Model Architectures and Training Techniques for High-Precision - - PowerPoint PPT Presentation

Pavlo Molchanov Stephen Tyree Jan Kautz

Model Architectures and Training Techniques for High-Precision Landmark Localization

Sina Honari Jason Yosinski Pascal Vincent Christopher Pal

2

KEYPOINT DETECTION / LANDMARK LOCALIZATION

The problem of localizing important points on images

Keypoints for human face can be:

• left/right eye
• nose
• left/right mouth corner

Applications include:

• Face alignment/rectification
• Emotion recognition
• Head pose estimation
• Person identification

3

MOTIVATION

Conventional ConvNets: alternating convolutional and max-pooling layers Max-pooled Features: loses precise spatial information, but gets robust features Networks of only Conv layers: lots of false positives, but keeps spatial information

Robustness Precision Precision False positives

Can we take robust pooled features and keep positional information?

4

SUMMATION-BASED NETWORKS (SUMNETS)

Sums features of different granularity (FCN[1], HyperColumn[2])

[1] J. Long, E. Shelhamer and T. Darrell. Fully convolutional networks for semantic segmentation. In CVPR, 2015 [2] B.Hariharan,P.Arbela ́ez,R.Girshick,andJ.Malik.Hyper- columns for object segmentation and fine-grained localization. In CVPR, 2015. C=Convolution P=Pooling U= Upsampling Branch=horizontal C, U layers

Coarse to Fine Branches

5

SUMMATION-BASED NETWORKS (SUMNETS)

Pre-softmax activations Softmax probabilities

Coarse to Fine Branches

Sum of Branches

6

SUMMATION-BASED NETWORKS (SUMNETS)

Pre-softmax activations Softmax probabilities

Coarse to Fine Branches

Sum of Branches

Recombinator Networks

Learning Coarse-to-Fine Feature Aggregation

(CVPR 2016)

Sina Honari Jason Yosinski Pascal Vincent Christopher Pal

Montreal Institue for Learning Algorithms

The model feeds coarse features into finer layers early in their computation

Recombinator Networks (RCNs)

C=Convolution P=Pooling U= Upsampling K= Concatenation Branch=horizontal C, U layers

Coarse to Fine Branches

Recombinator Networks (RCNs)

A Convolutional Encoder-Decoder Network with Skip Connections

SumNets vs. RCNs

Summation-Based Networks (SumNets) Recombinator Networks (RCNs)

Pre-softmax activations SumNet RCN

SumNets vs. RCNs

SumNet RCN Pre-softmax activations Softmax probabilities

SumNets vs. RCNs

Pre-softmax activations Softmax probabilities

Prediction Samples

TCDCN SumNet RCN

Red is model prediction Green is GT key-points

Comparison with SOTA

Landmark Estimation Error (as percent; lower is better) 300W Dataset MTFL Dataset

Error=Euclidean distance between GT & predicted key-points normalized by inter-ocular distance

15 15

Sina Honari Jan Kautz Pascal Vincent Christopher Pal Pavlo Molchanov Stephen Tyree

Improving Landmark Localization with Semi-Supervised Learning

(CVPR 2018)

16 16

MOTIVATION

Smiling

Landmarks

Fast Very time consuming

Attribute

Labeling: ~60s

Looking straight

Labeling: ~1s


Manual landmark localization is a tedious task (to build datasets)

17 17

MOTIVATION

Smiling

Landmarks

Fast Very time consuming

Attribute

Labeling: ~60s

Looking straight

Labeling: ~1s


Manual landmark localization is a tedious task (to build datasets)

Can we use an attribute (e.g. head pose) to guide landmark localization?

19 19

SEMI-SUPERVISED LEARNING 1

Using CNNs with sequential multitasking

1. First predict landmarks 2. Use predicted landmarks to predict attribute

20 20

SEMI-SUPERVISED LEARNING 1

Using CNNs with sequential multitasking

Forward pass: landmarks help attribute Backward pass

1. First predict landmarks 2. Use predicted landmarks to predict attribute 3. Get gradient from attribute to the landmark localization network

21 21

SEMI-SUPERVISED LEARNING 1

To train the entire network end-to-end we use soft-argmax to predict landmarks

Soft-argmax

Soft-argmax estimates location of the scaled centrum of mass: ü Continuous, not discrete ü Differentiable

22 22

SEMI-SUPERVISED LEARNING 2

Equivariant Landmark Transformation

Ask the model to make equivariant prediction w.r.t to image transformations

• Predict landmarks (L) on an image I
• Apply a transformation T to image I
• Predict landmarks (!′) on an image I ′
• Apply transformation T to landmarks L
• Compare !′ with $ ⊙ !
• Get gradient from ELT loss

23 23

SEMI-SUPERVISED LEARNING 2

Equivariant Landmark Transformation

Ask the model to make equivariant prediction w.r.t to image transformations

• Predict landmarks (L) on an image I
• Apply a transformation T to image I
• Predict landmarks (!′) on an image I′
• Apply transformation T to landmarks L
• Compare !′ with $ ⊙ !
• Get gradient from ELT loss

24 24

LEARNING LANDMARKS

Making use of all data

• Loss from GT Landmarks
• Loss from Attributes (A) using

Sequential Multi-tasking

• Loss from Equivariant Landmark

Transformation (ELT)

• S << M <= N

25

RESULTS

Faces

just CNN

Method Training data

100%

26

RESULTS

Faces

just CNN just CNN

Method Training data

100% 5%

27

RESULTS

Faces

Training data

100% 5% 5% just CNN semi supervised CNN just CNN

Method

28

COMPARISON WITH SOTA

Faces

5.43 4.35 4.25 4.05 3.92 3.73 2.72 2.17 2.88 2.46 2.03 1.59

1 2 3 4 5 6 C D M E R T L B F S D M C F S S R C P R C C L L v e t a l . O u r O u r + S S L O u r + S S L O u r + S S L

100% labeled data 1% 5% 100% AFLW dataset:

• 19 landmarks
• Head pose: yaw, pitch, roll
• ~25k images

Error metric

29

COMPARISON WITH SOTA

Faces

5.43 4.35 4.25 4.05 3.92 3.73 2.72 2.17 2.88 2.46 2.03 1.59

1 2 3 4 5 6 C D M E R T L B F S D M C F S S R C P R C C L L v e t a l . O u r O u r + S S L O u r + S S L O u r + S S L

100% labeled data 1% 5% 100% AFLW dataset:

• 19 landmarks
• Head pose: yaw, pitch, roll
• ~25k images

Error metric

30

COMPARISON WITH SOTA

Faces

5.43 4.35 4.25 4.05 3.92 3.73 2.72 2.17 2.88 2.46 2.03 1.59

1 2 3 4 5 6 C D M E R T L B F S D M C F S S R C P R C C L L v e t a l . O u r O u r + S S L O u r + S S L O u r + S S L

100% labeled data 1% 5% 100% AFLW dataset:

• 19 landmarks
• Head pose: yaw, pitch, roll
• ~25k images

Error metric

31

COMPARISON WITH SOTA

Faces

5.43 4.35 4.25 4.05 3.92 3.73 2.72 2.17 2.88 2.46 2.03 1.59

1 2 3 4 5 6 C D M E R T L B F S D M C F S S R C P R C C L L v e t a l . O u r O u r + S S L O u r + S S L O u r + S S L

100% labeled data 1% 5% 100% AFLW dataset:

• 19 landmarks
• Head pose: yaw, pitch, roll
• ~25k images

Error metric

32

COMPARISON WITH SOTA

Faces

RCN+ (L+ELT+A) 100% RCN+ (L+ELT+A) 1% RCN+ (L) 1%

33

CONCLUSIONS

• Fuse predictions from multiple granularity
• Let network to learn fusing method
• Additional attributes and prior improve results with semi-supervised learning
• Works with landmarks on hands as well
• Read more in our CVPR2016 paper: https://arxiv.org/abs/1511.07356 ,

and CVPR2018: https://arxiv.org/abs/1709.01591

THANK YOU!

Pavlo Molchanov pmolchanov@nvidia.com Sina Honari honaris@iro.umontreal.ca

Comparison with SOTA

Loss: Softmax loss on key-points + L2-norm Error: Euclidean distance between GT & predicted key-points normalized by inter-ocular distance

Loss & Error

Mask: 0 branch is omitted, 1 branch in included.

Masking Branches

SumNet RCN Mask AFLW AFW AFLW AFW coarse → fine 1, 0, 0, 0 10.54 10.63 10.61 10.89 0, 1, 0, 0 11.28 11.43 11.56 11.87 1, 1, 0, 0 9.47 9.65 9.31 9.44 0, 0, 1, 0 16.14 16.35 15.78 15.91 0, 0, 0, 1 45.39 47.97 46.87 48.61 0, 0, 1, 1 13.90 14.14 12.67 13.53 0, 1, 1, 1 7.91 8.22 7.62 7.95 1, 0, 0, 1 6.91 7.51 6.79 7.27 1, 1, 1, 1 6.44 6.78 6.37 6.43

SumNet RCN Coarse to Fine Coarse to Fine

Adding More Branches

SumNet RCN Coarse to Fine Coarse to Fine
