(1) Lung Anatomy Anterior Posterior Right Left 2 Approaching a CXR 1. Patient and clinical details 2. Technical adequacy 1. Projection 2. Inspiration 3. Rotation 3. ABCDE 1. Airway position of trachea 2. Breathing

slide-1
SLIDE 1
slide-2
SLIDE 2

2

Lung Anatomy

Right Left Anterior Posterior

(1)

slide-3
SLIDE 3

1. Patient and clinical details 2. Technical adequacy 1. Projection 2. Inspiration 3. Rotation 3. ABCDE 1. Airway – position of trachea 2. Breathing – lungs 3. Circulation – cardiac and mediastinal contours 4. Diaphragm – contours and below the diaphragm 5. Everything else – lines and tubes 4. Review areas 1. Lung apices 2. Costophrenic angles 3. Behind the heart 4. Behind and below the diaphragm

3

Approaching a CXR

slide-4
SLIDE 4

History

A 35-year-old gentleman presents with a fever and cough. He has a background

  • f

HIV and his most recent CD4 count was normal. On examination, he has bronchial breathing and dull percussion on the left.

Observations

HR 101, BP 130/86, RR 22, SpO2 93%, Temp 38.8

4

Case-based discussion: 1

PLEASE INSERT IMAGE HERE (if appropriate)

slide-5
SLIDE 5

5

Question: 1

What radiographic feature is most suggestive of consolidation? 1) Loss of the left heart border 2) Ill-defined opacification 3) Air bronchograms 4) Interstitial shadowing 5) Bronchial wall thickening

slide-6
SLIDE 6

6

Question: 1

What radiographic feature is most suggestive of consolidation? 1) Loss of the left heart border 2) Ill-defined opacification 3) Air bronchograms 4) Interstitial shadowing 5) Bronchial wall thickening

slide-7
SLIDE 7

7

slide-8
SLIDE 8

8

slide-9
SLIDE 9

9

Lung Anatomy

Right Left Anterior Posterior

(1)

slide-10
SLIDE 10

10

Lung Anatomy

Right Left Anterior Posterior

slide-11
SLIDE 11
slide-12
SLIDE 12

Definition: loss of a normal thoracic contour (e.g. heart border or diaphragmatic border) as a result of pathology that is contiguous with that border. Useful in lots of contexts!

  • Lobar collapse
  • Mediastinal masses
  • Consolidation

12

Silhouette sign

slide-13
SLIDE 13

History

A 35 year old gentleman presents with a fever and cough. He has a background

  • f

HIV and his most recent CD4 count was normal. On examination, he has bronchial breathing and dull percussion on the left.

Observations

HR 101, BP 130/86, RR 22, SpO2 93%, Temp 38.8

13

Case-based discussion: 1

PLEASE INSERT IMAGE HERE (if appropriate)

slide-14
SLIDE 14

14

Question: 2

What is the most likely causative organism? 1) SARS-CoV-2 2) Streptococcus pneumoniae 3) Mycobacterium tuberculosis 4) Pneumocystis jirovecii 5) Staphylococcus aureus

slide-15
SLIDE 15

15

Question: 2

What is the most likely causative organism? 1) SARS-CoV-2 2) Streptococcus pneumoniae 3) Mycobacterium tuberculosis 4) Pneumocystis jirovecii 5) Staphylococcus aureus

slide-16
SLIDE 16

16

slide-17
SLIDE 17

History

A 30-year-old man presents to the Emergency Department with pleuritic chest pain and shortness of breath. He is usually fit and well however is a smoker. On examination, he appears dyspneic but is not in respiratory distress. There is reduced air entry at the left apex.

Observations

HR 85, BP 110/80, RR 22, SpO2 95%, Temp 37.3

17

Case-based discussion: 2

PLEASE INSERT IMAGE HERE (if appropriate)

slide-18
SLIDE 18

18

Question: 3

What is the most likely cause for the patient’s clinical presentation? 1) Pneumonia 2) Pulmonary embolism 3) Spontaneous pneumothorax 4) Tension pneumothorax 5) Costochondritis

slide-19
SLIDE 19

19

Question: 3

What is the most likely cause for the patient’s clinical presentation? 1) Pneumonia 2) Pulmonary embolism 3) Spontaneous pneumothorax 4) Tension pneumothorax 5) Costochondritis

slide-20
SLIDE 20

20

Pneumothorax

Definition

  • Presence of gas within the

pleural cavity

(2) (3)

slide-21
SLIDE 21

21

slide-22
SLIDE 22

22

slide-23
SLIDE 23

History

A 30-year-old man presents to the Emergency Department with pleuritic chest pain and shortness of breath. He is usually fit and well however is a smoker. On examination, he appears dyspneic but is not in respiratory distress. There is reduced air entry at the left apex.

Observations

HR 85, BP 110/80, RR 22, SpO2 95%, Temp 37.3

23

Case-based discussion: 2

PLEASE INSERT IMAGE HERE (if appropriate)

slide-24
SLIDE 24

24

Question: 4

How should you manage this patient? (Pneumothorax measures 1 cm at the hilum) 1) Pleurodesis 2) Aspirate and repeat imaging 3) Chest drain insertion 4) Observe for 24 hours 5) Discharge and review as outpatient

slide-25
SLIDE 25

25

Question: 4

How should you manage this patient? (Pneumothorax measures 1 cm at the hilum) 1) Pleurodesis 2) Aspirate and repeat imaging 3) Chest drain insertion 4) Observe for 24 hours 5) Discharge and review as outpatient

slide-26
SLIDE 26

1. Patient and clinical details 2. Technical adequacy 1. Projection 2. Inspiration 3. Rotation 3. ABCDE 1. Airway – position of trachea 2. Breathing – lungs 3. Circulation – cardiac and mediastinal contours 4. Diaphragm – contours and below the diaphragm 5. Everything else – lines and tubes 4. Review areas 1. Lung apices 2. Costophrenic angles 3. Behind the heart 4. Behind and below the diaphragm

26

Approaching a CXR

slide-27
SLIDE 27

History

A 75-year-old man who was admitted earlier in the day with an ischaemic stroke has developed increasing shortness of breath and a cough. On examination, he appears distressed. There are bibasal crepitations.

Observations

HR 90, BP 110/80, RR 28, SpO2 95%, Temp 37.8

27

Case-based discussion: 3

PLEASE INSERT IMAGE HERE (if appropriate)

slide-28
SLIDE 28

28

Question: 5

How would you manage this patient? 1) IV antibiotics 2) IV diuretics 3) Discuss radiograph with seniors/radiology 4) Remove NG tube 5) None of the above

slide-29
SLIDE 29

29

Question: 5

How would you manage this patient? 1) IV antibiotics 2) IV diuretics 3) Discuss radiograph with seniors/radiology 4) Remove NG tube 5) None of the above

slide-30
SLIDE 30

30

slide-31
SLIDE 31

31

Question: 6

Which of the following is NOT correct when assessing the position of an NG tube? 1) It is safe to feed a patient through an NG tube with its tip in the duodenum 2) The NG tube must bisect the carina 3) The tip of the NG tube must be seen below the diaphragm 4) It is safe to feed a patient through an NG tube with its tip in the oesophagus 5) Measuring the pH of the aspirate is the first-line test

slide-32
SLIDE 32

32

Question: 6

Which of the following is NOT correct when assessing the position of an NG tube? 1) It is safe to feed a patient through an NG tube with its tip in the duodenum 2) The NG tube must bisect the carina 3) The tip of the NG tube must be seen below the diaphragm 4) It is safe to feed a patient through an NG tube with its tip in the oesophagus 5) Measuring the pH of the aspirate is the first-line test

slide-33
SLIDE 33

An NG tube must: 1. Pass through the middle of the chest/mediastinum

  • 2. It must bisect the carina
  • 3. It must cross the diaphragm in the midline
  • 4. Its tip must be clearly visible below the diaphragm (10

cm below the GOJ)

33

NG Tube Assessment

slide-34
SLIDE 34

34

slide-35
SLIDE 35

History

A 57 year-old man presents with a cough and weight loss. He is an ex- smoker and uses inhalers for COPD. He attends A&E with worsening shortness of breath. On examination, he is dyspneic.

Observations

HR 88, BP 101/78, RR 25, SpO2 87%, Temp 37.1 ABG Shows a type 1 respiratory failure

35

Case-based discussion: 4

PLEASE INSERT IMAGE HERE (if appropriate)

slide-36
SLIDE 36

36

Question: 7

What is the most likely cause for the patient’s type 1 respiratory failure? 1) Bronchogenic carcinoma 2) Exacerbation of COPD 3) Lobar collapse 4) Pneumonia 5) Heart failure

slide-37
SLIDE 37

37

Question: 7

What is the most likely cause for the patient’s type 1 respiratory failure? 1) Bronchogenic carcinoma 2) Exacerbation of COPD 3) Lobar collapse 4) Pneumonia 5) Heart failure

slide-38
SLIDE 38

38

slide-39
SLIDE 39

39

Lung Anatomy

Right Left Anterior Posterior

slide-40
SLIDE 40

40

slide-41
SLIDE 41

41

slide-42
SLIDE 42

1. Patient and clinical details 2. Technical adequacy 1. Projection 2. Inspiration 3. Rotation 3. ABCDE 1. Airway – position of trachea 2. Breathing – lungs 3. Circulation – cardiac and mediastinal contours 4. Diaphragm – contours and below the diaphragm 5. Everything else – lines and tubes 4. Review areas 1. Lung apices 2. Costophrenic angles 3. Behind the heart 4. Behind and below the diaphragm

42

Approaching a CXR

slide-43
SLIDE 43

43

Question: 8

The loss of the left hemidiaphragm in this case is known as which sign? 1) Felson’s sign 2) Mach effect 3) Luftsichel sign 4) Silhouette sign 5) Sail sign

slide-44
SLIDE 44

44

Question: 8

The loss of the left hemidiaphragm in this case is known as which sign? 1) Felson’s sign 2) Mach effect 3) Luftsichel sign 4) Silhouette sign 5) Sail sign

slide-45
SLIDE 45

Aetiology:

  • Endobronchial obstruction
  • Mucus plug in young asthmatic
  • Endobronchial carcinoma until proven otherwise in older patient or smoker
  • Foreign body in children

Radiographic features:

  • Triangular retrocardiac opacity (sail sign) represents the collapsed left lower lobe
  • Loss of most of the left hemidiaphragm (silhouette sign) – due to loss of the air-tissue interface
  • Loss of the left hilum (pulled down due to volume loss)
  • Tracheal deviation towards the side of the collapsed lung (not seen in this case) which is also

due to volume loss

  • Increased lucency within the remaining left lung (hyperinflation of the left upper lobe)

45

Summary of Left Lower Lobe Collapse

slide-46
SLIDE 46

46

slide-47
SLIDE 47

History

A 40-year-old woman who was admitted with osteomyelitis in her foot is due to be discharged with long term

  • utpatient

antibiotic therapy. She has a past medical history of type 2 Diabetes Mellitus. You are are reviewing her most recent chest XR with your consultant before discharging her.

47

Case-based discussion: 5

PLEASE INSERT IMAGE HERE (if appropriate)

slide-48
SLIDE 48

48

Question: 9

How should you manage the patient? 1) Request a chest CT 2) Insert a cannula and discharge patient home for OPAT 3) Discharge patient for OPAT 4) Insert a chest drain 5) None of the above

slide-49
SLIDE 49

49

Question: 9

How should you manage the patient? 1) Request a chest CT 2) Insert a cannula and discharge patient home for OPAT 3) Discharge patient for OPAT 4) Insert a chest drain 5) None of the above

slide-50
SLIDE 50

50

slide-51
SLIDE 51

51

(4)

slide-52
SLIDE 52

History

A 31-year-old woman presents to the Emergency Department with acute shortness of breath and wheeze. She has a past medical history of asthma. On examination, she has a widespread wheeze. Dullness to percussion at the right apex

Observations

HR 90, BP 110/80, RR 25, SpO2 100%, Temp 37.8

52

Case-based discussion: 6

PLEASE INSERT IMAGE HERE (if appropriate)

slide-53
SLIDE 53

53

Question: 10

Based on the clinical findings and chest radiograph, what is the most likely diagnosis? 1) Right upper lobe collapse secondary to mucus plugging 2) Right upper zone primary lung carcinoma 3) Right upper lobe collapse secondary to an endobronchial carcinoma 4) Right upper zone pneumonia 5) Acute exacerbation of asthma

slide-54
SLIDE 54

54

Question: 10

Based on the clinical findings and chest radiograph, what is the most likely diagnosis? 1) Right upper lobe collapse secondary to mucus plugging 2) Right upper zone primary lung carcinoma 3) Right upper lobe collapse secondary to an endobronchial carcinoma 4) Right upper zone pneumonia 5) Acute exacerbation of asthma

slide-55
SLIDE 55

55

slide-56
SLIDE 56

56

slide-57
SLIDE 57

57

Question: 11

Which of the following is not a sign of loss of volume in right upper lobe collapse? 1) Elevation of the right hemidiaphragm 2) Decreased spacing between the right ribs 3) Right upper zone opacification 4) Rightward tracheal deviation 5) Elevation of the right hilum

slide-58
SLIDE 58

58

Question: 11

Which of the following is not a sign of loss of volume in right upper lobe collapse? 1) Elevation of the right hemidiaphragm 2) Decreased spacing between the right ribs 3) Right upper zone opacification 4) Rightward tracheal deviation 5) Elevation of the right hilum

slide-59
SLIDE 59
  • 1. Deviation of structures:
  • 1. Trachea
  • 2. Hila
  • 3. Mediastinum
  • 2. Elevation of the diaphragm
  • 3. Decreased spacing between the ribs

59

Signs of volume loss

slide-60
SLIDE 60

History

A 45-year-old man presents to the Emergency Department with central chest pain. He is normally fit and well but has been taking regular NSAIDs following an injury a month ago. On examination, the lungs are clear.

Observations

HR 103, BP 98/62, RR 25, SpO2 94%, Temp 38.1 A blood gas reveals a lactate of 3.2

60

Case-based discussion: 7

PLEASE INSERT IMAGE HERE (if appropriate)

slide-61
SLIDE 61

61

Question: 12

What finding is present on the chest radiograph? 1) Bilateral hilar enlargement 2) Pneumoperitoneum 3) Right apical pneumothorax 4) Left apical pneumothorax 5) Widened mediastinum

slide-62
SLIDE 62

62

Question: 12

What finding is present on the chest radiograph? 1) Bilateral hilar enlargement 2) Pneumoperitoneum 3) Right apical pneumothorax 4) Left apical pneumothorax 5) Widened mediastinum

slide-63
SLIDE 63

63

slide-64
SLIDE 64

64
