Leveraging orientation knowledge to enhance human pose estimation methods S. Azrour, S. Pi erard, M. Van Droogenbroeck INTELSIG Laboratory, University of Li` ege, Belgium Conference on Articulated Motion and Deformable Objects (AMDO 2016)


slide-1
SLIDE 1

Leveraging orientation knowledge to enhance human pose estimation methods

  • S. Azrour, S. Pi´

erard, M. Van Droogenbroeck INTELSIG Laboratory, University of Li` ege, Belgium

Conference on Articulated Motion and Deformable Objects (AMDO 2016) 13-15th July 2016

1 / 16

slide-2
SLIDE 2

What is human pose estimation ?

Definition (Human pose estimation) In computer vision, it is the study of algorithms and systems that recover the pose of a human body, which consists of joints and rigid parts.

2 / 16

slide-3
SLIDE 3

Application of human pose estimation: some examples

Motion analysis Medical Entertainment Animation movies

3 / 16

slide-4
SLIDE 4

Types of camera-based pose estimation

The camera-based pose estimation (or motion capture) can be marker-based or markerless: maker-based: markers are put on the subject and the pose is recovered by localizing these markers with a multi-camera setup. markerless: the subject has nothing to wear and its pose is recovered using a body model tracking method or a machine learning technique.

4 / 16

slide-5
SLIDE 5

Markerless pose estimation using a machine learning technique

I Pose estimation algorithms developed by Microsoft for the Kinect camera

(from “J. Shotton, R. Girshick et al., PAMI 2013” ). 5 / 16

slide-6
SLIDE 6

Silhouette ambiguity

I There is an intrisic limitation when using color cameras: for

  • ne given silhouette, two different poses are possible

= ⇒ Depth cameras help to overcome this limitation but it still remains hard to disambiguate the silhouette orientation and predict the body joint positions at the same time.

6 / 16

slide-7
SLIDE 7

Using an orientation information to improve the pose estimation

Idea

It is preferable to rely on an additional method that is specifically designed for orientation estimation instead of trying to recover the joint positions and disambiguate the silhouette orientation all at once.

How can we estimate the orientation ?

I The orientation estimation can be obtained from the image itself or

thanks to any kind of sensors through a machine learning or a tracking algorithm.

7 / 16

slide-8
SLIDE 8

Using an orientation information to improve the pose estimation

I The configuration considered in this work: I How do we take advantage of the orientation estimation ?

= ⇒ We slice the full orientation range into smaller ranges and learn

a different model for each of these smaller ranges.

8 / 16

slide-9
SLIDE 9

Outline of our method

9 / 16

slide-10
SLIDE 10

Synthetic data generation

I The body model is created with MakeHuman. I Depth images are rendered inside Blender. I Poses are taken randomly from the CMU motion capture database.

10 / 16

slide-11
SLIDE 11

Pose estimation algorithm used in this work

We use our own implementation of the offset joint regression algorithm proposed by Microsoft (R. Girshick et al., ICCV, 2011).

I The machine learning technique used is a random forest. I Each pixel of the silhouette predicts a set of 3D offsets toward the

body joints.

I These predictions are then aggregated using Mean Shift.

11 / 16

slide-12
SLIDE 12

Experiments

I We compared the accuracy of the estimated pose when using

1, 4 and 12 models.

I We considered two scenarios:

1

A constant global learning dataset size.

2

A constant learning dataset size per model.

12 / 16

slide-13
SLIDE 13

Results with a constant global learning dataset size

⇒ Significant reduction of the error when going from 1 to 4 models. ⇒ However, going from 4 to 12 models slightly worsens the performance.

13 / 16

slide-14
SLIDE 14

Results with a constant learning dataset size per model

⇒ Systematic decrease of the error when the number of models is increased. ⇒ However, small difference between 4 and 12 models suggests a plateau is reached.

14 / 16

slide-15
SLIDE 15

Mean error according to the orientation

5 10 15 30 210 60 240 90 270 120 300 150 330 180 Right shoulder 1 model (|LS|=2000) 12 models (|LS|=12x2000) 1 model (|LS|=8000) 4 models (|LS|=4x2000) 12 models (|LS|=12x666) 5 10 15 30 210 60 240 90 270 120 300 150 330 180 Right elbow 1 model (|LS|=2000) 12 models (|LS|=12x2000) 1 model (|LS|=8000) 4 models (|LS|=4x2000) 12 models (|LS|=12x666) 5 10 15 30 210 60 240 90 270 120 300 150 330 180 Right wrist 1 model (|LS|=2000) 12 models (|LS|=12x2000) 1 model (|LS|=8000) 4 models (|LS|=4x2000) 12 models (|LS|=12x666) 5 10 15 30 210 60 240 90 270 120 300 150 330 180 Right hip 1 model (|LS|=2000) 12 models (|LS|=12x2000) 1 model (|LS|=8000) 4 models (|LS|=4x2000) 12 models (|LS|=12x666) 5 10 15 30 210 60 240 90 270 120 300 150 330 180 Right knee 1 model (|LS|=2000) 12 models (|LS|=12x2000) 1 model (|LS|=8000) 4 models (|LS|=4x2000) 12 models (|LS|=12x666) 5 10 15 30 210 60 240 90 270 120 300 150 330 180 Right ankle 1 model (|LS|=2000) 12 models (|LS|=12x2000) 1 model (|LS|=8000) 4 models (|LS|=4x2000) 12 models (|LS|=12x666)

15 / 16

slide-16
SLIDE 16

Conclusion

I We can improve the accuracy of the estimated pose by taking advantage

  • f an orientation estimation.

I One way to take advantage of the orientation estimation is to learn

multiple models specialized for different range of orientations.

I We show that accuracy can be significantly improved when the number of

models increases, even while keeping a constant global learning dataset size.

16 / 16
