Management of SCA-based Radio Systems with the PlatformManager Component

Shan Wang

National University of Defense Technology Research Center of Software Defined Radio Engineering

Outline

The problem we have met Principal of the Solution Implementation Functional Scalability

Problem

In software radio systems ……  More and more hardware and software resources need to be managed.  More and more functional requirements of dynamic control, such as configure, query, reconfiguration.  Diversification of communication protocols with host.

Other factors

 The SCA specification itself does not clearly stipulate platform management.  The external host software is not required to be an SCA- compliant component. How?

Problem

How to manage and operate such systems conveniently, and how to transplant applications flexibly have become a problem to be solved urgently in reality.

Principal of the Solution

 No matter how we solve this problem, the premise is that the platform management function must be a SCA-compliant component.  Considering that the device-related characteristics of the platform management function, we tend to design it as a device component, which locates in the software radio system as a service.

PlatformManager Service(PMS)

Agent of SNMP Networks Management

Software Radio Systems

UDP Server …… UDP Client Other requirements Platform Manager Service Core Framework Applications Devices ...

Internal Control Channel External Data Channel

Primary Functions of the current PMS

Management

• f the Domain

Query and Config

• f Channels

Query and Config

• f Applications

Modification

• f the Route Table

 Provide a general management style for SCA-based platform.  Able to monitor and control all registered components in the domain.  Fully compliant with SCA specifications  Working in GPPs, with excellent portability.

Effects of the Solution

Functional Scalability

Extended Functions

Resource Monitor Fault Tolerance and Health Management Dynamic Migration ……

Resource Monitor

report

Node 1 Node 2 Node n

qurey

Resource Monitor

PMS component

Func(1) Func(3) Func(2)

Fault Tolerance and Health Management

Failured component Locate Judge Recover User

CF

PMS Component

Resource Monitor Fault Tolerance and Health Management

Dynamic Migration

RF module Signal Process App/Service Protocol module RF PHY NET Data/Voice MAC/LLC Signal Process PHY MAC/LLC

Thank you. Any question？
