Microphone Array Processing

M4 Progress Report Iain McCowan January 28, 2003

Objective and Aims

• Objective
• to demonstrate viability and advantages of

microphone arrays for speech acquisition in meetings

• Aims

1. measurement and analysis of speaker turns 2. benchmark microphone array against close-talking microphones for speech recognition 3. precise tracking of people

Progess in past 6 months

• 1. measurement and analysis of speaker turns
• location based speaker segmentation
• 2. speech recognition evaluation
• comparison between lapel,array and single

distant microphone on small vocab task

• 3. audio-visual speaker tracking (Daniel)

measuring and analysing speaker turns

speaker turn segmention important for

• selecting audio for playback
• speaker recognition
• speaker adaptation for recognition
• segmenting speech transcriptions

also...

• analysis of speaker turns could be useful to detect higher

level dialogue actions (monologues, general discussion, ...)

but traditional techniques struggle in meetings

• multiple speakers, significant proportion of overlapping

speech (~15% of words)

location based speaker segmentation

Assumptions

• distinct source locations can be associated with distinct

speakers

• speech sounds dominate others in meetings

Proposed Technique

• Measurement : source location of principal sounds

represented by microphone pair time delays as features (vector with 1 value per microphone pair)

• Model : GMM distribution characterising centroid of known

speaker location (set manually from vector of theoretical delay values)

• System : incorporate GMM’s into minimum duration HMM

for all (4) speakers, segment using Viterbi decoding.

• to appear in Lathoud,ICASSP 03

location based speaker segmentation

experiments

• data: 20 minutes, including 5 minutes from each of 4

distinct speaker locations. spliced together to give segments between 5-20 seconds.

• evaluation:
• frame accuracy (FA, % of correctly labeled frames)
• precision, recall, F-measure
• results

0.77 0.73 0.81 88.3% LPCC 0.98 0.98 0.98 99.1% location F recall precision FA system

location based speaker segmentation

extension to dual speaker overlap segments

• manually constructed HMM of alternating short

speaker turns. 6 additional classes in the HMM (+4 individual speaker classes)

• data: same but each speaker change had 5-15

seconds of overlap

• results

0.90 0.86 0.94 94.1% (85.5%)

• verlap

0.98 0.98 0.98 99.1% no overlap F recall precision FA test set

measuring and analysing speaker turns

extensions...

• current system measures activity of each speaker location
• simpler detection of overlap
• ngoing work
• remove limiting assumptions
• remove a priori knowledge of locations
• automatic clustering of locations
• allow many-many relationship between speaker-location
• couple with speaker clustering/identification based on standard LPCC

features

• not all sounds are speech
• classify detected segments as speech/non-speech
• analysis of speaker turns
• recognition of higher-level structure, such as overlap, dialogues,

monologues, discusssions, etc...

• to be discussed more in meeting segmentation work tomorrow...

speech recognition evaluation

• data collection
• re-recorded Numbers 95 corpus in meeting room, across a

circular 8-element microphone array, and 3 lapel microphones

• loud-speakers used (lapel microphones attached to

material just below speaker)

• scenarios

1. single speaker (~ 20dB) 2.

• ne overlapping speaker (2 different locations) (~ 0dB)

3. two overlapping speakers (~ -3dB)

• will be made publicly available in conjunction with OGI

speech recognition evaluation

• GMM/HMM recognition system (HTK)
• in each case, adaptation from clean models using development set
• first results (baseline on clean test set 6.3% WER)
• for single speaker in normal conditions
• lapel microphone and microphone array give 7% word error rate
• single table-top microphone gave 10% word error rate.
• with a competing speaker (overlapping speech) at same level
• lapel microphone gives 27% word error rate
• microphone array gives 19% word error rate
• single table-top microphone gives 60% word error rate
• two competing speakers
• lapel 35%, array 26%, single table-top 74%
• indicates that array can be as good as, or better than lapel

microphones for speech recognition

• but, comparing with unenhanced lapel at this point...

speech recognition evaluation

speech recognition

for more details see Moore, ICASSP 03 future work

• benchmark against lapel microphones on large

vocabulary task (M4 data, ICSI data???)

• additional (post-beamforming) enhancement in case of

detected overlapping speech (dual channel techniques)

audio-visual speaker tracking

use audio source localisation to help a visual

tracker to

• initialise
• recover from tracking errors / visual occlusion

see Daniel’s presentation...

summary

microphone arrays proving to be useful devices for

recording and analysing meetings

• facilitate accurate speaker turn segmentation (esp. multi-

speaker overlap)

• comparable speech recognition performance to

(unenhanced) lapel microphones in ideal case, better in case of noise (eg overlap speech)

• accurate tracking of speakers

also...

• developing prototype stand-alone real-time system (8

inputs, 8 outputs, Analog Devices TigerSHARC, Firewire

• /p)

relevance to M4 partners

collaboration

• sharing of location-based speech activity features to

facilitate multi-modal research

• provide ‘mixed’ single audio channel as alternative to simple

addition of lapel channels

comparison

• array vs close-talking microphone speaker turn

segmentation

• provide array output signal for comparison with lapels on

(eventual) large vocablary recognition system

• compare with close-talking microphone enhancement (??)

during overlap segments on Numbers task
