Marguerite PIERRE CEA Saclay ARCHES scientific workshop Paris December, 2015 XXL in short: 1) FIND ~ 500 X-ray clusters in 50 deg 2 2) DO COSMOLOGY Background image : CFHT i X-ray clusters ~ 5% Blue contours : XMM XLSSC 001 @ z=0.61

slide-1
SLIDE 1

Marguerite PIERRE CEA Saclay

ARCHES scientific workshop Paris December, 2015

slide-2
SLIDE 2

XXL in short:

1) FIND ~ 500 X-ray clusters in 50 deg2 2) DO COSMOLOGY

X-ray clusters ~ 5% Background image : CFHT i Blue contours : XMM

slide-3
SLIDE 3

XLSSC 001 @ z=0.61

slide-4
SLIDE 4

Working with these data : difficult ! : misleading (Poisson) : ambitious … but feasible and exciting !

XLSSC 008 @ z=0.30

slide-5
SLIDE 5

ž XMM VLP (2010) following XMM-LSS (2000-2010) :

  • 2 x 25 deg2 area
  • Total time > 6Ms
  • Largest XMM programme to date

ž An international consortium gathering ~ 100

scientists.

ž The 542 XMM observations were completed in

2013

ž First series of papers submitted to A&A in July

2015

slide-6
SLIDE 6
  • 1. Scientific motivations
  • 2. The XMM observations
  • 3. The follow-up programme
  • 4. The cluster catalogue
  • 5. Overview of the first results : 13 papers
  • 6. A comprehensive associated simulation
  • programme. Future
slide-7
SLIDE 7
slide-8
SLIDE 8

ž Obtain a sample of ~ 500 clusters of

galaxies out to z~1

ž Well-defined selection effects ž Self-consistent cluster mass

measurements

ž Cluster counts AND cluster LSS

è Standalone cosmological constraints

slide-9
SLIDE 9

XXL Ref. Dark Energy Task Force *clusters* Pierre et al 2011

slide-10
SLIDE 10
slide-11
SLIDE 11

LSS Surveys Roadmap

!

  • I. Shipsey

Stage IV Stage III

2014 2016 2018 2020 2022 2024 2026 2028 2030 2032

BOSS Dark Energy Survey HETDEX Hyper-Suprime D.E. Spectro. Instr. EUCLID Large Synoptic Survey Telescope WFIRST

  • AFTA

eBOSS Prime Focus Spectro.

spectroscopy imaging

High degree of complementary between missions

Image: Ian Shipsey XMM-XXL

slide-12
SLIDE 12

ž Cluster physics

~ 500 clusters

  • Scaling relations
  • Baryon budget
  • Galaxies in clusters

ž AGN physics

~ 25,000 AGNs

  • AGN evolution
  • AGNs in LSS
  • Search for exotic and very distant objects
slide-13
SLIDE 13

XXL standard processing 1: F. Pacaud Processing for the diffuse background: S. Snowden

slide-14
SLIDE 14

EXPO map

XXL-N 25 deg2

In CFHTLS-W1 2h23 -5d00 (extension of the XMM-LSS field)

Moon

slide-15
SLIDE 15

XXL-N

1 deg BKG map

XXL north

1 deg BKG map 13 pointings (+2 thanks to mosaic mode)

Observed Good Usable Lost

slide-16
SLIDE 16

EXPO map

XXL-S 25 deg2

23h30 -55d00 within the SPT 100 deg2 Deep Field

slide-17
SLIDE 17

XXL south

7 pointings (+1 with mosaic) 1 deg BKG map

Observed Good Usable Lost

slide-18
SLIDE 18

z = 0.053 z = 1.22

slide-19
SLIDE 19

I 3.6 µm 4.5 µm

slide-20
SLIDE 20

~ surface brightness limited

slide-21
SLIDE 21

Flux (cts/s) Core radius (arsec)

Not a flux limit ! Class 1 sample

Pacaud et al 2006

slide-22
SLIDE 22
slide-23
SLIDE 23

ž Deep multi-band imaging

  • CFHTLS
  • DECam (Lidman et al)
  • HSC

ž Extensive spectroscopic follow-up

  • ESO LP – NTT & VLT (Adami et al)
  • WHT (Poggianti et al)
  • AAOmega (Lidman et al)
  • Associated with GAMA and VIPERS
slide-24
SLIDE 24

ž Full IR coverage

  • Spitzer
  • WIRCAM @ CFHT
  • VISTA

ž On-going radio surveys

  • GMRT (Raychaudury et al)
  • VLA, ATCA (Smolcic et al)
  • SPT, ACT

ž Existing public surveys

  • SDSS, Galex, . . .
slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27

Selction: C1+C2 flux in r=1’ (>3 10-14)

slide-28
SLIDE 28

Brightest 100 cluster sample

Self-consistent analyses WMAP9 cosmology assumed

slide-29
SLIDE 29
slide-30
SLIDE 30

Slope 2.66 +/- 0.15 E(z)1.46+/-0.80 !CAVEAT! Compatible with self-similar evolution

slide-31
SLIDE 31

38 XXL clusters with CFHT-Lens

slide-32
SLIDE 32

38 XXL clusters with CFHT-Lens Self-similarity 40%

  • ffset ?
slide-33
SLIDE 33
slide-34
SLIDE 34

No evolution for F(Lx) !

slide-35
SLIDE 35

OWLS models

}

slide-36
SLIDE 36

Using

lensing masses

OWLS models

}

slide-37
SLIDE 37

. XXL 100 sample

slide-38
SLIDE 38

XMM photon map Optical galaxy density contours Image size 20’x13’

slide-39
SLIDE 39
slide-40
SLIDE 40
  • First XXL results
  • 13 papers
  • General presentation
  • The 100 brightest clusters + science
  • A few interesting clusters
  • The 1000 brightest AGNs
  • VLA and ATCA catalogues
  • ESA-ESO-A&A press release on December 15th
slide-41
SLIDE 41
  • General catalogues (Milano)
  • X-ray
  • Optical
  • Radio

http://cosmosdb.iasf-milano.inaf.it/XXL/

  • Dedicated cluster database (Lyon)
  • X-ray parameters
  • X-ray, optical, IR images
  • Detail of the redshift measurements
  • Follow-up information

http://xmm-lss.in2p3.fr:8080/xxldb/index.html

slide-42
SLIDE 42

~ 500 clusters ~ 10 000 AGNs (5 10-15 erg/s/cm2, completeness limit) > 25 000 AGNs in total

slide-43
SLIDE 43

ž Reprocessing of the X-ray data – with overlap ž Cosmology with the full cluster sample (2016)

Simultaneous fit of:

  • Cosmology
  • Selection effects
  • Cluster physics evolution (scaling relations – baryon fraction)

ž Use numerical simulations to refine the selection function:

  • OWLS (McCarthty et al)
  • Aardvark (Evrard et al)
  • Horizon (Devriendt et al)
  • DEUS (Alimi et al)

ž And, of course, AGN LSS and AGN science ž Final multi-λ catalogues => Legacy

slide-44
SLIDE 44

OWLS simulations (X-ray flux) McCarthy, Le Brun, 2014 10ks XMM photon image Faccioli, Sauvageot et al in

slide-45
SLIDE 45

15 December 2015 ESA-ESO A&A press-release 13 papers

Stay tuned!
