Marshall Mix Design

slide-2
SLIDE 2

CIVL 3137 2

Asphalt Concrete Properties

Stability Workability Skid Resistance Durability Stripping Fatigue Cracking Thermal Cracking Bleeding

Good Bad

slide-3
SLIDE 3

CIVL 3137 3

Stability

The ability to withstand traffic loads without distortion or deflection, especially at higher temperatures.

To get good stability, use strong, rough, dense-graded, cubical aggregate with just enough binder to coat the aggregate particles. Excess asphalt cement lubricates the aggregate particles and lets them slide past each

  • ther more easily, which reduces stability.
slide-4
SLIDE 4

CIVL 3137 4

Workability

The ability to be placed and compacted with reasonable effort and without segregation of the coarse aggregate.

Too much asphalt cement makes the mix tender and difficult to compact to the proper density. Asphalt cement with a low viscosity at compacting temperatures can also make a mix tender as can too much natural sand because it has smooth, round grains. Too little asphalt cement can make the mix stiff and difficult to compact as well.

slide-5
SLIDE 5

CIVL 3137 5

Skid Resistance

Proper traction in wet and dry conditions.

To get good skid resistance, use smaller aggregate so there are lots of contact points, use hard aggregate that doesn’t polish and make sure you have enough air voids to prevent bleeding. Some states now use an open-graded friction course (OGFC) that goes on top of the pavement and allows water to drain through the open pores to the dense graded layer below where it flows to the sides of the pavement, eliminating hydroplaning.

slide-6
SLIDE 6

CIVL 3137 6

Durability

The ability to resist aggregate breakdown due to wetting and drying, freezing and thawing,

  • r excessive inter-particle forces.

To get good durability, use strong, tough, nonporous aggregate and lots of asphalt cement to completely coat all of the aggregate particles (to keep them dry) and fill all of the voids between particles (to slow the oxidation

  • f the asphalt cement).
slide-7
SLIDE 7

CIVL 3137 7

Stripping

Separation of the asphalt cement coating from the aggregate due to water getting between the asphalt and the aggregate.

To reduce stripping, use clean, rough, hydrophobic aggregate and add lots

  • f asphalt cement to provide a thick coating of asphalt on every aggregate

particle.

slide-8
SLIDE 8

CIVL 3137 8

Bleeding

The migration of asphalt cement to the surface

  • f the pavement under wheel loads, especially

at higher temperatures.

To prevent bleeding, incorporate enough air voids so the asphalt can compress by closing air voids rather than by squeezing asphalt cement

  • ut from between the aggregate particles. If the VFA is too high, there is

no place for the asphalt cement to go when the pavement compresses.

slide-9
SLIDE 9

CIVL 3137 9

Fatigue Cracking

Cracking resulting from repeated flexure of the asphalt concrete due to traffic loads.

To minimize fatigue cracking, use the proper asphalt cement grade and have a thick asphalt cement coating to make the concrete flexible.

slide-10
SLIDE 10

CIVL 3137 10

Thermal Cracking

Cracking that results from an inability to acclimate to a sudden drop in temperature.

To minimize thermal cracking, use the proper asphalt cement grade and have a thick asphalt cement coating to make the concrete flexible.

slide-11
SLIDE 11

Summary

Use dense-graded, cubical aggregate that is strong, tough, hydrophobic, and nonporous. Use the correct asphalt cement grade for the job environment to prevent thermal cracking, fatigue cracking, draindown, and tenderness. Incorporate enough air voids to prevent bleeding but not so much as to reduce stability.

CIVL 3137 11

slide-12
SLIDE 12

Summary

Too little asphalt cement is bad because it can promote poor stability, poor workability, poor durability, stripping, and fatigue cracking. Too much asphalt cement is bad because it can promote poor stability, poor workability, poor skid resistance and bleeding. The goal of mix design is to balance all of these competing interests.

CIVL 3137 12

slide-13
SLIDE 13

CIVL 3137 13

Mix Design Basics

The right grade of asphalt cement

Relates to stability, workability, fatigue cracking, thermal cracking

The right type of aggregate

Relates to stability, workability, durability, stripping, skid resistance

The right gradation of aggregate

Relates to stability, workability

The right mix volumetrics

Relates to stability, durability, stripping, bleeding, skid resistance

slide-14
SLIDE 14

Marshall Mix Design

CIVL 3137 15

During WWII, the U.S. Army Waterways Experiment Station (WES) in Vicksburg, Mississippi was tasked with developing a mix design method for airfield pavements to address the poor performance exhibited by existing asphalt pavements under ever increasing aircraft wheel loads. They refined a method first developed in 1939 by Bruce Marshall at the Mississippi Highway Department into what we know today as the Marshall Mix Design Method by adding additional performance criteria to the ones that Marshall used and creating rigorous test specifications.

slide-15
SLIDE 15

Marshall Mix Design Steps

  • 1. Select an asphalt cement suitable for the climate.
  • 2. Select aggregates that meet the suitability criteria.
  • 3. Create an aggregate blend that meets the gradation criteria.
  • 4. Establish specimen mixing and compaction temperatures from

the viscosity-temperature chart for the asphalt cement.

  • 5. Compact three specimens at each of five asphalt contents 0.5%

apart spanning the expected optimum asphalt content.

  • 6. Determine the mix volumetrics (Gmb, Gmm,VTM, VMA, VFA) of

each specimen.

  • 7. Measure the performance properties of each specimen at the

high service temperature of 60ºC (140ºF).

CIVL 3137 16

slide-16
SLIDE 16

Temperature Requirements

  • In order to thoroughly mix the asphalt cement and

aggregate together, the asphalt cement should be heated to a temperature that produces a viscosity

  • f 170  20 cS during mixing.
  • In order to properly compact the resulting mixture,

it should either be reheated or allowed to cool to a whatever temperature produces an asphalt cement viscosity of 280  30 cS.

CIVL 3137 17

slide-17
SLIDE 17

Temperature-Viscosity

CIVL 3137 18

Peanut Butter Ketchup Chocolate Syrup Honey Tomato Juice Vegetable Oil

AASHTO T-245 MARSHALL MIXING TEMP. RANGE (170 +/- 20 cSt) AASHTO T-245 MARSHALL COMPACTING TEMP. RANGE (280 +/- 30 cSt)

slide-18
SLIDE 18

Marshall Specimens

Marshall specimens are prepared one at a time by mixing approximately 1200 g of the trial aggregate blend with enough asphalt cement to produce the desired asphalt content (Pb). The aggregate, asphalt cement, spoons, spatulas, and mixing bowls all must be heated to the proper mixing

  • temperature. Otherwise, the asphalt cement will not

properly coat all of the aggregate particles and will stick to the tools rather than the aggregate.

CIVL 3137 19

slide-19
SLIDE 19

Marshall Specimens

As soon as the binder and aggregate have been mixed together, a 4-in-diameter by 2½-in-high specimen is prepared by compacting the asphalt into a mold with a compaction hammer (called a Marshall hammer). The hammer consists of a 10 lb mass falling 18 in. per blow. Depending on the design traffic loads, either 35, 50, or 75 blows of the hammer are applied to each side of the specimen. The goal is to replicate the density of the asphalt after years of traffic has been applied to it.

CIVL 3137 20

slide-20
SLIDE 20

CIVL 3137 21

Marshall Specimens

Traffic Blows / Side Light 35 Medium 50 Heavy 75

10# 18"

Make 3 specimens at each of 5 different asphalt contents

More traffic = more compaction over time = denser asphalt

slide-21
SLIDE 21

CIVL 3137 22

Marshall Hammer

Mold Hammer

slide-22
SLIDE 22

Marshall Specimens

After curing overnight, the compacted specimen is weighed in air and suspended in water to determine its unit weight (density), voids in total mix (VTM), voids in mineral aggregate (VMA), and voids filled with asphalt (VFA). Of course this assumes the bulk specific gravity of the aggregate blend (Gsb) and the maximum specific gravity of the asphalt concrete (Gmm) at that asphalt content were previously determined.

CIVL 3137 23

slide-23
SLIDE 23

CIVL 3137 24

Mix Volumetrics

(Taken from The Asphalt Institute Manual ES-1, Second Edition)

Weigh in Air Weigh in Water

slide-24
SLIDE 24

CIVL 3137 25

Unit Weight / Density

in air mb SSD in water

W G W W  

3 mb mb

G 997.0 kg m   

3 mb mb

G 62.24 lb ft   

slide-25
SLIDE 25

CIVL 3137 27

Voids in Total Mix (Air Voids)

mb mm

G VTM 1 100% G         

Gmb = bulk specific gravity of compacted mixture

D 2726 - Bulk Specific Gravity and Density

  • f Compacted Bituminous Mixtures

Gmm = maximum specific gravity of the mixture

D 2041 - Theoretical Maximum Specific Gravity and Density of Bituminous Paving Mixtures

slide-26
SLIDE 26

CIVL 3137 29

Voids in Mineral Aggregate

 

mb b sb

G 1 P VMA 1 100% G           Gmb = bulk specific gravity of compacted mixture Gsb = bulk specific gravity of the aggregate blend Pb = asphalt binder content of mixture

slide-27
SLIDE 27

CIVL 3137 30

Voids Filled with Asphalt

VTM VFA 1 100% VMA         

VFA is the percentage of the available space between the aggregate particles (the VMA) that is occupied by asphalt binder rather than by air voids.

slide-28
SLIDE 28

Performance Testing

After being weighed in air and water, the specimen is heated for 20-30 minutes in a water bath at 140ºF in preparation for performance testing. The performance test used in Marshall mix design is called the stability and flow test. The heated specimen is placed in a compression testing machine (called a Marshall tester) between two semi-circular loading

  • heads. It is then loaded at a constant rate of 2 in/min

until a peak load is determined.

CIVL 3137 31

slide-29
SLIDE 29

Performance Testing

The maximum load (in pounds) recorded during the test is termed the Marshall stability and the amount of head travel (specimen compression) needed to reach that load (in units of 0.01 in) is termed the flow.

CIVL 3137 32

slide-30
SLIDE 30

CIVL 3137 33

Performance Testing

140oF

flow stability deflection

(0.01 in)

load

(lbs)

slide-31
SLIDE 31

CIVL 3137 34

Stability and Flow Tester

slide-32
SLIDE 32

Marshall Mix Design Steps

The previous steps are repeated 15 times (to make 3 specimens at each of 5 different asphalt contents). At that point, we have collected all of the information that we need to do our mix design. Here “mix design” means finding an asphalt content for this trial aggregate blend that produces specimens whose mix volumetrics (VTM, VMA, and VFA) and performance properties (stability and flow) meet all

  • f the specifications.

CIVL 3137 35

slide-33
SLIDE 33

Marshall Mix Design Steps

For each asphalt content, we calculate the average unit weight, stability, VTM, VMA, VFA, and flow then plot those averages as a function of the asphalt content. From the plots we determine (a) the asphalt content that produces the maximum unit weight, (b) the asphalt content that produces the maximum stability, and (c) the asphalt content that produces exactly 4% air voids (VTM).

CIVL 3137 36

slide-34
SLIDE 34

CIVL 3137 38

Unit Weight Results

159 160 161 162 163 164 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) Unit Weight (pcf)

Maximum Unit Weight @ 5.1% AC

slide-35
SLIDE 35

CIVL 3137 39

1500 1600 1700 1800 1900 2000 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) Marshall Stability (lbs)

Stability Results

Maximum Stability @ 4.7% AC

slide-36
SLIDE 36

CIVL 3137 40

1 2 3 4 5 6 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) VTM (%)

VTM Results

4% Air Voids @ 4.3% AC

slide-37
SLIDE 37

CIVL 3137 41

13 14 15 16 17 18 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) VMA (%)

VMA Results

slide-38
SLIDE 38

CIVL 3137 42

50 60 70 80 90 100 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) VFA (%)

VFA Results

slide-39
SLIDE 39

CIVL 3137 43

5 10 15 20 25 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) Flow

Flow Results

slide-40
SLIDE 40

Optimum Asphalt Content

The Asphalt Institute suggests the optimum asphalt content is the average of the three asphalt contents determined from the plots. Based on the values taken from the example plots, the optimum asphalt content for this trial aggregate blend is 4.7%.

CIVL 3137 44

slide-41
SLIDE 41

CIVL 3137 45

Optimum Asphalt Content

% 7 . 4 3 3 . 4 7 . 4 1 . 5 AC    

Maximum Density Maximum Stability 4% Air Voids

Asphalt Institute Procedure

slide-42
SLIDE 42

Optimum Asphalt Content

The National Asphalt Pavement Association (NAPA) suggests the optimum asphalt content is simply the asphalt content that produces exactly 4% air voids. From our example plots, this would be 4.3%. Which one is correct? Keep in mind that these are just trials. Like the mix design method for concrete, the idea is to get you in the ballpark, then you can tweak the design as needed.

CIVL 3137 46

slide-43
SLIDE 43

CIVL 3137 47

Optimum Asphalt Content

 5.1 AC  4.7   4.3 4.3% 1

Maximum Density Maximum Stability 4% Air Voids

NAPA Procedure

This is what TDOT uses

slide-44
SLIDE 44

Optimum Asphalt Content

Once you’ve estimated the optimum asphalt content, you need to go back to the plots and estimate the VTM, VMA, VFA, stability and flow of a specimen made at the optimum asphalt content (which probably isn’t one of the asphalt contents you used to produce the specimens). If these values meet the requirements in the next slide, you’re done. Otherwise, you need to either tweak the asphalt content (if possible) or try a different aggregate blend.

CIVL 3137 48

slide-45
SLIDE 45

CIVL 3137 49

Marshall Criteria

(Asphalt Institute Criteria)

Criteria Min. Max. Min. Max. Min. Max. Number of Blows Stability (lbs) 500 750 1500 Flow 8 20 8 18 8 16 Air Voids (%) 3 5 3 5 3 5 VMA (%) See Next Slide Light Traffic Medium Traffic Heavy Traffic 35 50 75 16 14 1800

TDOT uses 2000

18 750 1200

slide-46
SLIDE 46

CIVL 3137 51

Marshall VMA Criteria

Minimum VMA (%)

10

Nominal Maximum Particle Size

20 30 40 50 2" 1½" 1" ¾" ½" 4 3/8" 8 40 Deficient in either asphalt or air voids

(Assuming 4% Design Air Voids)

slide-47
SLIDE 47

Question to Ponder

Why does the minimum VMA requirement increase with a decrease in the NMAS?

CIVL 3137 56

Minimum VMA (%)

10

Nominal Maximum Particle Size

20 30 40 2" 1½" 1" ¾" ½" 4 3/8" 8 40 Deficient in either asphalt or air voids

slide-48
SLIDE 48

Question to Ponder

Recall that the VMA is the void space around all of the aggregate particles in the compacted specimen if you could make all of the asphalt cement disappear. Mathematically, this is equal to the volume of the air voids between the particles plus the volume of the effective asphalt cement coating the particles.

CIVL 3137 57

slide-49
SLIDE 49

CIVL 3137 58

Voids in Mineral Aggregate

VTM

(Voids in Total Mix)

VMA

(Voids in Mineral Aggregate)

slide-50
SLIDE 50

Question to Ponder

As we’ve mentioned numerous times, the smaller the aggregate, the larger the surface area per unit volume. So asphalt concrete that is made with an aggregate blend having a small NMAS requires more effective asphalt cement to coat all of those surfaces. Thus the VMA must be higher in order to have enough room in the aggregate skeleton for all that extra binder.

CIVL 3137 59

slide-51
SLIDE 51

CIVL 3137 60

Effect of NMAS on Surface Area

surface area = 11 ft2 surface area = 22 ft2

10" effective asphalt volume  aggregate surface area

slide-52
SLIDE 52

Marshall Criteria

For the purpose of our example, let’s assume we are designing our mix for heavy traffic. That means the stability at our optimum asphalt content must exceed 1800 lb, the flow must be between 8 and 14, the air voids must be between 3% and 5%, the VFA must be between 65% and 75% and, if we assume that the NMAS of our aggregate blend is ¾", the VMA must be at least 14%. Let’s see how we did.

CIVL 3137 61

slide-53
SLIDE 53

CIVL 3137 62

1500 1600 1700 1800 1900 2000 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) Marshall Stability (lbs)

Check Stability @ Optimum

(assume heavy traffic for this example)

OK

slide-54
SLIDE 54

CIVL 3137 63

5 10 15 20 25 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) Flow

Check Flow @ Optimum

(assume heavy traffic for this example)

OK

slide-55
SLIDE 55

CIVL 3137 64

1 2 3 4 5 6 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) VTM (%)

Check VTM @ Optimum

(assume heavy traffic for this example)

OK (but just barely)

slide-56
SLIDE 56

CIVL 3137 65

50 60 70 80 90 100 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) VFA (%)

Check VFA @ Optimum

(assume heavy traffic for this example)

Not OK

slide-57
SLIDE 57

CIVL 3137 66

VMA Criteria

Minimum VMA (%)

10

Nominal Maximum Particle Size

20 30 40 50 2" 1½" 1" ¾" ½" 4 3/8" 8 40 Deficient in either asphalt or air voids 14

(assume a ¾" NMAS for this example)

slide-58
SLIDE 58

CIVL 3137 67

13 14 15 16 17 18 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) VMA (%)

Check VMA @ Optimum

(assume a ¾" NMAS for this example)

OK

slide-59
SLIDE 59

CIVL 3137 68

13 14 15 16 17 18 3.5 4.0 4.5 5.0 5.5 6.0 6.5 Asphalt Content (%) VMA (%)

Check VMA @ Optimum

TDOT also requires the AC to be less than that which minimizes VMA

(assume a ¾" NMAS for this example)

OK

slide-60
SLIDE 60

Marshall Criteria

At an optimum asphalt content of 4.7% we barely meet the VTM requirement and didn’t meet the VFA

  • requirement. What does this tell us?

We just barely have enough air voids and too much

  • f the VMA space is filled with asphalt cement, so it

is likely that our VMA is actually too low.

CIVL 3137 69

slide-61
SLIDE 61

Marshall Criteria

If the VMA is higher, there will be more room in the aggregate skeleton for asphalt cement and air voids. If we kept the amount of asphalt cement the same, that means there would be more air voids (VTM) and the asphalt cement would occupy less of the available space, bringing the VFA down. So how could we increase the VMA?

CIVL 3137 70

slide-62
SLIDE 62

CIVL 3137 71

Ways to Increase VMA

  • 1. Reduce the dust (fines) content
  • 2. Reduce the amount of sand
  • 3. Gap-grade the aggregate blend
slide-63
SLIDE 63

Ways to Increase VMA

Remember that one of the reasons the TDOT 411-D specifications don’t exactly match the theoretical maximum density curve is to “open up” the gradation to allow room for asphalt cement and air. All three of the steps on the previous slide would “open up” the gradation by removing some of the smaller material.

CIVL 3137 72

slide-64
SLIDE 64

CIVL 3137 73

TDOT Specifications

20 40 60 80 100 0.01 0.1 1 10 100 Percent Passing Opening Size (mm)

1½" ¾"

3/8"

4 8 16 30 50 100 200

Maximum Density Curve

TDOT Grading E

slide-65
SLIDE 65

CIVL 3137 76

Ways to Increase VMA

  • 1. Reduce the dust (fines) content
  • 2. Reduce the amount of sand
  • 3. Gap-grade the aggregate blend
  • 4. Replace some of the natural sand (if

used) with manufactured sand

slide-66
SLIDE 66

Ways to Increase VMA

Recall that manufactured sand is angular and natural sand is rounded. Recall, too, that the void content of angular sand is higher than that of rounded sand (which is why void content is used to determine fine aggregate angularity). So replacing some of the natural sand with the same weight of manufactured sand will increase the VMA.

CIVL 3137 77

slide-67
SLIDE 67

Natural Sand

CIVL 3137 78

slide-68
SLIDE 68

Manufactured Sand

CIVL 3137 79

slide-69
SLIDE 69

CIVL 3137 81

Ways to Increase VMA

  • 1. Reduce the dust (fines) content
  • 2. Reduce the amount of sand
  • 3. Gap-grade the aggregate blend
  • 4. Replace some of the natural sand (if

used) with manufactured sand

  • 5. Increase fractured face percentage
  • 6. Reduce flat-and-elongated particles
slide-70
SLIDE 70

Ways to Increase VMA

Assuming you are using a crusher run gravel as your coarse aggregate, you could run the material through the crusher again to increase the fractured face

  • percentage. This would make the coarse aggregate

more angular, which has the same effect on VMA as replacing natural sand with manufactured sand.

CIVL 3137 82

slide-71
SLIDE 71

Ways to Increase VMA

Replacing flat and elongated particles increases VMA by replacing each long skinny rock with two

  • r three smaller equidimensional rocks. Since there

will be void spaces between the smaller rocks that didn’t exist before, the VMA will increase.

CIVL 3137 83

slide-72
SLIDE 72

Ways to Increase VMA

If none of the steps above fix the problem, you may want to consider a different aggregate source.

CIVL 3137 84
