[PDF] - Linear algebra A brush-up course Anders Ringgaard Kristensen 1 PDF Document

SLIDE 1

1

Linear algebra A brush-up course

Anders Ringgaard Kristensen

Advanced Herd Management 2 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Outline

Real numbers
Operations
Linear equations
Matrices and vectors
Systems of linear equations

SLIDE 2

2

3 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Let us start with something familiar!

Real numbers! The real number system consists of 4 parts:

A set R of all real numbers A relation < on R. If a, b ∈ R, then a < b is either true or

false. It is called the order relation.

A function +: R × R → R . The addition operation A function · : R × R → R . The multiplication operation.

A number of axioms apply to real numbers

4 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Axioms for real numbers I Associative laws

a + (b + c) = (a + b) + c a · (b · c) = (a · b) · c

Commutative laws

a + b = b + a a · b = b · a

Distributive law

a · (b + c) = a · b + a · c

SLIDE 3

3

5 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Axioms for real numbers II

Additive identity (”zero” element)
There exist an element in R called 0 so that, for all a, a + 0 =

a

Additive inverse
For all a there exists a b so that a + b = 0, and b = − a
Multiplicative identity (”one” element)
There exists an element in R called 1 so that, for all a, 1 · a = a
Multiplicative inverse
For all a ≠ 0 there exists a b so that a · b = 1, and b = a-1

6 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Solving equations

Let a ≠ 0 and b be known real numbers, and x be an unknown real number. If, for some reason, we know that a · x = b, we say that we have an equation. We can solve the equation in a couple of stages using the axioms: a · x = b ⇔ a-1 · a · x = a-1 · b ⇔ 1 · x = a-1 · b ⇔ x = a-1 · b

SLIDE 4

4

7 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Example of a trivial equation Farmer Hansen has delivered 10000 kg milk to the dairy last week. He received a total payment of 23000 DKK. From this information, we can find the milk price per kg (a = 10000, b = 23000, x = milk price):

10000 · x = 23000 ⇔ x = 10000-1 · 23000 = 0.0001 · 23000 = 2.30

So, the milk price is 2.30 DKK/kg

a · x = b ⇔ x = a-1 · b

8 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

What is a matrix? A matrix is a rectangular table of real numbers arranged in columns and rows. The dimension of a matrix is written as n × m, where n is the number of rows, and m is the number of columns. We may refer to a matrix using a single symbol, like a, b, x etc. Some times we use bold face (a, b, x) or underline (a, b, x) in order to emphasize that we refer to a matrix and not just a real number.

SLIDE 5

5

9 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Examples of matrices

A 2 × 3 matrix:
A 4 x 3 matrix:
Symbol notation for a 2 × 2 matrix:

10 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Special matrices

A matrix a of dimension n × n is called a quadratic matrix:
A matrix b of dimension 1 × n is called a row vector:
A matrix c of dimension n × 1 is called a column vector:

SLIDE 6

6

11 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Operations: Addition

Two matrices a and b may be added, if they are of

same dimension (say n × m):

From the axioms of real numbers, it follows directly that

the commutative law is also valid for matrix addition:

a + b = b + a

12 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Additive identity? Does the set of n × m matrices have a ”zero” element 0 so that for any a, a + 0 = a If yes, what does it look like?

SLIDE 7

7

13 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Operations: Multiplication Two matrices a and b may be multiplied, if a is

f dimension n × m, and b is of dimension m × k

The result is a matrix of dimension n × k . Due to the dimension requirements, it is clear that the commutative law is not valid for matrix multiplication.

Even when b · a exists, most often a · b ≠ b · a

14 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Vector multiplication A row vector a of dimension 1 × n may be multiplied with a column vector b of dimension n × 1. The product a · b is a 1 × 1 matrix (i,e. a real number), where as the product b · a is a quadratic n × n matrix:

SLIDE 8

8

15 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Matrix multiplication revisited

2 6 4 3 5 An element in the product is calculated as the product of a row and a column 1 2 3 4 2 1 2 3 2 1

21 30 15 24 22 26

A 3 × 3 matrix multiplied with a 3 × 2 matrix

16 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Multiplicative identity Does the set of matrices have a ”one” element I1, so that if I1 is an n × m matrix, then for any m × k matrix a, I1· a = a If yes:

What must the value of n necessarily be? What are the elements of I1 – what does the matrix look like?

Does there exist a ”one” element I2 so that for any matrix a of given dimension, a · I2 = a If yes: Same questions as before

SLIDE 9

9

17 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Additive inverse It follows directly from the axioms for real numbers, that every matrix a, has an additive inverse, b, so that a + b = 0 , and, for the additive inverse, b = −a

18 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Other matrix operations

A real number r may be multiplied with a matrix a
The transpose a’ of a matrix a is formed by changing

columns to rows and vice versa:

SLIDE 10

10

19 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Other matrix operations: Examples If r = 2, and then: The transpose a’ of a is

20 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Multiplicative inverse I

Does every matrix a ≠ 0 have a multiplicative inverse,

b, so that a · b = I

If yes,
What does it look like?

SLIDE 11

11

21 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Multiplicative inverse II

A matrix a only has a multiplicative inverse under certain conditions:

The matrix a is quadratic (i.e. the dimension is n × n) The matrix a is non-singular:

A matrix a is singular if and only if det(a) = 0, where det(a) is the determinant of a For a quadratic zero matrix 0, we have det(0) = 0, so 0 is singular (as expected) Many other quadratic matrices are singular as well

22 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Determinant

The determinant of a quadratic matrix is a real

number.

Calculation of the determinant is rather complicated

for large dimensions.

The determinant of a 2 × 2 matrix:
The determinant of a 3 × 3 matrix:

SLIDE 12

12

23 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

The (multiplicative) inverse matrix

If a quatratic matrix a is non-singular, it has an inverse a-1, and:

a · a-1 = I a-1 · a = I

The inverse is complicated to find for matrices

f high dimension.

For real big matrices (millions of rows and columns) inversion is a challenge even to modern computers. Inversion of matrices is crucial in many applications in herd management (and animal breeding)

24 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Inversion of ”small” matrices I

A 2 × 2 matrix a is inverted as
Example

SLIDE 13

13

25 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Inversion of ”small” matrices II A 3 × 3 matrix a is inverted as Example

26 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Why do we need matrices?

Because they enable us to express very complex

relations in a very compact way.

Because the algebra and notation are powerful tools in

mathematical proofs for correctness of methods and properties.

Because they enable us to solve large systems of linear

equations.

SLIDE 14

14

27 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Complex relations I

Modelling of drinking patterns of weaned piglets.

28 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Complex relations

Madsen et al. (2005) performed an on- line monitoring of the water intake of

piglets. The water intake Yt at time t

was expressed as Where Simple, but …

SLIDE 15

15

29 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Complex relations II

F, θt and wt are of dimension 25 × 1, G and Wt are of

dimension 25 × 25.

The value of θt is what we try to estimate.

30 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Systems of linear equations

A naïve example: Old McDonald has a farm …
On his farm he has some sheep, but he has forgotten

how many. Let us denote the number as x1 .

On his farm he has some geese, but he has forgotten

how many. Let us denote the number as x2 .

He has no other animals, and the other day he counted

the number of heads of his animals. The number was

25. He knows that sheep and geese have one head

each, so he set up the following equation:

1x1 + 1x2 = 25
He also counted the number of legs, and it was 70. He

knows that a sheep has 4 legs and a goose has 2 legs, so he set up the following equation:

4x1 + 2x2 = 70

SLIDE 16

16

31 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Old McDonald’s animals

We have two equations
1x1 + 1x2 = 25
4x1 + 2x2 = 70
Define the following matrix a and the (column-) vectors

x and b

We may then express the two equations as one matrix

equation:

32 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Solving systems of linear equations

Having brought the system of linear equations to the elegant form, solution for x is just as straight forward as with an equation of real numbers: This is true no matter whether we have a system of 2 equations like here, or we have a system of a million equations (which is not at all unrealistic). a · x = b ⇔ a-1 · a · x = a-1 · b ⇔ I · x = a-1 · b ⇔ x = a-1 · b

SLIDE 17

17

33 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Linear regression and matrices I

In a study of children born in

Berkeley 1928-29 the height and weight of 10 18-year old girls were measured.

It is reasonable to assume that

the weight Yi depends on the height xi according to the following linear regression model:

Yi = β0 + β1xi + εi where,

β0 and β1 are unknown parameters The εi are N(0, σ2)

34 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Linear regression and matrices II

Let us define the following matrices:
We may then write our model in matrix notation simply as:
Y = xβ + ε

SLIDE 18

18

35 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Linear regression and matrices III

The least squares estimate of β is

36 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Define the vector of predictions as Then an estimate s2 for σ2 is

Where n = 10 is the number of observations and k = 2 is the number of parameters estimated.

Applying these formulas yields:

Linear regression and matrices IV

SLIDE 19

19

37 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Visual inspection of the fitted curve

Weight versus heigth of 18-year old girls 45 50 55 60 65 70 75 80 150 160 170 180 190 Heigth, cm Weight, kg Observations Fitted regression

38 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Comparison with SAS

The tiny SAS program to the left does exactly the

same. Data one; input x y; cards; 169.6 71.2 166.8 58.2 157.1 56 181.1 64.5 158.4 53 165.6 52.4 166.7 56.8 156.5 49.2 168.1 55.6 165.3 77.8 proc glm; model y = x; run;

Standard Parameter Estimate Error t Value Pr > |t| Intercept

36.87588227 64.47280001 -0.57 0.5831

x 0.58208000 0.38918152 1.50 0.1731 Sum of Source DF Squares Mean Square F Value Pr > F Model 1 159.9474360 159.9474360 2.24 0.1731 Error 8 572.0135640 71.5016955

SLIDE 20

20

39 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

A class variable: Boys and girls I

If it had been 5 girls and 5 boys we had observed, the

data could have looked like this (where xi1 = 0 means girl and xi1 = 1 means boy):

40 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

A class variable: Boys and girls II We obtain the following estimate for β The interpretation is that the weight of a boy is 4.49 kg lower than the weight of a girl of exactly same heigth. (Since we have declared 5 arbitrarily selected girls for boys, the result should not be interpreted at all)

SLIDE 21

21

41 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Let us run the model in SAS

A binary variable ”boy” is

introduced in order to distinguish observations for boys from those for girls.

The ”class” statement informs

SAS, that it is a categorical variable.

We want the parameter

estimates to be printed. Data one; input x boy y; cards; 169.6 1 71.2 166.8 1 58.2 157.1 0 56 181.1 1 64.5 158.4 0 53 165.6 0 52.4 166.7 1 56.8 156.5 0 49.2 168.1 1 55.6 165.3 0 77.8 proc glm; class boy; model y = boy x/solution; run;

42 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

The SAS System 15:03 Friday, August 12, 2005 3 The GLM Procedure Dependent Variable: y Sum of Source DF Squares Mean Square F Value Pr > F Model 2 184.3390600 92.1695300 1.18 0.3622 Error 7 547.6219400 78.2317057 Corrected Total 9 731.9610000 R-Square Coeff Var Root MSE y Mean 0.251843 14.87282 8.844869 59.47000 Source DF Type I SS Mean Square F Value Pr > F boy 1 32.0410000 32.0410000 0.41 0.5426 x 1 152.2980600 152.2980600 1.95 0.2056 Source DF Type III SS Mean Square F Value Pr > F boy 1 24.3916240 24.3916240 0.31 0.5940 x 1 152.2980600 152.2980600 1.95 0.2056 Standard Parameter Estimate Error t Value Pr > |t| Intercept -78.04418172 B 99.91919818 -0.78 0.4604 boy 0 4.49418348 B 8.04862772 0.56 0.5940 boy 1 0.00000000 B . . . x 0.81722505 0.58571438 1.40 0.2056 The SAS System 15:03 Friday, August 12, 2005 8 The GLM Procedure Dependent Variable: y NOTE: The X'X matrix has been found to be singular, and a generalized inverse was used to solve the normal equations. Terms whose estimates are followed by the letter 'B' are not uniquely estimable

SLIDE 22

22

43 Anders Ringgaard Kristensen, IPH Anders Ringgaard Kristensen, IPH

Why does SAS complain?

Because SAS fits the model below:
The columns of x are clearly dependent. Summing columns
