TSXV: NAR TSXV:NAR Mel Diamond Project Nunavut Project Update February 8 2017 CAUTIONARY STATEMENT This presentation contains projections and forward looking information that involve various risks and uncertainties, including, without


slide-1
SLIDE 1

TSXV:NAR TSXV: NAR

Mel Diamond Project Nunavut

Project Update February 8 2017

slide-2
SLIDE 2

This presentation contains projections and forward looking information that involve various risks and uncertainties, including, without limitation, statements regarding the potential extent of mineralization, resources, reserves, exploration results and plans and

  • bjectives of North Arrow Minerals Inc. These risks and uncertainties include, but are

not restricted to, the amount of geological data available, the uncertain reliability of drilling results and geophysical and geological data and the interpretation thereof and the need for adequate financing for future exploration and development efforts. There can be no assurance that such statements will prove to be accurate. Actual results and future events could differ materially from those anticipated in such statements. These and all subsequent written and oral forward-looking statements are based on the estimates and opinions of management on the dates they are made and are expressly qualified in their entirety by this notice. The Company assumes no obligation to update forward looking statements should circumstances or management's estimates or

  • pinions change.

2

CAUTIONARY STATEMENT

Forward Looking Information Qualified Person under NI 43-101

Disclosure of a scientific or technical nature related to North Arrow’s projects in this presentation has been reviewed and approved by Ken Armstrong, P.Geo. President and CEO of North Arrow and a Qualified Person under NI 43-101.

slide-3
SLIDE 3

MEL PROJECT - NU

Mel Project

  • 100% interest in 7,500 hectare property on Melville

Peninsula; 140 km south of Hall Beach; 210 km northeast Naujaat.

  • Three to five unique unsourced KIM trains well-

defined from over 750 NAR & historic till samples.

  • 2013, 2014, 2015 and 2016 till sampling &

prospecting programs have systematically advanced the project.

  • Applying for drill permits - 2017 or 2018.

3

slide-4
SLIDE 4

10 km Northern Train Southern Train

  • Acquired in 2013.
  • Two unsourced clusters of

kimberlite indicator minerals (KIMs) from +500 till samples in assessment records; “Northern Train” and “Southern Train”.

  • Trains contain pyrope and

eclogite garnets as well as ilmenites.

  • Short programs have been

conducted annually out of Naujaat.

  • 2016 sampling conducted
  • nly on Northern Train; ice

direction understood; 3 or more possible source target areas have been defined.

MEL PROJECT - NU

4

slide-5
SLIDE 5

MEL PROJECT, NORTHERN TRAIN 2013 & 2014

  • Highest kimberlite

indicator mineral grain (“KIM”) counts were ~10 grains.

  • Sampling in 2013

and 2014 focused

  • n the potential

cut-off area.

Pre-2013 Historic Data Pre-2013 Data

2013 & 2014 till sampling focus area

5

slide-6
SLIDE 6
  • Started to define

potential source area.

  • Two trains started

to emerge.

  • Best sample

located in the southwest limit of sampling representing new source area.

  • Planned broad infill

till sampling program for 2015.

MEL PROJECT, NORTHERN TRAIN 2013 to 2014

Historic Data and NAR 2013-2014

2013-14 Till Results 6

slide-7
SLIDE 7
  • Started to define

potential source area.

  • Two trains started

to emerge.

  • Best sample

located in the southwest limit of sampling representing new source area.

  • Planned broad infill

till sampling program for 2015.

MEL PROJECT, NORTHERN TRAIN 2013 to 2014

Historic Data and NAR 2013-2014

2013-14 Till Results 7

slide-8
SLIDE 8
  • Started to define

potential source area.

  • Two trains started

to emerge.

  • Best sample

located in the southwest limit of sampling representing new source area.

  • Planned broad infill

till sampling program for 2015.

MEL PROJECT, NORTHERN TRAIN 2013 to 2014

Historic Data and NAR 2013-2014

2013-14 Till Results

2015 Till Sampling Focus Area

8

slide-9
SLIDE 9
  • 2015 was most

intensive program yet.

  • Over 200 samples

taken.

  • Three very high

grain counts in train 1 with barren samples up ice suggest it could be cut-off.

  • Train 2 yields

highest KIM counts yet and appears to be cut-off; close to source.

  • Possible third train

defined with possible cut-off.

MEL PROJECT, NORTHERN TRAIN 2013 to 2015

Historic Data and NAR 2013-2015

2015 Till Results 9

slide-10
SLIDE 10
  • 2015 was most

intensive program yet.

  • Over 200 samples

taken.

  • Three very high

grain counts in train 1 with barren samples up ice suggest it could be cut-off.

  • Train 2 yields

highest KIM counts yet and appears to be cut-off; close to source.

  • Possible third train

defined with possible cut-off.

MEL PROJECT, NORTHERN TRAIN 2013 to 2015

Historic Data and NAR 2013-2015

2015 Till Results 10

slide-11
SLIDE 11
  • 2015 was most

intensive program yet.

  • Over 200 samples

taken.

  • Three very high

grain counts in train 1 with barren samples up ice suggest it could be cut-off.

  • Train 2 yields

highest KIM counts yet and appears to be cut-off; close to source.

  • Possible third train

defined with possible cut-off.

MEL PROJECT, NORTHERN TRAIN 2013 to 2015

Historic Data and NAR 2013-2015

2015 Till Results

2016 Till Sampling Focus Area

11

slide-12
SLIDE 12

MEL PROJECT, NORTHERN TRAIN 2013 to 2016

Historic Data and NAR 2013-2016

2016 Till Results

  • 111 samples
  • Program designed

to firmly establish up-ice cut-offs for Trains 1, 2 & 3.

  • Most samples are

barren of KIMs – confirming KIM Trains are now well cut-off.

  • Train 2 sample with

>1,200 KIMs – an

  • rder of magnitude

more KIMs; close!

  • Infill sampling

shows potential for two more source areas.

12

slide-13
SLIDE 13

MEL PROJECT, NORTHERN TRAIN 2013 to 2016

Historic Data and NAR 2013-2016

Sample yielded

  • ver 1200 KIMs

2016 Till Results

  • 111 samples
  • Program designed

to firmly establish up-ice cut-offs for Trains 1, 2 & 3.

  • Most samples are

barren of KIMs – confirming KIM Trains are now well cut-off.

  • Train 2 sample with

>1,200 KIMs – an

  • rder of magnitude

more KIMs; close!

  • Infill sampling

shows potential for two more source areas.

13

slide-14
SLIDE 14

MEL PROJECT – GEOCHEMISTRY

2 4 6 8 10 12 14 16 1 2 3 4 5 6 7 8 9 10 Cr2O3 wt.% CaO wt.%

PYROPE GARNETS

Mel 2015 Tills

G10 G9

0.0 0.5 1.0 1.5 2.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 TiO2 wt% Na2O wt%

ECLOGITIC GARNETS

Mel 2015 Tills

0.09 Wt% Na2O

1 2 3 4 5 6 7 8 9 10 11 12 3 5 7 9 11 13 15 Cr2O3 (wt%) MgO (wt%)

ILMENITES

Mel 2015 Tills

40 42 44 46 48 50 52 54 56 58 60 2 4 6 8 10 12 14 16 18 TiO2 wt.% MgO wt%

ILMENITES

Mel 2015 Tills

Kimberliti c Non- Kimberlitic

Pyrope Garnet Eclogitic Garnet Ilmenite Ilmenite 14

slide-15
SLIDE 15

MEL PROJECT – NEXT STEPS

  • Detailed prospecting and ground geophysics.
  • Drill and exploration camp permits pending.
  • Community Consultations planned for April 2017.
  • Exploration drilling of priority targets.

15

slide-16
SLIDE 16

16

NORTH ARROW - THE WAY FORWARD

Project Location Commodity Interest Comment

Pikoo Saskatchewan Diamonds 100%*

*Upon closing acquisition of SWY’s 15%;

10 Kimberlites discovered to date; 2017 – till sampling & drilling Qilalugaq Nunavut Diamonds 100%*

*Upon closing acquisition of SWY’s 18%;

Large Q1-4 kimberlite with fancy

  • rangey-yellow diamond population;

2017 – delineation drilling; 2017-2018 – bulk sample leading to PEA Lac de Gras NWT Diamonds ~39%** JV w DDC

**Interest recalculation pending;

2017 Ground Geophysics & Drilling Mel Nunavut Diamonds 100% 2017 – Detailed prospecting & ground geophysics Luxx Nunavut Diamonds 100% Drill ready targets Loki NWT Diamonds 100% Lac de Gras area; Incl. EG05 kimberlite; 2017 – data compilation, ground geophysics & drilling Timiskaming Ontario Diamonds 80% Database evaluation Hope Bay Nunavut Gold 100% Northern Hope Bay greenstone belt; 3km north of TMAC’s Doris Gold Mine; Several Au showings / JV potential
