Machining in precision 2019 Our company - Family company - Family - - PowerPoint PPT Presentation

Machining in precision

2019

Our company

• Family company - Family Yagli
• Founded in 1994 in Corum / Turkey
• Modern production halls
• High precision turning and milling
• 29 CNC turning and milling centers
• Supplier in the field of cutting and gear cutting

technology

• Engineering in the field of cutting and gear cutting

technology

• DIN EN ISO 9001:2015, ISO 14001:2004,

OHSAS 18001:2007, ISO 10002:2014, ISO 28000:2007, IATF 16949:2016 certified

Vision

• Quality leadership
• World leader company
• Long-term and successful cooperation with our

customers & solution partners

Mission

• Education & promotion of the workforce
• Sustainable development
• Customer satisfaction
• Solution-oriented approach

Values

• Innovation & Development
• Environmental Protection
• Trust
• Creativity

Our Vision, Mission & Values

1 3 1 2 1

USA Mexico Germany Switzerland France Sweden India Brasil

10

Our Customers Abroad and Active Sectors

Energy- & plant construction Machinery- & Automotive Engineering Rail vehicle

1 2 5 4

Canada

1

Denmark UK

Our Reference and Solution Partner

General Electric

Headquarter Sales Office

✈

• Distance from the Capital of TURKEY (Ankara)

:200 Km

• Distance from to Merzifon Airport (Amasya)

: 40 Km

• Distance from Carşamba Airport (Samsun)

: 150 Km

Our presence

1.200 m² 5.600 m² 10.000 m²

1994 1999 2019

45

6 130

1994 1999 2019

Das Unternehmensprofil

Number of employees Area of our new production hall

Top Management Management Employees

Our employees and production

Das Unternehmensprofil

FINANCE MANAGER PLANNING & STOREHOUSE MANAGER

GENERAL MANAGER

BOARD CHAIRMAN

ADMINIS. AFFAIRS RESP.

PURCH. MANAGER SALES & CUST.

• REL. MAN.

OFFER PREPARATION MANAGER QUALITY MANAGER HUMAN RESOURCE MAN. IT MANAGER PRODUCTION MANAGER TOOLING

RESP. MAINTENANCE & REPAIR RESP. CUTTING RESP. PACKAGING RESP. FINANCIAL RESP. ACCOUNTING RESPONSIBLE SALES RESPONSIBLE DRAFTSMAN STOREHOUSE RESP. INCOMING CONTROL RESP. VICE GENERAL MANAGE VICE GENERAL MANAGE VICE GENERAL MANAGE VICE GENERAL MANAGER KEY ACCOUNT MANAGER ERP RESP. IT RESP. OFFER PREP. RESPONSIBLE PRODUCTION METHOD DEVELOPMENT RESPONSIBLE PURCHASING RESP. PRODUCTION CONTROL RESP. INTERLUDE CONTROLREP. MANAGEMENT REPRESENTATIVE LOGISTIK RESPONSIBLE QUALITY CONTROL RESP. FINAL CONTROL RESP. QUALITY LAB. RESP.

Arbeitssicherheit & Gesundheitsmanagement

ISO 9001:2015 ISO 14001:2015 OHSAS 18001:2007

Qualitätsmanagement Umweltmanagement

Our certifications

ISO 28000:2007 ISO 14001:2015 IATF 16949:2016

Our certifications

Casting & forging parts

Broaching & coating

Turning & Milling Welding

Gear parts

Our Production Technologies

All quality controls of the raw materials are carried out in the incoming goods according to DIN ISO and DIN standards

Steel

• St 35 / St 52 / S235JR / EN1A-Pb / EN8 / EN9 / EN21

Alloyed steel

• AISI 303 / 304 / 316L / 316Ti / 410 / 1.4104 / CF8M / 17- 4PH

Aluminium

• 6061-T6 / 6082-T6 / 2024 / 7075 / 356T6 / LM9 / LM24 / LM25

Copper

• Any form of copper and brass

Materials of Our Production

Production of welded parts Threads, shafts & spare parts for the automotive & rail sector Transmission & Drive Systems

Unsere Produktgruppen Our product groups

Quality Metalworking and machining Energy & transfer parts for high and medium voltage

Our product groups

7 axis CNC machine CNC gear cutting machine (max 320 mm diameter, 250 mm length, max 6 modules) 4 units 5 axis CNC machine 13 units CNC milling - Vertical machining centers (600x600x1500 mm) 12 units CNC turning (max 350 mm diameter, max 1000 mm length) Broaching Universal gear milling machine Cylindrical grinding surface grinding machine Conventional turning and milling machine Fully automatic ripper

Our machinery park

− Longitudial working range X / mm 650 − Cross working range Y / mm 650 − Vertical working range Z / mm 550 − A-axis / mm +91/-121° − C-axis / mm n x 360° − Feed rate Rapid Traverse X, Y, Z m/min 45 − Feed rate Rapid Traverse A, C °/sec 0150, 210 − Working spindle / kW 39 − Work table clamping surface / mm Ø 500 / 630 −

• Max. workpiece weight / kg

500 / 800

 − 5-axis CNC high precision machine − Longitudial working range X / mm 800 − Cross working range Y / mm 800 − Vertical working range Z / mm 550 − A-axis / mm +91/-121° − C-axis / mm n x 360° − Feed rate Rapid Traverse X, Y, Z m/min 45 − Feed rate Rapid Traverse A, C °/sec 0150, 210 − Working spindle / kW 39 − Work table clamping surface / mm Ø 500 / 630 −

• Max. workpiece weight / kg

500 / 800

 − 5-axis CNC high precision machine

Our machinery park

GEORG FISCHER HPM 600 U GEORG FISCHER MILL P 800 U

−

• max. turning Ø / mm

658 −

• max. turning length /mm

1519 − Spindle motor main spindle / kW 30
 −

• max. revolutions main spindle / Upm

4.000
 − Spindle hole / mm 91
 −

• max. rod passage / mm

80
 − C-axis 0,0001°
 − Spindle motor milling spindle / kW 22
 −

• max. revolutions milling spindle / Upm

12.000
 − B-axis 0,0001°
 − CNC controlled tailstock, integrated follower quill MK5 chip conveyor 5-axis CNC gear cutting machine for fast speed, high rigidity for gear cutting process −

• max. workpiece Ø / mm

200 − Working range X,Y,Z / mm 300 / 200 / 300 − Swivel angle (HOB) ±45˚ −

• max. hob dia. / length / mm

130 / 230 − Milling-way / mm 170 − Milling revolutions / Upm 200~1,500 − Fast Rapid Traverse / m / min 15 − C-axis max. revolutions / Upm 300

CNC Gear Hobbing S&T Dynamics GHO-200 MAZAK-INTEGREX İ 300 S, Turning & Milling Center

Our machinery park

−

• max. turning Ø / mm

400 −

• max. turning length / mm

650 −

• max. swing Ø / mm

1500 − Working range / mm X,Z 600*600 − Spindle revolutions / Upm 4000 − Spindle power / kW 21/27 −

• max. turning Ø / mm

500 −

• max. turning length / mm

1500 −

• max. swing Ø / mm

800 − Working range / mm X,Z 800*1500 − Spindle revolutions / Upm 4000 − Spindle power / kW 22/33 Spinner-TC 600 CNC Turning Spinner-TC 800 L CNC Turning, with Y axes

Our machinery park

− Working range X,Y,Z / mm 620, 520, 460 − Fixed rigid table − 2-axis table / D 650 − Round table − Spindle revolutions / Upm 9000 (Option:12.000) − Power (S6 40%/S1) / kW 19 − Torque /S6 40%/S1) / Nm 121 − Spindle mount type SK40 − Spindel Taper NO.50 − Transmission Bel t/Gear − Spindle torque / rpm 8000 − Working range X,Y,Z / mm 1300, 700, 650 − Distance spindle head to table / mm 200-850 mm − Rapid Traverse X, Y / M/Min 15 − Milling Rapid Traverse X, Y, Z / M/Min 15, 15, 12 − Motor X/Y/Z axis (Fanuc) / Kw 4.0 AGMA-VMC 158 G Milling Center Spinner-U 620 5 Axes Milling Center

Our machinery park

Our machinery park

Gear measuring machine Spectral analysis machine Aberlink 3D CMM ZEISS Contura

Our quality management

Hardness Tester : Rockwell, Brinell & Vickers

Headquarter: Organize Sanayi Bỏlgesi

• 12. Cad No: 6 ÇORUM / TURKEY

Tel: (+90) 364 254 91 02 Fax: (+90) 364 254 91 18 info@yagmaksan.com www.yagmaksan.com

Sales Office: Britzer Damm 12, 12347 Berlin / Germany Tel: (+49) 30 634 13 585 Fax: (+49) 30 634 13 586 emre.ziypak@yagmaksan.com Sales Office: Ufuk Üniversitesi Caddesi, Ambrosia Plaza,

• No. 18/34 Cukurambar

06510 Ankara / Turkey Tel: (+49) 30 634 13 585 info@yagmaksan.com

Many Thanks
