Mashing up JavaScript Advanced techniques for modern web applications Bastian Hofmann VZnet Netzwerke Ltd. Wtf? JavaScript Apps CORS and OAuth2 Local Storage OEmbed and Caja WebSockets, ActivityStrea.ms and PubsubHubbub

slide-1
SLIDE 1

Mashing up JavaScript

Advanced techniques for modern web applications Bastian Hofmann VZnet Netzwerke Ltd.

slide-2
SLIDE 2

Wtf?

slide-3
SLIDE 3
slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10
  • JavaScript Apps
  • CORS and OAuth2
  • Local Storage
  • OEmbed and Caja
  • WebSockets, ActivityStrea.ms and

PubsubHubbub

slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15

http://slideshare.net/bashofmann

slide-16
SLIDE 16

https://github.com/bashofmann/statusnet_js_mashup

slide-17
SLIDE 17

Let‘s write a JS App

slide-18
SLIDE 18

History & Bookmarking

slide-19
SLIDE 19

www.example.com#Page

slide-20
SLIDE 20

http://sammyjs.org/

slide-21
SLIDE 21

API Access

slide-22
SLIDE 22
slide-23
SLIDE 23

Same Origin Policy

slide-24
SLIDE 24

Cross-Origin Resource Sharing

Backend api.twitter.com Client client.net AJAX Access-Control-Allow-Origin: * http://www.w3.org/TR/cors/

slide-25
SLIDE 25

var html="<ul>"; for (var i=0; i < viewers.length; i++) { html += "<li>" + viewers[i].displayName + "</li>"; } html += "<ul>"; document.getElementById("#div").innerHTML = html;

Where is the error?

slide-26
SLIDE 26

Templates

slide-27
SLIDE 27

Mustache.JS

https://github.com/janl/mustache.js

}

slide-28
SLIDE 28

var feed = []; var app = Sammy('#main', function() { this.use(Sammy.Mustache, 'ms'); this.get('#/', function() { this.trigger('getFeed'); }); ... }); jQuery(function() { app.run('#/'); });

slide-29
SLIDE 29

var feed = []; var app = Sammy('#main', function() { this.use(Sammy.Mustache, 'ms'); this.get('#/', function() { this.trigger('getFeed'); }); ... }); jQuery(function() { app.run('#/'); });

slide-30
SLIDE 30

var feed = []; var app = Sammy('#main', function() { this.use(Sammy.Mustache, 'ms'); this.get('#/', function() { this.trigger('getFeed'); }); ... }); jQuery(function() { app.run('#/'); });

slide-31
SLIDE 31

var feed = []; var app = Sammy('#main', function() { this.use(Sammy.Mustache, 'ms'); this.get('#/', function() { this.trigger('getFeed'); }); ... }); jQuery(function() { app.run('#/'); });

slide-32
SLIDE 32

var feed = []; var app = Sammy('#main', function() { this.use(Sammy.Mustache, 'ms'); this.get('#/', function() { this.trigger('getFeed'); }); ... }); jQuery(function() { app.run('#/'); });

slide-33
SLIDE 33

this.bind('getFeed', function() { var that = this; $.ajax({ url: 'http://..._timeline.json', success: function(response) { feed = response; that.trigger('renderFeed'); } }); }); this.bind('renderFeed', function() { this.feed = feed; this.partial('js/templates/feed.ms'); });

slide-34
SLIDE 34

this.bind('getFeed', function() { var that = this; $.ajax({ url: 'http://..._timeline.json', success: function(response) { feed = response; that.trigger('renderFeed'); } }); }); this.bind('renderFeed', function() { this.feed = feed; this.partial('js/templates/feed.ms'); });

slide-35
SLIDE 35

this.bind('getFeed', function() { var that = this; $.ajax({ url: 'http://..._timeline.json', success: function(response) { feed = response; that.trigger('renderFeed'); } }); }); this.bind('renderFeed', function() { this.feed = feed; this.partial('js/templates/feed.ms'); });

slide-36
SLIDE 36

this.bind('getFeed', function() { var that = this; $.ajax({ url: 'http://..._timeline.json', success: function(response) { feed = response; that.trigger('renderFeed'); } }); }); this.bind('renderFeed', function() { this.feed = feed; this.partial('js/templates/feed.ms'); });

slide-37
SLIDE 37

this.bind('getFeed', function() { var that = this; $.ajax({ url: 'http://..._timeline.json', success: function(response) { feed = response; that.trigger('renderFeed'); } }); }); this.bind('renderFeed', function() { this.feed = feed; this.partial('js/templates/feed.ms'); });

slide-38
SLIDE 38

this.bind('getFeed', function() { var that = this; $.ajax({ url: 'http://..._timeline.json', success: function(response) { feed = response; that.trigger('renderFeed'); } }); }); this.bind('renderFeed', function() { this.feed = feed; this.partial('js/templates/feed.ms'); });

slide-39
SLIDE 39

<ul> {{#feed}} <li> <p>{{{statusnet_html}}}</p> <p>{{created_at}} {{#user}} {{name}} {{/user}} </p> </li> {{/feed}} </ul>

slide-40
SLIDE 40

<ul> {{#feed}} <li> <p>{{{statusnet_html}}}</p> <p>{{created_at}} {{#user}} {{name}} {{/user}} </p> </li> {{/feed}} </ul>

slide-41
SLIDE 41

<ul> {{#feed}} <li> <p>{{{statusnet_html}}}</p> <p>{{created_at}} {{#user}} {{name}} {{/user}} </p> </li> {{/feed}} </ul>

slide-42
SLIDE 42

<ul> {{#feed}} <li> <p>{{{statusnet_html}}}</p> <p>{{created_at}} {{#user}} {{name}} {{/user}} </p> </li> {{/feed}} </ul>

slide-43
SLIDE 43

DEMO

slide-44
SLIDE 44

Authorization

slide-45
SLIDE 45
slide-46
SLIDE 46

+----------+ Client Identifier +----------------+ | |>---(A)-- & Redirection URI --->| | | | | | End <--+ - - - +----(B)-- User authenticates -->| Authorization | User | | | Server | | |<---(C)--- Redirect URI -------<| | | Client | with Access Token | | | in | in Fragment +----------------+ | Browser | | | +----------------+ | |>---(D)--- Redirect URI ------->| | | | without Fragment | Web Server | | | | with Client | | (F) |<---(E)--- Web Page with ------<| Resource | | Access | Script | | | Token | +----------------+ +----------+

OAuth 2

http://tools.ietf.org/html/draft-ietf-oauth-v2

slide-47
SLIDE 47

this.bind('getFeed', function() {

  • auth2.retrieveAccessToken();

if (! oauth2.store['access_token']) { this.redirect('#Login'); return; } ... });

slide-48
SLIDE 48

this.bind('getFeed', function() {

  • auth2.retrieveAccessToken();

if (! oauth2.store['access_token']) { this.redirect('#Login'); return; } ... });

slide-49
SLIDE 49

this.get('#Login', function() { var consumerKey = 'abc....'; window.open('http://status.net/api/oauth2/ authorize?response_toke=token&client_id=' + consumerKey); });

slide-50
SLIDE 50

this.get('#Login', function() { var consumerKey = 'abc....'; window.open('http://status.net/api/oauth2/ authorize?response_toke=token&client_id=' + consumerKey); });

slide-51
SLIDE 51

<script type="text/javascript"> var fragment = location.hash.substr(1);

  • pener.parent.oauth2.storeToken(fragment);

window.close(); </script>

slide-52
SLIDE 52

<script type="text/javascript"> var fragment = location.hash.substr(1);

  • pener.parent.oauth2.storeToken(fragment);

window.close(); </script>

slide-53
SLIDE 53

<script type="text/javascript"> var fragment = location.hash.substr(1);

  • pener.parent.oauth2.storeToken(fragment);

window.close(); </script>

slide-54
SLIDE 54

<form action="#Entry" method="post"> <textarea name="comment"></textarea> <input type="submit" value="send"/> </form>

slide-55
SLIDE 55

<form action="#Entry" method="post"> <textarea name="comment"></textarea> <input type="submit" value="send"/> </form>

slide-56
SLIDE 56

<form action="#Entry" method="post"> <textarea name="comment"></textarea> <input type="submit" value="send"/> </form>

slide-57
SLIDE 57

this.post('#Entry', function() { var that = this; $.ajax({ url: 'http://status.net/.../ update.json?oauth_token=' +

  • auth2.store['access_token'],

type: 'POST', data: { 'status': that.params['comment'] }, success: function() { that.redirect('#/'); } }); });

slide-58
SLIDE 58

this.post('#Entry', function() { var that = this; $.ajax({ url: 'http://status.net/.../ update.json?oauth_token=' +

  • auth2.store['access_token'],

type: 'POST', data: { 'status': that.params['comment'] }, success: function() { that.redirect('#/'); } }); });

slide-59
SLIDE 59

this.post('#Entry', function() { var that = this; $.ajax({ url: 'http://status.net/.../ update.json?oauth_token=' +

  • auth2.store['access_token'],

type: 'POST', data: { 'status': that.params['comment'] }, success: function() { that.redirect('#/'); } }); });

slide-60
SLIDE 60

this.post('#Entry', function() { var that = this; $.ajax({ url: 'http://status.net/.../ update.json?oauth_token=' +

  • auth2.store['access_token'],

type: 'POST', data: { 'status': that.params['comment'] }, success: function() { that.redirect('#/'); } }); });

slide-61
SLIDE 61

this.post('#Entry', function() { var that = this; $.ajax({ url: 'http://status.net/.../ update.json?oauth_token=' +

  • auth2.store['access_token'],

type: 'POST', data: { 'status': that.params['comment'] }, success: function() { that.redirect('#/'); } }); });

slide-62
SLIDE 62

this.post('#Entry', function() { var that = this; $.ajax({ url: 'http://status.net/.../ update.json?oauth_token=' +

  • auth2.store['access_token'],

type: 'POST', data: { 'status': that.params['comment'] }, success: function() { that.redirect('#/'); } }); });

slide-63
SLIDE 63

Storing the access token

slide-64
SLIDE 64

Local Storage

http://www.w3.org/TR/webstorage/

slide-65
SLIDE 65

localStorage.setItem("key", value);

slide-66
SLIDE 66

localStorage.getItem("key");

slide-67
SLIDE 67

DEMO

slide-68
SLIDE 68

Mash it up!

slide-69
SLIDE 69

cool video: http://www.youtube.com/ watch?v=OFzkTxiwziQ

slide-70
SLIDE 70

OEmbed

http://oembed.com/

slide-71
SLIDE 71

http://www.youtube.com/watch?v=OyJd2qsRkNk

slide-72
SLIDE 72
slide-73
SLIDE 73

http://www.youtube.com/oembed?url=http%3A%2F %2Fwww.youtube.com%2Fwatch%3Fv %3DOyJd2qsRkNk&maxwidth=500&format=json

slide-74
SLIDE 74

{ "provider_url":"http:\/\/www.youtube.com\/", "title":"Jupiter Jones - Das Jahr in dem ich schlief (Musik Video)", "html":"\u003cobject width=\"500\" height=\"306\"\u003e \u003cparam name=\"movie\" value=\"http:\/\/www.youtube.com\/v\/ OyJd2qsRkNk?version=3\"\u003e\u003c\/param\u003e\u003cparam name= \"allowFullScreen\" value=\"true\"\u003e\u003c\/param\u003e \u003cparam name=\"allowscriptaccess\" value=\"always\"\u003e \u003c\/param\u003e\u003cembed src=\"http:\/\/www.youtube.com\/v\/ OyJd2qsRkNk?version=3\" type=\"application\/x-shockwave-flash \" width=\"500\" height=\"306\" allowscriptaccess=\"always \" allowfullscreen=\"true\"\u003e\u003c\/embed\u003e\u003c\/object \u003e", "author_name":"St182", "height":306, "thumbnail_width":480, "width":500, "version":"1.0", "author_url":"http:\/\/www.youtube.com\/user\/Stinkfist182", "provider_name":"YouTube", "thumbnail_url":"http:\/\/i4.ytimg.com\/vi\/OyJd2qsRkNk\/ hqdefault.jpg", "type":"video", "thumbnail_height":360 }

slide-75
SLIDE 75

cool video:

slide-76
SLIDE 76

http://embed.ly/

slide-77
SLIDE 77
slide-78
SLIDE 78

Caja

http://code.google.com/p/google-caja/

slide-79
SLIDE 79

html_sanitize(‘<script>alert(“foo“);</script>‘)

slide-80
SLIDE 80

DEMO

slide-81
SLIDE 81

Instant updates without reloading

slide-82
SLIDE 82

PubSubHubbub

retrieves Atom feed with Hub URL Hub posts sth pings every subscriber subscribes for feed acks subscription

http://code.google.com/p/pubsubhubbub/

slide-83
SLIDE 83

<link rel="alternate"href="http:// status.net.xyz:8061/index.php/api/statuses/ user_timeline/3.atom"type="application/atom +xml" title="Notice feed for bastian (Atom)"/>

slide-84
SLIDE 84

<entry> <activity:object-type>http://activitystrea.ms/schema/1.0/ note</activity:object-type> <id>http://status.net.xyz:8061/index.php/notice/20</id> <title>hello from client</title> <content type="html">hello from client</content> <link rel="alternate" type="text/html" href="http:// status.net.xyz:8061/index.php/notice/20"/> <activity:verb>http://activitystrea.ms/schema/1.0/post</ activity:verb> <published>2011-05-23T21:07:33+00:00</published> <updated>2011-05-23T21:07:33+00:00</updated> <link rel="ostatus:conversation" href="http://status.net.xyz: 8061/index.php/conversation/20"/> <georss:point>52.52437 13.41053</georss:point> <link rel="self" type="application/atom+xml"href="http:// status.net.xyz:8061/index.php/api/statuses/show/20.atom"/> <link rel="edit" type="application/atom+xml"href="http:// status.net.xyz:8061/index.php/api/statuses/show/20.atom"/> <statusnet:notice_info local_id="20" source="api" favorite="false"repeated="false"></statusnet:notice_info> </entry>

slide-85
SLIDE 85

http://activitystrea.ms/

slide-86
SLIDE 86

<link href="http://status.net.xyz:8061/ index.php/main/push/hub" rel="hub"/>

slide-87
SLIDE 87

PubSubHubbub

retrieves Atom feed with Hub URL Hub posts sth pings every subscriber subscribes for feed acks subscription

http://code.google.com/p/pubsubhubbub/

slide-88
SLIDE 88

http://nodejs.org/

slide-89
SLIDE 89

WebSockets

http://dev.w3.org/html5/websockets/

slide-90
SLIDE 90

socket.io

http://socket.io/

slide-91
SLIDE 91

Browser Notifications

slide-92
SLIDE 92

webkitNotifications.createNotification(image, title, text).show();

slide-93
SLIDE 93

webkitNotifications.requestPermission();

slide-94
SLIDE 94

retrieve Stream with Hub Ajax: request Subscription WebSockets: new Post subscribe at hub challenge ack new post Notification new post

slide-95
SLIDE 95

DEMO

slide-96
SLIDE 96

http://bit.ly/oscon_js_mashup

Rate and Comment

slide-97
SLIDE 97

h"p://twi"er.com/Bas2anHofmann h"p://profiles.google.com/bashofmann h"p://lanyrd.com/people/Bas2anHofmann/ h"p://slideshare.net/bashofmann mail@bas2anhofmann.de
