Monitoring Weather and Climate from Space July 2017 1 EUM/SCIR/VWG/17/901618 EUMETSAT mission planning YEAR... 03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35

slide-1
SLIDE 1

1 EUM/SCIR/VWG/17/901618

July 2017

Monitoring Weather and Climate from Space

slide-2
SLIDE 2

2 EUM/SCIR/VWG/17/901618

EUMETSAT mission planning

03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 YEAR...

METEOSAT SECOND GENERATION METEOSAT THIRD GENERATION EUMETSAT POLAR SYSTEM (EPS) MTG-I-1 : IMAGERY MTG-S-1: SOUNDING MTG-I-2: IMAGERY MTG-I-3: IMAGERY MTG-S-2: SOUNDING MTG-I-4: IMAGERY METOP-SG A: SOUNDING AND IMAGERY METOP-SG B: MICROWAVE IMAGERY JASON (HIGH PRECISION OCEAN ALTIMETRY) COPERNICUS SENTINEL-3 A/B/C/D SENTINEL-4 ON MTG-S SENTINEL-5 ON METOP-SG A

03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 YEAR...

Mandatory Programmes Optional Programmes

EUMETSAT POLAR SYSTEM SECOND GENERATION (EPS-SG)

Third Party Programmes

METOP-A METOP-B METOP-C METEOSAT-8 METEOSAT-9 METEOSAT-10 METEOSAT-11 JASON-2 JASON-3 SENTINEL-6 (JASON-CS)

slide-3
SLIDE 3

3 EUM/SCIR/VWG/17/901618

EUMETSAT mission planning

JASON-2 2009 Sentinel-3 2016 JASON-CS/ SENTINEL-6 2021 JASON-3 2016 Metop-A 2007 Metop-B 2013 Metop-C 2019 Metop-SG A Sounding & Imagery 2022 Metop-SG B Microwave Imagery 2023 Sentinel-5

  • n Metop-SG A

2022 Sentinel-4

  • n MTG-S

2022 MTG-S Sounding 2023 MTG-I Imagery 2021 MSG-4 / Meteosat-11 In-orbit storage 2016 Meteosat-10 2013 Meteosat-9 2006 Meteosat-8 2004

slide-4
SLIDE 4

4 EUM/SCIR/VWG/17/901618

Current EUMETSAT satellites

METOP-A & -B (98.7° incl.) LOW EARTH, SUN-SYNCHRONOUS ORBIT EUMETSAT POLAR SYSTEM (EPS) / INITIAL JOINT POLAR SYSTEM JASON-2 & -3 (63° incl.) LOW EARTH, NON-SYNCHRONOUS ORBIT OCEAN SURFACE TOPOGRAPHY MISSION, SHARED WITH CNES/NOAA/EU METEOSAT-8 (41.5° E) GEOSTATIONARY ORBIT METEOSAT 2ND GENERATION PROVIDING IODC FROM FEBRUARY 2017 – MID-2020 METEOSAT-9, -10, -11 GEOSTATIONARY ORBIT METEOSAT 2ND GENERATION TWO-SATELLITE SYSTEM FULL DISC IMAGERY MISSION (15 MINS) (METEOSAT-10 (0°)) RAPID SCAN SERVICE OVER EUROPE (5 MINS) (METEOSAT-9 (9.5° E)) METEOSAT-11 STORED IN ORBIT (UNTIL MID-2018) SENTINEL-3 (98.65° incl.) LOW EARTH, SUN-SYNCHRONOUS ORBIT COPERNICUS SATELLITES DELIVERING MARINE AND LAND OBSERVATIONS

slide-5
SLIDE 5

5 EUM/SCIR/VWG/17/901618

Current EUMETSAT satellites

slide-6
SLIDE 6

6 EUM/SCIR/VWG/17/901618

Deploying the MSG and Metop satellites

METEOSAT SECOND GENERATION METEOSAT-8 METEOSAT-9 METEOSAT-10 METEOSAT-11 EUMETSAT POLAR SYSTEM (EPS) METOP-A METOP-B METOP-C

2025 YEAR... 2024 2023 2022 2021 2020 2019 2018 2017 2016 2015 2014 2013 2012 2011 2010 2009 2008 2007 2006 2005 2004 2003 2002 Metop-B launch 17 September 2012 Metop-A launch 19 October 2006 MSG-1 (Meteosat-8) launch 28 August 2002 MSG-2 (Meteosat-9) launch 21 December 2005 MSG-3 (Meteosat-10) launch 5 July 2012 MSG-4 (Meteosat-11) launch 15 July 2015

slide-7
SLIDE 7

7 EUM/SCIR/VWG/17/901618

Meteosat Second Generation: a two-satellite operational system

slide-8
SLIDE 8

8 EUM/SCIR/VWG/17/901618

MSG for nowcasting of severe weather: thunderstorms

slide-9
SLIDE 9

9 EUM/SCIR/VWG/17/901618

MSG for transport: aviation

Eyjafjallajökull ash cloud from 7 to 11 May 2010 (second eruption)

slide-10
SLIDE 10

10 EUM/SCIR/VWG/17/901618

MSG for confirmation of forecasts

slide-11
SLIDE 11

11 EUM/SCIR/VWG/17/901618

EUMETSAT Polar System: part of the Initial Joint Polar System shared with the US

slide-12
SLIDE 12

12 EUM/SCIR/VWG/17/901618

Impact of EUMETSAT satellites on NWP

Metop In-situ NOAA + Suomi-NPP Geostationary Other Low Earth Orbit

slide-13
SLIDE 13

13 EUM/SCIR/VWG/17/901618

Five-day forecast of cyclone Sandy landfall on the US coast by the ECMWF global model, with (left) and without (right) ingestion of observations from polar orbiting satellites, compared to the

  • perational analysis (best approximation
  • f ground truth, centre)

EPS contribution to numerical weather prediction

slide-14
SLIDE 14

14 EUM/SCIR/VWG/17/901618

Altimetry missions – past, present, future

GEOSAT 1985-1990 TOPEX-POSEIDON 1992-2006 GFO 1998-2008 ENVISAT 2002-2012 JASON-1 2001-2013 ERS-2 1995-2011 ERS-1 1991-2000 JASON-2 2008 CRYOSAT 2010 SARAL 2013 SENTINEL-3A-D 3A 2016 3B 2017 3C Before 2020 3D 20?? JASON-3 2016 HY-2A-G 2A 2011 2B 2018 2C 2018 2D 2019 2E 2021 2F 2020 2G 2022 CFOSAT 2018 JASON-CS/ SENTINEL-6 A 2020 B 2026 SWOT 2020

slide-15
SLIDE 15

15 EUM/SCIR/VWG/17/901618

Jason contributing to mean sea level observations

slide-16
SLIDE 16

16 EUM/SCIR/VWG/17/901618

Jason-3 contributing to El Nino observations

slide-17
SLIDE 17

17 EUM/SCIR/VWG/17/901618

EUMETSAT ground systems across Europe

EPS GROUND STATION SVALBARD MTP BACKUP MTG TT&C GROUND STATION CHEIA MSG GROUND STATION AND EUMETCAST UPLINK USINGEN EUMETCAST AFRICAN TURNAROUND RECEPTION STATION AND EPS BACKUP CONTROL CENTRE MADRID EUMETCAST AFRICAN TURNAROUND UPLINK NEAR PARIS EUMETSAT HEADQUARTERS MISSION CONTROL CENTRE DARMSTADT MSG BACKUP AND RANGING GROUND STATION MASPALOMAS, GRAN CANARIA MTP PRIMARY GROUND STATION EUMETCAST TURNAROUND STATION MTG TT&C GROUND STATION FUCINO ASCAT TRANSPONDER 3 YOZGAT PROVINCE ASCAT TRANSPONDER 1 ANKARA PROVINCE ASCAT TRANSPONDER 2 ESKISEHIR PROVINCE MTG GROUND STATIONS LEUK, LARIO

slide-18
SLIDE 18

18 EUM/SCIR/VWG/17/901618

Delivering time-critical data to three continents

2-10 11-50 51-200 201-500 1 User 500+ 0 User

  • 2262 users in Member States
  • 5 users in Cooperating State
  • 2779 users world-wide
4

3

EUMETCast Africa EUTELSAT 5 WEST A, C-BAND EUMETCast Europe EUTELSAT 10A, KU-BAND 23 May 2017

slide-19
SLIDE 19

19 EUM/SCIR/VWG/17/901618

  • Online access to data
  • EUMETView: visualisation service to view

EUMETSAT (Meteosat & Metop) and Copernicus Sentinel-3 marine imagery in an interactive way using an online map viewer.

19

slide-20
SLIDE 20

20 EUM/SCIR/VWG/17/901618

Online access to data

eoportal.eumetsat.int create and manage your user account, subscribe to our services navigator.eumetsat.int explore our catalogue, what and where, supporting documentation eumetcast.com learn more about our push delivery service coda.eumetsat.int download Sentinel-3 marine and atmosphere data archive.eumetsat.int

  • rder past data

eumetview.eumetsat.int visualise and explore, create layers in GIS applications

slide-21
SLIDE 21

21 EUM/SCIR/VWG/17/901618

EUMETSAT Data Centre

§ Archive dating back to 1981 § 1.0 Petabytes stored § 1.5 Petabytes retrieved annually § Raw and reprocessed data, centrally and decentrally produced § Networked with Satellite Application Facilities (SAFs) § Access online via Product Navigator

slide-22
SLIDE 22

22 EUM/SCIR/VWG/17/901618

MTG full operational configuration

MTG-I Rapid Scan Service MTG-S Sounding Service MTG-I Full Scan Service

slide-23
SLIDE 23

23 EUM/SCIR/VWG/17/901618

MTG-I imaging mission

§ Imagery mission implemented by two MTG-I satellites § Full disc imagery every 10 minutes in 16 bands § Fast imagery of Europe every 2.5 minutes § New Lightning Imager (LI) § Start of operations in 2021 § Operational exploitation: 2021-2042

slide-24
SLIDE 24

24 EUM/SCIR/VWG/17/901618

MTG-S sounding mission

§ Hyperspectral infrared sounding mission § 3D weather cube: temperature, water vapour, O3, every 30 minutes over Europe § Air quality monitoring and atmospheric chemistry in synergy with Copernicus Sentinel-4 instrument § Start of operations in 2023 § Operational exploitation: 2023-2042

slide-25
SLIDE 25

25 EUM/SCIR/VWG/17/901618

4D weather cube with MTG-I and MTG-S

§ Lightning § Convection § Winds § Atmosphere

slide-26
SLIDE 26

26 EUM/SCIR/VWG/17/901618

MTG – higher resolution imagery

Example of ash detection, SEVIRI Natural Colour RGB, 12:15 UTC, 26 November 2006 (left), MODIS True Colour RGB, 12:20 UTC, 26 November 2006

slide-27
SLIDE 27

27 EUM/SCIR/VWG/17/901618

EPS-SG full operational configuration

Metop-SG A Sounding & Imagery Metop-SG B Microwave Imagery

slide-28
SLIDE 28

28 EUM/SCIR/VWG/17/901618

EPS-SG A sounding and imagery mission

  • 1. IASI-NG

Infrared Atmospheric Sounding

  • 2. MWS

Microwave Sounding

  • 3. METImage

Visible-Infrared Imaging

  • 4. RO

Radio Occultation

  • 5. 3MI

Multi-viewing, -channel, -polarisation Imaging

  • 6. Copernicus Sentinel-5

UN/VIS/NIR/SWIR Sounding

1 4 3 6 2 5 4

slide-29
SLIDE 29

29 EUM/SCIR/VWG/17/901618

EPS-SG B microwave imagery mission

  • 1. SCA

Scatterometer

  • 2. RO

Radio Occultation

  • 3. MWI

Microwave Imaging for Precipitation

  • 4. ICI

Ice Cloud Imager

  • 5. ARGOS-4

Advanced Data Collection System

1 4 3 2 5 1 1 2

slide-30
SLIDE 30

30 EUM/SCIR/VWG/17/901618

EPS-SG mission capabilities

§ Major improvements to all EPS observation missions § Infrared and microwave sounding § Optical imagery (METImage, developed by DLR) § Scatterometer § Radio occultation § New imagery missions: § 3MI: first operational imaging polarimeter § MWI: microwave imagery of precipitation § ICI: Ice Cloud imagery

slide-31
SLIDE 31

31 EUM/SCIR/VWG/17/901618

Jason-CS

  • 1. Poseidon-4

Dual Frequency Altimeter

  • 2. AMR-C

Advanced Microwave Radiometer

  • 3. DORIS

Doppler Orbitography and Radiopositioning Integrated by Satellite

  • 4. GNSS RO

GNSS Radio Occultation

  • 5. LRA

Laser Retroreflector Array

  • 6. GNSS POD

GNSS Precise Orbit Determination (unseen on top of the satellite)

1 3 6 2 5 4

slide-32
SLIDE 32

32 EUM/SCIR/VWG/17/901618

From weather to environmental forecasting

slide-33
SLIDE 33

33 EUM/SCIR/VWG/17/901618

Third party programmes in support of Copernicus

03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 YEAR...

METEOSAT THIRD GENERATION MTG-S-1: SOUNDING MTG-S-2: SOUNDING METOP-SG A: SOUNDING AND IMAGERY JASON (HIGH PRECISION OCEAN ALTIMETRY) COPERNICUS SENTINEL-3 A/B/C/D SENTINEL-4 ON MTG-S SENTINEL-5 ON METOP-SG A

03 04 05 06 07 08 09 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 YEAR...

Monitoring Atmospheric Composition

EUMETSAT POLAR SYSTEM SECOND GENERATION (EPS-SG)

Monitoring the ocean

JASON-2 JASON-3 SENTINEL-6 (JASON-CS)

slide-34
SLIDE 34

34 EUM/SCIR/VWG/17/901618

Sentinel-3

  • 1. OLCI

Ocean and Land Colour Instrument

  • 2. SLSTR

Sea and Land Surface Temperature Radiometer

  • 3. SRAL

SAR Radar Altimeter

  • 4. MWR

Microwave Radiometer

1 3 2 4

slide-35
SLIDE 35

35 EUM/SCIR/VWG/17/901618

EUMóNOAA Cooperation

slide-36
SLIDE 36

36 EUM/SCIR/VWG/17/901618

EUMóNOAA Cooperation (1)

  • Cooperation in satellite meteorology,
  • ceanography and climate monitoring
  • Focus on operational data exchange, data

redistribution, production of climate-relevant datasets, scientific exchange, user training, coordination through multilateral partnerships (CGMS, CEOS, GEO)

slide-37
SLIDE 37

37 EUM/SCIR/VWG/17/901618

EUMóNOAA Cooperation (2)

  • Joint programmes:
  • Joint Polar System – EPS-SG and JPSS
  • Altimetry - Jason-CS/Sentinel-6
  • Data Exchange & Distribution:
  • MSG at 0deg & IODC
  • GOES-R
  • GEONETCast
  • Science:
  • Many joint science activities
slide-38
SLIDE 38

38 EUM/SCIR/VWG/17/901618

That’s it ….
