℓ−1

i

,

each Qℓ orthogonal transform is sparse, guaranteeing the existence of a fast wavelet transform (Φ0 is taken to be the standard basis, φ0

m = em).

11/32 .

11/32

Multiresolution Matrix Factorization (MMF)

.

Classical approach: Define wavelets

− →

Derive FWT MMF approach: Prescribe form of FWT

− →

Wavelets fall out

13/32 .

13/32

.

Multiresolution Matrix Factorization

( . ) QL . . . ( . ) Q1 ( .

.

) A ( . ) Q⊤

1

. . . ( . ) Q⊤

L

≈ ( . ) H

• Each Qℓ is super-sparse (Givens rotation or k–point rotation).
• For some nested sequence of sets [n] = S1 ⊇ S2 ⊇ . . . ⊇ SL+1,

[Qℓ][n]\Sℓ, [n]\Sℓ = In−δℓ−1.

• H is core-diagonal.

Here A can be the Laplacian of a graph or any symmetric matrix.

14/32 .

14/32

.

Multiresolution Matrix Factorization

( .

.

) A ≈ ( . ) Q⊤

1

. . . ( . ) Q⊤

L

( . ) H ( . ) QL . . . ( . ) Q1

The columns of Q⊤

1 Q⊤ 2 . . . Q⊤ L are a

• Wavelet basis for the column space of A.
• A multilevel sparse dictionary (hierarchically sparse PCA).

MMF structure is a generalization of the notion of rank.

15/32 .

15/32

.

Computation

MMF reduces find the wavelet basis to an optimization problem minimize

[n] ⊇ S1 ⊇ . . . ⊇ SL H∈Hn

SL; Q1, . . . , QL∈ Q

∥ A − Q⊤

1 . . . Q⊤ L H QL . . . Q1 ∥2

Frob.

for a given class Q of local rotations and dimensions δ1 ≥ δ2 ≥ . . . δL. Natural greedy optimization approach:

A → Q1AQ⊤

1 → Q2Q1AQ⊤ 1 Q⊤ 2 → . . . .

In practice combined with randomization and othe tricks to make it fast.

16/32 .

16/32

.

Hierarchical structure

The sequence in which MMF (with k ≥ 3) eliminates dimensions induces a (soft) hierarchical clustering amongst the dimensions (mixture of trees).

17/32 .

17/32

.

Applications

• 1. Generate a wavelet bass for graphs/matrices.
• 2. Reveal structural properties of graphs (communities).
• 3. Generate graphs with hierarchical structure.
• 4. Compress graphs and matrices (sketching).
• 5. Fast approximate matrix inverse → preconditioner.
• 6. Hierachical scaffold for other fast numerics.

18/32 .

18/32

.

Relationship to other algorithms

• Treelets [Lee, Nadler & Wasserman, 2008]: special case with k = 2 and

heuristic approach.

• Diffusion wavelets [Coifman and Maggioni, 2006]: fual approach – focus
• n smoothness rather than sparsity (leads to repeated Gram–Schmidt).
• Fast multipole methods [Greengard & Rokhlin, 1987–] Aggregate at

different scales.

• Multigrid [Brandt, 1970s–] Solve complex problems at multiple scales that

communicate with each other.

• Hierarchical Matrices [Hackbusch, Borm, Chandrasekaran,…]

H–matrices, H2–matrices, HSS matrices,...

19/32 .

19/32

The pMMF library

.

Highly optimized open source parallel C++ library:

• Custom sparse matrix classes
• Blocked matrices → parallelism
• Randomization, etc..
• Interface: C++ API/Matlab/command line/GUI.

http://people.cs.uchicago.edu/ risi/MMF/index.html

21/32 .

21/32

.

Blocking and stages

Rows/columns are clustered, matrix is correspondingly blocked, and rotations are found within clusters. A run of rotations conforming to the same clustering structure is called a stage. .

• A

→

.

• Q⊤

1

·

.

• A

·

.

• Q⊤

1

Different columns of blocks (“towers”) can be sent to different processors.

22/32 .

22/32

.

Reblocking

After the stage is complete, rows/columns are reclustered. It is critical that reblocking also be efficient. .

→

. . . . .

→

. . . . .

→

.

→

.

→

.

23/32 .

23/32

.

Matrix Free Arithmetic

When applying an MMF factorization to a vector, the vector must go through the same reblocking process.

. . .

.

• Q3

.

• Q2

.

• Q1

.

• v

24/32 .

24/32

.

Graph demo

25/32 .

25/32

.

Compression results

26/32 .

26/32

.

Preconditioning results

27/32 .

27/32

.

Wall clock time

28/32 .

28/32

.

Further Applications

[Meneveau] [Lieberman-Aiden et al., 2009]

29/32 .

29/32

CONCLUSIONS

.

Conclusions

• Matrices coming from data are usually NOT like
• Random matrices
• Worst case matrices
• Low rank matrices.
• Large–scale problems can only be solved by breaking them into smaller
• nes.
• In Applied Math there is a long tradition of this, but not obvious how to translate

it to less structured setting.

• MMF is a way to find the multiresolution structure in data and exploit it for both

computational and statistical ends.

• Multiresolution structure is an alternative to the notion of rank.

31/32 .

31/32

.

Acknowledgements

Co-authors:

• Nedelina Teneva (UChicago)
• Pramod Mudrakarta (UChicago)
• Vikas Garg (MIT)

Thanks:

• Andreas Krause and Joel Tropp.

32/32 .

32/32
