Linked lists

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 1

Announcements

• HW1 due tonight!

– Only one partner in a group needs to submit – See course webpage for details about page/question linking, and adding a partner to the submission

• PA1 out

– GradeScope configuration to follow shortly

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 2

Linked lists

• Imagine an array partially filled with data

– And we want to insert an item in a particular position in the middle

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 3

A motivation

12 15 16 19 22 28 34 37 41 46 17 All of these elements must be shifted over one at a time

Linked lists are a dynamic data structure that can achieve fast insertions/ deletions in the middle

Linked list nodes

• A linked list is a dynamic data structure that consists
• f nodes linked together
• A node is a data structure that contains

– data – the location of the next node

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 4

Node pointers

• A node contains the address of the next node in the list

– In C++ this is recorded as a pointer to a node

• Nodes are created in dynamic memory

– And their memory locations are not in sequence

• The data attribute of a node varies depending on what the node

is intended to store

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 5

Linked lists

• A linked list is a chain of nodes where each node stores the

address of the next node

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 6

7 2 6 8 Start This symbol indicates a null pointer

Linked list implementation

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 7

Node class

class Node { public: int data; Node* next; };

next points to another node, hence its type Node*

• attributes / members of a particular node can be accessed using the

'.' (dot) operator

– or the '->' (arrow) operator as a shorthand for pointer types

• equivalent to dereferencing and using dot operator

Node nd; nd.data = 5; Node* p = nd.next; (*p).data = 5; Node* q = *((*p).next).next; Node* r = q->next->next;

Building a linked list

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 8

Node* a = new Node(7, null);

Assume we have written a parameterized constructor for the Node class 7 a

Building a linked list

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 9

Node* a = new Node(7, null); a->next = new Node(3, null);

7 a 3

Traversing a linked list

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 10

Node* a = new Node(7, null); a->next = new Node(3, null); Node* p = a; p = p->next; // go to next node p = p->next;

7 a 3 p

Linked list insertion

• Insertion in a singly-linked list requires only updating the next

node reference of the preceding position

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 11

… 15 16 19 22 28 a p

Node* b = new Node(17, p->next);

17 b

p->next = b;

Important! Be aware that sequential nodes are not guaranteed to be found in sequential memory locations!

Linked list removal

• Likewise, we can remove a node by updating the pointer of the

preceding node

– but remember to delete the removed node!

… 15 16 19 22 28 a p b

p->next = b->next; delete b;

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 12

Some linked list variations

• Suppose we have a basic singly-linked list with a head pointer

as defined above

– operations at the back of the list have (relatively) poor complexity, requiring a traversal – but we can give ourselves a tail pointer for very little overhead, maintained during operations at the back of the list

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 13

class Node { public: int data; Node* next; Node(int d, Node* nd) { data = d; next = nd; } }; class LinkedList { private: Node* head; int length; public: LinkedList(); ... }; class LinkedList { private: Node* head; Node* tail; int length; public: LinkedList(); ... };

Singly-linked list with tail pointer

• We can now perform insertion at the back of list in 𝑃 1 time!

– What about insertion in the middle of the list? – What about removal from the back of the list?

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 14

Insertion at back of list

1 2 3 4 6 7 9 head tail new

Doubly-linked list

• Node definition contains an additional pointer

– links to previous node in the list, allows traversal or access towards the front of the list

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 15

class Node { public: int data; Node* prev; Node* next; // constructors, etc. };

2 9 6 5 head

• Provides access to the previous and next nodes from a single

pointer (e.g. for insertion/removal)

– but, requires more pointer management in programming

Doubly-linked list insertion

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 16

After some specified node

12 4 23 6 head

Node* curr, * temp; ... // use a loop to move curr into place temp = new Node(); temp->data = 7; temp->prev = curr; temp->next = curr->next; curr->next->prev = temp; curr->next = temp;

curr temp 7

Doubly-linked list removal

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 17

At some specified node

12 4 23 6 head 7

Node* curr; ... // move curr to the node to be removed curr->next->prev = curr->prev; curr->prev->next = curr->next; delete curr; curr = NULL;

curr

Circular linked lists

• The last node in the list points back to the first node

– requires no change to the Node definition – circular property is maintained during operations

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 18

Singly-linked version

head 12 15 7

• How to check when we reach the end in a traversal?

– address of next is the same as the address of the front – but still must be careful to do NULL check on empty list!

Circular singly-linked list

• Insertion in the middle of a circular singly-linked list is no

different from inserting into a NULL-terminated list

– what about inserting at the head? – need to iterate a pointer to the last node in the list!

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 19

Insertion at head

head 12 15 9 7 3

Node* ptr, * newnode; ptr = head; while (ptr->next != head) ptr = ptr->next; newnode = new Node(); newnode->data = 4; newnode->next = head; ptr->next = newnode; head = newnode;

newnode 4 ptr

Circular doubly-linked list

• The last node in the list points to the first node

– and the first node points to the last node

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 20

head 6 23 15 What is the time complexity of accessing the last element of a circular doubly-linked list?

Readings for this lesson

• Carrano & Henry

– Background: 1.4, C1.1-C1.4 – C2.3, C2.5 (Pointers, dynamic arrays) – Chapter 4 (Linked lists)

• Next class:

– Carrano & Henry: Chapter 6 (ADT Stack)

January 20, 2020 Cinda Heeren / Andy Roth / Geoffrey Tien 21
