MANUFACTURING OF DMF TYPE III PHARMACEUTICAL PACKAGING COMPONENTS UNDER cGMP ENVIORNMENT: CONTAINERS & CLOSURES DMF # 20132 FACTORY BUILDING AT A GLANCE Exechon a proprietorship firm Commercially started in Dec 2006. It is
SLIDE 2
SLIDE 3
AT A GLANCE
Exechon a proprietorship firm Commercially started in Dec 2006.
It is located at Vadodara.
Total built up area 6000 sq.mtr.
Land area 50000 sq.mtr.
ISO 9001:2008 Certified by DNV.
Product : DMF TYPE III Containers & Closures for Pharmaceutical
Packaging Application.
SLIDE 4
SALIENT FEATURES..
Controlled, clean manufacturing environment.
State of the art IBM Technology imported from Europe & USA.
- Mfg. DMF Type III products and Products are made out of FDA
approved, DMF listed imported resin and colorant.
Exclusive focus on pharmaceutical packaging products for regulated market.
Centrally air conditioned mfg facility equipped with HEPA filter.
ISO 9001:2008 certified unit by DNV, cGMP Environment, bottles comply with USP <661> recent addition.
Installed capacity to make 120Mn bottles and 60 Mn Screw Caps per year.
Young team ‐ trained in India as well as outside India to master the know‐how.
SLIDE 5
STATE-OF THE ART TECHNOLOGY
SLIDE 6
SALIENT FEATURES..
High performance PLC based Injection molding machines for precise molding of Screw caps.
Fully automatic, full‐hot runner, Injection molds for screw Caps, imported from USA & Korea.
Fully automatic, PLC controlled, Cap‐lining machine from Europe
Central Pneumatic Conveying system from L&T‐MOTAN, Germany for automatic material conveying & color dosing.
100% Power Back up
Oil Free air compressor – Technology from Japan
SLIDE 7
PRODUCT RANGE
40cc to 950cc white PE round shaped, IBM, with SP 400NF.
1750cc, 2000cc, 2500cc white PE round shaped, EBM, with SP400 NF.
40cc to 1500cc – HW bottles (EBM), with SP400NF.
OINDP containers of 15cc, 20cc, 30cc sizes SN as well as CN
600cc & 750cc Cylindrical jars with accessories Screw Caps with liner ranging from 33mm to 100mm
SLIDE 8
Committed to meet most exacting schedules with care…
10 Micron clean, enclosed finished goods warehouse.
FIFO in‐place.
Double bag packing with inner label + corrugated shipper dully taped and labeled.
24 Hrs X 365 days – A.C. Storage for Caps & Liner, with temp. mapping.
Warehouse capable to store 10 Mn Units of bottles & Caps.
SLIDE 9
FRONT VI EW OF PLANT
SLIDE 10
VI EW OF PRODUCTI ON CORI DORE
SLIDE 11
QUALITY POLICY STATEMENT
Exechon considers QUALITY as one of the principle strategic obj.
to guarantee their customer for the product safety in every way.
Committed to meet customer’s needs by compliance with applicable
statutory and regulatory obligations, international product quality standards to ensure customer satisfaction every time.
The stringent quality standard and production efficiency shall
be achieved by investing in technology and continuous training to its team members.
It is our Endeavor to create a culture of Total Quality where
continual improvement of our people, our processes and our products become a way of life.
SLIDE 12
Best Of Quality Control Instruments..
Contact less dimension measurement using Japanese Optical Focus Technology.
Non destructive wall thickness measurement using magnetic thickness gauge imported from USA.
Induction sealing machine, lab version, from USA.
Cap torque analyzer, from USA
Various Measuring instruments from Japan
Electronic weighing balance for weight measurement.
SLIDE 13
PRIMARY RAW MATERIALS
MATERIAL GRADE DMF # IMPORTED FROM HDPE RESIN MARLEX HHM 5502 BN 1016 QATAR PE COLORANT AMPACET_11447 19122 THAILAND HEATSEAL LINER SANCAP HS 035 / Triseal HS 123 / HS130 2518 / 1378 USA PPHP RESIN PURELL HP570R 13038 EUROPE PP COLORANT AMPACET_11343 19123 THAILAND
SLIDE 14
BLEND OF BEST… Offers Gross Advantage to Customer !
Best of Technology Well Trained Manpower DMF sourced Primary Material QMS ISO 9001 : 2008 Well designed Infrastructure cGMP Environment Production Capacity Timely Delivery Continuous Improvement Approach
SLIDE 15
WE HAVE BEEN SUCCESSFULLY AUDITED BY
Mallinckrodt / Tyco Healthcare of USA
Cadila Healthcare Limited
Torrent Pharmaceuticals
IPCA Laboratories
- Dr. Reddy’s Laboratories Ltd.
Sun Pharmaceuticals Industries Ltd.
Astra Zeneca – India
Unique Pharmaceuticals Lab.
Alembic Limited
Amneal Pharmaceuticals Ltd
Glenmark Pharmaceuticals Ltd
SLIDE 16
Thank You !
Contact Details : Exechon (Properitor – Shivani Trust) Block # 596, ECP Canal Road
- Vill. – Luna, Taluka
– Padra
- Dist. –
Vadodara 391440, India. Ph # +91‐2662‐221422 | Fax # +91‐2662‐221426 Contact Person :
- Mr. Mukesh L.
