Manufactured System Design w w w. t r a n s p o r t a t i o n . o h i o . g o v 1 Manufactured Systems L&D Vol. 2 Section 1117.1 Provides quality treatment only w w w. t r a n s p o r t a t i o n . o h i o . g o v 2 Manufactured System
SLIDE 2
SLIDE 3
w w w. t r a n s p o r t a t i o n . o h i o . g o v
3
Manufactured System Treatment Processes
SLIDE 4
w w w. t r a n s p o r t a t i o n . o h i o . g o v
4
Design Process
Treatment Goals Siting Analysis Manufactured System Sizing Other Considerations
SLIDE 5
w w w. t r a n s p o r t a t i o n . o h i o . g o v
5
Design Process
Treatment Goals Siting Analysis Manufactured System Sizing Other Considerations
SLIDE 6
w w w. t r a n s p o r t a t i o n . o h i o . g o v
6
Project Example
Intersection improvement Add turn lane All within existing right-of-way
SLIDE 7
w w w. t r a n s p o r t a t i o n . o h i o . g o v
7
Project Example
SLIDE 8
w w w. t r a n s p o r t a t i o n . o h i o . g o v
8
Project Example – Treatment Goals
Project EDA = 2.28 ac All within existing right-of-way Aix = 2.28 ac; Ain = 0.0 ac T% = [(Aix x 20)+(Ain x 100)] / (Aix + Ain) T% = [(2.28 x 20)+(0.0 x 100)] / (2.28 + 0) T% = 20% 20% x 2.28 ac = 0.46 ac
SLIDE 9
w w w. t r a n s p o r t a t i o n . o h i o . g o v
9
Project Example – Treatment Goals
Project EDA = 2.28 ac >= 1 ac
Need a post-construction BMP
All redevelopment
Need to treat 0.46 ac (20%)
All in existing right-of-way
All existing right-of-way considered impervious Therefore no “new impervious area in new permanent right-of-way” Water quality treatment only required
SLIDE 10
w w w. t r a n s p o r t a t i o n . o h i o . g o v
10
Design Process
Treatment Goals Siting Analysis Manufactured System Sizing Other Considerations
SLIDE 11
w w w. t r a n s p o r t a t i o n . o h i o . g o v
11
Siting Analysis
Manufactured systems near storm sewers Avoid underground utilities Avoid pipes at depths greater than 10 ft Avoid trunk lines (pipes with WQF greater than 6 cfs) Site system outside of paved areas for maintenance
SLIDE 12
w w w. t r a n s p o r t a t i o n . o h i o . g o v
12
Footprint
SLIDE 13
w w w. t r a n s p o r t a t i o n . o h i o . g o v
13
Maximum Depth
Contech CDS Model 4045-8-C
SLIDE 14
w w w. t r a n s p o r t a t i o n . o h i o . g o v
14
Maximum Depth
Image: Contech
SLIDE 15
w w w. t r a n s p o r t a t i o n . o h i o . g o v
15
No Trunk Lines
SLIDE 16
w w w. t r a n s p o r t a t i o n . o h i o . g o v
16
Siting Analysis
Tributary area = 12.42 ac
- Trib. Area within R/W = 1.94 ac
SLIDE 17
w w w. t r a n s p o r t a t i o n . o h i o . g o v
17
Design Process
Treatment Goals Siting Analysis Manufactured System Sizing Other Considerations
SLIDE 18
w w w. t r a n s p o r t a t i o n . o h i o . g o v
18
Manufactured System Sizing Design after January 2019 Water Quality Flow (WQF): Q = CiA Calculate time of concentration to determine i
Tc = overland + shallow conc. + pipe flow To = 16 min Ts = 7 min Tp = 2 min
Tc = 16 + 7 + 2 = 25 min
SLIDE 19
w w w. t r a n s p o r t a t i o n . o h i o . g o v
19
SLIDE 20
w w w. t r a n s p o r t a t i o n . o h i o . g o v
20
Manufactured System Sizing Design after January 2019 Water Quality Flow (WQF): Q = CiA
C = 0.41 i = 1.13 in/hr A = 12.42 ac.
WQF = 0.41 * 1.13 in/hr * 12.42 ac WQF = 5.75 cfs ODOT Type 4
SLIDE 21
w w w. t r a n s p o r t a t i o n . o h i o . g o v
21
Manufactured System Sizing
SLIDE 22
w w w. t r a n s p o r t a t i o n . o h i o . g o v
22
SLIDE 23
w w w. t r a n s p o r t a t i o n . o h i o . g o v
23
BMP Calcs Spreadsheet
SLIDE 24
w w w. t r a n s p o r t a t i o n . o h i o . g o v
24
Design Process
Treatment Goals Siting Analysis Manufactured System Sizing Other Considerations
SLIDE 25
w w w. t r a n s p o r t a t i o n . o h i o . g o v
25
Sample Plan Note W103
SLIDE 26
w w w. t r a n s p o r t a t i o n . o h i o . g o v
26
Manufactured System Considerations
Vacuum truck maintenance every 4 – 12 months
Access and safety for maintenance crew Need to close lanes
- Max. depth of vac truck suction (~20 ft)
- Max. flow 6 cfs
May need to separate off-site flows
SLIDE 27
w w w. t r a n s p o r t a t i o n . o h i o . g o v
27
Manufactured System Considerations
ODOT Qualified Products List – 31 Products Manufactured Water Quality Structure (SS- 995)
Advance Drainage AquaShield Bio Clean Contech Environment 21 Hydro Int.
All hydrodynamic separators
SLIDE 28
w w w. t r a n s p o r t a t i o n . o h i o . g o v
28
Manufactured System Considerations
Some Cartridge Filters: 80% TARP TSS Distribution Hydrodynamic Separators: 80% ODOT Sand, 50% TARP Catch Basin Inserts: May Capture > 200 microns
Cartridge (Contech)
- Hydro. Sep. (Contech)
Basin Insert (Contech)
SLIDE 29
w w w. t r a n s p o r t a t i o n . o h i o . g o v
29
Research: Particle Size Distribution
Image: 3P Technik UK
SLIDE 30
w w w. t r a n s p o r t a t i o n . o h i o . g o v
30
10 20 30 40 50 60 70 80 90 100 1 10 100 1,000
Percent Finer Particle Size (µm)
Sediment Particle Distributions
NJDEP Test US Silica OK110 US Silica F110
80% TSS Removal
Research: Particle Size Distribution
SLIDE 31
w w w. t r a n s p o r t a t i o n . o h i o . g o v
31
Questions ?
Jon Prier, P.E. jonathan.prier@dot.ohio.gov 614-644-1876
