LLC MP “TEKOM” First national producer of solar vacuum collectors under “Star Energy” trademark

Manufacturing, engineering, realization, installation, maintenance service

Founded in 2003, a special division of MP “Tekom” specializes in alternative energy including solar energy (solar photo-electric modules and solar hot-water supply items). Since 2009, “Star Energy” TM launched its own production of solar collectors in Odessa (Ukraine). What we do:

• Project design, economic effjciency calculation, installation and maintenance

service of hot-water supply solar systems and heating systems on the basis of vacuum solar collectors.

• Project design and installation of photo-electric systems of electrical supply.

First national producer of solar vacuum collectors: production by “Star Energy” TM

Production units:

— Mechanical Turning, sawing, drilling, grinding — Plasma treatment — Soldering — Heat-insulating — Packaging — Assembling

Production in Odessa (Ukraine), 1/6 Krasnoslobodskaya str.. — production unit — 400 sq. m — warehouse/storage — 3 000 cubic meters

Solar systems of hot-water supply

Production of “Star Energy”

— U-type (based on the U-type pipe) — with “heat pipe”

Collector type Number of elements (pipes)

Energy saving per year of exploitation, in radiant quantities kW hour/year Gcal СВК-15 15 1548 1,33 СВК-20 20 2064 1,81 СВК-30 30 3096 2,66

— 5 years guarantee from the produce — Service life — not less that 15 years

Solar vacuum collector (SVK) types:

Construction features of solar vacuum collectors

Three-layer selective coating of vacuum pipes guarantees absorption of direct, diffuse and UV solar radiation. Solar vacuum collector based on a heat pipe with inert gas inside provides for minimum quantity of heat carrier and high temperatures all year round. Glass core minimizes the volume of the vacuum pipe at the same time providing for a more intensive natural circulation and speeds up the water heating process.

Scheme DHW and CH using solar vacuum collectors “Star Energi” TM

95 ˚C 65 ˚C

Benefjts of solar collectors by “Star Energy”

Solar hot-water boilers by “Star Energy” TM guarantee the most effjcient energy supply by:

• High level of environmental safety: the systems don’t throw harmful

substances intothe atmosphere;

• Long service period — not less than 15 years;
• Low maintenance cost;
• Pay-off period of 2-5 years;
• Provide for 90% of hot-water demand and 40% of heating demand;
• Easy to connect to existing heating systems;
• Self-suffjciency: opportunity to create an autonomous system of heating

and hot- water supply with simultaneous use of solid-fuel boilers, electric boilers and heat pump units;

• Enough power to heat water even in open-air swimming pools.

Even though in winter period the effjciency of solar collectors is usually lower than during spring or summer months, in sunny winter days they can provide for up to 60-70% of hot water demand.

Spheres of application

 Social sphere:

Support of hot-water supply and heating in hospitals, kindergartens, schools, etc.

 Manufacturing:

Support of hot-water supply, heating and technical liquids heating at plants, factories and sea ports, etc.

 Agriculture:

support of hot-water supply and heating at farms.

 Hospitality:

Support of hot-water supply and heating at hotelsand mini-hotels.

Spheres of application

 Health resorts:

support of hot-water supply and heating at resorts.

Spheres of application

Completed projects “Belaya Akatsia” spa resort (Odessa)

One of the largest venue in Ukraine for implementation of solar vacuum collectors —120 items with a total area of 450 sq. m.

Completed projects

Kindergartens — “Solnyshko” — “Raduga” — “Svetlyachok”

Voznesensk town, Nikolaevskaya oblast

“Motor-Sitch” factory

Zaporozhie city

“Stirol” factory

Gorlovka town, Donetskaya oblast

Completed projects

— “GoodZone Club” resort

Karolino-Bugaz village, Odesskaya oblast

— “Sergeevka” kids resort

Sergeevka village, Odesskaya oblast

Completed projects

Economic effect and pay-off period

Earameters of economic effect and pay-off period are calculated individually for each project taking into consideration the following factors:

• Accessibility of traditional sources of energy, their cost, logistic characteristics of the object;
• Required installed capacity of the solar collectors system. While increasing the power

(number) of the collectors, the cost (share) of the auxiliary equipment goes down.

• Choice of the type of back-up energy source (solid fuel boiler, electric boiler, etc.);
• Location of the object, solar activity in that region.

In general, pay-off period can be calculated using the following formula:

T = SC/ (Q CT),

where SC — is incremental cost of the solar system, ₴ / sq. m Q — annual amount of heat, produced by the solar system, Gcal per sq. m СТ — cost of heating produced by traditional energy source, ₴ / Gcal

If you aim to save up to 90% when heating water and up to 40% when maintaining your heating system, you should consider using our solar vacuum collectors. By using solar vacuum collectors produced by “Star Energy” TM you contribute to conservation of natural resources and to reduction of hazardous substances and greenhouse gases ejection, thus preventing global changes of the world climate. The money that you save turn into the clean and safe environment, our kids’ health and thenations benefjt.

Maxim Parhomenko Cell (067) 772-54-70 Vladimir Dorus Cell (063) 149-7-222 Sergey Kulish Cell (066) 557-86-57

Contact us:

Odessa 65006 Ukraine 1/6 Krasnoslobodskaya str. tell +38 (048) 784-62-91, (0482) 33 75 52 E-mail: 7846291@ukr.net Website: www.star-energy.com.ua www.tekomod.com www.star-energy.co.ua
