Model Synchronization with the Role-oriented Single Underlying Model Model Synchronization Multiple models express different concerns of interrelated trans concepts S T Interrelated concepts lead to much related models Related

slide-1
SLIDE 1

Model Synchronization with the Role-oriented Single Underlying Model

slide-2
SLIDE 2

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 2

Model Synchronization

  • Multiple models express different concerns of interrelated

concepts

  • Interrelated concepts lead to much related models
  • Related models:
  • Contain redundant information
  • Independently editing leads to inconsistencies
  • Solution: Defining model synchronizations between

interrelated models

  • Unidirectional synchronization
  • Bidirectional synchronization

S T

trans

S T S T

slide-3
SLIDE 3

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 3

Model Synchronization at Runtime

Currently often used:

  • Manually triggering of the synchronization process
  • Batch updates of the whole model
  • Specification of Synchronization rules at design time
  • Synchronization of two models

Runtime model synchronization:

  • Automatically triggering of the synchronization process

(immediate and continuous updates at runtime)

  • Incremental updates of small changes
  • Specification of models/views from the single underlying

model (SUM) at runtime (add and remove models/views at runtime)

  • Multiple models are views of underlying model

S T U S T U

RSUM

slide-4
SLIDE 4

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 4

Why Model Synchronization at Runtime?

  • Multiple related models in a self-

adaptive software system

  • This models must be hold

consistent over time

  • Needs an efficient runtime

synchronization mechanism

Knowledge Monitor Analyze Plan Execute

Managed Systems Evaluation Models Change Models Analysis Models Monitoring Models Systems Models Execution Models

slide-5
SLIDE 5

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 5

Roles in a Nutshell

Library Example [Kühn2014]

Library name: String Employee Person

name: String salary: Double

Manager Children (1..1)

0..1 1..* 0..*

Compartment Type Natural Type Role Type Fills-Relation Association

RoleGroup (n..m)

Context- Dependent Behavioral Relational

SLUB:Library

name=SLUB

Alice:Person

name=Alice salary=50000 man:Manager

Bob:Person

name=Bob salary=30000 emp:Employee

slide-6
SLIDE 6

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 6

Research Questions

Goals:

  • Simplify model synchronization between multiple runtime models with a

single underlying model

  • Flexible and extensible single underlying model approach with runtime view

creation mechanisms Requirements: 1. Incremental model synchronization 2. Runtime model synchronization 3. Runtime creation of views 4. Synchronization of multiple models 5. Integration of runtime models as views and elements in the single underlying model

Library name: String Employee Person

name: String salary: Double

Manager Children (1..1)

0..1 1..* 0..*

slide-7
SLIDE 7

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 7

Running Example

  • Two related models in the library and employee

context

  • Combination to one single underlying models
  • Related models are now only views and are

automatically synchronized with the underlying model Combination: ModelA.Person = ModelB.Person ModelA.Employee = ModelB.Employee ModelA ModelB

slide-8
SLIDE 8

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 8

Overall Concept

  • RSUM contains naturals, relational

compartments and management compartment

  • RSUMManagement manages the

instances in the RSUM and the extensions

  • RSUMManager coordinates the role

bindings

  • Runtime integration of new naturals,

relational compartments and extensions possible

  • Traceability information over the play

relations

RSUM OtherViews OtherViews EmployeeAndManagerView Library

name

Employee

salary

Person

name

LibraryHasEmployee Target Source LibraryAndEmployeeView Employee HasManager Library Employee Has OtherViews View ManagerOfEmployee Target

RoleGroup (1..1)

Source

manager employees

0..1 0..* 1 1 1 1 1 1 0..* 0..* 0..* 0..1

RsumManagement

+createView(query)

RsumManager

+manage()

Extensions

…

Extensions Extensions Extension

…

Natural Compartment Role Plays Relation RoleGroup (n..m) Role

. . .

Relation Role

1 1

n..m n..m Role n..m Role cardinality n..m

slide-9
SLIDE 9

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 9

RSUM

Concept of Relational Compartments

Relational compartments represent relations in the underlying model Advantages: 1. Loading relations at runtime (using class loader functionality from programming languages like Scala and Java) 2. Extending naturals with new relations at runtime (playing of roles in relational compartments) 3. Add behavior and states to relations (methods and attributes in relational compartments) 4. n-ary relations (more role types in the relational compartment) Limitations: 1. One relational compartment for each instance pair 2. Management of play relations of instances

Library

name

Employee

salary

LibraryHasEmployee Target Source LibraryAndEmployeeView Library Employee Has

employees

0..* 1 1 1 0..* 0..* 1

slide-10
SLIDE 10

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 10

Extension Mechanism

Extension mechanism allows adding of new functionalities to the RSUM Use cases:

  • History mechanism
  • Save changes over a period of time on one element
  • Allows logging on specific elements
  • Versioning mechanism
  • Allows UNDO and REDO operations on single model elements

Library

name

RsumManagement

+createView(query)

RsumManager

+manage()

Extensions Extensions Extensions Extension

…

slide-11
SLIDE 11

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 11

Deep Views

  • Runtime models that depend on
  • ther runtime models
  • Create a structure of deep views
  • Destruction of CompleteLibrary view

also destroys the two other views

  • Create a structure for the views
  • Insert a new abstraction layer

RSUM Library

name

Employee

salary

Person

name

LibraryHasEmployee Target Source CompleteLibraryView HasManager Library Employee Has ManagerOfEmployee Target

RoleGroup (1..1)

Source

manager employees

0..1 0..* 1 1 1 1 1 1 0..* 0..* 0..* 0..1 1 1

EmployeeAndManagerView LibraryAndEmployeeView Employee HasManager Library Employee Has

1 1 1 1 0..* 0..* 0..* 0..1

slide-12
SLIDE 12

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 12

Creation Process

Process of adding a manager relation between two employee 1. Get the naturals of the employees from the RSUM 2. Create a new ManagerOfEmployee compartment in the RSUM 3. Bind the source and target roles to the used employees 4. Create a new HasManager role in the view and bind it to the new relational compartment 5. Add a new RsumManager role for the relational compartment in the RSUMManagement

RsumM:RsumManagement EM1:ManOfEmp

T1: Target S1: Source Rm3: RsumManager

EaM: EaMView E2:Employee

name=Alice salary=45000

E1:Employee

name=Bob salary=60000 Rm2: RsumManager Rm1: RsumManager Er1: Employee Mr1: HasManager Er2: Employee

View 4 4 1 5 3 3 2 3 4 1

slide-13
SLIDE 13

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 13

Implementation with SCROLL

SCala ROLes Language (SCROLL) [Leuthäuser2015]:

  • Role-based programming language
  • Open source Scala library
  • Implements most role features [Kühn2014]
  • Flexible, lightweight, and easily extensible
  • Compartments contain role graphs

Important operators:

  • “Play” binds a role to a player
  • “+” operator before a method call performs a dynamic

dispatch to a suitable role played by the receiver Scala allows class loading for runtime integration of new relational compartments, views, and extensions class Library ( _name : String ) { private var name : String = _name def getName (): String = name def setName (n: String): Unit = { name = n } } class LibraryRole ( name : String ) extends IViewRole { def getNameView (): String = { return + this getName () } def setNameView ( name : String ): Unit = { + this setName (name) + this changeTrigger () } }

slide-14
SLIDE 14

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 14

  • bject RsumManagement extends MultiCompartment {

protected var extensions = ListBuffer [..]() protected var activeViews = ListBuffer [..]() protected var allViews = ListBuffer [..]() protected var allRelations = ListBuffer [..]() protected var allNaturals = ListBuffer [..]() /* Insertion, creation, and deletion of views */ class RsumManager () { def manageRsum (input : Object): Unit = { if ( input.isInstanceOf [IRelationCompartment]) allRelations = allRelations :+ input else allNaturals = allNaturals :+ input input play roles in activeViews and extenstions } } }

Limitations of Implementation

  • Currently hand written prototype
  • Runtime models as compartments with roles as new
  • bjects
  • Limitations from the use of relational compartments
  • No dynamic loading of roles into compartments
  • No domain specific language to describe the models

as views from the RSUM

  • Remove relations from the classes and use them as

naturals

  • Sometimes complex mechanism to combine all

models in one RSUM

slide-15
SLIDE 15

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 15

Related Work

MORSE Approach [Holmes2009]

  • Model aware service environment consisting of a model repository and model-aware services
  • Repository manages model projects and artifacts
  • Using unique ids for all elements

SM@RT Tool [Song2010]

  • Synchronization between running models and a MOF-compliant
  • Synchronizations are triggered before and after write operations

TGGs [Vogel2010]

  • Synchronize and generate runtime models with triple graph grammars
  • Incremental updates at runtime
slide-16
SLIDE 16

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 16

Comparison with View-based Approaches

EMF Profiles

[Langer2012]

mVTGG

[Anjorin2014]

OSM

[Atkinson2010]

OpenFlexo

[Golra2016]

VIATRA viewers

[Depreceni 2014]

RSUM Bidirectional updates

  • Immediate updates
  • Incremental updates
  • Virtual views

○ ○

  • Deep views

n.a.

  • ○

○

  • No object schizophrenia

○ ○ ○ ○ ○

slide-17
SLIDE 17

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 17

Conclusion & Future Work

  • Advantages of roles as the foundation for a runtime model synchronization

approach using a single underlying model

  • Runtime models as views over a single underlying model that manages the

information

  • Feasibility of the role-oriented single underlying model approach by prototypically

splitting a model into two views and synchronize them

  • Implementation with SCROLL
  • Extend the implementation to a framework
  • Use a domain specific language to create the views form the RSUM in a

simple way

  • Extend the example and show the benefits on a bigger case study

S T U

RSUM

slide-18
SLIDE 18

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 18

References (1)

[Anjorin2014] A. Anjorin, S. Rose, F. Deckwerth, and A. Schürr. 2014. “Efficient Model Synchronization with View Triple Graph Grammars”. In Modelling Foundations and Applications. Springer International Publishing, Cham, 1–17. [Atkinson2010] C. Atkinson, D. Stoll, and P . Bostan. 2010. Orthographic Software Modeling: A Practical Approach to View-Based Development. In Communications in Computer and Information Science. Springer Science & Business Media, 206–219. [Debreceni2014] C. Debreceni, Á. Horváth, Á. Hegedüs, Z. Ujhelyi, I. Ráth, and D. Varró. 2014. “Query-driven Incremental Synchronization of View Models”. In 2nd Workshop on View-Based, Aspect-Oriented and Orthographic Software Modelling. ACM. [Golra2016] F. R. Golra, A. Beugnard, F. Dagnat, S. Guerin, and C. Guychard. 2016. “Addressing Modularity for Heterogeneous Multi-model Systems Using Model Federation”. In Companion Proceedings of the 15th International Conference on Modularity. ACM, 206–211. [Holmes2009] T. Holmes, U. Zdun, and S. Dustdar. 2009. “MORSE: A Model-Aware service environment”. In 2009 IEEE Asia-Pacific Services Computing Conference (APSCC). 470–477. [Kühn2014] T. Kühn, M. Leuthäuser, S. Götz, C. Seidl, and U. Aßmann, "A Metamodel Family for Role-Based Modeling and Programming Languages," Cham: Springer International Publishing, 2014, pp. 141–160.

slide-19
SLIDE 19

Model Synchronization with the Role-oriented Single Underlying Model Software Technology Group / Werner, Christopher MRT 2018 // 14.10.2018 Folie 19

References (2)

[Langer2012] P . Langer, K. Wieland, M. Wimmer, J. Cabot, et al. 2012. “EMF Profiles: A Lightweight Extension Approach for EMF Models”. Journal of Object Technology 11, 1 (2012), 1–29. [Leuthäuser2015] M. Leuthäuser and U. Aßmann, "Enabling view-based programming with scroll: Using roles and dynamic dispatch for etablishing view-based programming," in Proceedings of the 2015 Joint MORSE/VAO Workshop

  • n Model-Driven Robot Software Engineering and View-based Software-Engineering, New York, NY, USA: ACM, 2015,
  • pp. 25–33.

[Song2010] H. Song, Y. Xiong, F. Chauvel, G. Huang, Z. Hu, and H. Mei. 2010. “Generating Synchronization Engines between Running Systems and Their Model-Based Views”. In Models in Software Engineering. Springer Berlin Heidelberg, 140–154. [Vogel2010] T. Vogel, S. Neumann, S. Hildebrandt, H. Giese, and B. Becker. 2010. “Incremental Model Synchronization for Efficient Run-Time Monitoring”. In Models in Software Engineering. Springer Berlin Heidelberg, 124–139.
