SLIDE 1
TII National Roads
Conference 2016
28th September 2016
Luas Cross City
Background to Luas Cross City (LCC) The works involved in delivering LCC Key Issues for the delivery phase …..have we got to so far
- Why?
- What?
- How?
- Where?
Luas Cross City Why? Background to Luas Cross City (LCC) What? - - PowerPoint PPT Presentation
Luas Cross City Why? Background to Luas Cross City (LCC) What? - - PowerPoint PPT Presentation
TII National Roads Conference 2016 28 th September 2016 Luas Cross City Why? Background to Luas Cross City (LCC) What? The works involved in delivering LCC How? Key Issues for the delivery phase Where? ..have we got to so
SLIDE 2
SLIDE 3
NTA Transport Strategy 2016 - 2035
2035 Metropolitan Light Rail Network
(Source: NTA Draft Transport Strategy 2016 – 2035)
Luas Red Line Luas Cross City Luas Green Line
Luas Finglas Luas Poolbeg Luas Lucan Luas Bray
SLIDE 4
Benefits of LCC
SLIDE 5
What does LCC involve?
SLIDE 6
What does LCC involve? Luas Cross City Aerial Map
- Total route length 5.6km - equating to approximately 13.3km of single track
equivalent
- 6 km off-street between Broadstone and Broombridge
- 2.1 km at Broombridge depot for tram stabling
- 5.2 km of embedded on street track in city centre
SLIDE 7
LCC Programme
SLIDE 8
Heritage Works – KN Networks Services
SLIDE 9
Cellar Works – KN Networks Services
SLIDE 10
Utility Works – GMC Utilities
- c.70km of new ducting and
pipe-work
- 2 km of Sewer re-lining
- Construction of 50 no. new
drainage manholes
- Building Service connections
SLIDE 11
Utility Works
SLIDE 12
Main Infrastructure Works – Sisk-Steconfer Joint Venture
- HV and LV ducting and chambers
- Track installation
- Ballasted
- Embedded Rails
- Structural Works
- Depot Construction
- Stop Construction
- Traffic Signalling
- OCS Installation
SLIDE 13
Access Crossings maintained
Install Traffic Management and fencing Plane out carriageway Excavations & Pipelaying Hardcore Fill Concrete foundation Track Assembly & rebar Overhead wires erected at night at end of program Installation of facade fixings Isolated works for pole installation New Road Surfacing Concrete trackslab Secondary ducting works and new granite paving
Typical Methodology
Works Completion Remove Traffic Management Replace road surface with new
SLIDE 14
Key Issues for Delivery
Site Access / Traffic Management
LCC Traffic Forum (~Monthly) NTA/DCC/TII/Dublin Bus/ Bus Eireann / An Garda Síochána LCC Traffic Group (Weekly) NTA/DCC/TII/Dublin Bus/ Bus Eireann / An Garda Síochána Contractors’ Traffic Management Application to DCC Roadworks Control Unit
SLIDE 15
Key Issues for Delivery Communications
KEY PILLARS
- Public Office
- Web-site - Traffic
updates, works progress, maps
- CRM
database – members of public and other interested parties
- Local liaison officers –
direct contact with retailers/shops/reside nts
- Sponsorships – Local
communities, Dublin Town events
SLIDE 16
Works Progress – end of August 2016
NORTH SIDE OF LIFFEY SOUTH SIDE OF LIFFEY
SLIDE 17
Works Progress – end of June 2016
SLIDE 18
Works Progress – end of June 2016
SLIDE 19
Works Progress – end of June 2016
SLIDE 20
Works Progress – end of June 2016
SLIDE 21
Works Progress – end of June 2016
SLIDE 22
Works Progress – end of June 2016
SLIDE 23
Works Progress – end of June 2016
SLIDE 24
Works Progress – end of June 2016
SLIDE 25
Works Progress – end of June 2016
SLIDE 26
