DWG NO.: ARCHITECT: RETAIL STOREFRONT MODIFICATION MISRA & ASSOCIATES P.C. 275 MADISON AVE, NEW YORK, NY 01 TITLE: ARCHITECTURE PLANNING INTERIOR DESIGN SCALE: EXISTING CORNER VIEW 174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212)

slide-1
SLIDE 1

01

N.T.S.

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

EXISTING CORNER VIEW

slide-2
SLIDE 2

DN UP UP DN

J/C

RAD

AREA OF PROPOSED EXTERIOR WORK

EAST 40TH STREET MADISON AVENUE

EXTERIOR ALTERATIONS AT ENTRANCE APPROVED UNDER LPL COFA-19-12925 DATED 07/07/2017

UP 4R UP 4R

AREA OF PROPOSED INTERIOR WORK

EXTENT OF EXISTING MEZZANINE ABOVE UP TO MEZZANINE DOWN TO CELLAR COMMERCIAL SPACE

CH 8'-1" AFF CH 15'-0" AFF

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

EXISTING FIRST FLOOR PLAN 02

1/16"=1'-0"

slide-3
SLIDE 3

EXISTING BASE ELEVATION ALONG EAST 40TH ST. 03

N.T.S.

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

AREA OF PROPOSED WORK

slide-4
SLIDE 4

04

N.T.C.

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

EXISTING STOREFRONTS

PHOTO #1

275 MADISON - RETAIL STOREFRONT ALONG EAST 40TH ST.

EXISTING BUILDING LOBBY ENTRANCE EXISTING RETAIL ENTRANCE

slide-5
SLIDE 5

EXISTING BASE ELEVATION ALONG EAST 40TH ST. 05

N.T.S.

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

slide-6
SLIDE 6

06

N.T.C.

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

EXISTING STOREFRONTS

PHOTO #1

275 MADISON - RETAIL STOREFRONTS ALONG MADISON AVE

slide-7
SLIDE 7

DN UP UP UP 4R DN

J/C

RAD

EAST 40TH STREET MADISON AVENUE

AREA OF PROPOSED EXTERIOR WORK

NEW HANDICAP LIFT PLATFORM

AREA OF PROPOSED INTERIOR WORK

A A

A-102, A-300, A-301, A-302, A-303 A-101

EXTERIOR ALTERATIONS AT ENTRANCE APPROVED UNDER LPL COFA-19-12925 DATED 07/07/2017

LANDING ELEV. +1.9375 BUILDING LOBBY

  • ELEV. 0.00

EXTENT OF EXISTING MEZZANINE ABOVE EXTENT OF EXISTING MEZZANINE ABOVE UP TO MEZZANINE DOWN TO CELLAR COMMERCIAL SPACE EXISTING 1 STOP PASSENGER ELEVATOR DOWN TO CELLAR COMMERCIAL SPACE TO BE MODERNIZED AND REFURBISHED

CH 8'-1" AFF CH 15'-0" AFF

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

PROPOSED FIRST FLOOR PLAN 07

1/16"=1'-0"

slide-8
SLIDE 8

East 40th Street Madison Avenue

UP OFFICE TELE CLOSET BOILER ROOM CLOSET ELEC ELEC CLOSET CLOSET ELEC TOILET CHILLER ROOM SUMP PUMP

  • ELEC. STORAGE

BATHROOM CELLAR COMMERCIAL SPACE

CELLAR PLAN 08

1/16"=1'-0"

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

slide-9
SLIDE 9

09

N.T.S.

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

EXISTING ELEVATION PHOTOS

slide-10
SLIDE 10

10

N.T.S.

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

  • EXIST. METAL MOLDING PHOTOS

METAL MOLDING METAL MOLDING

slide-11
SLIDE 11

PROPOSED ELEVATION

EXISTING FRAME DECORATION TO REMAIN FUTURE TENANT SIGNAGE 5-SIDED LETTERFORMS ADHERED TO NEW STOREFRONT GLASS WITH DOUBLE-SIDED GLAZING TAPE AND STRUCTURAL SILICONE WITH VINYL BACKING ON INTERIOR SIDE SIDEWALK ALONG EAST 40TH ST. NEW GLASS

7'-6"

RETAIL LEVEL T.O.1ST FLR T.O.SILL

EXISTING ELEVATION

EXISTING METAL MOLDING TO REMAIN REMOVE EXISTING GLASS REMOVE EXISTING METAL MOLDING

4'-5" 2'-113

4"

4'-2"

REMOVE BULKHEAD WALL UNDERNEATH WINDOW SILL SIDEWALK ALONG EAST 40TH ST.

2'-113

4"

EXISTING & PROPOSED FACADE ELEVATION 11

3/16"=1'-0"

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

slide-12
SLIDE 12

REMOVE EXISTING DECORATIVE METAL MOLDING AT EXTERIOR UNDERNEATH WINDOWS REMOVE EXISTING WINDOW FRAME REMOVE BULKHEAD WALL UNDERNEATH WINDOW SILL REMOVE EXISTING GLASS EXTERIOR INTERIOR NEW CONCRETE TO MATCH EXISTING ADJACENT SIDEWALK UP 2R NEW FRAME FILL & PATCH FLOORING WHERE NEEDED NEW DOORS

PROPOSED PLAN

  • REMOVE EXISTING DECORATIVE METAL MOLDING

EXTERIOR INTERIOR NEW HANDRAIL FASTENED TO FLOOR SLAB NEW HANDRAIL FASTENED TO FLOOR SLAB LANDING ELEV. +1.9375

EXISTING & PROPOSED FACADE PLAN 12

3/8"=1'-0"

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

  • EXIST. PLAN

1 PROPOSED PLAN 2

slide-13
SLIDE 13

EXISTING DECORATIVE METAL MOLDING TO REMAIN

  • EXIST. GLASS TO

BE REMOVED REMOVE EXISTING METAL MOLDING REMOVE BULKHEAD WALL UNDERNEATH WINDOW SILL T.O. FLOOR T.O. SIDE WALK EXISTING DECORATIVE METAL MOLDING TO REMAIN NEW GLASS TRANSOM NEW BLACK GRANITE TO MATCH EXISTING T.O.SWING DOOR EL.

7'-6"

EXTERIOR INTERIOR

NEW PIECE OF METAL MOLDING TO MATCH EXISTING STAINLESS STEEL CLAD NARROW STILE GLASS DOOR T.O. FIRST FLOOR

3'-0"

13

3/8"=1'-0"

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

DEMOLITION AND PROPOSED SECTIONS

PROPOSED SECTION 2 DEMOLITION SECTION 1

slide-14
SLIDE 14

1 2" STARPHIRE

TEMPERED GLASS NEW STAINLESS STEEL FRAME CONTINUOUS PERIMETER GASKETING (TYP.) STAINLESS STEEL CLAD NARROW STILE GLASS DOOR NEW BLACK GRANITE TO MATCH EXISTING EXTERIOR CAULKING NEW 2HR RATED WALL EXISTING DECORATIVE METAL MOLDING TO REMAIN

L C L C TO FACE OF BUILDING INTERIOR EXTERIOR

PROPOSED DOOR DETAIL 14

3/8"=1'-0"

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

slide-15
SLIDE 15

UP 4R UP 4R

NEW HANDICAP LIFT PLATFORM

A A

LANDING ELEV. +1.9375 BUILDING LOBBY

  • ELEV. 0.00

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:

EXISTING & PROPOSED INTERIOR STAIR AREA AT BUILDING LOBBY PLAN 15

3/8"=1'-0"

  • EXIST. PLAN

1 PROPOSED PLAN 2

slide-16
SLIDE 16

EXISTING BUILDING ENTRANCE NEW HANDICAP LIFT PLATFORM

REVOLVING DOORS

RETAIL LEVEL T.O.1ST FLR FINISH FLR T.O.LOBBY

PROPOSED INTERIOR STAIR AREA AT BUILDING LOBBY SECTION 16

3/8"=1'-0"

TITLE: DWG NO.:

SCALE:

MISRA & ASSOCIATES P.C.

ARCHITECTURE PLANNING INTERIOR DESIGN

174 FIFTH AVENUE, NEW YORK, N.Y. 10010 TEL. (212) 674 8020

ARCHITECT:

RETAIL STOREFRONT MODIFICATION 275 MADISON AVE, NEW YORK, NY

10.03.2017

DATE:
