MAHASRI/AMY Monsoon Asian Hydro- Atmosphere Scientific Research - - PowerPoint PPT Presentation

MAHASRI/AMYと日変化研究

Jun Matsumoto

Department of Geography, Tokyo Metropolitan University JAMSTEC/ IORGC

Monsoon Asian Hydro- Atmosphere Scientific Research and Prediction Initiative

http://mahasri.cr.chiba-u.ac.jp/

Data Management Water and Energy Budget Studies Water Resource Applications Project Stable Water Isotope Intercomparison Group Worldwide Integrated Study

• f Extremes

Transferability

CEOP

IAEA

Northeast Asia Tropics Tibet/Himalaya East Asia

MAHASRI

Objective Objective

"To establish hydro-meteorological prediction system, particularly up to seasonal time-scale, through better scientific understanding of Asian monsoon variability".

Long Long-

• term Time Schedule

term Time Schedule

• October, 2006-March, 2010: Research phase I

(2006-2007: Build-up new observation systems)

• 2008(-2009): IOP-year (AMY: Asian Monsoon

Year)

• 2011-2014: Research phase II
• 2015: Concluding phase

Key Science Issues (1) Key Science Issues (1)

• Atmosphere-ocean-land interactions in the

Asian monsoon system-

• Scale-interactions among diurnal, synoptic,

intraseasonal and seasonal variability of Asian monsoon rainfall

• Effect of various-scale orography on monsoon

rainfall

Diurnal, Intraseasonal and Seasonal variations over Sumatera

Westward migration Eastward migration 01 02 01 02 M J J A S O N D J F M A M J J A S O N D J F M A N AA’ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ↑ BB’ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ EQ CC’ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ △ ○ ↓ DD’ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ △ △ S EE’ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○

(a) (b) (c)

GMS Cloud Top Temperature 850 hPa Westerly 300 hPa Eassterly

(Sakurai et al., 2004; JMSJ)

Onset of rainy season over East Tibet (6月13日)

6月21-23日 6月26-28日 7月17-21日

Plateau Edge Plateau Edge

Time-cross section of Tbb in June/July of 1998

(Yasunari & Miwa, 2006: JMSJ)

GMS IR GMS IR JMA JMA-

• sfc

sfc

A 1998 SCSMEX case ? ? ? ?

• 2. Rainstorm genesis mechanism
• 2. Rainstorm genesis mechanism

(T.C.Chen, Personal Com.)

6Z, 12Z 0Z, 18Z

→ Afternoon/Evening → Midnight/Morning

Genesis location/timing of rainstorm Genesis location/timing of rainstorm

• 3. Genesis: Diurnal variation
• 3. Genesis: Diurnal variation

(T.C.Chen, Personal Com.)

Diurnal Cycle: Local time of maximum precipitation

Satellite ‘Observations’ Model Simulation

(Lau et al. 2007)

Can GCM simulate the timing of diurnal cycle?

(Arakawa & Kitoh)

• 20km AGCM captures spatial

distribution of diurnal rainfall peak time over both land and the ocean within a few hours

• Few difference between 20km and

120km AGCMs

New field observation plan New field observation plan

• Asian Monsoon Year (AMY)-2008

in collaboration with MAHASRI Japan- JEPP, JAMSTEC/IORGC China- 973AIPO India- CTCZ Australia etc. - SPICE THORPEX-YOTC

Objective of AMY Objective of AMY’ ’08 08

• To improve Asian monsoon predictions, in

particular, in intraseasonal and seasonal time scales To attain its goal….

• Clarify multi-scale interactions among diurnal,

synoptic and intraseasonal variations of Asian monsoon

• Clarify land surface processes related with

Asian monsoon variability

• Clarify the role of aerosol on Asian monsoon

variability

MAHASRI and related Projects

JEPP: Indian Ocean JEPP: Indian Ocean

AMY (Asian Monsoon Year) is planned from April 2008 to March 2009 continent

JEPP: Indochina

MAHASRI

JEPP: Indian Ocean JAMSTEC/IORGC : Palau Chinese Taipei EAMEX India CTCZ India STORM JEPP: Tibet JAMSTEC/IORGC: SE Asia JEPP: Thailand China AIPO JEPP: Maritime Continent

Japan EOS Promotion Program (JEPP) Theme 2-1: Observation Network in Indian Ocean and Maritime Continent Japan Agency for Marine-Earth Science and Technology (JAMSTEC) Indian-Ocean Mooring Array

• K. Mizuno (IORGC)

Maritime-Continent Radar Network

• M. D. Yamanaka (IORGC)

Buoy Observation

• Y. Kuroda

(IORGC/MARITEC)

• K. Ando (IORGC)

Y.Yamaguchi,Y.Ishihara K.Matsumoto (MARITEC)

Data Analysis

• Y. Masumoto

(IORGC/UTokyo)

H.Hase, I.Ueki (IORGC)

Radar Observation

• H. Hashiguchi

(KyotoU)

Y.Shibagaki (OsakaECU) T.Shimomai (ShimaneU) M.K.Yamamoto(KyotoU) M.Kawashima, Y.Fujiyoshi (Hokkaido U)

• R. Shirooka, M.Katsumata

(IORGC)

Data Analysis

• M. D. Yamanaka

(IORGC/KobeU)

• S. Mori, P.M. Wu,

Hamada J.I., S. Ogino, K.Ichiyanagi, T.Sasaki (IORGC) Y.Tachibana (IORGC/TokaiU) 80° 70° 80° 70° 10° 0°

• 10°

Japan EOS Promotion Program (JEPP) Theme 2-2 by Prof. Ishikawa, Kyoto-U. Promotion of Integrated Observational Study of Energy and Water Circulation on and over the Tibetan Plateau

Ground Based Obs. Systems Satellite Obs. Systems

HUMIDITY (AIRS) SURFACE FLUX (FY2C)

and

• thers

Data Integration, Visualization, Mining

SOIL WATER(SSMI)

4-D Data Assimilation

Japan EOS Promotion Program (JEPP) Theme 2-2 by Prof. Matsumoto, U-Tokyo

Development of rainfall observation system in Southeast Asia

（1）Research on rainfall distribution （2）Research on flood prediction Rainfall observation by automatic rain Rainfall estimation using radar and gauges and development of real-time satellite observation and its data transmission system application to flood prediction

Objective: Develop rainfall observation system in order to understand water cycle and its variability by climatic changes in tropical Asian monsoon region

• ver Indochina

IP

Automatic rain gauge Networks India, Bangladesh 36 Thailand 18 Vietnam 33 Rainfall estimation by satellite

• bservation

Flood prediction Radar data + Raingauge data → Composite rainfall data Similar to Radar-AMeDAS system in Japan

Automatic rain gauges in Indochina High Density Rain Gauges１ High Density Rain Gauges ２

18 N

インド亜大陸北東部における降水量の観測

Site description

Mae Wang basin in Chiang Mai (basin area : 600 km2)

(Oki JEPP)

Air Tem perature & Hum idity W ind Speed & Direction : Soil Tem perature : Soil Moisture 2 .7 m Short & long-w ave radiation

• 5 cm
• 1 0 cm
• 2 0 cm
• 4 0 cm

Rain Fall 1 .0 m 2 .0 m Ground W ater Level Air pressure in Data logger box River W ater Level

Instrumentation : Tel-super site

NO.1 Making well at NO.4

(Oki JEPP)

Facilities Facilities

V.

• V. International Collaboration

International Collaboration

(T.C.Chen, Personal Com.)

Time Schedule in 2007(1) Time Schedule in 2007(1)

• Jan. 8/10 :The 1-st MAHASRI/AMY Workshop:

at Tokyo, Japan

• Jan. 22-25:GEWEX-SSG at Hawaii, USA.
• Feb. 19-22:CLIVAR-AMMP at Hawaii, USA.
• Mar. 22-24: WMO/CAS WG Meeting on

Tropical Meteorology Research at Guangzhou, China

• Mar. 26-30: 28th session of the WCRP-JSC at

Zanzibar, Tanzania

• Apr. 23-25: 2008 Asian Monsoon Year (AMY08)

International Workshop at Beijing, China

Time Schedule in 2007 (2) Time Schedule in 2007 (2)

• Jun. 11-12:PSA Meteorology and Atmospheric

Sciences Scientific Committee Meeting at Taipei

• Jun. 13-17:Pacific Science Congress XXI (PSC21) at

Okinawa, Japan

• Jul. 2-13: IUGG XXIV 2007 Session JMS011 on

Monsoon system at Perugia, Italy

• Jul. 30-Aug. 4: The 4 th AOGS 2007 Session AS07

GEOSS, CEOP and MAHASRI at Bangkok, Thailand

• Aug. 9-13 : MAIRS/CEOP Workshop on semi-arid

region at Lanzhou, China

• Sept. 3-7: CEOP, MAHASRI/AMY meeting in

Indonesia

.

Thank you! The END
