SLIDE 1
Agenda
- Project Overview
- Bridge Construction Process
- Project Challenges
- Project Successes
- Upcoming Project Activities
2
Milton Madison Bridge: Construction Update Aaron L. Stover, PE, SE - - PowerPoint PPT Presentation
Milton Madison Bridge: Construction Update Aaron L. Stover, PE, SE - - PowerPoint PPT Presentation
2012 KYTC Partnering Conference September 11, 2012 Milton Madison Bridge: Construction Update Aaron L. Stover, PE, SE Michael Baker Jr., Inc. Agenda Project Overview Bridge Construction Process Project Challenges Project
SLIDE 2
SLIDE 3
Markland Dam Project Site I-275 I-65 Cincinnati Louisville
Study Area
One of two Ohio River bridges between Cincinnati and Louisville
I-65 Bridge - 46 miles Markland Dam - 26 miles I-275 Bridge – 65 miles
3
Project Overview
SLIDE 4
Project Timeline
- June 2008 – Kickoff Environmental Process
- Fall 2009 – Proposed Superstructure Replacement
- February 2010 – TIGER Grant Funding Announced
- September 2010 – Contractor Announced (Walsh)
- January 2011 – Construction Began
- April 25-29th 2012 – First Bridge Closure
- June 25-29th – First Bridge Lift
- Sept 10th– Second Bridge Lift
- 2013 – New bridge Open to Traffic
4
SLIDE 5
Project Purpose and Need
- KYTC Structurally Deficient List
- Weight Restriction
5
Structurally Deficient Functionally Obsolete
SLIDE 6
- Milton Approach re-construction
- STR 1 replace KY Approaches
- STR 2 Truss replacement
– Pier Strengthening and Scour Mitigation – Superstructure Replacement
6
Milton, KY Madison, IN
- STR 3 – Replace IN Approaches
- STR 4 – Pedestrian Access to Park
No Right-of-Way required 1 2 3 4
Selected Alternative: Superstructure Replacement
SLIDE 7
12’-0”
LANE
8’-0”
SHOULDER
5’-0” 12’-0”
LANE
8’-0”
SHOULDER 7
Typical Section
- Existing 20 ft curb to curb – Becomes 40 ft
- 5 ft pedestrian walkway
- 8 ft shoulders will accommodate bicyclists
SLIDE 8
Selected Alternative
8
Existing Bridge Proposed Bridge
SLIDE 9
Bridge Construction Process
9
SLIDE 10
Design – Build Letting Summary
- September 22, 2010
- Five Contractors submitted bids
- Formula for Effective Bid Price
- lowest effective bid wins
- [A + B – Adjustment]
- A = construction cost ($102-$127 million)
- B = closure days x $25,000/day. (365 days max)
- Adjustment = $3.75 million for early opening
(Sept 2012 or May 2013)
10
SLIDE 11
Project Partners
SLIDE 12
Construction Overview
- Strengthen existing piers
- Innovative construction process:
- Build a new truss on downstream piers while
the existing bridge remains open to traffic
- Remove old truss and slide the new truss
- nto the strengthened existing piers
- Shorten closure periods (approx 10 days)
12
SLIDE 13
13
Step 1
- Pier strengthening and widening begins
- Detour approach ramps are built on Vaughn Dr and KY 36
- Existing bridge remains open to traffic
Construction Sequence
SLIDE 14
14
Pier Strengthening
SLIDE 15
15
SLIDE 16
Madison Temporary Access Ramp
16
Courtesy Debbie Crawford
SLIDE 17
Milton Temporary Access Ramp
17
Courtesy Debbie Crawford
SLIDE 18
18
Step 2
- Bridge closed to traffic for 5 days
- Approach ramps are connected to existing bridge
- Existing bridge reopens to traffic using approach ramps
- Pier strengthening work continues
Construction Sequence
SLIDE 19
Madison Demolition
19
SLIDE 20
Madison Demolition
20
SLIDE 21
21
Closure – Started off with a bang…
SLIDE 22
Madison Demolition
22
SLIDE 23
23
Truss Erection on Barges
SLIDE 24
Truss Assembly Yard
24
SLIDE 25
Span 2 Nearing Completion
25
SLIDE 26
26
Step 3
- Downstream bridge piers are constructed
- Truss Erected on Downstream Piers
Construction Sequence
SLIDE 27
27
SLIDE 28
Temporary Towers - P3 & P4
28
SLIDE 29
Sliding Girders
29
SLIDE 30
30
SLIDE 31
31
Step 3
- Downstream bridge piers are constructed
- Truss Erected on Downstream Piers
Construction Sequence
SLIDE 32
Span 2 Truss Float Out
32
SLIDE 33
Span 2 Lift (Animation)
33
SLIDE 34
Span 2
34
SLIDE 35
Truss Float
35
SLIDE 36
Truss Float
36
SLIDE 37
Span 3 Lift – 9/10/12
37
SLIDE 38
Jacking Platform
38
SLIDE 39
Sidewalk Superintendents
39
SLIDE 40
Span 3 Float (Animation)
40
SLIDE 41
Span 3 Lift (Animation)
41
SLIDE 42
42
SLIDE 43
43
SLIDE 44
44
Step 4
- Downstream bridge is connected to US 421
- Traffic is rerouted onto downstream bridge
Construction Sequence
SLIDE 45
45
Step 5 Existing bridge is demolished
- Detour approach ramps are removed
- Pier strengthening and widening is completed
Construction Sequence
SLIDE 46
46
Step 6
- bridge closed for 5 days
- new truss superstructure is moved from
downstream piers to its permanent place
- New Milton-Madison Bridge opens to traffic
- Downstream piers are removed
Construction Sequence Bridge Slide
SLIDE 47
47
SLIDE 48
48 Pulling Strands Bearing Pulling Bracket
SLIDE 49
Project Challenges
49
SLIDE 50
50
8 flood events 131 Flood Days 20 days/yr allowed for in contract Record Rainfall
SLIDE 51
Spring 2011 Flooding
51
SLIDE 52
Project Successes
52
SLIDE 53
Temporary Ramps Completed
53
SLIDE 54
Lifts of Span 2 and Span 3
54
SLIDE 55
Peregrine Falcons Hatched
55
SLIDE 56
56
Next Steps?
Stick Build out the end spans Complete the Approach Spans Cast the Deck Switch Traffic to new Bridge
SLIDE 57
57
