SLIDE 1
Modeling and Searching for Non-Coding RNA
W.L. Ruzzo !
http://www.cs.washington.edu/homes/ruzzo http://www.cs.washington.edu/homes/ruzzo/ courses/gs541/10sp
Modeling and Searching for Non-Coding RNA W.L. Ruzzo ! - - PowerPoint PPT Presentation
Modeling and Searching for Non-Coding RNA W.L. Ruzzo ! - - PowerPoint PPT Presentation
Modeling and Searching for Non-Coding RNA W.L. Ruzzo ! http://www.cs.washington.edu/homes/ruzzo http://www.cs.washington.edu/homes/ruzzo/ courses/gs541/10sp GENOME 541 Syllabus ! protein and DNA sequence analysis to
SLIDE 2
SLIDE 3
The Message!
Cells make lots of RNA! Functionally important, functionally diverse! Structurally complex! New tools required! !alignment, discovery, search, scoring, etc.!
10
noncoding RNA!
SLIDE 4
Rough Outline!
Today!
Noncoding RNA Examples! RNA structure prediction!
Lecture 2!
RNA “motif” models! Search!
Lecture 3!
Motif discovery! Applications!
17
SLIDE 5
RNA !
DNA: DeoxyriboNucleic Acid! RNA: RiboNucleic Acid!
Like DNA, except:! Lacks OH on ribose (backbone sugar)! Uracil (U) in place of thymine (T)! A, G, C as before!
18
uracil! thymine!
CH3!
pairs ! with A!
SLIDE 6
- Fig. 2. The arrows show the situation as it
seemed in 1958. Solid arrows represent probable transfers, dotted arrows possible
- transfers. The absent arrows (compare Fig. 1)
represent the impossible transfers postulated by the central dogma. They are the three possible arrows starting from protein.!
SLIDE 7
“Classical” RNAs!
rRNA - ribosomal RNA (~4 kinds, 120-5k nt)! tRNA - transfer RNA (~61 kinds, ~ 75 nt)! RNaseP - tRNA processing (~300 nt)! snRNA - small nuclear RNA (splicing: U1, etc, 60-300nt)! a handful of others!
SLIDE 8
A G A C U G A C G A UC A C G C A G U C A Base pairs A U C G A C A U G U
RNA Secondary Structure: "
RNA makes helices too!
26
5´ 3´
Usually single stranded!
SLIDE 9
Bacteria !
Triumph of proteins! ~ 80% of genome is coding DNA! Functionally diverse! !receptors! !motors! !catalysts! !regulators (Monod & Jakob, Nobel prize 1965)! !… !
28
SLIDE 10
Proteins catalyze & regulate biochemistry!
29
SLIDE 11
34
Alberts, et al, 3e.
Protein way Riboswitch alternative
SAM! Grundy & Henkin, Mol. Microbiol 1998 Epshtein, et al., PNAS 2003 Winkler et al., Nat. Struct. Biol. 2003
Not the only way!!
SLIDE 12
35
Alberts, et al, 3e.
Protein way Riboswitch alternatives
SAM-II!
SAM-I! Grundy, Epshtein, Winkler et al., 1998, 2003
Corbino et al., Genome Biol. 2005
Not the only way!!
SLIDE 13
36
Alberts, et al, 3e. Corbino et al., Genome Biol. 2005
Protein way Riboswitch alternatives
SAM-III!
SAM-II! SAM-I!
Fuchs et al., NSMB 2006
Grundy, Epshtein, Winkler et al., 1998, 2003
Not the only way!!
SLIDE 14
37
Alberts, et al, 3e. Corbino et al., Genome Biol. 2005
Protein way Riboswitch alternatives
Weinberg et al., RNA 2008 SAM-III! SAM-II! SAM-I! Fuchs et al., NSMB 2006 Grundy, Epshtein, Winkler et al., 1998, 2003 SAM-IV!
Not the only way!!
SLIDE 15
38
Alberts, et al, 3e.
Protein way Riboswitch alternatives
Corbino et al., Genome
- Biol. 2005
Weinberg et al., RNA 2008 SAM-III! SAM-II! SAM-I! Fuchs et al., NSMB 2006 Grundy, Epshtein, Winkler et al., 1998, 2003 SAM-IV!
Not the only way!!
Meyer, etal., BMC Genomics 2009
SLIDE 16
39
SLIDE 17
40
SLIDE 18
Riboswitches !
~ 20 ligands known; multiple nonhomologous solutions for some! dozens to hundreds of instances of each! TPP known in archaea & eukaryotes!
- ne known in bacteriophage!
- n/off; transcription/translation; splicing; combinatorial
control! In some bacteria, more riboregulators identified than protein TFs! all found since ~2003!
SLIDE 19
58
SLIDE 20
ncRNA Example: T-boxes !
SLIDE 21
ncRNA Example: 6S !
medium size (175nt)! structured! highly expressed in E. coli in certain growth conditions! sequenced in 1971; function unknown for 30 years!
SLIDE 22
6S mimics an "
- pen promoter!
Barrick et al. RNA 2005 Trotochaud et al. NSMB 2005 Willkomm et al. NAR 2005
E.coli
Bacillus/" Clostridium! Actino- bacteria! 64
SLIDE 23
65
1 10 100 1,000 23S rRNA 16S rRNA Group II intron tmRNA OLE Group I intron RNase P AdoCbl riboswitch glmS ribozyme Lysine riboswitch IMES-1 IMES-2 GOLLD HEARO Average size (nucleotides) Multistem junctions plus pseudoknots Not ribozyme Unknown function Ribozyme
LETTERS
Exceptional structured noncoding RNAs revealed by bacterial metagenome analysis
Zasha Weinberg1,2, Jonathan Perreault2, Michelle M. Meyer2 & Ronald R. Breaker1,2,3
Vol 462 |3 December 2009 |doi:10.1038/nature08586
SLIDE 24
RNAs of unusual size and complexity!
b
ACAAAATATATTACTCAACTGTCAG ATGAGCCAAAAACGCGAACTAGAA ACAAAATATATCACTCAACTATGAGCCAAAAACGCGAACTAGAA
- A. variabilis
Nostoc sp. 149530 151150 75790 HEARO HEARO
1–58 nt 1–2 nt 1–9 nt 0–39 nt 0–7 nt 0–18 nt 0–10 nt 1–6 nt 0–11 nt G A G Y R C U ACG U U R C A C C Y G R A UG Y Y Y Y A G U Y Y G C Y C U G R Y R Y Y R Y R R Y A A CAU U CG A R G R R R R A A Y Y Y Y R G R R R Stem usually has A bulge
- r A-C
mismatch Pseudoknot 0–17 nt U Y C C UC Y C UR AR G R GYY U C C A U G A 3′ integration site 0–14 nt U U A A A C A R Y R RG G R R A G U G 73% U C A CG C U G G C GA A AG G Y A A A G C G C C G A A G G 7% 5′ 0–70 nt G U C A R Y A C C C C U R AA G G G GC U U R G Y U G A C Y A
a
5′ integration site 3′ 0–1490 nt
ORF
|
66
SLIDE 25
a
GOLLD
U Y A A A Y C U R Y G CA R R Y R R G G C A U Y R A A G R G R A G U A R Pseudoknot E-loop R R R G G Y R G Y A U Y U Y U C A A A A G R R R R C R Y R R R C R C C Y Y Y A A G A A A A G U Y Y Y R G Y R Y G A A G C UA U R Y Y R G Y Y R RR Y C C A A G Y Y R G A G U A R Y Y R Y A R A R UG R U R Y U A A R A Y C G 0–129 nt (can contain tRNA) R Y R R R Y Y Y R G C C G U R E-loop 0–2 nt 0–22 nt 0–7 nt G R R U A C G U G G A A R R R R G AA A U A A U Y Y Y A A A G Y Y Y R UG U A U C U C AR U 3′ 0–3 nt 0–2 nt AR Y G R U A Y R Y Y A G Y Y R A G G G Y R A C CU R R GG R R R R R R R U A Y Y G R Y G YR GR Y Y R RUUG A G R U G R RA A Y CAAU A R G A A A R Y Y R 5′ 0–2 nt 3 nt 7 or 8 nt G G C G Y Y U A G U C Y A R A U AARC Y G A A R G R R U AAA G G U G C G Y Y R R A R R C R U A R R CA G R R G G R Y Y CA G G C G U C Pseudoknot G A U C 1–2 nt AGRR Y UGY RA RA A RU R GRY Y A U C C R R Y Y Y A Y A U U G C G U Y C A A U R Y AR A G R C U U A A A A C C G AA G G U A G Y G UA C R G G UG GU G C U G U U R Y U C CUU R Y Y Y C U AC C A R G G U U G A A G R C U U G A A R U AU G Pseudoknot Pseudoknot Pseudoknot
Variable-length hairpin Variable-length loop Zero-length connector Variable-length region 90% 97% 75% 50% Nucleotide identity Nucleotide present 75%
N N
97%
N
90% Covarying mutations Base pair annotations R: A or G, Y: C or U. nt: nucleotides Compatible mutations No mutations observed Modular sub-structure
67
b
GOLLD phage genomic DNA GOLLD phage genomic DNA 1 0.5 Bacterial cell density GOLLD RNA Mitomycin C No treatment 2 4 6 8 10 12 14 22 2 4 6 8 10 12 14 22 Hours Fraction of maximum
|
SLIDE 26
RNAs of unusual abundance!
More abundant than 5S rRNA! From unknown marine organisms!
68
! ! !
SLIDE 27
Summary: RNA in Bacteria !
Widespread, deeply conserved, structurally sophisticated, functionally diverse, biologically important uses for ncRNA throughout prokaryotic world.! Regulation of MANY genes involves RNA!
In some species, we know identities of more ribo- regulators than protein regulators!
Dozens of classes & thousands of new examples in just last 5 years!
SLIDE 28
Vertebrates!
Bigger, more complex genomes! <2% coding! But >5% conserved in sequence?! And 50-90% transcribed?! And structural conservation, if any, invisible
(without proper alignments, etc.)!
What’s going on?!
SLIDE 29
Vertebrate ncRNAs!
mRNA, tRNA, rRNA, … of course! PLUS:! snRNA, spliceosome, snoRNA, teleomerase, microRNA, RNAi, SECIS, IRE, piwi-RNA, XIST (X-inactivation), ribozymes, …!
77
SLIDE 30
MicroRNA !
1st discovered 1992 in C. elegans! 2nd discovered 2000, also C. elegans!
and human, fly, everything between!
21-23 nucleotides!
literally fell off ends of gels!
Hundreds now known in human!
may regulate 1/3-1/2 of all genes! development, stem cells, cancer, infectious diseases,…!
79
SLIDE 31
siRNA !
“Short Interfering RNA”! Also discovered in C. elegans! Possibly an antiviral defense, shares machinery with miRNA pathways! Allows artificial repression of most genes in most higher organisms! Huge tool for biology & biotech!
80
2006 Nobel Prize! Fire & Mello!
SLIDE 32
Human Predictions !
Evofold! S Pedersen, G Bejerano, A Siepel, K Rosenbloom, K Lindblad-Toh, ES Lander, J Kent, W Miller, D Haussler, "Identification and classification of conserved RNA secondary structures in the human genome." PLoS Comput. Biol., 2, #4 (2006) e33. ! 48,479 candidates (~70% FDR?)! RNAz! S Washietl, IL Hofacker, M Lukasser, A Hutenhofer, PF Stadler, "Mapping of conserved RNA secondary structures predicts thousands of functional noncoding RNAs in the human genome." Nat. Biotechnol., 23, #11 (2005) 1383-90.! 30,000 structured RNA elements ! 1,000 conserved across all vertebrates. ! ~1/3 in introns of known genes, ~1/6 in UTRs ! ~1/2 located far from any known gene! FOLDALIGN! E Torarinsson, M Sawera, JH Havgaard, M Fredholm, J Gorodkin, "Thousands of corresponding human and mouse genomic regions unalignable in primary sequence contain common RNA structure." Genome Res., 16, #7 (2006) 885-9.! 1800 candidates from 36970 (of 100,000) pairs! CMfinder! Torarinsson, Yao, Wiklund, Bramsen, Hansen, Kjems, Tommerup, Ruzzo and Gorodkin. Comparative genomics beyond sequence based alignments: RNA structures in the ENCODE regions. Genome Research, Feb 2008, 18(2):242-251 PMID: 18096747! 6500 candidates in ENCODE alone (better FDR, but still high)!
SLIDE 33
Bottom line? !
A significant number of “one-off” examples ! Extremely wise-spread ncRNA expression ! At a minimum, a vast evolutionary substrate ! New technology (e.g. RNAseq) exposing more! How do you recognize an interesting one?! Conserved secondary structure !
SLIDE 34
A G A C U G A C G A UC A C G C A G U C A Base pairs A U C G A C A U G U
RNA Secondary Structure: "
RNA makes helices too!
103
5´ 3´
Usually single stranded!
SLIDE 35
A G A C U G A C G A UC A C G C A G U C A A C A U
RNA Secondary Structure: can be fixed while sequence evolves!
104
A G C C A A A C C A UC A G G U U G G C A A C A U
G-U!
SLIDE 36
Why is RNA hard to deal with?!
A C U G C A G G G A G C A A G C G A G G C C U C U G C A A U G A C G G U G C A U G A G A G C G U C U U U U C A A C A C U G U U A U G G A A G U U U G G C U A G C G U U C U A G AG C U G U G A C A C U G C C G C G A C G G G A A A G U A A C G G G C G G C G A G U A A A C C C G A U C C C G G U G A A U A G C C U G A A A A A C A A A G U A C A C G G G A U A C G
A: Structure often more important than sequence
105
SLIDE 37
Structure Prediction"
SLIDE 38
RNA Structure !
Primary Structure: !Sequence! Secondary Structure: !Pairing! Tertiary Structure: !3D shape!
113
SLIDE 39
RNA Pairing!
Watson-Crick Pairing!
C - G ! !~ 3 kcal/mole! A - U ! !~ 2 kcal/mole!
“Wobble Pair” G - U ! !~1 kcal/mole! Non-canonical Pairs (esp. if modified)!
SLIDE 40
tRNA 3d Structure!
SLIDE 41
tRNA - Alt. Representations!
Anticodon loop! Anticodon" loop!
3’! 5’!
116
a.a.
SLIDE 42
tRNA - Alt. Representations!
Anticodon! loop! Anticodon" loop!
3’! 5’!
5’! 3’!
117
SLIDE 43
Definitions!
Sequence 5’ r1 r2 r3 ... rn 3’ in {A, C, G, T}! A Secondary Structure is a set of pairs i•j s.t.!
i < j-4, and ! ! ! no sharp turns! if i•j & i’•j’ are two different pairs with i i’, then!
j < i’, or ! i < i’ < j’ < j !
2nd pair follows 1st, or is nested within it; " no “pseudoknots.”!
SLIDE 44
RNA Secondary Structure: Examples !
119
!
C! G! G! C! A! G! U! U! U! A! U! A! C! C! G! G! U! G! U! A! G! G! C! A! G! U! U! A! C! G! G! C! A! U! G! U! U! A!
sharp turn! crossing!
- k!
G! !4! U! A! C! C! G! G! U! U! G! A! base pair! C! G! G! C! A! G! U! U! U! A! C! A! U! A! C! G! G! G! G! U! A! U! A! C! C! G! G! U! G! U! A! A! C!
SLIDE 45
Nested! Pseudoknot! Precedes!
SLIDE 46
Approaches to Structure Prediction!
Maximum Pairing" + works on single sequences" + simple"
- too inaccurate!
Minimum Energy" + works on single sequences"
- ignores pseudoknots "
- only finds “optimal” fold!
Partition Function" + finds all folds"
- ignores pseudoknots!
SLIDE 47
Nussinov: Max Pairing!
B(i,j) = # pairs in optimal pairing of ri ... rj! B(i,j) = 0 for all i, j with i j-4; otherwise! B(i,j) = max of:!
B(i,j-1)! max { B(i,k-1)+1+B(k+1,j-1) | " i ! k < j-4 and rk-rj may pair}!
R Nussinov, AB Jacobson, "Fast algorithm for predicting the secondary structure of single-stranded RNA." PNAS 1980.
SLIDE 48
“Optimal pairing of ri ... rj”"
Two possibilities!
j Unpaired: " Find best pairing of ri ... rj-1! j Paired (with some k):" Find best ri ... rk-1 + " best rk+1 ... rj-1 plus 1! Why is it slow? " Why do pseudoknots matter?!
j i j-1 j k-1 k i j-1 k+1
SLIDE 49
Nussinov: " A Computation Order!
B(i,j) = # pairs in optimal pairing of ri ... rj! B(i,j) = 0 for all i, j with i j-4; otherwise! B(i,j) = max of:!
B(i,j-1)! max { B(i,k-1)+1+B(k+1,j-1) | " i ! k < j-4 and rk-rj may pair}!
Time: O(n3)!
K=2! 3! 4! 5!
SLIDE 50
Which Pairs? !
Usual dynamic programming “trace-back” tells you which base pairs are in the optimal solution, not just how many!
SLIDE 51
Approaches to Structure Prediction!
Maximum Pairing" + works on single sequences" + simple"
- too inaccurate!
Minimum Energy" + works on single sequences"
- ignores pseudoknots "
- only finds “optimal” fold!
Partition Function" + finds all folds"
- ignores pseudoknots!
SLIDE 52
Pair-based Energy Minimization !
E(i,j) = energy of pairs in optimal pairing of ri ... rj! E(i,j) = ! for all i, j with i j-4; otherwise! E(i,j) = min of:!
E(i,j-1)! min { E(i,k-1) + e(rk, rj) + E(k+1,j-1) | i ! k < j-4 }!
Time: O(n3)! energy of k-j pair!
SLIDE 53
Loop-based Energy Minimization!
Detailed experiments show it’s " more accurate to model based "
- n loops, rather than just pairs!
Loop types!
- 1. Hairpin loop!
- 2. Stack!
- 3. Bulge!
- 4. Interior loop!
- 5. Multiloop!
1 2 3 4 5
SLIDE 54
Zuker: Loop-based Energy, I!
W(i,j) = energy of optimal pairing of ri ... rj! V(i,j) = as above, but forcing pair i•j! W(i,j) = V(i,j) = ! for all i, j with i j-4! W(i,j) = min( W(i,j-1)," min { W(i,k-1)+V(k,j) | i ! k < j-4 } !! !)!
SLIDE 55
Zuker: Loop-based Energy, II !
V(i,j) = min(eh(i,j), es(i,j)+V(i+1,j-1), VBI(i,j), VM(i,j))! VM(i,j) = min { W(i,k)+W(k+1,j) | i < k < j } ! VBI(i,j) = min { ebi(i,j,i’,j’) + V(i’, j’) |" i < i’ < j’ < j & i’-i+j-j’ > 2 }!
!Time: O(n4) ! O(n3) possible if ebi(.) is “nice”!
hairpin! stack! bulge/! interior! multi-! loop! bulge/! interior!
SLIDE 56
Energy Parameters!
- Q. !Where do they come from?!
- A1. Experiments with carefully selected
synthetic RNAs!
- A2. Learned algorithmically from trusted
alignments/structures [Andronescu et al., 2007]!
SLIDE 57
Single Seq Prediction Accuracy!
Mfold, Vienna,... [Nussinov, Zuker, Hofacker, McCaskill]! Estimates suggest ~50-75% of base pairs predicted correctly in sequences of up to ~300nt! Definitely useful, but obviously imperfect!
SLIDE 58
Approaches to Structure Prediction!
Maximum Pairing" !+ works on single sequences" !+ simple" !- too inaccurate! Minimum Energy" !+ works on single sequences" !- ignores pseudoknots " !- only finds “optimal” fold! Partition Function" !+ finds all folds" !- ignores pseudoknots!
SLIDE 59
Approaches, II!
Comparative sequence analysis" !+ handles all pairings (potentially incl. pseudoknots)" !- requires several (many?) aligned," ! appropriately diverged sequences! Stochastic Context-free Grammars" Roughly combines min energy & comparative, but no pseudoknots! Physical experiments (x-ray crystalography, NMR)!
SLIDE 60
Summary!
RNA has important roles beyond mRNA! !Many unexpected recent discoveries! Structure is critical to function! !True of proteins, too, but they’re easier to find from sequence alone due, e.g., to codon structure, which RNAs lack! RNA secondary structure can be predicted (to useful accuracy) by dynamic programming! Next: RNA “motifs” (seq + 2-ary struct) well- captured by “covariance models”!
139
