Model Structure Selection

Tartu 2008

Neuron

• Takes number of inputs
• Processes them
• Uses the result for

activation function

http://www.bordalierinstitute.com/images/ Neuron.JPG

Neural network

• Simple neural network
• Fully connected two layer

feedforward network

• Input layer
• Hidden layer
• Output layer

Recurrent networks

• Output of the hidden units

are fed back as inputs to the network

• Time delay
• Later considered networks

do not have internal feedback

System identification

• Goals

– High degree of automation – Numberical reliability – Computational effjciency

• Experiment
• Select model structure
• Estimate model
• Validate model

Experiment

• Purpose

– Data collection – Varying input(s) to observe the impact on

• uputs
• Main issues

– Choice of sampling frequency – Design of suitable input signal – Preprocessing of data (noise removal, nonlinearity tests, disturbances)

Estimate & validate model

• Neural network community -> training
• r learning
• Picking the model
• Checking the requirements

Used terms

• Poles and zeros

– Consequences

• Linear model structures
• Linearity

y(t) = G(q-1)u(t) + H(q-1)e(t)

• One-step ahead prediction:

ŷ(t|t-1) = H-1(q-1)G(q-1)u(t) + [1 - H-1(q-1)]y(t)

• True system

y(t) = G0(q-1)u(t) + H0(q-1)e0(t)

Used terms vol 2

• Model structure
• Predictor form:

Used terms vol 3

• Basic requirement:
• Model is simply a particular choice of

parameter vector, say,

Another form of a model

• Rewriting general model structure as:

The Finite Impulse Response FIR

• Simplest type, let’s choose:
• The predictor:
• The parameter vector

ARX model structure (AutoRegressive, eXternal input)

• The model corresponds to the choice:
• The predictor takes the form:
• The parameter vector is:

ARMAX model structure

(AutoRegressive, Moving Average, external input)

• Corresponds to the choice:
• The predictor takes the form:
• The parameter vector is:

Output error omdel structure OE

• Used if only noise = white

measurement noise

• Corresponding to the choice of G and

H

Output error model structure continues

• Regression vector
• Parameter vector

The State Space Innovations Form (SSIF)

• Widely used alternative
• Assume that system is described:
• Optimal one-step ahead predictor:

SSIF

• Also known as Kalman filter
• Matrix is known as Kalman gain
• Poles of the predictor:

Nonlinear Model Structures Based on Neural Networks

• Selecting model structure more

complicated

• Family of model structures -> MLP

networks

– With this choice 2 issues

• Inputs to the network
• Internal network architecture

– Often used approach  reusing input structures from linear models

Nonlinear Model Structures Based on Neural Networks

• Structural decisions are reasonable to handle
• Suitable to design control systems

NNFIR and NNARX

• Predictors are

stable

• This is important

as the stability issue is much more complex than for linear systems

• Deterministic & noise level insignificant

NNARMAX

• Despite the feedforward

network, the predictor has feedback

• Regressors:
• Recurrent network
• Stability as a local

properties

NNOE

• Some regressors are the predictions of

past outputs

• Has the same problems as NNARMAX

NNSSIF

• Like NNOE and NNARMAX
• Same problems with NNSSIF as with

SSIF

– Problem solving: two separate networks

Stability

• Very important in control theory
• Necessary that the control system is

stable

• Stability during training
• Stability

Asymptotic stability

Exponential stability
