Multi-Level Languages are Generalized Arrows

Adam Megacz 12-Apr-2011 1/38

Lambda Calculus Review

τ := Int | τ->τ | . . . e := x | e e | λx.e [Var] x:τ ⊢ x:τ Γ, x:τ1 ⊢ e:τ2 [Lam] Γ ⊢ (λx.e):τ1->τ2 Γ1 ⊢ e1:τ1 Γ2 ⊢ e2:τ1->τ2 [App] Γ1, Γ2 ⊢ e2e1:τ2 3/38

Flattening, in Detail

What follows is the simplified translation, which works only when higher-order functions are not used. Specifically, the context (area to the left of the turnstile) may not contain any variables with ->’s in their types. 5/38

Flattening, in Detail

Let’s try an example. We’re going to flatten this expression: subtract_second_from_third :: Int -> (Int -> (Int -> Int)) subtract_second_from_third x y z = z - y But first, we need to desugar it. The expression above is really just syntactic sugar for this: subtract_second_from_third = \x -> \y -> \z -> (-) z y Also, note that this expression has (-) as a free variable, with the following type: (-) :: Int -> Int -> Int We’ll come back to this. 7/38

Flattening, in Detail

Let’s try an example. We’re going to flatten this expression: subtract_second_from_third :: Int -> (Int -> (Int -> Int)) subtract_second_from_third x y z = z - y But first, we need to desugar it. The expression above is really just syntactic sugar for this: subtract_second_from_third = \x -> \y -> \z -> (-) z y Also, note that this expression has (-) as a free variable, with the following type: (-) :: Int -> Int -> Int We’ll come back to this. 7/38

Flattening, in Detail

Let’s try an example. We’re going to flatten this expression: subtract_second_from_third :: Int -> (Int -> (Int -> Int)) subtract_second_from_third x y z = z - y But first, we need to desugar it. The expression above is really just syntactic sugar for this: subtract_second_from_third = \x -> \y -> \z -> (-) z y Also, note that this expression has (-) as a free variable, with the following type: (-) :: Int -> Int -> Int We’ll come back to this. 7/38

Flattening, in Detail

The (simplified) flattening process involves six steps:

• 1. Construct the proof that the expression is well-typed
• 2. Skolemize the proof
• 3. Make contraction, and exchange explicit in the proof
• 4. Make left and right expansion explicit in the proof
• 5. Make weakening explicit in the proof
• 6. Walk the proof

In practice, steps 2-5 are performed simultaneously as one big step. In these slides they are presented as separate steps in an order which keeps each of the proofs small enough to fit on a slide. 9/38

Flattening, in Detail

The (simplified) flattening process involves six steps:

• 1. Construct the proof that the expression is well-typed
• 2. Skolemize the proof
• 3. Make contraction, and exchange explicit in the proof
• 4. Make left and right expansion explicit in the proof
• 5. Make weakening explicit in the proof
• 6. Walk the proof

In practice, steps 2-5 are performed simultaneously as one big step. In these slides they are presented as separate steps in an order which keeps each of the proofs small enough to fit on a slide. 9/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 1: Construct the Proof

subtract_first_from_third = \x -> \y -> \z -> ((-) z) y

λx λy λz app app (-) z y [Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

11/38

Step 2: Skolemize the Proof

Now, we skolemize the proof to eliminate function types a->b. Wherever an expression of function type appears to the right of the turnstile, like this: Γ ⊢ e:α->β 12/38

Step 2: Skolemize the Proof

Now, we skolemize the proof to eliminate function types a->b. Wherever an expression of function type appears to the right of the turnstile, like this: Γ ⊢ e:α->β we will add a new skolem variable with a fresh name to the left of the turnstile and apply the expression to it, like this: a:α, Γ ⊢ e a:β 12/38

Step 2: Skolemize the Proof

Now, we skolemize the proof to eliminate function types a->b. Wherever an expression of function type appears to the right of the turnstile, like this: Γ ⊢ e:α->β we will add a new skolem variable with a fresh name to the left of the turnstile and apply the expression to it, like this: a:α, Γ ⊢ e a:β Repeated application of the procedure above will leave us with a proof which has no ->’s to the right of the turnstile. 12/38

Skolemizing Lam

y:α, Γ ⊢ e:β [Lam] Γ ⊢ (λy.e):α->β 13/38

Skolemizing Lam

y:α, Γ ⊢ e:β [Lam] Γ ⊢ (λy.e):α->β Notice what happens to the Lam rule when we skolemize it: y:α, Γ ⊢ e:β [Skolemized-Lam] a:α, Γ ⊢ (λy.e) a:β 13/38

Skolemizing Lam

y:α, Γ ⊢ e:β [Lam] Γ ⊢ (λy.e):α->β Notice what happens to the Lam rule when we skolemize it: y:α, Γ ⊢ e:β [Skolemized-Lam] a:α, Γ ⊢ (λy.e) a:β Because (λy.e) a reduces via β-reduction to e[y := a], Skolemized-Lam is nothing more than variable renaming. We can eliminate it entirely by changing the names of the variables in the proof tree above it: . . . y:α, Γ ⊢ e:β Γ ⊢ (λy.e):α->β ⇒ . . . y:α, Γ ⊢ e:β a:α, Γ ⊢ (λy.e) a:β ⇒ . . . [y:=a] a:α, Γ ⊢ e[y:=a]:β 13/38

Skolemizing App

Something interesting happens to the App rule, as well: Γ1 ⊢ e:α Γ2 ⊢ f:α->β [App] Γ1, Γ2 ⊢ f e:β Γ1 ⊢ e:α a:α, Γ2 ⊢ f a:β [App] Γ1, Γ2 ⊢ f e:β Look at what happens if we erase the variable names and expressions: Γ1 ⊢ α α, Γ2 ⊢ β [App] Γ1, Γ2 ⊢ β This is none other than the famous cut rule from logic! Main Idea: if an expression does not use higher-order functions, we can skolemize its proof to obtain one with no Lam rules or ->’s, and in which the App rules are natural-deduction cuts. 14/38

Step 2: Skolemize the Proof

Here is our proof again, showing in red the parts which will be removed by skolemization:

[Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

15/38

Step 2: Skolemize the Proof

Here is our proof again, showing in red the parts which will be removed by skolemization:

[Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int ⊢ (-) : Int->Int->Int [App] z : Int ⊢ (-) z:Int->Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int [Lam] x:Int, y:Int ⊢ \z -> (-) z y:Int->Int [Lam] x:Int ⊢ \y -> \z -> (-) z y:Int->(Int->Int) [Lam] ⊢ \x -> \y -> \z -> (-) z y:Int->(Int->(Int->Int))

And here what is left after skolemizing it; the skolem variables are shown in red.

[Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int a : Int, b:Int ⊢ (-) a b : Int [App] b:Int, z : Int ⊢ (-) z b:Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int

15/38

Step 3: Make Contraction and Exchange Explicit

You’ll notice that I played fast and loose with the order of the variables in the context; we must now use explicit rules to re-arrange the context. Here is the rule for exchange:

A, B ⊢ C [Exch] B, A ⊢ C

And here is our proof with exchange made explicit:

[Var] y:Int ⊢ y:Int [Var] z:Int ⊢ z:Int a : Int, b:Int ⊢ (-) a b : Int [App] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int [App] x:Int, y:Int, z:Int ⊢ (-) z y:Int

16/38

Step 4: Make Left and Right Expansion Explicit

Our [App] rule looks like this: A ⊢ B X, B ⊢ C [App] X, A ⊢ C Notice that in the hypotheses, the “inner pair” don’t match. We would prefer to use [App’], which requires that they do match: A ⊢ B B ⊢ C [App’] A ⊢ C A ⊢ B [Left] X, A ⊢ X, B A ⊢ B [Right] X, A ⊢ B, X We can rewrite any use of [App] using [App’] and [Left] or [Right]: A ⊢ B [Left] X, A ⊢ X, B X, B ⊢ C [App’] X, A ⊢ C 17/38

Step 4: Make Left and Right Expansion Explicit

Here is what our proof looks like with [App’] instead of [App] and explicit [Left] and [Right]:

[Var] y:Int ⊢ y:Int [Right] y:Int, z:Int ⊢ y:Int, z:Int [Var] z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int . . . b : Int, z:Int ⊢ (-) z b : Int [App’] x:Int, y:Int, z : Int ⊢ (-) z y:Int

18/38

Step 5: Make Weakening Structurally Explicit

Finally, you’ll notice that although we never used the variable y, I never explicitly threw it away. We will now do that using the [Weak] rule:

[Weak] q:α ⊢

Here is the result:

[Weak] x:Int ⊢ [Right] x:Int, y:Int, z:Int ⊢ , y:Int, z:Int [Var] y:Int ⊢ y:Int [Left] z:Int, y:Int ⊢ z:Int, y:Int [Var] z:Int ⊢ z:Int [Left] b:Int, z:Int ⊢ b:Int, z:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int . . . b : Int, z:Int ⊢ (-) z b : Int [App’] y:Int, z : Int ⊢ (-) z y:Int . . . y:Int, z : Int ⊢ (-) z y:Int [LeftUnit] , y:Int, z:Int ⊢ (-) z y:Int [App’] x:Int, y:Int, z:Int ⊢ (-) z y:Int

19/38

Step 6: Walk the Proof

Almost there! We now “walk” the proof from the bottom to the top, doing a purely local translation. Here is the rule for the translation function − on proofs, whose argument is a proof and whose result is a Haskell expression.

• .

. . H1 · · · . . . Hn [R] C

• = R
• .

. . H1

• · · ·
• .

. . Hn

• Var

= id App’ = >>> Lam = skolemized away App = skolemized away Weak = ga drop >>> Cont = ga copy >>> Exch = ga swap >>> Right = ga first Left = ga second LeftUnit = ga cancell >>> RightUnit = ga cancelr >>> LeftCancel = ga uncancell >>> RightCancel = ga uncancelr >>> Assoc = ga assoc >>> UnAssoc = ga unassoc >>> 20/38

Step 6: Walk the Proof

• [Weak]

x:Int ⊢ [Right] x:Int, y:Int, z:Int ⊢ , y:Int, z:Int [Var] y:Int ⊢ y:Int [Right] y:Int, z:Int ⊢ y:Int, z:Int [Var] z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int . . . b : Int, z:Int ⊢ (-) z b : Int [App’] y:Int, z : Int ⊢ (-) z y:Int . . . y:Int, z : Int ⊢ (-) z y:Int [LeftUnit] , y:Int, z:Int ⊢ (-) z y:Int [App’] x:Int, y:Int, z:Int ⊢ (-) z y:Int

• 21/38

Step 6: Walk the Proof

• [Weak]

x:Int ⊢ [Right] x:Int, y:Int, z:Int ⊢ , y:Int, z:Int

• >>>
• [Var]

y:Int ⊢ y:Int [Right] y:Int, z:Int ⊢ y:Int, z:Int [Var] z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int . . . b : Int, z:Int ⊢ (-) z b : Int [App’] y:Int, z : Int ⊢ (-) z y:Int . . . y:Int, z : Int ⊢ (-) z y:Int [LeftUnit] , y:Int, z:Int ⊢ (-) z y:Int

• 22/38

Step 6: Walk the Proof

(ga first

[Weak] x:Int ⊢ ) >>>

• [Var]

y:Int ⊢ y:Int [Right] y:Int, z:Int ⊢ y:Int, z:Int [Var] z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int . . . b : Int, z:Int ⊢ (-) z b : Int [App’] y:Int, z : Int ⊢ (-) z y:Int . . . y:Int, z : Int ⊢ (-) z y:Int [LeftUnit] , y:Int, z:Int ⊢ (-) z y:Int

• 23/38

Step 6: Walk the Proof

(ga first ga drop) >>>

• [Var]

y:Int ⊢ y:Int [Right] y:Int, z:Int ⊢ y:Int, z:Int [Var] z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int . . . b : Int, z:Int ⊢ (-) z b : Int [App’] y:Int, z : Int ⊢ (-) z y:Int . . . y:Int, z : Int ⊢ (-) z y:Int [LeftUnit] , y:Int, z:Int ⊢ (-) z y:Int

• 24/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>>

• [Var]

y:Int ⊢ y:Int [Right] y:Int, z:Int ⊢ y:Int, z:Int [Var] z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int . . . b : Int, z:Int ⊢ (-) z b : Int [App’] y:Int, z : Int ⊢ (-) z y:Int

• )

25/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>>

(

• [Var]

y:Int ⊢ y:Int [Right] y:Int, z:Int ⊢ y:Int, z:Int

• >>>
• [Var]

z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int

• ))

26/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>>

((ga first

[Var] y:Int ⊢ y:Int ) >>>

• [Var]

z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int

• ))

27/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>>

• [Var]

z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int [Exch] b : Int, z:Int ⊢ (-) z b : Int

• ))

28/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>> (ga swap >>>

• [Var]

z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int a : Int, b:Int ⊢ (-) a b : Int [App’] z:Int, b : Int ⊢ (-) z b:Int

• )))

29/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>> (ga swap >>>

• [Var]

z:Int ⊢ z:Int [Right] z:Int, b:Int ⊢ z:Int, b:Int

• >>> (

a : Int, b:Int ⊢ (-) a b : Int ))))

30/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>> (ga swap >>> (ga first

[Var] z:Int ⊢ z:Int ) >>> ( a : Int, b:Int ⊢ (-) a b : Int ))))

31/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>> (ga swap >>> (ga first id) >>> (

a : Int, b:Int ⊢ (-) a b : Int ))))

32/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>> (ga swap >>> (ga first id) >>> (

a : Int, b:Int ⊢ (-) a b : Int ))))

Hrm, what do we do about that annoying left-over hypothesis we mentioned earlier? 33/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>> (ga swap >>> (ga first id) >>> (

a : Int, b:Int ⊢ (-) a b : Int ))))

Hrm, what do we do about that annoying left-over hypothesis we mentioned earlier? We turn it into a variable of garrow type! 33/38

Step 6: Walk the Proof

(ga first ga drop) >>> (ga cancell >>> ((ga first id) >>> (ga swap >>> (ga first id) >>> (

a : Int, b:Int ⊢ (-) a b : Int ))))

flattened :: GArrow g (**) u => g (Int**Int) Int

• - a variable for the flattened "minus"
• > g (Int**(Int**Int)) Int
• - the resulting term

flattened minus = ga_first ga_drop >>> ga_cancell >>> ga_first id >>> ga_swap >>> ga_first id >>> minus

35/38

Boxes and Wires

flattened :: GArrow g (**) u => g (Int**Int) Int

• - a variable for the flattened "minus"
• > g (Int**(Int**Int)) Int
• - the resulting term

flattened minus = ga_first ga_drop >>> ga_cancell >>> ga_first id >>> ga_swap >>> ga_first id >>> minus

x z drop y first cancell z () y id first swap z y z y y z id first x y minus

37/38

For More Information:

http://www.cs.berkeley.edu/~megacz/garrows/ http://arxiv.org/abs/1007.2885v2 38/38
