Leffakone

Matthieu Weber (mweber@mit.jyu.fi), 2006 Released under the Creative Commons Attribution license

What For?

• Watch & record TV (analog and DVB)
• Watch videos (DVD Video, DivX/XviD, MPEG1/2. . . )
• Listen to music (MP3, Ogg/Vorbis. . . )
• Watch pictures (e.g., from a digital camera)
• Play video games (e.g., MAME)
• Videoconference

MW/LDD/2006/Leffakone 1

TV Recording

• Electronic program guide (EPG) with XMLTV (source: yle.fi or

katso.fi)

• Scheduling based on the EPG:

– single program recording – repeated recordings based on the program’s name

• Safety time-padding (start recording 5 min earlier than EPG time,

stop recording 5 minutes later)

• Automatic TV commercial detection when recording, skipped when

watching (based on black frames)

MW/LDD/2006/Leffakone 2

User Interfaces

• On-Screen Display (OSD)

– User interface on TV – Infrared remote control

• Web interface

– Only for scheduling and managing disk space – Possibly accessible from all over the World

MW/LDD/2006/Leffakone 3

Hardware Configuration

Hauppauge WinTV Go (PAL/Secam) Hauppauge WinTV Nova−T (DVB−T) Sound

Digital Camera

Microphone

TV Hi−Fi

Serial

CF reader Gamepads Infrared receiver Modem

AMD Athlon XP 2200+ 256 Mo RAM 120 Go HDD DVD−ROM DVD burner Parallel Matrox G400 Ethernet USB

Composite IN Line IN Line OUT

RGB switch A/V switch RGB input

Mic IN Antenna IN

LAN

Wake−On−LAN

Video−conferencing

Timer

MW/LDD/2006/Leffakone 4

Software Configuration

Freevo XFree86 Lirc Recordserver mencoder nukkumaatti mplayer

• hphone

tv_video

MW/LDD/2006/Leffakone 5

Conclusion

• Used daily since 2004 (including while away on holidays)
• Features matching my needs

MW/LDD/2006/Leffakone 6
