Aleksander Zdyb Modern Security Model for Linux Operating Systems Aleksander Zdyb S OFTWARE E NGINEER T IZEN P LATFORM S ECURITY a.zdyb@samsung.com https://github.com/azdyb Briefly about security requirements About Tizen operating system

slide-1
SLIDE 1

Modern Security Model for Linux Operating Systems

Aleksander Zdyb

slide-2
SLIDE 2

SOFTWARE ENGINEER TIZEN PLATFORM SECURITY

Aleksander Zdyb

a.zdyb@samsung.com https://github.com/azdyb

slide-3
SLIDE 3
  • Briefly about security requirements
  • About Tizen operating system
  • Dedicated security model
  • Application lifecycle
  • Summary

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 3/46

slide-4
SLIDE 4

ABOUT SECURITY

REQUIREMENTS

slide-5
SLIDE 5

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 5/46

(CC ) Stiftelsen Elektronikkbransjen (CC ) Intel Free Press (CC ) Sascha Müsse

slide-6
SLIDE 6

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 6/46

slide-7
SLIDE 7

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 7/46

slide-8
SLIDE 8
  • Classic approach: software acts on behalf of user to full extent
  • Usage of many kinds of privileges is more and more common
  • There is a conflict between privileges granularity

and comfort of usage and administration

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 8/34

slide-9
SLIDE 9

ABOUT TIZEN

slide-10
SLIDE 10

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 10/46

  • Modern operating system

for embedded devices

  • A Linux distribution
  • Developed by Open Source

community

  • Main contribution from Samsung

at the moment

slide-11
SLIDE 11
  • Smartphones, smartwatches,

smart TVs

  • IVI systems (In-Vehicle Infotainment)
  • And more

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 11/46

wiki.tizen.org

slide-12
SLIDE 12

TIZEN 2.x

  • Commercially released in many

Samsung's devices (smartwatches, smart TVs, smartphones)

  • Security ensured with classic

mechanisms of Linux TIZEN 3.0

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 12/46

  • Still in developent
  • Works on ODROID XU3 (arm),

MinnowBoard MAX (x86_64) and other architectures

  • Modern, dedicated security model
slide-13
SLIDE 13

SERVICES, RESOURCES

AND PRIVILEGES

slide-14
SLIDE 14

Example services and resources

  • E-mail
  • Camera
  • Networking

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 14/46

slide-15
SLIDE 15

Example services and resources

  • E-mail
  • Camera
  • Networking

Related privileges

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 15/46

  • Reading, sending messages
  • Contacts preview
  • Taking photos
  • Browsing pictures
  • Accessing remote hosts
  • Usage of different protocols
slide-16
SLIDE 16

Camera Internet Location Contacts Applications Services and resources

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 16/46

Mapy Kalkulator Przeglądarka Gra

slide-17
SLIDE 17

Camera Internet Location Contacts

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 17/46

Mapa Kalkulator Przeglądarka Gra

Access control

Applications Services and resources

slide-18
SLIDE 18

DEDICATED SECURITY MODEL

slide-19
SLIDE 19

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 19/46

  • DAC – Discretionary Access Control

(classic access control system)

  • Smack – Simplified Mandatory

Access Control Kernel (one of LSMs)

  • Cynara – dedicated privilege

checker (userspace)

Cynara DAC Smack

slide-20
SLIDE 20
  • Protects resources on filesystem
  • Access control set by owner
  • f the resource
  • Access types: r w x
  • Subject is identified by its id

and groups it belongs to

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 20/46

Larry Ewing and The GIMP

slide-21
SLIDE 21
  • Protects resources on filesystem
  • Access control set by owner
  • f the resource
  • Access types: r w x
  • Subject is identified by its id

and groups it belongs to

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 21/46

slide-22
SLIDE 22
  • Both object and subject are

identified by their labels

  • Access control is set

by administrator

  • Access types: a r w x t l

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 22/46

(GFDL) Casey Schaufler

slide-23
SLIDE 23

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 23/46

action

(a r w x l)

  • bject

(label 2)

subject

(label 1)

slide-24
SLIDE 24

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 24/46

Floor (_)

  • Read-only system

directories

  • Kernel’s helper

processes

System

  • /run, /dev, /var/log
  • System services

User

  • Home directories
  • Launcher

and users’ services

Domains are sets of labels with common prefix. There are other labels, like System::Shared, User::Home and more.

slide-25
SLIDE 25

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 25/46

  • System service keeping and

managing security policies

  • Dedicated solution for Tizen 3.0
  • Generic – can be easily deployed

in other Linux distributions

slide-26
SLIDE 26

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 26/46

Application Service Cynara

Extension

slide-27
SLIDE 27

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 27/46

Cynara

Built-in Manifests Privacy Manager Administrator

slide-28
SLIDE 28

LIFECYCLE

OF APPLICATION

slide-29
SLIDE 29

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 29/46

  • Security Manager – service

managing and configuring all of security modules in operating systems

  • Made for Tizen 3.0
  • Can be deployed in other Linux

distributions

slide-30
SLIDE 30

Security Manager is involved in:

  • installing applications – populates

Cynara's database, creates Smack labels for apps

  • launching applications – applies

security context (labels, groups) on behalf of launcher

  • managing security policies –

supports edition of policies by administrator and users (Privacy Manager)

  • managing users

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 30/46

(CC) Patrick Breen

slide-31
SLIDE 31

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 31/46

Installator Unpacking files Globally For user Security Manager Populating Cynara’s db Creating labels for apps Labelling files

Depends on configuration and privileges

manifest

Installator configures application with help from Security Manager

slide-32
SLIDE 32

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 32/46

Launcher

  • Spawns a process

Cynara

  • SM checks in Cynara what groups

to apply for process

DAC

  • SM sets effective groups to allow access

to some special files (e.g. devices)

Smack

  • SM sets a proper Smack label

for process

slide-33
SLIDE 33

Hi Cynara! Can Maps haz perms to read location? Yep, them can haz dat!

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 33/46

GPS

slide-34
SLIDE 34

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 34/46

Client User Privilege

Cynara

Client is a Smack label identifying the application One of privileges in Tizen 3.0, e.g. http://tizen.org/privilege/location Service managing protected resource (e.g. GPS location) checks in Cynara, if the access should be granted Application (e.g. maps) run with a proper label and by a given user (e.g. Suzan, uid=1001) requests access GPS location (bound to privilege http://tizen.org/privilege/location) User is an uid

  • f user running

the application

GPS

MAPS

slide-35
SLIDE 35
slide-36
SLIDE 36

Hi Cynara! Can Calculator haz Camera, if them want? No, man! No way we gib them dat!

Launcher

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 36/46

slide-37
SLIDE 37

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 37/46

Application (e.g. Camera) run with a proper label and by a given user (e.g. Susan, uid=1001) requests access to device /dev/camera

/dev/camera

Linux checks (DAC) if process belongs to a proper group (e.g. camera_users) Groups are assigned by Security Manager on every launch

slide-38
SLIDE 38

BONUSES

slide-39
SLIDE 39
  • Serving on D-Bus? We’ve got your back
  • Nether – networking access control
  • nice-lad – auditing
  • Vasum – containers

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 39/46

slide-40
SLIDE 40

SUMMARY

slide-41
SLIDE 41
  • Security of embedded systems and privacy of stored data are very important
  • Classic security mechanisms are not enough
  • Security must be taken into account from the very beginning
  • Security doesn't have to be burdensome for developers

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 41/46

slide-42
SLIDE 42

QUESTIONS?

slide-43
SLIDE 43

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 43/46

  • https://wiki.tizen.org/wiki/Main_Page
  • https://wiki.tizen.org/wiki/Security/Overview
  • https://wiki.tizen.org/wiki/Security:Cynara
  • https://wiki.tizen.org/wiki/Security:nice-lad
slide-44
SLIDE 44

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 44/46

  • https://github.com/Samsung/security-manager
  • https://github.com/Samsung/nether
  • https://github.com/Samsung/nice-lad
  • https://github.com/Samsung/vasum
  • https://github.com/Samsung/cynara
slide-45
SLIDE 45
  • https://www.flickr.com/photos/elektronikkbransjen/15523115208/
  • https://www.flickr.com/photos/intelfreepress/8047838494/
  • https://www.flickr.com/photos/saschamuesse/15563157851/
  • https://wiki.tizen.org/wiki/File:IVISimulator2.png
  • http://en.wikipedia.org/wiki/Tux#/media/File:Tux.png
  • http://en.wikipedia.org/wiki/Smack_(software)#/media/File:Smack-tux.svg

A.ZDYB | „MODERN SECURITY MODEL FOR LINUX OPERATING SYSTEMS” | BRUSSELS 2016-01-30 | 45/46

slide-46
SLIDE 46

THANKS FOR

LISTENING
