Spatial Cognition 2016 MULTIMODAL SEMANTIC SIMULATIONS OF LINGUISTICALLY UNDERSPECIFIED MOTION EVENTS Nikhil Krishnaswamy and James Pustejovsky, Brandeis University August 5, 2016, Spatial Cognition 2016, Philadelphia, PA, USA Remarkable

slide-1
SLIDE 1

Spatial Cognition 2016

MULTIMODAL SEMANTIC SIMULATIONS OF LINGUISTICALLY UNDERSPECIFIED MOTION EVENTS

Nikhil Krishnaswamy and James Pustejovsky, Brandeis University August 5, 2016, Spatial Cognition 2016, Philadelphia, PA, USA

slide-2
SLIDE 2

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Foundations

  • Remarkable number of concepts in human mental model
  • Mental models are adaptable
  • Can make sense of new situations, contexts, and

kinds of knowledge

  • Can be revised based on new experience
  • Mental models are embodied and multimodal
  • Embodiment maps concepts between domains
  • Modalities (perceptual and effector) constitute

aspects of representation

  • “Simulation”: mental instantiation of an utterance, based
  • n embodiment

August 5, 2016 Philadelphia, PA, USA

2

slide-3
SLIDE 3

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Past/Related Research

  • Spatial/temporal algebraic interval logic
  • Allen Temporal Relations (Allen, 1983)
  • Region Connection Calculus (RCC8) (Randell et al., 1992)
  • RCC-3D (Albath, et al., 2010)
  • Generative Lexicon, DITL (Pustejovsky, 1995; Pustejovsky and

Moszkowicz, 2011)

  • Static scene generation
  • WordsEye (Coyne and Sproat, 2001)
  • LEONARD (Siskind, 2001)
  • Stanford NLP Group (Chang et al., 2015)
  • QSR/Game AI approaches to scenario-based simulation (Forbus et al.,

2001; Dill, 2011)

  • Spatial constraint mapping to animation (Bindiganavale and Badler, 1998)

August 5, 2016 Philadelphia, PA, USA

3

slide-4
SLIDE 4

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Allen T emporal Relations

August 5, 2016 Philadelphia, PA, USA

4

slide-5
SLIDE 5

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Region Connection Calculus

August 5, 2016 Philadelphia, PA, USA

5

slide-6
SLIDE 6

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

WordsEye

August 5, 2016 Philadelphia, PA, USA

6

slide-7
SLIDE 7

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Cognitive Linguistic Simulation

August 5, 2016 Philadelphia, PA, USA

7

“Enterp the parking lot” Path depends on bounds of parking lot “Enter” is a path verb (Pustejovsky and Moszkowicz, 2011)

slide-8
SLIDE 8

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Cognitive Linguistic Simulation

August 5, 2016 Philadelphia, PA, USA

8

“Hurrym to the car” Path depends on location of car “Hurry” is a manner of motion verb (Pustejovsky and Moszkowicz, 2011)

slide-9
SLIDE 9

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Events as Programs

  • Path verbs designate a distinguished

value in the state-to-state location change

  • Change in value is tested
  • Manner of motion verbs iterate a state-

to-state location change

  • Change in value is assigned/reassigned
  • Verbs can be realized as programs

enacted over arguments (Naumann, 1999)

August 5, 2016 Philadelphia, PA, USA

9

slide-10
SLIDE 10

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Events as Programs

  • Programs are compositional
  • Program’s linguistic representation can be

broken down into subevents

  • Simple programs
  • translocate, rotate, grasp, hold, release, etc.
  • Complex programs
  • put, stack, etc.

August 5, 2016 Philadelphia, PA, USA

10

slide-11
SLIDE 11

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

VoxML

  • VoxML:

Visual Object Concept Modeling Language (Pustejovsky and Krishnaswamy, 2016)

  • Annotation and modeling language for “voxemes”
  • Visual instantiation of a lexeme
  • Scaffold for mapping from lexical information to

simulated objects and operationalized behaviors

  • Encodes afforded behaviors for each object
  • Gibsonian - afforded by object structure (e.g. grasp,

move, lift) (Gibson, 1977; 1979)

  • Telic - goal-directed, purposeful (e.g. drink from)

(Pustejovsky, 1995)

August 5, 2016 Philadelphia, PA, USA

11

slide-12
SLIDE 12

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

VoxML

August 5, 2016 Philadelphia, PA, USA

12

slide-13
SLIDE 13

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

VoxML

August 5, 2016 Philadelphia, PA, USA

13

slide-14
SLIDE 14

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

VoxSim: Software Architecture

August 5, 2016 Philadelphia, PA, USA

14

We begin by inpu+ng a sentence in plain English

Put the spoon in the mug

slide-15
SLIDE 15

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

VoxSim: Software Architecture

August 5, 2016 Philadelphia, PA, USA

15

From a dependency parse, we extract labeled en<<es in the scene, and verbs those en<<es may afford

Put the spoon in the mug put [in] mug spoon Voxeme: PROGRAM Voxeme: RELATION(OBJECT) Voxeme: OBJECT

slide-16
SLIDE 16

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

VoxSim: Software Architecture

August 5, 2016 Philadelphia, PA, USA

16

Resolve the parsed sentence into a predicate-logic formula

Voxeme: PROGRAM Voxeme: RELATION(OBJECT) Voxeme: OBJECT put spoon [in] mug put(x,y) x := spoon y := in(z) z: = mug put(spoon,in(mug))

slide-17
SLIDE 17

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

VoxSim: Software Architecture

August 5, 2016 Philadelphia, PA, USA

17

Each predicate is opera<onalized according to its type structure

put(spoon,in(mug))

  • in(z): takes object,
  • utputs location
  • put(x,y): path verb
  • while(!at(y), move(x))
slide-18
SLIDE 18

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Semantic Processing

August 5, 2016 Philadelphia, PA, USA

18

  • Object bounds may not

contour to geometry

  • e.g. Concave objects
  • Semantic information

imposes further constraints

  • “in cup”: (PO | TPP | NTPP)

with area denoted by cup’s interior

  • Interpenetrates bounds,

but not geometry

slide-19
SLIDE 19

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Semantic Processing

August 5, 2016 Philadelphia, PA, USA

19

  • Can test be satisfied

with current object configuration?

  • Can test be satisfied

by reorienting

  • bjects?
  • Can test be satisfied

at all?

slide-20
SLIDE 20

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Rig Attachment

August 5, 2016 Philadelphia, PA, USA

20

  • Temporary parent-child relationship between joint on rig

and manipulated object

  • Allows agent and object to move together
  • “Object model” + “Action model” = “Event model”
slide-21
SLIDE 21

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Demo

August 5, 2016 Philadelphia, PA, USA

21

slide-22
SLIDE 22

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Discussion

August 5, 2016 Philadelphia, PA, USA

22

  • Platform for incorporating motion/dynamic semantics

into visualization

  • Visualization → Simulation → Minimal Model
  • Runtime visualization generation necessitates assigning

values in the simulation to parameters unspecified in minimal model

  • e.g. speed, direction, etc.
  • Complete set of primitive programs in a particular

domain unknown

slide-23
SLIDE 23

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Future Work

August 5, 2016 Philadelphia, PA, USA

23

  • Monte-Carlo simulation generation with multiple

evaluation tasks

  • Given visualization with randomly-assigned

underspecified variables, choose best description

  • Given description, choose best visualization from

randomly-generated set

  • Automatic evaluation of actual simulation result vs.

DITL-derived satisfaction conditions

  • Corpus building for linked videos and simulations with

event labels for machine learning of event classification

slide-24
SLIDE 24

Spatial Cognition 2016

Nikhil Krishnaswamy | nkrishna@brandeis.edu

Acknowledgments

August 5, 2016 Philadelphia, PA, USA

24

Brandeis University Student Workers Jessica Huynh Paul Kang Subahu Rayamajhi Amy Wu Beverly Lum Victoria Tran
