Light Regional Council ADAC Implementation Overview Drivers for electronic processing LGA R&D Funded Pilot Experiences to Date Challenges for Implementation Drivers Drivers 1,000 Lots per year? 30 Lots per year LGA

SLIDE 1

Light Regional Council ADAC Implementation

SLIDE 2

Overview

Drivers for electronic processing
LGA R&D Funded Pilot
Experiences to Date
Challenges for Implementation

SLIDE 3

Drivers

SLIDE 4

Drivers

30 Lots per year 1,000 Lots per year?

SLIDE 5

LGA R&D Funded Pilot

3744m2 Road Surface
4262m2 Road Pavement
10 Pram Ramps
127.4m Spoon Drain
905m Kerb & Gutter
825m Footpath
1 Indented Car Park
4 Side Entry Pits
2 Junction Boxes
1 Grated Inlet Pit
7 Stormwater Allotment Connections
353m Stormwater Pipe
6 Sewer Flushing Points
24 Sewer Inspection Points
1 Sewer Manhole
123m Sewer pipe
1 Roundabout
3 Splitter Islands

Freeling Estate - Stage 7 (33 Allotment Release)

10 hours to input

SLIDE 6

LGA R&D Funded Pilot

As-Constructed data provided as XML script

SLIDE 7

LGA R&D Funded Pilot

XML script read into FME to transform data

SLIDE 8

LGA R&D Funded Pilot

Excel Output from FME for Conquest Input

Complicated asset register meant some manual input was still required – macros were developed to assist: VBA script

SLIDE 9

LGA R&D Funded Pilot

GIS Output from FME

Assets were output as individual MapInfo tab files. Surface and Pavement assets had to be drawn manually due to survey data incompatibility at the roundabout.

SLIDE 10

LGA R&D Funded Pilot

GIS Output from FME

Manually drawn GIS vs. ADAC GIS output

SLIDE 11

Experiences to Date

XML script – some modifications (errors/omissions)
FME – changes to match output requirements & resolve errors
Excel VBA – macros developed to auto-fill from manual input
Missing Assets & Fields – surfaces, pavement, kerbing & footpaths

Runtimes: Savings = Approx. 6 hours 30 minutes for 33 allotments

ADAC FME = 16.4 seconds Excel input + VBA = 15 minutes Manual input of missing assets = 3 hours Upload to Conquest = 10 minutes Manual Conquest + MapInfo Input = 10 hours

SLIDE 12

Challenges for Implementation

Showing benefits to developers (faster Council processing = $)
Upskilling required in all phases:
Superintendent & Surveyor to produce good XML
Council staff in managing FME and excel script
Asset Register currently not well aligned to ADAC
Less visual verification / potentially more difficult to spot errors
