MERCURY JET TARGET FOR E-951

• C. C. Finfrock, G. A. Greene and H. G. Kirk

E-951 Collaboration for Targetry Design Brookhaven National Laboratory December 15, 2000

Brookhaven Science Associates U.S. Department of Energy

Target Requirements Target Requirements

Generate a one cm. diameter arcing horizontal jet of mercury to provide a 10 to 15 cm interaction length with the proton beam. Provide an unobstructed view of the interaction zone for high speed imaging. Operate simply, reliably and remotely. Safely contain projectiles which may be generated by mercury-beam interactions Manage mercury vapor generation Mounting system to provide for easy interchange of other test targets Materials of construction must be compatible with mercury and survive a radiation environment.

Brookhaven Science Associates U.S. Department of Energy

Conceptual Approach Conceptual Approach

Internal and external target containments:

Use commercial conflat vacuum components, blind-flange beam windows, quartz and/or Lexan view ports wherever possible. Use standard instrumentation and pneumatic feedthroughs wherever possible.

Design approach:

design to reduce beam intensity on windows

• ptimize materials to insure survivability

insure mercury compatibility fiducial registration for target change out

Brookhaven Science Associates U.S. Department of Energy

Materials Considerations Materials Considerations

Containments:

commercially available stainless steel components for inner containment welded stainless steel sheet for outer containment Inconel-718 external beam windows quartz internal viewports Lexan external view ports

Valves:

stainless steel bodies Poly-Ether-Ether-Ketone seats Ethylene-Propylene o-rings

Brookhaven Science Associates U.S. Department of Energy

Pneumatically Actuated Ball Valve Pneumatically Actuated Ball Valve

Whitey "60" series valve

prepared by : C. Finfrock Date : 11/17/00 E-951 Muon Muon Collider Targetry

part numberSS-63TS8-33C

with pneumatic actuator

1/2 inch swagelok fittings rated 2200 psig from -20 to 100 F rated 800 psig at 300 F rated 100 psig at 450 F weight: 7.24 lbs body: stainless steel seats: teflon cost: $391.10

Brookhaven Science Associates U.S. Department of Energy

Pneumatic Control System for Fluid Jet Pneumatic Control System for Fluid Jet

E-951 Muon Muon Collider Targetry drawn by : C. Finfrock Date : 10/30/00

pneumatic control system

• Comp. Air

for mercury jet target (prototype)

vent vent V1 V2 V3 V4

Stop Jet: Close V1, close V2, V3 to vent reset for next shot: V4 to Comp air Jet Delivery: V4 to vent, V3 to comp. air, open V2, openV1

1/3 psi check valve

Brookhaven Science Associates U.S. Department of Energy

Apparatus to Simulate Hg Jet With Water Apparatus to Simulate Hg Jet With Water

Brookhaven Science Associates U.S. Department of Energy

Water Arc Simulation of Mercury Jet Water Arc Simulation of Mercury Jet

Brookhaven Science Associates U.S. Department of Energy

0.0 0.1 0.2 0.3 0.4

• 0.15
• 0.10
• 0.05

0.00 0.05 0.10 0.15 0.20

distance (meters)

Superposition of Jet Trajectory and Calculation Superposition of Jet Trajectory and Calculation

Brookhaven Science Associates U.S. Department of Energy

Overall Beam Line Layout Overall Beam Line Layout

56x51 56x51

P1 (2H)

56x51

PA

56x51 56x51

A3Q7 8Q48 A3Q6 A3Q8

PA

B (2H)

N3Q48-3 8Q48

56x51

CA

56x51 56x51 56x51

TARGET

56x51 56x51 56x51 56x51 63x44

A (2H) A (2H) A (2H) A (2H) B (2H) B (2H) A (2H) B (2H)

B(1H)

A (1H) #1, CA CA #2, CA

B(1H) E(3H)

A (2H)

PA 27

11' ROOF 9' ROOF

#1 #1 P3

A E E F

#2

PA PA PA 96x24x72 96x24x72 120x48x120 120x48x120 120x48x120 168x48x120 E E 192x24x72 192x24x132 192x24x132 96x24x132

PA

36

E (3H)

M229 M222

13'5''x2'x2'' 13'5''x2'x2'' 13'5''x2'x2'' Telescope and CCD Camera Laser Diode Fresnel Lens Fiberoptic Cable

19

Brookhaven Science Associates U.S. Department of Energy

Schematic of Traversing Table Layout Schematic of Traversing Table Layout

A A 56x51 56x51 LT-10 Y

CR

42'x2'x2'

12

40'x2'x11'

#2 #1 #2 #1

(6PL)13'5''x8'8''x2''

Target Cell Telescope & CCD Camera Shielding Fiberoptic Cable Fresnel Lens

ELEVATION SECTION FF

Brookhaven Science Associates U.S. Department of Energy

Mercury Jet Internal Confinement, Remote Reservoir Design Mercury Jet Internal Confinement, Remote Reservoir Design

Mercury Jet

drawn by : C. Finfrock Date : 11/30/00 E-951 Muon Muon Collider Targetry

Internal Confinement III

proton beam going left to right

4" dia x 8" long 1.5 liter 6" dia x 4" long 1.5 liter

from delivery tank to nozzle inlet to delivery tank

manual drain collection tank

driving pressure / vent driving pressure / vent from collection tank

Brookhaven Science Associates U.S. Department of Energy

Mercury Jet Internal Confinement, Integral Reservoir Design Mercury Jet Internal Confinement, Integral Reservoir Design

Mercury Jet

drawn by : C. Finfrock Date : 12/01/00 E-951 Muon Muon Collider Targetry

Internal Confinement V

projectile trajectory from left to right

4" dia x 8" long 1.5 liter

to delivery tank from mercury confinement from delivery tank to jet nozzle manual drain driving pressure / vent driving pressure / vent I 718 beam window (x2)

Brookhaven Science Associates U.S. Department of Energy

Looking Into The Secondary Confinement From Above Looking Into The Secondary Confinement From Above

Hg Jet Component Layout in

drawn by : C. Finfrock Date : 12/06/00 E-951 Muon Muon Collider Targetry

DRAFT

particle trajectory from left to right

External Confinement, Plan View

table top confinement envelope

Hg Adsorber Model #

driving pressure driving pressure

Koby 500-SKCB Hg Adsorber Model # Koby 500-SKCB Hg Adsorber Model # Koby 500-SKCB

Revised : 12/14/00

Brookhaven Science Associates U.S. Department of Energy

Side View of the Secondary Confinement Side View of the Secondary Confinement

Hg Jet External Confinement

drawn by : C. Finfrock Date : 12/14/00 E-951 Muon Muon Collider Targetry

Side Elevation View

particle trajectory from left to right

table top

Brookhaven Science Associates U.S. Department of Energy

Detail of the Upstream Experiment Mount, Table Component Detail of the Upstream Experiment Mount, Table Component

drawn by : C. Finfrock Date : 12/12/00 E-951 Muon Muon Collider Targetry

Sub-base for Mounting Expt.

Material : CRS

Upstream Mount

plan view elevation MSC part # 06984348, half in. bullet nosed pin, pressed in, 2 places 2 in by 2 in by 0.5 in build-ups welded on each end

"A" "A"

• sect. A-A

Brookhaven Science Associates U.S. Department of Energy

Detail of the Upstream Experiment Mount, Target Component Detail of the Upstream Experiment Mount, Target Component

drawn by : C. Finfrock Date : 12/12/00 E-951 Muon Muon Collider Targetry

Sub-base Mating Mount

Material : CRS

Upstream Mount

plan view elevation 2 in by 2 in by 0.5 in build-ups welded on each end bolt holes appropriate for mounting to apparatus MSC part # 06984546, half in. liner for pin, pressed in, 2 places

• sect. A-A

"A" "A"

Brookhaven Science Associates U.S. Department of Energy

Detail of the Downstream Experiment Mount, Table Component Detail of the Downstream Experiment Mount, Table Component

Sub Base for Mounting Expt.

drawn by : C. Finfrock Date : 12/14/00 E-951 Muon Muon Collider Targetry

Downstream mount

Fixture Jack, MSC # 82408915 to be pressed in

Brookhaven Science Associates U.S. Department of Energy

Current Status Current Status

Water jet tests are essentially complete. Mercury jet target designs are substantially complete, minor detailing still underway. Test stand will be installed in beam line very soon. Materials list with prices and quotes about 75%

• complete. Ready to order many components

now. Next step is to prepare for the experiment safety review, then begin target construction.
