Measurement Considerations for Evaluating BTI Effects in SiC MOSFETs

Daniel Habersat Aivars Lelis (TL), Ronald Green

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Background

 Switching oxide trap, direct tunneling mechanism.  Defect is an E′ center (hole trap), associated with O vacancy  Similar behavior as seen with ionizing radiation

• n Si/SiO2.

 Presence of defect confirmed in SiC MOS  Bias and temperature convert neutral Si-dimer to active E′ center  Same as in Si/SiO2 PBTI ? Meta-stable high-temperature electron trap ? Counteracting mobile ion or polarization charge ? Indirect tunneling via interface traps

EFM EV EC EFS

SiO2 SiC

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

5 10 15 3 3.5 4 4.5 Drain Current [mA] Gate-Source Bias [V] pre-stress stress Vendor A 2.9 MV/s

Typical PBS Response (simplified)

• Representative pre- and

post-stress ID-VGS

• Charge-trapping-like

response:

• PBS shifts curves

positively

• NBS shifts curves

negatively

• Roughly linear-with-log

time

• Generally nonpermanent

and reversible … BUT:

+ stress 1 2 1 2 10⁻⁶ 10⁻³ 10⁰ 10³ 10⁶ 4.2 4.4 4.6 4.8 5 5.2 5.4 5.6 5.8 Threshold Voltage [V] Stress Time [s] Vendor B Vendor A

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

tM [s] 10-6 10-4 10-2 100 102 104

Experimental: Measurement Considerations

VT drift results are highly dependent on the delay between stress and measurement!

0.1 0.2 0.3 0.4 0.5 0.6 0.7 VT Drift [V] tS [s] 10-6 10-4 10-2 100 102 104 Pre-stress Stress Recover 5 10 15 20 VGS [V] Time

Recovery during delay appears to be the dominant reason for differences between measurements.

VGS = +15 V VGS = +2 V

Data from Vendor A COTS Increasing tS ΔVT as measured normally 2 μs measurement time 2 s measurement time

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

HTGB Qualification Specifications

• AEC – Q101 Stress Test Qualification for Automotive Grade Discrete

Semiconductors

• JEDEC JESD-22 A108E Reliability Test Methods for Packaged Devices
• MIL-STD-750 Test Methods for Semiconductors

AEC Q101 – Rev D JESD-22 A108E “Electrical testing shall be completed as soon as possible and no longer than 96 hours after removal of bias from devices.”

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces Industry Needs and Existing HTGB Test Method for SiC MOSFETs

• Industry requires large-scale test

systems for qualification testing and screening.

• Many SiC manufacturers qualify

devices to Q101 automotive standard.

• Devices stressed in parallel for 1000

hours.

• Biased cool down to 25 °C (1 min. bias

interruption allowed per JESD22 - A108C for moving devices to test area).

• Bias interruption times generally >> 1

minute in practice.

• Devices can remain unbiased for up

to 96 hrs. prior to electrical testing per JESD22 – A108C without any requirement to reapply bias stress.

• JESD22-A108C does have an additional

stress requirement when devices have remained unbiased for longer than 96

• hrs. prior to electrical testing.
• Serial testing leads to variation in

interrupt/delay times

AEC-Q101- Rev D1

• Sept. 6, 2013

Example of HTGB test procedure used by manufacturers for qualification:

Type Test Description Condition

Device HTRB High Temperature Reverse Bias 1000 hr. HTGB High Temperature Gate Bias 1000 hr. HTOL High Temperature Operating Life 1000 hr.

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Gate Biasing Sequence

Pre-stress Stress Interrupt Reapply (1) (2) (3) (4) Gate-Source Bias Time [arb]

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

5 10 15 3 3.5 4 4.5 Drain Current [mA] Gate-Source Bias [V] pre-stress interrupt reapply stress Vendor A 2.9 MV/s

Sequential Charging of the Oxide Traps

• Tunneling fronts move into

the oxide

• Bias determines resultant

charge state

• Time determines penetration

depth (log t)

• Superposition of multiple

fronts

Static Oxide Bulk Measurement Trap Occupation Interface + stress interrupt reapply 1 2 2 3 3 4 1 2 3 4 Gate-Source Bias Time [arb] Prestress (1) Stress (2) Interrupt (3) Reapply (4)

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Pre-stress Biasing

Pre-stress Stress Interrupt Reapply (1) (2) (3) (4) Gate-Source Bias Time [arb]

Pre-stress

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Pre-stress bias (PBS)

10⁻⁶ 10⁻³ 10⁰ 10³ 3 3.5 4 4.5 5 5.5 Threshold Voltage [V] Positive Bias Stress Time [s] 0 V pre / +25 V stress –5 V pre / +25 V stress –10 V pre / +25 V stress Vendor B

• Identical stressing

parameters

• Pre-stress time for roughly

the same time as the stress (2×104 s)

• Three pre-stress biases:

0V, -5V, and -10V (saturated by -15V)

• More negative biasing

causes:

• Negative shift in original

VT

• Reduced VT for first

100s or so

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Pre-stress bias (NBS)

• Identical stressing

parameters

• Pre-stress time for roughly

the same time as the stress (2×104 s)

• Three pre-stress biases:

0V, +5V, and +10V (no saturation seen to +25V)

• More positive biasing

causes:

• Positive shift in original

VT

• No significant changes

in post-NBS VT values

10⁻⁶ 10⁻³ 10⁰ 10³ 3 3.5 4 4.5 5 5.5 Threshold Voltage [V] Negative Bias Stress Time [s] +10 V pre / –15 V stress +5 V pre / –15 V stress 0 V pre / –15 V stress Vendor B

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Pre-stress Bias (Drift)

• Interpretation of results usually

based on drift values

• PBS Drift:
• Early times appear identical
• Dispersion in final drift

values based on pre-bias magnitude (larger pre-bias -> larger drift)

• 0V device seems to have

lower density of switching

• xide traps
• NBS Drift:
• Drifts are parallel
• Magnitude of drift correlates

with pre-bias magnitude

• 0V device seems to have a

lower density of fast interface states

10⁻⁶ 10⁻³ 10⁰ 10³

• 2
• 1.5
• 1
• 0.5

0.5 1 1.5 2 Threshold Voltage Drift [V] Stress Time [s]

–10 V pre / +25 V stress 0 V pre / –15 V stress –5 V pre / +25 V stress +5 V pre / –15 V stress 0 V pre / +25 V stress +10 V pre / –15 V stress

Vendor B

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Sweep Speed

Pre-stress Stress Interrupt Reapply (1) (2) (3) (4) Gate-Source Bias Time [arb]

Sweep Speed

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Sweep Speed (PBS)

10⁻⁶ 10⁻³ 10⁰ 10³ 2.5 3 3.5 4 4.5 5 Threshold Voltage [V] Stress Time [s] 2 x 10⁶ (5 µs) 2 x 10⁵ (50 µs) 2 x 10⁴ (500 µs) 4 x 10³ (2.5 ms)

Slew Rate [V/s]

Vendor A

• Already know that faster

sweeps  larger drift

• With negative pre-stress

bias, reference VT was independent of slew rate (???)

• Faster sweep  capture of

more near-interface states

• Growth of VT (i.e. drift) is

roughly parallel for longer times

• As stress’ tunneling

front moves deeper, measurement speed matters less

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Sweep Speed (NBS)

10⁻⁶ 10⁻³ 10⁰ 10³ 2.5 3 3.5 4 4.5 5 Threshold Voltage [V] Stress Time [s] 4 x 10³ (2.5 ms) 2 x 10⁴ (500 µs) 2 x 10⁵ (50 µs) 2 x 10⁶ (5 µs)

Slew Rate [V/s]

Vendor A

• Contrast NBS to PBS:
• Reference VT IS slew-rate

dependent

• Drift rate (slope) is also slew-

rate dependent

• Why are the responses so

different between PBS and NBS?

• ¯\_(ツ)_/¯
• Under investigation

? Combination of interactions between pre-stress bias, stress bias, and portions of the IV sweep before and after the VT measurement ? Initial response to NBS is very rapid, while PBS tends to be slower… ? PBS: (Np/nPp/nPp/…) ? NBS: (Pn/pNn/pNn/…)

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Interrupt Time

Pre-stress Stress Reapply (1) (2) (3) Gate-Source Bias Time [arb]

Interrupt

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Interrupt Time

• Study the effects of

interrupt time, for relatively “long” stresses

• Drift between the two I-V

curves immediately before and after the bias interruption

• With interrupt time <<

stress time, we get a recovery in the VT drift that is independent of stress time

• Only affecting the traps

nearest to the interface

• Deeper traps remain

undisturbed

5 10 15 3 3.5 4 4.5 Drain Current [mA] Gate-Source Bias [V] pre-stress interrupt stress Vendor A 2.9 MV/s + stress interrupt 1 2 2 3 1 2 3 10⁻⁶ 10⁻³ 10⁰ 10³

• 0.8
• 0.7
• 0.6
• 0.5
• 0.4
• 0.3
• 0.2
• 0.1

Threshold Voltage Drift [V] Interrupt Time [s] 3.2 x 10¹ 1.0 x 10² 3.2 x 10² 1.0 x 10³ 3.2 x 10³

Stress Time [s]: Vendor A 1.3 MV/s

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Reapply Time

Pre-stress Stress Interrupt Reapply (1) (2) (3) (4) Gate-Source Bias Time [arb]

Reapply

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

5 10 15 3 3.5 4 4.5 Drain Current [mA] Gate-Source Bias [V] pre-stress interrupt reapply stress Vendor A 2.9 MV/s

Reapply Time

• 32s +25V stress
• Short duration interrupts

cause some loss of VT drift

• Longer interruptions can

cause almost ALL drift to recover

• Highlighted scenario:
• 32s stress, 10s interrupt
• No reapply  nearly

total recovery of VT

• 0.3s reapply  nearly

full VT drift observed

10⁻⁶ 10⁻³ 10⁰ 10³ 0.05 0.1 0.15 0.2 0.25 0.3 0.35 Threshold Voltage Drift [V] Reapply Time [s] 1 x 10⁻⁴ 1 x 10⁻³ 1 x 10⁻² 1 x 10⁻¹ 1 x 10⁰ 1 x 10¹ Vendor B 1.3 MV/s

Interrupt Time [s]:

+ stress interrupt reapply 1 2 2 3 3 4 1 2 3 4

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Universal Drift Again

• As shown last

year: square of reapply time, divided by interrupt time, gives a reasonable correlation with fractional VT drift

• Specific fraction

appears to have a sweep rate component (???)

• Reapply time

much shorter than interrupt time can restore most of the drift

10⁻¹² 10⁻⁹ 10⁻⁶ 10⁻³ 10⁰ 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1 Fractional VT Drift tR

2/tI [s]

Vendor B 1.3 MV/s

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

High Temperature Bias Stressing, Interruption, and Reapplication

10⁻¹⁸ 10⁻¹⁵ 10⁻¹² 10⁻⁹ 10⁻⁶ 10⁻³ 10⁰ 10³ 10⁶ 10⁹

• 0.2

0.2 0.4 0.6 0.8 1 1.2 Fractional VT Drift tR2 / tI [s] 25°C 175°C

• Room temperature

analysis  reasonable agreement with high temperature data

• Yes, activation is
• ccurring and

changing the active trap density, but the basic tunneling mechanism behaves the same

UNCLASSIFIED UNCLASSIFIED

The Nation’s Premier Laboratory for Land Forces

Significance / Take-Aways

• Establish a pre-stress conditioning protocol (e.g., bias at −10 V

for 1 hour). A pre-stress that opposes the polarity of the stress will show the most meaningful results.

• A consistently applied pre-stress conditioning will provide a

sound basis for evaluating drift between devices or tests of the same device. Otherwise, you will need to look at bothVT and VT drift.

• Make your measurements as quickly (and consistently) as

possible.

• Minimize bias interruptions and delays between stressing and

measuring.

• An estimate of the VT drift lost due to a bias interruption after a

long-term stress could be estimated by conducting a shorter stress measurement with the same interrupt time (as long as the new stress time is still greater than the interrupt time).

• If there is a bias interruption, even for a short time, re-establish

the stress bias and hold briefly, immediately before measuring.

• Perform measurements at the same temperature as the
• stressing. (This will both reduce any bias interruptions as well as

prevent thermally-induced relaxation of trapped charge.)
